Indesit IWDC 6145 User manual

GB
1
Contents
Installation, 2-3
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Description of the washer-dryer and
starting a wash cycle, 4-5
Control panel
Indicator lights
Starting a wash cycle
Wash cycles, 6
Table of wash cycles
Personalisation, 7
Setting the temperature
Setting the drying cycle
Functions
Detergents and laundry, 8
Detergent dispenser drawer
Preparing the laundry
Garments requiring special care
Load balancing system
Precautions and tips, 9
General safety
Disposal
Care and maintenance, 10
Cutting off the water or electricity supply
Cleaning the washer-dryer
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Troubleshooting, 11
Service, 12
IWDC 6145
Instructions for use
WASHER-DRYER
English,1
GB BG
Français,25
F
Česky,49
CZ
Nederlands,37
NL
Български,13

2
GB
Installation
! This instruction manual should be kept in a safe place for
future reference. If the washer-dryer is sold, transferred or
moved, make sure that the instruction manual remains with
the machine so that the new owner is able to familiarise
himself/herself with its operation and features.
! Read these instructions carefully: they contain vital infor-
mation relating to the safe installation and operation of the
appliance.
Unpacking and levelling
Unpacking
1. Remove the washer-dryer from its packaging.
2. Make sure that the washer-dryer has not been damaged
during the transportation process. If it has been damaged,
contact the retailer and do not proceed any further with the
installation process.
3. Remove the 4 protective
screws (used during tran-
sportation) and the rubber
washer with the correspon-
ding spacer, located on the
rear part of the appliance
(see figure).
4. Close off the holes using the plastic plugs provided.
5. Keep all the parts in a safe place: you will need them again
if the washer-dryer needs to be moved to another location.
! Packaging materials should not be used as toys for children.
Levelling
1. Install the washer-dryer on a flat sturdy floor, without resting
it up against walls, furniture cabinets or anything else.
2. If the floor is not perfectly
level, compensate for any
unevenness by tightening or
loosening the adjustable front
feet (see figure); the angle
of inclination, measured in
relation to the worktop, must
not exceed 2°.
Levelling the machine correctly will provide it with stability,
help to avoid vibrations and excessive noise and prevent it
from shifting while it is operating. If it is placed on carpet or
a rug, adjust the feet in such a way as to allow a sufficient
ventilation space underneath the washer-dryer.
Connecting the electricity and water
supplies
Connecting the water inlet hose
1. Connect the supply pipe
by screwing it to a cold water
tab using a ¾ gas threaded
connection (see figure).
Before performing the con-
nection, allow the water to
run freely until it is perfectly
clear.
2. Connect the inlet hose to
the washer-dryer by screwing
it onto the corresponding
water inlet of the appliance,
which is situated on the top
right-hand side of the rear
part of the appliance (see
figure).
3. Make sure that the hose is not folded over or bent.
! The water pressure at the tap must fall within the values
indicated in the Technical details table (see next page).
! If the inlet hose is not long enough, contact a specialised
shop or an authorised technician.
! Never use second-hand hoses.
! Use the ones supplied with the machine.

GB
3
Technical data
Model IWDC 6145
Dimensions
width 59.5 cm
height 85 cm
depth 53,5 cm
Capacity from 1 to 6 kg for the wash programme;
from 1 to 5 kg for the drying programme
Electrical
connections
please refer to the technical data plate fixed
to the machine
Water con-
nections
maximum pressure 1 MPa (10 bar)
minimum pressure 0.05 MPa (0.5 bar)
drum capacity 52 litres
Spin speed up to 1400 rotations per minute
Energy rated
programmes
according to
regulation
EN 50229
Wash: programme 2; temperature 60°C;
run with a load of 6 kg.
Drying: first drying cycle performed with a 1 kg
load, by selecting a drying time of 60 min;
Second drying cycle performed with a 5 kg load
and the DRYING knob on the setting.
This appliance conforms to the following EC
Directives:
- 89/336/EEC dated 03/05/89 (Electro-
magnetic Compatibility) and subsequent
modifications
- 2002/96/EC
- 2006/95/EC Low Voltage)
65 - 100 cm
Connecting the drain hose
Connect the drain hose,
without bending it, to a drai-
nage duct or a wall drain
located at a height between
65 and 100 cm from the
floor;
alternatively, rest it on
the side of a washbasin
or bathtub, fastening the
duct supplied to the tap
(see figure). The free end
of the hose should not be
underwater.
! We advise against the use of hose extensions; if it is
absolutely necessary, the extension must have the same
diameter as the original hose and must not exceed 150 cm
in length.
Electrical connections
Before plugging the appliance into the electricity socket,
make sure that:
• the socket is earthed and complies with all applicable
laws;
• the socket is able to withstand the maximum power load
of the appliance as indicated in the Technical data table
(see opposite);
• the power supply voltage falls within the values indicated
in the Technical data table (see opposite);
• the socket is compatible with the plug of the washer-dr-
yer. If this is not the case, replace the socket or the plug.
! The washer-dryer must not be installed outdoors, even
in covered areas. It is extremely dangerous to leave the
appliance exposed to rain, storms and other weather
conditions.
! When the washer-dryer has been installed, the electricity
socket must be within easy reach.
! Do not use extension cords or multiple sockets.
! The cable should not be bent or compressed.
! The power supply cable must only be replaced by autho-
rised technicians.
Warning! The company shall not be held responsible in the
event that these regulations are not respected.
The first wash cycle
Once the appliance has been installed, and before you use
it for the first time, run a wash cycle with detergent and no
laundry, using the wash cycle 2.

4
GB
Detergent dispenser drawer: used to dispense
detergents and washing additives (see “Detergents and
laundry”).
ON/OFF button: switches the washer-dryer on and off.
WASH CYCLE knob: programmes the wash cycles. Du-
ring the wash cycle, the knob does not move.
FUNCTION buttons with indicator light: used to select the
available functions. The indicator light corresponding to the
selected function will remain lit.
TEMPERATURE knob: sets the temperature or the cold
wash cycle (see “Personalisation”).
DRYING knob: used to set the desired drying programme
(see “Personalisation”).
WASH CYCLE PROGRESS/DELAY TIMER
indicator
light
s: used to monitor the progress of the wash cycle.
The illuminated indicator light shows which phase is in
progress.
If the Delay Timer function has been set, the time remai-
ning until the wash cycle starts will be indicated (see next
page).
DOOR LOCKED indicator light: indicates whether the
door may be opened or not (see next page).
START/PAUSE button with indicator light: starts or tem-
porarily interrupts the wash cycles.
N.B. To pause the wash cycle in progress, press this
button; the corresponding indicator light will flash orange,
while the indicator light for the current wash cycle phase
will remain lit in a fixed manner. If the DOOR LOCKED
indicator light is switched off, the door may be opened.
To start the wash cycle from the point at which it was inter-
rupted, press this button again.
Standby mode
This washing machine, in compliance with new energy
saving regulations, is fitted with an automatic standby
system which is enabled after a few minutes if no activity is
detected. Press the ON-OFF button briefly and wait for the
machine to start up again.
Description of the washer-dryer
and starting a wash cycle
WASH CYCLE PROGRESS/
DELAY TIMER indicator lights
DOOR LOCKED
indicator light
START/
PAUSE
button with
indicator light
Control panel
Detergent dispenser drawer
ON/OFF button
WASH CYCLE
knob
TEMPERATURE
knob
FUNCTION
buttons with
indicator lights
DRYING
knob

GB
5
Indicator lights
The indicator lights provide important information.
This is what they can tell you:
Delayed start
If the DELAY TIMER function has been activated (see “Per-
sonalisation”), after the wash cycle has been started the
indicator light corresponding to the selected delay period
will begin to flash:
As time passes, the remaining delay will be displayed and
the corresponding indicator light will flash:
The set programme will start once the selected time delay
has expired.
Wash cycle phase indicator lights
Once the desired wash cycle has been selected and has be-
gun, the indicator lights switch on one by one to indicate which
phase of the cycle is currently in progress.
Note: when the drying cycle has finished, the DRYING
knob should be returned to the “0” position.
Function buttons and corresponding indicator lights
When a function is selected, the corresponding indicator
light will illuminate.
If the selected function is not compatible with the program-
med wash cycle, the corresponding indicator light will flash
and the function will not be activated.
If the selected function is not compatible with another
function which has been selected previously, the indicator
light corresponding to the first function selected will
flash and only the second function will be activated; the
indicator light corresponding to the enabled option will
remain lit.
Door locked indicator light
When the indicator light is on, the porthole door is locked
to prevent it from being opened; make sure the indicator
light is off before opening the door (wait approximately 3
minutes). To open the door during a running wash cycle,
press the START/PAUSE button; the door may be opened
once the DOOR LOCKED indicator light turns off.
Starting a wash cycle
1. Switch the washer-dryer on by pressing the ON/OFF button. All indicator lights will switch on for a few seconds, then they
will switch off and the START/PAUSE indicator light will pulse.
2. Load the laundry and close the door.
3. Set the WASH CYCLE knob to the desired programme.
4. Set the washing temperature (see “Personalisation”).
5. Set the drying cycle if necessary (see “Personalisation”).
6. Measure out the detergent and washing additives (see “Detergents and laundry”).
7. Select the desired functions.
8. Start the wash cycle by pressing the START/PAUSE button and the corresponding indicator light will remain lit in a fixed
manner, in green.
To cancel the set wash cycle, pause the machine by pressing the START/PAUSE button and select a new cycle.
9. At the end of the wash cycle the indicator light will switch on. The door can be opened once the DOOR LOCKED
indicator light turns off. Take out your laundry and leave the appliance door ajar to make sure the drum dries completely.
Switch the washer-dryer off by pressing the ON/OFF button.
Wash
Rinse
Spin/Drain
Drying
End of wash cycle

6
GB
Specials wash cycles
Sport Light ( wash cycle 9) is for washing lightly soiled sports clothing fabrics (tracksuits, shorts, etc.); for best results,
we recommend not exceeding the maximum load indicated in the “Table of wash cycles”. We recommend using a
liquid detergent and dosage suitable for a half-load.
Sport Shoes (
wash cycle 10) is for washing sports shoes; for best results, do not wash more than 2 pairs (fabric)
simultaneously.
Express Wash & Dry (
wash cycle 13) was designed to wash and dry lightly soiled garments quickly. This cycle may
be used to wash and dry a laundry load of up to 0.5 kg in just 35 minutes.
To achieve optimum results, use liquid detergent and pre-treat cuffs, collars and stains.
Wash cycles
The information contained in the table is intended as a guide only.
For all Test Institutes:
1) Test wash cycle in compliance with regulation EN 50229: set wash cycle 2 with a temperature of 60°C.
2) Long wash cycle for cottons: set wash cycle 2 with a temperature of 40°C.
Table of wash cycles
Wash cycles
Description of the wash cycle
Max.
temp.
(°C)
Max.
speed
(rpm)
Drying
Detergents Max.
load
(kg)
Cycle
duration
Prewash Main
wash
Fabric
softener
Daily
1Cotton with prewash: extremely soiled whites. 90° 1400     6 164’
2Cotton: extremely soiled whites. 90° 1400 -  6 145’
2Cotton (1): heavily soiled whites and resistant colours. 60° 1400 -  6 140’
2Cotton (2): lightly soiled whites and delicate colours. 40° 1400 -  6 123’
3Cotton: heavily soiled whites and resistant colours. 60° 1400 -  6 119’
4Coloured Cotton: lightly soiled whites and delicate colours. 40° 1400 -  6 89’
5Synthetics: lightly soiled resistant colours. 60° 800 -  2,5 85’
Special
6Wool: for wool, cashmere, etc. 40° 600 - -   1,5 55’
7Silk/Curtains: for garments in silk and viscose, lingerie. 30° 0 - -   1 55’
8 Jeans 40° 800 -  3 70’
9 Sport Light 30° 600 - -   3 68’
10 Sport Shoes 30° 600 - -   Max. 2
pairs 50’
Drying
11 Cotton dry - - - - - 5 -
12 Synthetics dry - - - - - 3 -
13 Express Wash & Dry 30° 1400 -  0,5 35’
Partial wash cycles
Rinse - 1400 - - 6 36’
Spin - 1400 - - - 6 16’
Drain - 0 - - - - 6 2’

GB
7
Setting the temperature
Turn the TEMPERATURE knob to set the wash temperature (see Table of wash cycles).
The temperature may be lowered, or even set to a cold wash . The washer-dryer will automatically prevent you from selec-
ting a temperature which is higher than the maximum value set for each wash cycle.
Setting the drying cycle
Turn the DRYING knob to select the desired drying
option. There are two options:
A - Based on time: From 40 minutes to 180.
B - Based on the desired laundry dryness level:
Iron dry : suitable for clothes which will need ironing
afterwards. the remaining dampness softens creases,
making them easier to remove.
Hanger dry : ideal for clothes which do not need to
be dried fully.
Cupboard dry : suitable for laundry which can be put
back in a cupboard without being ironed.
If your laundry load to be washed and dried is much greater than the maximum stated load (see adjacent table), perform the wash
cycle, and when the cycle is complete, divide the garments into groups and put some of them back in the drum. At this point,
follow the instructions provided for a “Drying only” cycle. Repeat this procedure for the remainder of the load.
Drying only
Use the cycle selector knob to select a drying cycle (11-12) in accordance with the type of fabric. The desired drying level or
time may also be set using the DRYING knob.
Functions
The various wash functions available with this washer-dryer will help to achieve the desired results, every time.
To activate the functions:
1. Press the button corresponding to the desired function;
2. the function is enabled when the corresponding indicator light is illuminated.
Note:
- If the selected function is not compatible with the programmed wash cycle, the corresponding indicator light will flash and
the function will not be activated.
- If the selected function is not compatible with another function which has been selected previously, the indicator light corre-
sponding to the first function selected will flash and only the second function will be activated; the indicator light correspon-
ding to the enabled option will remain lit.
Selecting this option enables you to suitably adjust drum rotation, temperature and water to a reduced load of lightly soiled
cotton and synthetic fabrics (refer to the
“Table of wash cycles” ). “ ” enables you to wash in less time thereby saving
water and electricity. We suggest using a liquid detergent suitably measured out to the load quantity.
1400-600
Press this button to reduce the spin speed.
Extra rinse
By selecting this option, the efficiency of the rinse is increased and optimal detergent removal is guaranteed. It is particularly
useful for sensitive skin.
Delay timer
This timer delays the start time of the wash cycle by up to 9 hours. Press the button repeatedly until the indicator light correspond-
ing to the desired delay time switches on. The fifth time the button is pressed, the function will be disabled.
N.B. Once the START/PAUSE button has been pressed, the delay time can only be modified by decreasing it until launching
the set programme.
Personalisation
Table of Drying times (guideline values)
Fabric
type Load type Max. load (kg)
Cupboard
dry
Henger
dry
Iron
dry
Cotton
Clothing of diffe-
rent sizes, Terry
towels
5 250 210 190
Synthe-
tics
Sheets, Shirts, Py-
jamas, socks, etc. 3 180 130 115

8
GB
Detergents and laundry
Detergent dispenser drawer
Good washing results also depend on the correct dose of
detergent: adding too much detergent will not necessa-
rily result in a more efficient wash, and may in fact cause
build up on the inside of your appliance and contribute to
environmental pollution.
! Do not use hand washing detergents because these
create too much foam.
Open the detergent di-
spenser drawer and pour
in the detergent or washing
additive, as follows.
compartment 1: Pre-wash detergent (powder)
compartment 2: Detergent for the wash cycle
(powder or liquid)
Liquid detergent should only be poured in immediately
prior to the start of the wash cycle.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow the grid.
Preparing the laundry
• Divide the laundry according to:
- the type of fabric/the symbol on the label
- the colours: separate coloured garments from whites.
• Empty all garment pockets and check the buttons.
• Do not exceed the listed values, which refer to the weight
of the laundry when dry:
Durable fabrics: max. 6 kg
Synthetic fabrics: max. 2,5 kg
Delicate fabrics: max. 2 kg
Wool: max. 1,5 kg
Silk: max. 1 kg
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1200 g
1 towel 150-250 g
Garments requiring special care
Wool: all wool garments can be washed using programme
6, even those carrying the “hand-wash only” label. For
best results, use special detergents and do not exceed 1,5
kg of laundry.
Silk: use special wash cycle 7 to wash all silk garments.
We recommend the use of special detergent which has
been designed to wash delicate clothes.
Curtains: fold curtains and place them in a pillow case or
mesh bag. Use wash cycle 7.
Jeans: Turn garments inside-out before washing and use
a liquid detergent. Use programme 8.
Load balancing system
Before every spin cycle, to avoid excessive vibrations and
to distribute the load in a uniform manner, the drum rotates
continuously at a speed which is slightly greater than the
washing rotation speed. If, after several attempts, the load
is not balanced correctly, the machine spins at a reduced
spin speed. If the load is excessively unbalanced, the
washer-dryer performs the distribution process instead of
spinning. To encourage improved load distribution and bal-
ance, we recommend small and large garments are mixed
in the load.
12
3

GB
9
Precautions and tips
! This Washer-dryer was designed and constructed in
accordance with international safety regulations. The fol-
lowing information is provided for safety reasons and must
therefore be read carefully.
General safety
• This appliance was designed for domestic use only.
• The Washer-dryer must only be used by adults, in accordance
with the instructions provided in this manual.
• Do not touch the machine when barefoot or with wet or
damp hands or feet.
• Do not pull on the power supply cable when unplugging
the appliance from the electricity socket. Hold the plug
and pull.
• Do not open the detergent dispenser drawer while the
machine is in operation.
• Do not touch the drained water as it may reach extreme-
ly high temperatures.
• Never force the porthole door. This could damage the
safety lock mechanism designed to prevent accidental
opening.
• If the appliance breaks down, do not under any circum-
stances access the internal mechanisms in an attempt
to repair it yourself.
• Always keep children well away from the appliance while
it is operating.
• The door can become quite hot during the wash cycle.
• If the appliance has to be moved, work in a group of two
or three people and handle it with the utmost care. Never
try to do this alone, because the appliance is very heavy.
• Before loading laundry into the Washer-dryer, make sure
the drum is empty.
• During the drying phase, the door tends to get
quite hot.
• Do not use the appliance to dry clothes that have
been washed with flammable solvents (e.g.
trichlorethylene).
• Do not use the appliance to dry foam rubber or
similar elastomers.
• Make sure that the water tap is turned on during
the drying cycles.
Disposal
• Disposing of the packaging materials: observe local
regulations so that the packaging may be re-used.
• The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment, requires that
old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected
separately in order to optimise the recovery and
recycling of the materials they contain and reduce
the impact on human health and the environment.
The crossed out “wheeled bin” symbol on the
product reminds you of your obligation, that when
you dispose of the appliance it must be separately
collected.
Consumers should contact their local authority or
retailer for information concerning the correct
disposal of their old appliance.

10
GB
Care and maintenance
Cutting off the water and electricity
supplies
• Turn off the water tap after every wash cycle. This will li-
mit wear on the hydraulic system inside the washer-dryer
and help to prevent leaks.
• Unplug the washer-dryer when cleaning it and during all
maintenance work.
Cleaning the washer-dryer
The outer parts and rubber components of the appliance
can be cleaned using a soft cloth soaked in lukewarm
soapy water. Do not use solvents or abrasives.
Cleaning the detergent dispenser drawer
Remove the dispenser by
raising it and pulling it out
(see figure).
Wash it under running wa-
ter; this operation should be
repeated frequently.
Caring for the door
and drum of your appliance
• Always leave the porthole door ajar in order to prevent
unpleasant odours from forming.
Cleaning the pump
The washer-dryer is fitted with a self-cleaning pump which
does not require any maintenance. Sometimes, small items
(such as coins or buttons) may fall into the pre-chamber
which protects the pump, situated in its bottom part.
! Make sure the wash cycle has finished and unplug the
appliance.
To access the pre-chamber:
1. using a screwdriver,
remove the cover panel on
the lower front part of the
washer-dryer (see figure);
2. unscrew the lid by rota-
ting it anti-clockwise (see
figure): a little water may
trickle out. This is perfectly
normal;
3. clean the inside thoroughly;
4. screw the lid back on;
5. reposition the panel, making sure the hooks are securely
in place before you push it onto the appliance.
Checking the water inlet hose
Check the inlet hose at least once a year. If there are any
cracks, it should be replaced immediately: during the wash
cycles, water pressure is very strong and a cracked hose
could easily split open.
! Never use second-hand hoses.

GB
11
Troubleshooting
Your washer-dryer could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that
the problem cannot be not solved easily using the following list.
Problem:
The Washer-dryer does not switch
on.
The wash cycle does not start.
The Washer-dryer does not take
in water (the indicator light for
the first wash cycle stage flashes
rapidly).
The Washer-dryer continuously
takes in and
drains water.
The Washer-dryer does not drain or
spin.
The Washer-dryer vibrates a lot
during the spin cycle.
The Washer-dryer leaks.
The “Functions” indicator lights
and the “start/pause” indicator
light flash, while one of the “phase
in progress” indicator lights and
the “door locked” indicator light
will remain lit in a fixed manner.
There is too much foam.
The washer-dryer does not dry.
Possible causes / Solutions:
• The appliance is not plugged into the socket fully, or is not making contact.
• There is no power in the house.
• The Washer-dryer door is not closed properly.
• The ON/OFF button has not been pressed.
• The START/PAUSE button has not been pressed.
• The water tap has not been opened.
• A delayed start has been set.
• The water inlet hose is not connected to the tap.
• The hose is bent.
• The water tap has not been opened.
• There is no water supply in the house.
• The pressure is too low.
• The START/PAUSE button has not been pressed.
• The drain hose is not fitted at a height between 65 and 100 cm from the floor
(see “Installation”).
• The free end of the hose is under water (see “Installation”).
• The wall drainage system is not fitted with a breather pipe.
If the problem persists even after these checks, turn off the water tap, switch the applian-
ce off and contact the Assistance Service. If the dwelling is on one of the upper floors of
a building, there may be problems relating to water drainage, causing the Washer-dryer
to fill with water and drain continuously. Special anti-draining valves are available in shops
and help to avoid this inconvenience.
• The wash cycle does not include draining: some wash cycles require the drain
phase to be started manually.
• The drain hose is bent (see “Installation”).
• The drainage duct is clogged.
• The drum was not unlocked correctly during installation (see “Installation”).
• The Washer-dryer is not level (see “Installation”).
• The Washer-dryer is trapped between cabinets and walls (see “Installation”).
• The water inlet hose is not screwed on properly (see “Installation”).
• The detergent dispenser drawer is blocked (for cleaning instructions, see “Care
and maintenance”).
• The drain hose is not fixed properly (see “Installation”).
• Switch off the machine and unplug it, wait for approximately 1 minute and then
switch it back on again.
If the problem persists, contact the Technical Assistance Service.
• The detergent is not suitable for machine washing (it should display the text
“for Washer-dryers” or “hand and machine wash”, or the like).
• Too much detergent was used.
• The appliance is not plugged into the socket, or not enough to make contact.
• There has been a power failure.
• The appliance door is not shut properly.
• A delayed start has been set.
• DRYING knob is in the 0 position.

12
GB
Service
Before calling for Assistance:
•Check whether you can solve the problem alone (see “Troubleshooting”);
• Restart the programme to check whether the problem has been solved;
• If this is not the case, contact an authorised Technical Assistance Centre using the telephone number provided on the
guarantee certificate.
! Always request the assistance of authorised technicians.
Have the following information to hand:
• the type of problem;
• the appliance model (Mod.);
• the serial number (S/N).
This information can be found on the data plate applied to the rear of the washer-dryer, and can also be found on the front of
the appliance by opening the door.

BG
13
Български Ñúäúðæàíèå
Ìîíòèðàíå, 14-15
Ðàçîïàêîâàíå è íèâåëèðàíå
Õèäðàâëè÷íè è åëåêòðè÷åñêè âðúçêè
Ïúðâî ïðàíå
Òåõíè÷åñêè äàííè
Îïèñàíèå íà ïåðàëíàòà ìàøèíà è ïóñêàíåòî
íà äàäåíà ïðîãðàìà, 16-17
Òàáëî çà óïðàâëåíèå
Ñâåòëèííè èíäèêàòîðè
Âêëþ÷âàíå íà ïðîãðàìà
Ïðîãðàìè, 18
Òàáëèöà ñ ïðîãðàìèòå
Ïåðñîíàëèçèðàíèÿ, 19
Çàäàâàíå íà òåìïåðàòóðàòà
Çàäàâàíå íà ñóøåíåòî
Ôóíêöèè
Ïåðèëíè ïðåïàðàòè è äðåõè çà ïðàíå, 20
×åêìåäæå çà ïåðèëíèòå ïðåïàðàòè
Ïîäãîòâÿíå íà ïðàíåòî
Ñïåöèôè÷íî ïðàíå
Ñèñòåìà çà èçìåðâàíå íà òîâàðà
Ìåðêè çà áåçîïàñíîñò è ïðåïîðúêè, 21
Îáùè ïðåäîõðàíèòåëíè ìåðêè
Ðåöèêëèðàíå
Ïîääðúæêà è ïî÷èñòâàíå, 22
Ñïèðàíå íà âîäàòà è èçêëþ÷âàíå íà åëåêòðîçàõðàíâàíåòî
Ïî÷èñòâàíå íà ïåðàëíàòà ìàøèíà
Ïî÷èñòâàíå íà ÷åêìåäæåòî çà ïåðèëíèòå ïðåïàðàòè
Ïîääðúæêà íà ëþêà è íà áàðàáàíà
Ïî÷èñòâàíå íà ïîìïàòà
Ïðîâåðêà íà ìàðêó÷à çà ñòóäåíàòà âîäà
Ïðîáëåìè è ìåðêè çà îòñòðàíÿâàíåòî èì, 23
Ñåðâèçíî îáñëóæâàíå, 24
BG
IWDC 6145
Èíñòðóêöèè çà ïîëçâàíå
ÏÅÐÀËÍÀ ÌÀØÈÍÀ
! Този символ ви напомня да прочетете настоящата книжка с
инструкции.

14
BG
Ìîíòèðàíå
! Âàæíî å äà ñúõðàíÿâàòå èíñòðóêöèèòå, çà äà ìîæåòå
äà ïðàâèòå äîïúëíèòåëíè ñïðàâêè ïî âñÿêî âðåìå. Â
ñëó÷àé ÷å ïåðàëíàòà ìàøèíà ñå ïðîäàäå, ïðåîòñòúïè
èëè ïðåìåñòè, òðÿáâà äà ñå ïîãðèæèòå èíñòðóêöèèòå
âèíàãè äà ÿ ïðèäðóæàâàò, çà äà ñå ïðåäîñòàâè
èíôîðìàöèÿ íà íîâèÿ ñîáñòâåíèê çà ðàáîòàòà è
ñúîòâåòíèòå ïðåäóïðåæäåíèÿ.
! Ïðî÷åòåòå âíèìàòåëíî èíñòðóêöèèòå: çàùîòî
ñúäúðæàò âàæíà èíôîðìàöèÿ çà ìîíòàæà,
èçïîëçâàíåòî è áåçîïàñíîñòòà.
Ðàçîïàêîâàíå è íèâåëèðàíå
Ðàçîïàêîâàíå
1. Ðàçîïàêîâàéòå ïåðàëíàòà ìàøèíà.
2. Ïðîâåðåòå äàëè ïåðàëíàòà ìàøèíà íå å ïîâðåäåíà
ïðè òðàíñïîðòèðàíåòî. Àêî å ïîâðåäåíà, íå ÿ
ñâúðçâàéòå, à ñå îáúðíåòå êúì ïðîäàâà÷à.
3. Ñâàëåòå 4-òå âèíòà
çà ïðåäïàçâàíå ïðè
òðàíñïîðò è ãóìè÷êàòà
ñúñ ñúîòâåòíàòà âòóëêà,
ïîñòàâåíè îò çàäíàòà
ñòðàíà (âèæ ïîêàçàíîòî
íà ôèãóðàòà).
4. Çàòâîðåòå îòâîðèòå ñ ïðåäîñòàâåíèòå ïëàñòìàñîâè
êàïà÷êè.
5. Ñúõðàíåòå âñè÷êè ÷àñòè: çà äà ñå ìîíòèðàò îòíîâî
ïðè íåîáõîäèìîñò ïåðàëíàòà ìàøèíà äà áúäå
òðàíñïîðòèðàíà.
! Îïàêîâú÷íèÿò ìàòåðèàë íå å äåòñêà èãðà÷êà.
Íèâåëèðàíå
1. Ìîíòèðàéòå ïåðàëíàòà ìàøèíà íà ðàâåí è òâúðä
ïîä, áåç äà ÿ îïèðàòå â ñòåíè, ìåáåëè è äð.
2. Àêî ïîäúò íå å
èäåàëíî õîðèçîíòàëåí,
êîìïåíñèðàéòå
íåðàâíîñòèòå, êàòî
îòâèåòå èëè çàâèåòå
ïðåäíèòå êðà÷åòà (âèæ
ôèãóðàòà); úãúëúò íà
íàêëîíà, èçìåðåí âúðõó
ðàáîòíàòà ïîâúðõíîñò, íå
òðÿáâà äà íàäâèøàâà 2°.
Òî÷íîòî íèâåëèðàíå
ïîçâîëÿâà ìàøèíàòà äà áúäå ñòàáèëíà è äà ñå
èçáÿãâàò âèáðàöèèòå, øóìúò è ïðåìåñòâàíåòî é ïî
âðåìå íà ðàáîòà. Êîãàòî íàñòèëêàòà å ìîêåò èëè
êèëèì, ðåãóëèðàéòå òàêà êðà÷åòàòà, ÷å ïîä ïåðàëíàòà
ìàøèíà äà îñòàíå äîñòàòú÷íî ìÿñòî çà âåíòèëàöèÿ.
Õèäðàâëè÷íè è åëåêòðè÷åñêè âðúçêè
Ñâúðçâàíå íà ìàðêó÷à êúì âîäîïðîâîäíàòà ìðåæà
1. Ñâúðæåòå çàõðàíâàùèÿ
ìàðêó÷, êàòî ãî çàâèåòå êúì
êðàíà çà ñòóäåíàòà âîäà ñ
íàêðàéíèê ñ ãàçîâà ðåçáà
3/4 (âèæ ôèãóðàòà).
Ïðåäè äà ãî ñâúðæåòå,
èçòî÷åòå âîäàòà, äîêàòî
ñå èçáèñòðè.
2. Ñâúðæåòå ìàðêó÷à
çà ñòóäåíàòà âîäà êúì
ïåðàëíàòà ìàøèíà,
êàòî ãî çàâèåòå êúì
ñïåöèàëíèÿ ùóöåð,
ðàçïîëîæåí îò çàäíàòà
ñòðàíà, ãîðå âäÿñíî (âèæ
ôèãóðàòà).
3. Âíèìàâàéòå ìàðêó÷à äà íå ñå ïðåãúâà è ïðèòèñêà.
! Íàëÿãàíåòî ïî âîäîïðîâîäíàòà ìðåæà òðÿáâà äà
áúäå â ãðàíèöèòå, óêàçàíè â òàáëèöàòà „Òåõíè÷åñêè
äàííè” (âæ. ñëåäâàùàòà ñòðàíèöà).
! Àêî äúëæèíàòà íà çàõðàíâàùèÿ ìàðêó÷ íå å
äîñòàòú÷íà, ñå îáúðíåòå êúì ñïåöèàëèçèðàí ìàãàçèí
èëè êúì îòîðèçèðàí òåõíèê.
! Íèêîãà íå èçïîëçâàéòå âå÷å óïîòðåáÿâàí ìàðêó÷.
! Èçïîëçâàéòå òåçè, êîåòî ñà äîñòàâåíè ñ ïåðàëíàòà
ìàøèíà.

BG
15
65 - 100 cm
Ñâúðçâàíå íà ìàðêó÷à çà ìðúñíàòà âîäà
Ñâúðæåòå ìàðêó÷à çà
ìðúñíàòà âîäà, áåç
äà ãî ïðåãúâàòå, êúì
êàíàëèçàöèîííàòà òðúáà
èëè êúì òðúáàòà çà
îòâåæäàíå â ñòåíàòà,
ðàçïîëîæåíè íà âèñî÷èíà
ìåæäó 65 è 100 ñì îò
ïîäà, èëè ãî ïîäïðåòå
íà ðúáà íà ìèâêàòà èëè
âàíàòà,
ñâúðçâàéêè äîñòàâåíèÿ
âîäà÷ êúì êðàíà (âæ.
ôèãóðàòà). Ñâîáîäíèÿò
êðàé íà ìàðêó÷à çà
ìðúñíàòà âîäà íå òðÿáâà
äà áúäå ïîòîïåí âúâ
âîäàòà.
! Íå ñå ïðåïîðú÷âà
èçïîëçâàíåòî íà óäúëæèòåëíè ìàðêó÷è. Àêî å
íåîáõîäèìî, óäúëæèòåëÿò òðÿáâà äà èìà ñúùèÿ
äèàìåòúð êàòî îðèãèíàëíèÿ è äà íå íàäâèøàâà 150
ñì.
Ñâúðçâàíå êúì åëåêòðè÷åñêàòà ìðåæà
Ïðåäè äà ñâúðæåòå ùåïñåëà â êîíòàêòà, ïðîâåðåòå
äàëè:
• êîíòàêòúò å çàçåìåí ñúãëàñíî äåéñòâàùèòå
ñòàíäàðòè;
• êîíòàêòúò ìîæå äà ïîåìå ìàêñèìàëíàòà ìîùíîñò
íà íàòîâàðâàíå íà ìàøèíàòà, óêàçàíà â òàáëèöàòà
ñ òåõíè÷åñêèòå äàííè (âèæ ñëåäâàùàòà ñòðàíèöà);
• çàõðàíâàùîòî íàïðåæåíèå å â ãðàíèöèòå íà
óêàçàíîòî â òàáëèöàòà ñ òåõíè÷åñêèòå äàííè (âèæ
ñëåäâàùàòà ñòðàíèöà);
• êîíòàêòúò îòãîâàðÿ íà ùåïñåëà íà ïåðàëíàòà
ìàøèíà.  ïðîòèâåí ñëó÷àé çàìåíåòå ùåïñåëà èëè
êîíòàêòà.
! Ïåðàëíàòà ìàøèíà íå ñå ìîíòèðà íà îòêðèòî, äîðè
ïîä íàâåñ, çàùîòî å ìíîãî îïàñíî äà ñå îñòàâè íà
âëèÿíèåòî íà àòìîñôåðíèòå óñëîâèÿ.
! Çà ìîíòèðàíàòà ïåðàëíà ìàøèíà åëåêòðè÷åñêèÿò
êîíòàêò òðÿáâà äà áúäå ëåñíî äîñòúïåí.
! Íå èçïîëçâàéòå óäúëæèòåëè èëè ðàçêëîíèòåëè.
! Êàáåëúò íå òðÿáâà äà áúäå îãúíàò èëè ñïëåñêàí.
! Çàõðàíâàùèÿò êàáåë òðÿáâà äà ñå ïîäìåíÿ ñàìî îò
îòîðèçèðàíè òåõíèöè.
Âíèìàíèå! Ôèðìàòà îòõâúðëÿ âñÿêàêâà îòãîâîðíîñò â
ñëó÷àèòå, â êîèòî òåçè íîðìè íå ñå ñïàçâàò.
Ïúðâî ïðàíå
Ñëåä èíñòàëèðàíå è ïðåäè óïîòðåáà âêëþ÷åòå åäèí
öèêúë íà èçïèðàíå ñ ïåðèëåí ïðåïàðàò, íî áåç äðåõè,
çàäàâàéêè ïðîãðàìà 2.
Òåõíè÷åñêè äàííè
Ìîäåë IWDC 6145
Ðàçìåðè
øèðèíà 59,5 ñì
âèñî÷èíà 85 ñì
äúëáî÷èíà 53,5 ñì
Âìåñòèìîñò îò 1 äî 6 êã. çà èçïèðàíåòî
îò 1 äî 5 êã. çà ñóøåíåòî
Åëåêòðè÷åñêî
çàõðàíâàíå
Âèæ òàáåëêàòà ñ õàðàêòåðèñòèêèòå,
ïîñòàâåíà íà ìàøèíàòà
Çàõðàíâàíå ñ
âîäà
ìàêñèìàëíî íàëÿãàíå 1 ÌÐà (10 bar)
ìèíèìàëíî íàëÿãàíå 0,05 ÌÐà (0,5 bar)
îáåì íà êàçàíà 52 ëèòðà
Ñêîðîñò íà
öåíòðîôóãàòà äî 1400 îáîðîòà/ìèíóòà
Ïðîãðàìè
çà ïðîâåðêà
ñúãëàñíî
íîðìà EN
50229
èçïèðàíåòî: ïðîãðàìà 2; òåìïåðàòóðà
60°; èçâúðøåíà ñ 6 êã ïðàíå.
ñóøåíå: ïúðâîíà÷àëíî ñóøåíå ïðè 1
êã. ïðàíå è èçáðàíà ïðîäúëæèòåëíîñò
îò 60 ìèí.;
ïîâòîðíî ñóøåíå ïðè 5 êã. ïðàíå, êàòî
ïðîãðàìàòîðúò ÑÓØÅÍÅ å ïîñòàâåí íà
ïîçèöèÿ .
Ïåðàëíàòà ìàøèíà ñúîòâåòñòâà íà
ñëåäíèòå Åâðîïåéñêè äèðåêòèâè:
- 89/336/ÑÅÅ îò 03/05/89 (çà
åëåêòðîìàãíèòíà ñúâìåñòèìîñò) è
ïîñëåäâàùèòå èçìåíåíèÿ
- 2002/96/CE
- 2006/95/CE (çà íèñêî íàïðåæåíèå)

16
BG
×åêìåäæå çà ïåðèëíèòå ïðåïàðàòè: çà äîçèðàíå
íà ïåðèëíèòå ïðåïàðàòè è äîáàâêèòå (âæ. “Ïåðèëíè
ïðåïàðàòè è äðåõè çà ïðàíå”).
Áóòîí ÂÊËÞ×ÂÀÍÅ/ÈÇÊËÞ×ÂÀÍÅ: çà âêëþ÷âàíå è
èçêëþ÷âàíå íà ïåðàëíÿòà.
Ïðîãðàìàòîð ÏÐÎÃÐÀÌÈ: çà çàäàâàíå íà ïðîãðàìèòå.
Ïî âðåìå íà èçïúëíåíèå íà ïðîãðàìàòà êëþ÷úò
îñòàâà íåïîäâèæåí.
Áóòîíè ñúñ ñâåòëèííè èíäèêàòîðè ÔÓÍÊÖÈß: çà
ñåëåêòèðàíå íà âúçìîæíèòå ôóíêöèè. Ñâåòëèííèÿò
èíäèêàòîð çà èçáðàíàòà ôóíêöèÿ ùå ïðîäúëæè äà
ñâåòè.
Ïðîãðàìàòîð ÑÓØÅÍÅ: çà äà çàäàäåòå æåëàíîòî
ñóøåíå (âæ. “Ïåðñîíàëèçèðàíèÿ”).
Ïðîãðàìàòîð ÒÅÌÏÅÐÀÒÓÐÀ: çà çàäàâàíå íà
òåìïåðàòóðà èëè ïðàíå ñúñ ñòóäåíà âîäà (âæ.
“Ïåðñîíàëèçèðàíèÿ”).
Ñâåòëèííè ÈÍÄÈÊÀÒÎÐÈ ÇÀ ÕÎÄ ÍÀ ÖÈÊÚË/
ÇÀÁÀÂÅÍÎ ÂÊËÞ×ÂÀÍÅ: çà äà ñëåäâàòå õîäà íà
èçïúëíåíèå íà ïðîãðàìàòà çà ïðàíå.
Âêëþ÷åíèÿò ñâåòëèíåí èíäèêàòîð ïîêàçâà, ÷å ñå
èçâúðøâà îïðåäåëåíà ôàçà îò öèêúëà.
Àêî å çàäàäåíà ôóíêöèÿòà “Çàáàâåíî âêëþ÷âàíå”, ùå
ñå ïîñî÷âà âðåìåòî, îñòàâàùî äî ñòàðòèðàíåòî íà
ïðîãðàìàòà (âæ. ñúñåäíàòà ñòðàíèöà).
Ñâåòëèíåí èíäèêàòîð ÁËÎÊÈÐÀÍ ËÞÊ: çà äà
ñå ðàçáåðå äàëè ëþêúò ìîæå äà ñå îòâîðè (âæ.
ñúñåäíàòà ñòðàíèöà).
Áóòîí ñúñ ñâåòëèíåí èíäèêàòîð ÑÒÀÐÒ/ÏÀÓÇÀ:
çà ñòàðòèðàíå íà ïðîãðàìèòå èëè âðåìåííîòî èì
ïðåêúñâàíå.
Çàáåëåæêà: çà çàäàâàíå íà ïàóçà â ïðàíåòî
íàòèñíåòå îòíîâî áóòîíà - èíäèêàòîðúò ùå
ìèãà ñ îðàíæåâà ñâåòëèíà, äîêàòî ñâåòëèííèÿò
èíäèêàòîð, óêàçâàù èçïúëíåíèå íà ôàçà, ùå
ñâåòè íåïðåêúñíàòî. Àêî ñâåòëèííèÿò èíäèêàòîð
ÁËÎÊÈÐÀÍ ËÞÊ å óãàñíàë, ùå ìîæå äà ñå îòâîðè
âðàòàòà íà ëþêà.
Çà ïðîäúëæàâàíå íà öèêúëà ïðàíå îò ìÿñòîòî, â
êîåòî å áèë ïðåêúñíàò, íàòèñíåòå îòíîâî òîçè áóòîí.
Ðåæèì íà stand by
 ñúîòâåòñòâèå ñ íîâèòå íîðìàòèâè çà ïåñòåíå
íà åíåðãèÿ òàçè ïåðàëíà ìàøèíà å ñíàáäåíà ñúñ
ñèñòåìà çà àâòîìàòè÷íî èçêëþ÷âàíå (stand by),
êîÿòî ñå çàäåéñòâà ñëåä 30 ìèíóòè â ñëó÷àé, ÷å
ìàøèíàòà íå ñå èçïîëçâà. Íàòèñíåòå çà êðàòêî áóòîí
ÂÊËÞ×ÂÀÍÅ/ÈÇÊËÞ×ÂÀÍÅ è èç÷àêàéòå ìàøèíàòà
äà ñå çàäåéñòâà îòíîâî.
Îïèñàíèå íà ïåðàëíàòà ìàøèíà è
ïóñêàíåòî íà äàäåíà ïðîãðàìà
Ñâåòëèííè ÈÍÄÈÊÀÒÎÐÈ ÇÀ
ÕÎÄ ÍÀ ÖÈÊÚË/ÇÀÁÀÂÅÍÎ
ÂÊËÞ×ÂÀÍÅ
Ñâåòëèíåí èíäèêàòîð
ÁËÎÊÈÐÀÍ ËÞÊ
Áóòîí ñúñ
ñâåòëèíåí
èíäèêàòîð
ÑÒÀÐÒ/
ÏÀÓÇÀ
Òàáëî çà óïðàâëåíèå
×åêìåäæå çà ïåðèëíèòå
ïðåïàðàòè
Ïðîãðàìàòîð
ÒÅÌÏÅÐÀÒÓÐÀ
Áóòîíè ñúñ ñâåòëèííè
èíäèêàòîðè ÔÓÍÊÖÈß
Áóòîí
ÂÊËÞ×ÂÀÍÅ/
ÈÇÊËÞ×ÂÀÍÅ
Ïðîãðàìàòîð
ÏÐÎÃÐÀÌÈ
Ïðîãðàìàòîð
ÑÓØÅÍÅ

BG
17
Ñâåòëèííè èíäèêàòîðè
Ñëåäÿùèòå ñâåòëèííè èíäèêàòîðè äàâàò âàæíà
èíôîðìàöèÿ.
Åòî êàêâî êàçâàò:
Îòëîæåí ñòàðò
Àêî å àêòèâèðàíà ôóíêöèÿòà “Çàáàâåíî âêëþ÷âàíå” (âæ.
“Ïåðñîíàëèçèðàíèÿ”), ñëåä ïóñêàíå íà ïðîãðàìàòà ùå
ñâåòíå èíäèêàòîðúò çà èçáðàíîòî çàáàâÿíå:
 òå÷åíèå íà âðåìåòî ùå ñå âèçóàëèçèðà îñòàâàùîòî
çàáàâÿíå ÷ðåç ìèãàíå íà ñúîòâåòíèÿ ñâåòëèíåí
èíäèêàòîð:
Ñëåä êàòî èçòå÷å çàäàäåíîòî âðåìå çà îòëàãàíå íà
ñòàðòà, èçáðàíàòà ïðîãðàìà ùå ñå âêëþ÷è.
Ñâåòëèííè èíäèêàòîðè çà òåêóùèòå ôàçè
Ñëåä êàòî å èçáðàí è ñòàðòèðàí æåëàíèÿò öèêúë íà
ïðàíå, ñâåòëèííèòå èíäèêàòîðè ùå ñâåòâàò åäèí ñëåä
äðóã, çà äà óêàçâàò õîäà íà öèêúëà:
Бележка: при завършване на цикълът сушене,
програматорът СУШЕНЕ трябва да се постави на
позиция “0”.
Áóòîíè çà ôóíêöèÿ è ñúîòâåòíè ñâåòëèííè
èíäèêàòîðè
Ïðè èçáîð íà ôóíêöèÿ ñúîòâåòíèÿò ñâåòëèíåí èíäèêàòîð
ùå ñâåòíå. Àêî èçáðàíàòà ôóíêöèÿ íå å ñúâìåñòèìà
ñúñ çàäàäåíàòà ïðîãðàìà, ñúîòâåòíèÿò ñâåòëèíåí
èíäèêàòîð ùå ìèãà è ôóíêöèÿòà íÿìà äà ñå àêòèâèðà.
Àêî èçáðàíàòà ôóíêöèÿ íå å ñúâìåñòèìà ñ äðóãà
ïðåäâàðèòåëíî çàäàäåíà, ñâåòëèííèÿò èíäèêàòîð,
ñúîòâåòñòâàù íà ïúðâàòà èçáðàíà ôóíêöèÿ, ìèãà
è ñå àêòèâèðà ñàìî âòîðàòà, êàòî èíäèêàòîðúò íà
àêòèâèðàíàòà ôóíêöèÿ ñâåòâà.
Ñâåòëèíåí èíäèêàòîð áëîêèðàí ëþê
Ñâåòåùèÿò ñâåòîèíäèêàòîð ïîêàçâà, ÷å ëþêúò å áëîêèðàí,
çà äà ñå âúçïðåïÿòñòâà îòâàðÿíåòî ìó; çà äà îòâîðèòå
ëþêà èç÷àêàéòå ñâåòîèíäèêàòîðà äà óãàñíå; (èç÷àêàéòå
îêîëî 3 ìèíóòè).Çà îòâàðÿíå íà ëþêà ïî âðåìå íà ïðàíå ñå
íàòèñêà áóòîí ÑÒÀÐÒ/ÏÀÓÇÀ; ìîæå äà îòâîðèòå ëþêà, àêî
ñâåòîèíäèêàòîðúò ÁËÎÊÈÐÀÍ ËÞÊ å óãàñíàë.
! Áúðçîòî ïðèìèãâàíå íà ñâåòîèíäèêàòîðèòå íà
„ôàçèòå çà ïðàíå“ è òîçè çà ÁËÎÊÈÐÀÍ ËÞÊ
ñèãíàëèçèðàò àíîìàëèÿ (âæ. “Íåèçïðàâíîñòè è
îòñòðàíÿâàíåòî èì”).
Âêëþ÷âàíå íà ïðîãðàìà
1. Âêëþ÷åòå ïåðàëíÿòà, êàòî íàòèñíåòå áóòîíà ÂÊËÞ×ÂÀÍÅ/ÈÇÊËÞ×ÂÀÍÅ. Âñè÷êè èíäèêàòîðè ùå ñå âêëþ÷àò
è ùå ñâåòÿò â ïðîäúëæåíèå íà íÿêîëêî ñåêóíäè, ñëåä êîåòî ùå óãàñíàò è ùå ñâåòè ñ ïóëñèðàùà ñâåòëèíà
èíäèêàòîðúò ÑÒÀÐÒ/ÏÀÓÇÀ.
2. Çàðåäåòå äðåõèòå çà ïðàíå è çàòâîðåòå ëþêà.
3. Çàäàéòå æåëàíàòà ïðîãðàìà ñ êëþ÷à ÏÐÎÃÐÀÌÈ.
4. Çàäàéòå òåìïåðàòóðàòà íà ïðàíå (âæ. “Ïåðñîíàëèçèðàíèÿ”).
5. Çàäàâàíå íà ñóøåíåòî, àêî å íåîáõîäèìî (âæ. “Ïåðñîíàëèçèðàíèÿ”).
6. Ïîñòàâåòå ïåðèëåí ïðåïàðàò è äîáàâêè âæ. “Ïåðèëíè ïðåïàðàòè è äðåõè çà ïðàíå”.
7. Èçáèðàíå íà æåëàíèòå ôóíêöèè.
8. Âêëþ÷åòå ïðîãðàìàòà, êàòî íàòèñíåòå áóòîíà ÑÒÀÐÒ/ÏÀÓÇÀ, ñúîòâåòíèÿò ñâåòëèíåí èíäèêàòîð ùå ñâåòè
ïîñòîÿííî â çåëåí öâÿò. Çà äà îòìåíèòå çàäàäåíèÿ öèêúë, ïîñòàâåòå ìàøèíàòà â ïàóçà, êàòî íàòèñíåòå áóòîíà
ÑÒÀÐÒ/ÏÀÓÇÀ, è èçáåðåòå íîâèÿ öèêúë.
9. Êîãàòî ïðîãðàìàòà ñâúðøè, ùå ñâåòíå èíäèêàòîðúò . Êîãàòî ñâåòîèíäèêàòîðúò ÁËÎÊÈÐÀÍ ËÞÊ óãàñíå,
ìîæå äà îòâîðèòå ëþêà. Èçâàäåòå ïðàíåòî è îñòàâåòå ëþêà ïðèòâîðåí, çà äà èçñúõíå áàðàáàíúò. Èçêëþ÷åòå
ïåðàëíÿòà, êàòî íàòèñíåòå áóòîíà ÂÊËÞ×ÂÀÍÅ/ÈÇÊËÞ×ÂÀÍÅ.
Ïðàíå
Èçïëàêâàíå
Öåíòðîôóãà/Èçòî÷âàíå íà âîäàòà
Ñóøåíå
Êðàé íà ïðàíåòî

18
BG
Ñïåöèàëíè ïðîãðàìè
Sport Light (ïðîãðàìà 9 ) ðàçðàáîòåíà å çà ïðàíå íà òúêàíè íà ëåêî çàìúðñåíî ñïîðòíî îáëåêëî (àíöóçè,
ïàíòàëîíè, äð.); çà ïîñòèãàíå íà ïî-äîáðè ðåçóëòàòè ñå ïðåïîðú÷âà äà íå ñå íàäâèøàâà ìàêñèìàëíîòî
íàòîâàðâàíå, óêàçàíî â „Tàáëèöà ñ ïðîãðàìèòå“. Ïðåïîðú÷âà ñå äà ñå èçïîëçâà òå÷åí ïåðèëåí ïðåïàðàò â
äîçà, ïîäõîäÿùà çà ïîëîâèí çàðåæäàíå.
Sport Shoes (ïðîãðàìà
10 ) ðàçðàáîòåíà å çà ïðàíå íà ñïîðòíè îáóâêè; çà ïîñòèãàíå íà ïî-äîáðè ðåçóëòàòè
äà íå ñå ïåðàò ïîâå÷å îò 2 ÷èôòà (тъкан).
Express Wash & Dry (ïðîãðàìà 13) å ñúçäàäåíà çà ïðàíå è ñóøåíå íà ëåêî çàìúðñåíè äðåõè çà êðàòêî
âðåìå. Ïðè èçáîð íà òîçè ðåæèì ìîæå äà ñå èçïåðå è èçñóøè ïðàíå äî 0,5 êã ñàìî çà 35 ìèíóòè. Çà
ïîñòèãàíå íà îïòèìàëíè ðåçóëòàòè èçïîëçâàéòå òå÷åí ïåðèëåí ïðåïàðàò. Ïðåäâàðèòåëíî îáðàáîòâàéòå
ìàíøåòèòå, ÿêèòå è ïåòíàòà.
Äàííèòå ïðèâåäåíè â òàáëèöàòà ñà óêàçàòåëíè.
Çà âñè÷êè Test Institutes:
1) Ïðîãðàìà çà ïðîâåðêà ñúãëàñíî ñòàíäàðò EN 50229: çàäàéòå ïðîãðàìà 2 ñ òåìïåðàòóðà 60 °C.
2) Äúëãà ïðîãðàìà çà ïàìóê; çàäàéòå ïðîãðàìà 2 ñ òåìïåðàòóðà 40 °C.
Ïðîãðàìè
Òàáëèöà ñ ïðîãðàìèòå
Ïðîãðàìè
Îïèñàíèå íà ïðîãðàìàòà
Ìàêñ.
òåìïå-
ðàòóðà
(°C)
Ìàêñ.
ñêîðîñò
(îáîðîòè
â
ìèíóòà)
ÑÓØ-
ÅÍÅ
Ïåðèëíè ïðåïàðàòè Çàðåæ-
äàíå
ìaêñ.
(êã)
Ïðîäúëæ-
èòåëíîñò
íà öèêúëà
Ïðåä-
ïðàíå
Îñíîâíî
ïðàíå
Îìåêî-
òèòåë
Ïðîãðàìè çà âñåêè äåí
1ÏÀÌÓ Ïðåäïðàíå: Áåëè, èçêëþ÷èòåëíî çàìúðñåíè. 90° 1400     6 164’
2ÏÀÌÓ: Áåëè, èçêëþ÷èòåëíî çàìúðñåíè. 90° 1400 -  6 145’
2ÏÀÌÓ (1): Áåëè è öâåòíè, óñòîé÷èâè, ñèëíî çàìúðñåíè. 60° 1400 -  6 140’
2ÏÀÌÓ (2): Áåëè è öâåòíè, íåóñòîé÷èâè, ñèëíî çàìúðñåíè. 40° 1400 -  6 123’
3ÏÀÌÓ: Áåëè è öâåòíè, óñòîé÷èâè, ñèëíî çàìúðñåíè. 60° 1400 -  6 119’
4ÏÀÌÓ–ÖÂÅÒÍÈ: Áåëè, ìàëêî çàìúðñåíè, è öâåòíè, íåóñòîé÷èâè. 40° 1400 -  6 89’
5ÑÈÍÒÅÒÈ×ÍÈ: Öâåòíè, óñòîé÷èâè, ìíîãî çàìúðñåíè. 60° 800 -  2,5 85’
Ñïåöèàëíè ïðîãðàìè
6ÂÚËÍÅÍÈ ÒÚÀÍÈ: Çà âúëíà, êàøìèð è ò.í. 40° 600 - -   1,5 55’
7ÎÏÐÈÍÀ/ÏÅÐÄÅÒÀ: Çà äðåõè îò êîïðèíà, âèñêîçà, ôèíî áåëî. 30° 0 - -   1 55’
8EN 40° 800 -  3 70’
9prt iht 30° 600 - -   3 68’
10 prt hes 30° 600 - -   (ìaêñ.2
÷èôòà.) 50’
Ïðîãðàìè çà ñóøåíå
11 Ñóøåíå “Ïàìóê”- - - - - 5 -
12 Ñóøåíå “Ñèíòåòè÷íè òúêàíè” - - - - - 3 -
13 ss as  y 30° 1400 -  0,5 35’
×àñòè÷íè ïðîãðàìè
ÈÇÏËÀÂÀÍÅ - 1400 - - 6 36’
ÖÅÍÒÐÎÔÓÃÀ - 1400 - - - 6 16’
ÈÇÏÎMÏÂÀÍÅ - 0 - - - - 6 2’

BG
19
Çàäàâàíå íà òåìïåðàòóðàòà
Çàâúðòàéêè êëþ÷à ÒÅÌÏÅÐÀÒÓÐÀ, ñå çàäàâà òåìïåðàòóðàòà íà ïðàíå (âæ. Òàáëèöà íà ïðîãðàìèòå).
Òåìïåðàòóðàòà ìîæå äà ñå ïîíèæè äî ïðàíå ñúñ ñòóäåíà âîäà ( ). Ïåðàëíÿòà àâòîìàòè÷íî ùå ïîïðå÷è äà ñå çàäàäå
òåìïåðàòóðà, êîÿòî å ïî-âèñîêà îò ìàêñèìàëíàòà òåìïåðàòóðà, ïðåäâèäåíà çà âñÿêà ïðîãðàìà.
Çàäàâàíå íà ñóøåíåòî
Ïðè çàâúðòàíå íà ïðîãðàìàòîð ÑÓØÅÍÅ ñå
çàäàâà æåëàíèÿò òèï ñóøåíå. Ïðåäâèäåíè ñà
äâå âúçìîæíîñòè:
A - Âúç îñíîâà íà âðåìåòî: îò 40 äî 180 ìèíóòè.
B - Âúç îñíîâà íà ñòåïåíòà íà âëàæíîñò íà
èçñóøåíèòå äðåõè:
Гладене : Препоръчва се за дрехи, които
по-късно ще се гладят. По-голямата степен на
влажност омекотява гънките и улеснява тяхното
отстраняване.
Закачалка : идеално сушене за дрехи, които не изискват пълно изсушаване.
Гардероб : подходящо сушене за дрехи, които ще се приберат направо в гардероба, без да се гладят.
Àêî ïî èçêëþ÷åíèå ïðàíåòî, êîåòî òðÿáâà äà áúäå èçïðàíî è èçñóøåíî, íàäõâúðëÿ ïðåäâèäåíîòî ìàêñèìàëíî êîëè÷åñòâî
(âæ. òàáëèöàòà íà ïðîãðàìèòå), èçâúðøåòå èçïèðàíåòî è ñëåä êàòî ïðîãðàìàòà å çàâúðøèëà, ðàçäåëåòå ïðàíåòî è
âúðíåòå åäíà ÷àñò â áàðàáàíà. Íà òîçè åòàï ñëåäâàéòå óêàçàíèÿòà çà èçâúðøâàíå íà ”Ñàìî ñóøåíå”. Ïîâòîðåòå ñúùèòå
îïåðàöèè çà îñòàíàëàòà ÷àñò îò ïðàíåòî.
Ñàìî ñóøåíå
Îò ïðîãðàìàòîðà èçáåðåòå äàäåíî ñóøåíå (11-12) âúç îñíîâà íà òèïà òúêàí. Âúçìîæíî å ñúùî òàêà íèâîòî èëè âðåìåòî
íà æåëàíîòî ñóøåíå äà ñå çàäàäå îò Ïðîãðàìàòîð ÑÓØÅÍÅ.
Ôóíêöèè
Äîïúëíèòå ôóíêöèè çà ïðàíå, ïðåäâèäåíè â ïåðàëíàòà ìàøèíà, äàâàò âúçìîæíîñò çà ïîñòèãàíå íà æåëàíîòî áÿëî è
÷èñòî ïðàíå; Çà àêòèâèðàíå íà âúçìîæíèòå ôóíêöèè:
1. íàòèñíåòå áóòîíà, ñúîòâåòñòâàù íà æåëàíàòà ôóíêöèÿ;
2. ñâåòâàíåòî íà ñúîòâåòíèÿ èíäèêàòîð ïîêàçâà, ÷å ôóíêöèÿòà å èçáðàíà.
Áåëåæêà:
- Àêî èçáðàíàòà ôóíêöèÿ íå å ñúâìåñòèìà ñúñ çàäàäåíàòà ïðîãðàìà, ñúîòâåòíèÿò ñâåòëèíåí èíäèêàòîð ùå ìèãà è
ôóíêöèÿòà íÿìà äà ñå àêòèâèðà.
- Àêî èçáðàíàòà ôóíêöèÿ íå å ñúâìåñòèìà ñ äðóãà ïðåäâàðèòåëíî çàäàäåíà, ñâåòëèííèÿò èíäèêàòîð,
ñúîòâåòñòâàù íà ïúðâàòà èçáðàíà ôóíêöèÿ, ìèãà è ñå àêòèâèðà ñàìî âòîðàòà, êàòî èíäèêàòîðúò íà àêòèâèðàíàòà
ôóíêöèÿ ñâåòâà.
С избирането на тази опция механичните движения, температурата и водата са оптимизирани за пране с намалено
зареждане на леко замърсени памучни и синтетични дрехи (виж „Tаблица с програмите“). С “ ” може да се пере
за по-кратко време, с намален разход на вода и енергия. Препоръчва се да се използва доза течен перилен препарат,
подходяща за количеството на заредения товар.
1400-600
С натискането на този бутон се намалява скоростта на центрофугата.
Äîïúëíèòåëíî èçïëàêâàíå
Ñ èçáîðà íà òàçè ôóíêöèÿ ñå óâåëè÷àâà åôèêàñíîñòòà íà èçïëàêâàíåòî è ñå ãàðàíòèðà ìàêñèìàëíî îòñòðàíÿâàíå
íà ïåðèëíèÿ ïðåïàðàò. Ïîäõîäÿùà å çà îñîáåíî ÷óâñòâèòåëíà êîæà.
Îòëîæåí Ñòàðò
Çàáàâÿ ïóñêàíåòî íà ìàøèíàòà äî 9 ÷àñà. Íàòèñíåòå ìíîãîêðàòíî áóòîíà, äîêàòî ñâåòíå èíäèêàòîðúò, ñúîòâåòñòâàù íà
æåëàíàòà ñòîéíîñò çà âðåìå íà çàáàâÿíå. Ïðè ïåòîòî íàòèñêàíå íà áóòîíà ôóíêöèÿòà íÿìà äà å àêòèâíà.
Çàáåëåæêà: Ñëåä êàòî âåäíúæ å íàòèñíàò áóòîíà ÑÒÀÐÒ/ÏÀÓÇÀ, âðåìåòî çà îòëàãàíå íà ñòàðòà ìîæå äà ñå ïðîìåíè ñàìî
ñ íàìàëÿâàíå, êàòî ñå ñòèãíå äî ïóñêàíå íà èçáðàíàòà ïðîãðàìà.
Ïåðñîíàëèçèðàíèÿ
Òàáëèöà ñ âðåìå çà èçñóøàâàíå (Óêàçàòåëíè ñòîéíîñòè)
Âèä òúêàí Òèï íà ïðàíåòî Ìàêñèìàëíè
êã.
Ãàðäåðîá Çàêà÷àëêà
Ãëàäåíå
Ïàìóê
Äðåõè ñ
ðàçëè÷íè
ðàçìåðè,
Õàâëèåíè êúðïè
5 250 210 190
Ñèíòåòè÷íè ×àðøàôè,
ôàíåëè 3 180 130 115

20
BG
Ïåðèëíè ïðåïàðàòè è
äðåõè çà ïðàíå
×åêìåäæå çà ïåðèëíèòå ïðåïàðàòè
Äîáðèÿò ðåçóëòàò îò ïðàíåòî çàâèñè è îò ïðàâèëíîòî
äîçèðàíå íà ïåðèëíèòå ïðåïàðàòè. ñ ïðåäîçèðàíå
íå ñå ïåðå ïî-åôèêàñíî, à òîâà âîäè äî îòëàãàíå íà
íàëåïè ïî âúòðåøíàòà ñòðàíà íà ïåðàëíàòà ìàøèíà
è äî çàìúðñÿâàíå íà îêîëíàòà ñðåäà.
! Íå èçïîëçâàéòå ïðåïàðàòè çà ðú÷íî ïðàíå, çàùîòî
îáðàçóâàò ìíîãî ïÿíà.
Èçòåãëåòå ÷åêìåäæåòî çà
ïåðèëíèòå ïðåïàðàòè è
èçñèïåòå ïðàõà çà ïðàíå
è äîïúëíèòå ïðåïàðàòè
ïî ñëåäíèÿ íà÷èí.
îòäåëåíèå 1: Ïðåïàðàò çà ïðåäïðàíå (íà ïðàõ)
îòäåëåíèå 2: Ïðåïàðàò çà ïðàíå (íà ïðàõ èëè òå÷åí)
Òå÷íèÿò ïðåïàðàò ñå èçñèïâà ïðåäè âêëþ÷âàíåòî íà
ìàøèíàòà.
îòäåëåíèå 3: Äîïúëíèòåëíè ïðåïàðàòè
(îìåêîòèòåë è äð.)
Îìåêîòèòåëÿò íå òðÿáâà äà èçëèçà èçâúí ðåøåòêàòà.
Ïîäãîòâÿíå íà ïðàíåòî
• Ðàçïðåäåëåòå ïðàíåòî ñúîáðàçíî:
- òèïà íà òúêàíèòå/ñèìâîëà âúðõó åòèêåòà.
- öâåòîâåòå: îòäåëåòå öâåòíèòå îò áåëèòå äðåõè.
• Èçïðàçíåòå äæîáîâåòå è ïðîâåðåòå êîï÷åòàòà.
• Íå íàäâèøàâàéòå óêàçíèòå ñòîéíîñòè çà òåãëîòî íà
ñóõîòî ïðàíå:
Óñòîé÷èâè òúêàíè: ìàêñèìàëíî 6 êã
Ñèíòåòè÷íè òúêàíè: ìàêñèìàëíî 2,5 êã
Ôèíè òúêàíè: ìàêñèìàëíî 2 êã
Âúëíåíè òúêàíè: ìàêñèìàëíî 1,5 êã
Êîïðèíà: ìàêñèìàëíî 1 êã
Êîëêî òåæàò äðåõèòå çà ïðàíå?
1 ÷àðøàô 400-500 ã
1 êàëúôêà 150-200 ã
1 ïîêðèâêà 400-500 ã
1 õàâëèÿ 900-1200 ã
1 êúðïà 150-250 ã
Ñïåöèôè÷íî ïðàíå
Âúëíåíè òúêàíè: Ñ ïðîãðàìà 6 å âúçìîæíî äà ñå
ïåðàò â ïåðàëíÿ âñÿêàêâè âúëíåíè äðåõè, ñúùî è òåçè
ñ åòèêåò “ñàìî çà ðú÷íî ïðàíå” . Çà ïîñòèãàíå íà
ïî-äîáðè ðåçóëòàòè èçïîëçâàéòå ñïåöèàëåí ïåðèëåí
ïðåïàðàò è íå íàäâèøàâàéòå 1,5 kg ïðàíå.
12
3
Êîïðèíà: èçïîëçâàéòå ñïåöèàëíàòà ïðîãðàìà 7 çà
ïðàíå íà âñè÷êè äðåõè îò êîïðèíà. Çà äåëèêàòíèòå
òúêàíè ñå ïðåïîðú÷âà èçïîëçâàíåòî íà ñïåöèàëåí
âèä ïåðèëåí ïðåïàðàò.
Ïåðäåòà: препоръчва се да се сгънат и поставят в
доставената торбичка. Èçïîëçâàéòå ïðîãðàìà 7.
Jeans: ïðåäè ïðàíå îáúðíåòå äðåõèòå è èçïîëçâàéòå
ñàìî òå÷åí ïåðèëåí ïðåïàðàò. Èçïîëçâàéòå ïðîãðàìà 8.
Ñèñòåìà çà èçìåðâàíå íà òîâàðà
Ïðåäè âñÿêî öåíòðîôóãèðàíå, ñ öåë èçáÿãâàíå
íà ïðåêàëåíè âèáðàöèè è çà ðàâíîìåðíî
ðàçïðåäåëÿíå íà òîâàðà, áàðàáàíúò ñå çàâúðòà
ñ ìàëêî ïî-âèñîêà îò òàçè ïðè ïðàíåòî ñêîðîñò.
Àêî ñëåä íàïðàâåíèòå ïîñëåäîâàòåëíè îïèòè
òîâàðúò âñå îùå íå å ïåðôåêòíî ðàçïðåäåëåí,
ìàøèíàòà èçâúðøâà öåíòðîôóãèðàíå ïðè ñêîðîñò,
ïî-íèñêà îò ïðåäâèäåíàòà. Ïðè íàëè÷èå íà
ïðåêàëåí äåáàëàíñèðàíå ïåðàëíÿòà èçâúðøâà
ðàçïðåäåëåíèåòî âìåñòî öåíòðîôóãàòà. Çà
óëåñíÿâàíå íà ïî-äîáðîòî ðàçïðåäåëåíèå íà òîâàðà
è ïðàâèëíîòî ìó áàëàíñèðàíå ñå ïðåïîðú÷âà äà ñå
ñìåñâàò äðåõè çà ïðàíå ñ ãîëåìè è ìàëêè ðàçìåðè.
