Infinite Peripherals LINEA PRO 5 User manual

Linea Pro 5 User Manual Page 1 of 1
UM-00025 Version: A
LINEA®PRO 5
USER MANUALLINEA PRO 5

Linea Pro 5 User Manual Page 2 of 31
UM-00025 Version: A
CONTACT INFORMATION
Mobility Sales/
Technical Support Center:
Infinite Peripherals, Inc.
17681 Mitchell N.
Irvine, CA 92614
Toll Free: [phone]
Ofice: [phone]
Headquarters/Main Warehouse Infinite Peripherals, Inc.
2312 Touhy Ave.
Elk Grove Village, IL 60007
Toll Free: [phone]
Ofice: [phone]
Fax: [phone]
Email — [email protected]
Web —ipcmobile.com

Linea Pro 5 User Manual Page 3 of 31
UM-00025 Version: A
LEGAL NOTICE
“Made for iPod” and “Made for iPhone” means that an electronic accessory has been designed to
connect specifically to the iPod or iPhone, respectively, and has been certified by the developer to
meet Apple performance standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that the use of this accessory with
iPhone may affect wireless performance.
COMPATIBILITY
Made for:
iPod touch® 5th generation mobile digital device
iPod touch® 6th generation mobile digital device
iPhone® 5 mobile digital device
iPhone® SE
TRADEMARK CREDITS
Infinite Periperhals, Mobilize Your Enterprise, Linea Pro, Infinea, Infinea Tab and Infinea Omni are
trademarks of Infinite Peripheral, Inc. All other trademarks are the property of their respective
owners.

Linea Pro 5 User Manual Page 4 of 31
UM-00025 Version: A
Table of Contents
CONTACT INFORMATION.......................................................................................................................................................1
LEGAL NOTICE...........................................................................................................................................................................2
COMPATIBILITY .........................................................................................................................................................................2
TRADEMARK CREDITS ...........................................................................................................................................................2
BOX CONTENTS.........................................................................................................................................................................5
ACCESSORIES ............................................................................................................................................................................5
GETTING STARTED .................................................................................................................................................................6
Warnings, Cautions, and Notes...........................................................................................................................................6
First Steps ...............................................................................................................................................................................6
PRODUCT FEATURES..............................................................................................................................................................7
PRODUCT OVERVIEW.............................................................................................................................................................8
Figure 1: Front View ......................................................................................................................................................8
Figure 2: Top View .........................................................................................................................................................8
Figure 3: Bottom View .................................................................................................................................................9
Figure 4: Back View .....................................................................................................................................................9
ASSEMBLING YOUR LINEA PRO 5...................................................................................................................................10
Figure 5: Linea Pro 5 Assembly ............................................................................................................................... 10
CHARGING YOUR LINEA PRO 5 ........................................................................................................................................11
Charging the Linea Pro 5 through the USB Port............................................................................................................ 11
Figure 6: USB Sync/Charge Port ...............................................................................................................................11
Figure 7: Battery Status by Number ........................................................................................................................12
DEVELOPING APPLICATIONS ...........................................................................................................................................13
PROGRAMMABLE OPTIONS............................................................................................................................................... 13
POWERING ON YOUR LINEA PRO 5...............................................................................................................................14
Figure 8: Power/Scan Button ....................................................................................................................................14
STATUS AND OPERATIONAL MODES ............................................................................................................................15
USING YOUR LINEA PRO 5 .................................................................................................................................................16
Barcode Scanner — 1D Barcodes...................................................................................................................................... 16
Figure 9: 1D Barcode Scanning .................................................................................................................................16
Barcode Scanner — 2D Barcodes......................................................................................................................................17
Figure 10: 2D Barcode Scanning ...............................................................................................................................17
Magnetic Stripe Reader (MSR) ......................................................................................................................................... 18
Figure 11: Magnetic Stripe Reader ............................................................................................................................18
Contactless Card Reader (RFID) ...................................................................................................................................... 19
Figure 12: RFID Reader ...............................................................................................................................................19
Syncing.................................................................................................................................................................................. 20
Figure 13: Syncing through USB Port ..................................................................................................................... 20

Linea Pro 5 User Manual Page 5 of 31
UM-00025 Version: A
RESETTING YOUR Linea Pro 5 ..........................................................................................................................................21
Figure 14: Reset Function ...........................................................................................................................................21
SERVICING YOUR LINEA PRO 5 ...................................................................................................................................... 22
Battery Replacement ..........................................................................................................................................................22
Figure 15: Battery Replacement/Servicing ............................................................................................................22
SRED Encrypted MSR Information...................................................................................................................................23
TROUBLESHOOTING ............................................................................................................................................................24
Troubleshooting > Card Reading .....................................................................................................................................24
Troubleshooting > Barcode Scanning.............................................................................................................................24
Troubleshooting > Contactless Card Reading...............................................................................................................25
TECHNICAL DATA ..................................................................................................................................................................26
WARRANTY .............................................................................................................................................................................. 28
DISCLAIMER............................................................................................................................................................................. 28
SYMBOLS FOR USE............................................................................................................................................................... 29
FEDERAL COMMUNICATIONS COMMISSION.............................................................................................................30
Federal Communications Commission (FCC) Statement .......................................................................................... 30
FCC RF Radiation Exposure Statement......................................................................................................................... 30

Linea Pro 5 User Manual Page 6 of 31
UM-00025 Version: A
BOX CONTENTS
The Linea Pro 5 ships with these items:
Qty Description Image
1 Linea Pro 5
1 Screw M1.6x4 - Security Torx
1 USB charge/sync cable*
*Note: Box contents may vary based on ordered configuration.
ACCESSORIES
Contact your Infinite Peripherals (IPC) account representative for information related to current and
future product availability.

Linea Pro 5 User Manual Page 7 of 31
UM-00025 Version: A
GETTING STARTED
Warnings, Cautions, and Notes
Please observe the Warnings, Cautions, and Notes presented throughout this manual. An explanation
of these items are:
Symbol Description
WARNING: Actions may result in a serious outcome (for example, injury, death, or other adverse
affect) to the user.
CAUTION: Special care is required to avoid damage to the product or other property.
Note: Important points and tips about the product are being provided.
First Steps
You can scan barcodes with the Linea Pro 5 and capture magnetic stripe information into the iPhone.
Before using your Linea Pro 5, the battery should be fully charged.
The following table will help you get the Linea Pro 5 ready for use:
Step Purpose Additional Information
1. Integrate your
Linea Pro 5 with
the iOS Device.
Connecting your Linea Pro 5 to your
iPhone.
See section:
ASSEMBLING YOUR
LINEA PRO 5
2. Charge your Linea
Pro 5
The battery should be fully charged
before use to ensure long battery life.
See section:
CHARGING YOUR
LINEA PRO 5
3. Install software Requires the installation of software on
your iOS for specific features..
See section:
DEVELOPING APPLICATIONS
4. Power on your
Linea Pro 5
Initialize the Barcode Scanner, Magnetic
Stripe Reader (MSR) and/or Radio
Frequency Identification (RFID) functions
for use.
See section:
POWERING ON YOUR
LINEA PRO 5

Linea Pro 5 User Manual Page 8 of 31
UM-00025 Version: A
PRODUCT FEATURES
The Linea Pro 5 allows mobile employees to convert their iPod or Phone into a powerful solution for
the retail, warehousing, supply chain, ticketing and hospitality industries. The Linea Pro 5 includes
an encrypted or unencrypted 3-track magnetic stripe reader, optional 1D or 2D barcode scanner,
optional Bluetooth®, and optional RFID.
Feature Description
1D/2D Barcode Scanner
Supports one-dimensional (1D) and two-dimensional (2D) barcode
symbols, which can be read in any direction (omni-directional). The
effective reading distance of the barcode reader varies depending on the
barcode size. The barcode scanner is also capable of reading barcodes on
an LCD screen.
Magnetic Stripe Reader
(MSR)
Built-in magnetic stripe reader. The card reader incorporates a (3) track,
bi-directional magnetic read head, requiring a single swipe to read field
data from all three tracks.
Contactless Card
Reader (RFID)
RFID tag/card reader with read and write capability at 13.56 MHz. The
RFID reader incorporates several RFID formats, depending on the model
of your Linea Pro 5.
Bluetooth
Compatibility
Available Bluetooth 2.0 SPP compatibility, which allows connection to a
Bluetooth peripheral such as a printer.
Syncing Enables your iOS to be synced with iTunes.
Indicators Four (4) LEDs indicate battery status levels and an electromagnetic
buzzer.
Battery Status The battery status may be checked by pressing the Battery Status button.
Use of the Barcode Scanning, Magnetic Card and/or RFID reader features requires the
installation of special software. Please contact your reseller to inquire about available
software, or contact Infinite Peripherals directly for recommendations on compatible third
party software solutions.

Linea Pro 5 User Manual Page 9 of 31
UM-00025 Version: A
PRODUCT OVERVIEW
9-pin Lightning™
connector
Figure 1: Front View
Scan Engine
Volume
Controls
Figure 2: Top View

Linea Pro 5 User Manual Page 10 of 31
UM-00025 Version: A
Audio Connector
USB Sync/Charge Port
Battery Status
Button & Indicators
Figure 3: Bottom View
iPhone On/Off Button
Scan
Button
Magnetic
Stripe
Reader
Figure 4: Back View

Linea Pro 5 User Manual Page 11 of 31
UM-00025 Version: A
ASSEMBLING YOUR LINEA PRO 5
1. Remove the top of the Linea Pro 5 case.
2. Insert the iPod or iPhone device.
3. Connect the iOS device by firmly sliding it onto the Lightning connector.
4. Guide the top piece onto the Linea Pro 5 using the large snap and firmly press the top piece onto
the body of the Linea Pro 5.
5. Secure the top piece into place using the Torx screw provided with your unit.
Figure 5: Linea Pro 5 Assembly

Linea Pro 5 User Manual Page 12 of 31
UM-00025 Version: A
CHARGING YOUR LINEA PRO 5
Charging the Linea Pro 5 through the USB Port
The Linea Pro 5 uses a Lithium ion rechargeable battery. The battery should be fully charged prior to
the first use.
The Linea Pro 5 supports pass through charging to the iOS device. The iPod or iPhone and Linea Pro
5 may be charged together via the mini USB port or by placing it in a Linea Pro 5 Single or 5-Unit
Charging Station. Due to current charging limitations, the Linea Pro 5 should not be charged via USB
from a PC/Mac connection.
To Charge the Linea Pro 5:
1. Connect mini USB charger cable to the USB port (shown in the figure below).
USB Sync/Charge Port
Figure 6: USB Sync/Charge Port
To prevent electrical damage to the Linea Pro 5 and/or battery, please use approved
USB to Mini USB cables only.
The battery should be charged in an ambient operating temperature of 0°C to +40°C.
Charging time for a fully drained battery is approximately 5h and 30 min to achieve full charge
status.
If the device is equipped with encrypted magnetic stripe reader, do not allow the battery to fully
discharge. The device will disconnect from the iPhone when the battery is drained below 3.6V.

Linea Pro 5 User Manual Page 13 of 31
UM-00025 Version: A
Battery Status Indicators
You can check the battery status by pressing the Battery Status button.
Numbers illuminated at the bottom of the unit identify the battery charge status.
Battery Status Numbers
Figure 7: Battery Status by Number
Battery Charge Status
1 1% - 25% charge
2 26% - 50% charge
3 51% - 75% charge
4 76% - 100% charge
It is not necessary for the iOS to be connected to the Linea Pro 5 in order to check the
battery status.

Linea Pro 5 User Manual Page 14 of 31
UM-00025 Version: A
DEVELOPING APPLICATIONS
Software is not provided with your Linea Pro 5. Please contact your reseller or Infinite Peripherals for
Third Party software solutions.
Integrating the Linea Pro 5 into your iOS application requires the use of the Infinite Peripherals
Universal SDK. The SDK incorporates an API specifically for developing applications to use Linea Pro
5 functionality.
For additional details on using the Infinite Peripheral Universal SDK, please refer to the appropriate
SDK documentation.
For the latest Infinite Peripheral Universal SDK please visit our developer portal:
developer.ipcmobile.com/
PROGRAMMABLE OPTIONS
Optional settings for the Linea Pro 5, which can be configured via the SDK include:
Programmable Options Description
Charging Current Charging current may be set to 500mA (default) or 1A
Set Charging
The Linea Pro 5 can charge the iPod/iPhone using its internal battery
by enabling the “setCharging” setting. When the Linea Pro 5 battery is
above 20%, it will then start to charge the iPod/iPhone battery
Enable Scan Button In order to scan, the Enable Scan Button must be set in the SDK.
Scan Mode
Linea Pro 5 supports the following Scan modes:
• Single Scan
Scanning a single barcode by pressing and releasing the Scan but-
ton.
• Multi Scan
Scanning multiple barcodes by pressing and holding the Scan but-
ton.
• Motion-Detect
Scanner is activated automatically when barcode is placed near the
barcode engine.
• Multi-Scan without Duplicates
Scanning multiple barcodes without duplicates.
Pass Through Sync
When the pass through sync setting is enabled and the USB cable is
plugged in, the iPhone 6 may be synced with a PC or MAC.
When syncing is required, enable the Pass through Sync setting in the
SDK. When this option is selected and the USB cable is plugged in, the
Linea Pro 5 will disconnect and the user will no longer be able to scan.
In order to use the scanner again, the USB cable must be removed.
Idle Time Default setting is 5400 seconds (90 minutes).

Linea Pro 5 User Manual Page 15 of 31
UM-00025 Version: A
POWERING ON YOUR LINEA PRO 5
The dual-purpose Scan button powers on the unit and scans barcodes.
To power on the Linea Pro 5:
1. With the Linea Pro 5 in powered off, press the Scan button until a single beep is heard. The unit is
now ready for use.
2. Press the Scan button a second time to activate the scanner for normal barcode scanning.
Scan Button
Figure 8: Power/Scan Button
When the Linea Pro 5 is left idling for an extended period, the power is automatically turned off to
preserve the charge on the internal battery pack.

Linea Pro 5 User Manual Page 16 of 31
UM-00025 Version: A
STATUS AND OPERATIONAL MODES
In addition, LEDs indicate the modes of operation. LEDs indicate connection status plus charging
and/or low battery conditions.
These conditions and their corresponding LEDs:
Operating Status
No LEDs Sleep or ready mode.
Multiple LEDs Displaying battery level status.
One LED is flashing Charging and syncing.

Linea Pro 5 User Manual Page 17 of 31
UM-00025 Version: A
USING YOUR LINEA PRO 5
Barcode Scanner — 1D Barcodes
The Linea Pro 5 1D model uses a scan engine that supports one-dimensional (1D) barcode symbols.
The effective reading distance of the barcode reader varies depending on the barcode size.
To scan a 1D barcode:
1. Press the Scan button to activate the Linea Pro 5.
2. Position the scan head as close to the barcode label as possible so that the scan line crosses both
ends of the barcode as shown in the figure below.
3. Slowly pull the unit back, increasing the distance between the barcode and scan head, until the
barcode has been read by the scanner.
Scan Button 15-20 cm
Figure 9: 1D Barcode Scanning

Linea Pro 5 User Manual Page 18 of 31
UM-00025 Version: A
Barcode Scanner — 2D Barcodes
The Linea Pro 5 2D model uses a scan engine that supports one-dimensional (1D) and two-
dimensional (2D) barcode symbols. The effective reading distance of the barcode reader varies
depending on the barcode size.
To scan a 2D barcode:
1. Press the Scan button to activate the Linea Pro 5.
2. Position the scan head so that the pointer is aimed at the barcode, and the barcode is within the
width of the red illumination box.
3. Slowly pull the unit back, gradually increasing the distance between the barcode and scanner, until
the barcode has been read by the scanner.
15-20 cm
Scan Button
Figure 10: 2D Barcode Scanning

Linea Pro 5 User Manual Page 19 of 31
UM-00025 Version: A
Magnetic Stripe Reader (MSR)
The Linea Pro 5 has a built-in magnetic stripe reader. The MSR incorporates a 3-track, bi-directional,
encryption-capable magnetic read head. A single swipe can read field data from all three tracks.
The MSR will function as an unencrypted MSR until an encryption key is injected into the MSR
head by a designated Infinite Peripherals key injection facility. Please contact an Infinite Peripherals
account representative for more information.
To use the Magnetic Stripe Reader
1. Press the Scan button to activate the Linea Pro 5.
2. Insert the card into either end of the reader with the magnetic stripe face up, then swipe the card
through toward the other end of the reader.
Swipe direction
Figure 11: Magnetic Stripe Reader
Keep the edge of the card flat on the inner edge of the reader to ensure that the magnetic stripe
passes over the read head evenly.

Linea Pro 5 User Manual Page 20 of 31
UM-00025 Version: A
Contactless Card Reader (RFID)
The built-in RFID tag/card reader incorporates several RFID format depending on the model of your
Linea Pro 5.
To use the RFID reader:
1. Press the Scan button to activate the Linea Pro 5.
2. Place the RFID tag/card over the receiver/transmitter as indicated by the RFID label. The data is
sent from the Linea Pro 5 Tab contactless reader to the iOS.
Figure 12: RFID Reader
Keep the face of the tag/card flat, with the receiver/transmitter as close as possible. Depending on
the type of RFID tags/cards being used, it may be necessary for tags/cards to make direct contact
with the surface where the RFID receiver/transmitter is located for proper reading and writing.
