Infinite Peripherals Imperea User manual

Imperea
USER MANUAL
For iPhone® 6s / 7 / 8

User Manual | Imperea
2
Contact Information
Mobility Sales/ Technical Support Center
Innite Peripherals, Inc.
17681 Mitchell N
Irvine, CA 92614
Toll-Free: [phone]
Ofce: [phone]
Website: ipcmobile.com
Headquarters/ Main Warehouse
Innite Peripherals, Inc.
2312 Touhy Avenue
Elk Grove Village, IL 60007
Toll-Free: [phone]
Ofce: [phone]
Fax: [phone]
Compatible Devices
Legal Notice
“Made for iPhone” (MFi) means that an electronic accessory has been designed to connect specically to the iPhone and
has been certied by the developer to meet Apple performance standards. Apple is not responsible for the operation of this
device or its compliance with safety and regulatory standards. Please note that the use of this accessory with an iPhone may
affect wireless performance.
• iPhone 6s
• iPhone 7
• iPhone 8
Trademarks
Innite Peripherals, Mobilize Your Enterprise, Linea Pro, Innea, Innea Tab, and Innea Omni are trademarks of Innite
Peripherals, Inc. All other trademarks are the property of their respective owners.
iOS Compatibility

User Manual | Imperea
3
Table of Contents
Legal Notice 2
Compatible Devices 2
Trademarks 2
Overview 4
Features 4
Accessories 4
Technical Specifications 5
Physical Dimensions 5
Connectivity 5
Certificates 5
Environment 5
Box Contents 6
Getting Started 6
Product Description 7
Assemble Your Imperea 8
Dissemble Your iOS Device from Imperea 9
Charge Imperea with the Single Charging Station 10
Battery Status 10
Developing Applications 10
Programmable Options 11
Charging Current 11
Set Charging 11
Enable Scan Button 11
Scan Mode 11
Pass-Through Sync 11
Idle Time 11
Using Your Imperea 12
Scan Barcodes 12
Servicing the Imperea 13
Replacing the Battery 13
Troubleshooting 14
Warranty 15
Disclaimer 15
Product Returns and Servicing 15
Symbols 16
Federal Communications Commissions 17

User Manual | Imperea
4
Visit our website at https://ipcmobile.com or contact your Innite Peripherals account representative for additional
information about our current and future product accessories.
Overview
Imperea is a durable, camera-based scanning device for your iOS device. As a high-speed scanning device with IP67 rating
for dust and moisture protection to withstand industrial conditions, Imperea includes a smart battery and intuitive SDK for
software integration.
Features
Camera-Based Barcode Scanner
Camera scanning SDK enables your iOS device to scan
any barcode even if poorly printed or curved.
Supports 1D/2D, 2D, 2D stacked, and 2D matrix barcode symbols
Single Charging Station with Wireless Qi
Technology
The smart battery uses wireless Qi technology that
charges both the Imperea battery and iOS device
simultaneously.
Battery Status
Four LEDs illuminate the battery status indication on
the back of Imperea.
Accessories
Battery
User swappable, rechargeable battery with 2100mAh
capacity. Supports wireless charging.

User Manual | Imperea
5
Connectivity
Certificates
Environment
Barcode Scanner
Camera-based scanning enables your iOS device to scan
all barcodes in all environments
Reads 1D/2D, 2D stacked, GS1, and 2D matrix barcodes
Temperature
Operation: 0°C to +40°C (32°F to 104°F)
Storage: -20°C to +65°C (-4°F to 149°F)
Relative Humidity
Operation and Storage: 5%-90%
CE, FCC, MFI, ROHS, UN38.3 for battery
Drop test MIL-STD-810 (4-ft to concrete)
IP67 rating
Battery
User-replaceable, rechargeable Lithium-Polymer
battery
3.7V, 2100mAH, 3.7 supporting wireless Qi charging
Smart battery with real-time charging status and
battery health for better battery management
Power Adapter
Custom power adapter included with single station
wireless charger
12 volts, 1.5A, 18W
LED Indicators
Four programmable LEDs on back of unit illuminate
when battery status button is pressed
Battery status colors: Blue, Green, Red, Amber
Accessories
Single station wireless charger
Input Voltage
5 volts
Technical Specifications
Physical Dimensions
Compatibility
iPhone 6s / 7 / 8
Dimensions (L x W x H)
160mm x 76.6mm x 18.6mm (6.3” x 3.01” x 0.73”)
Weight
155.129g (5.472 oz.) without iOS device
Buttons
Three user-congured blue buttons in the application
for features such as push-to-talk, camera, and
messaging
Battery status button on the battery
All existing iOS device buttons are accessible
Audio/Visual
Apple iPhone speakers and microphone
Front and back camera

User Manual | Imperea
6
Box Contents
• Before using your Imperea, remove the unit and any included accessories from the shipping cartoon and verify the contents against the packing list.
• Retain all packing materials, invoice, and bill of lading. These may be required to return the device for servicing later, or to process a claim with the
shipping carrier.
• Carefully inspect the contents inside of the packaging for any signs of damage. If there are signs of damage, do not attempt to use the unit. Notify your
account executive or contact technical support at https://ipcmobile.com/devices.
• Ensure the battery is fully charged prior to initial use.
Your Imperea and case includes a single-station charger with power adapter and a battery inside the unit.
Imperea (1) Single Station Charger (1)
Note:
Box contents and SKUs vary based on your order conguration.
Getting Started
The following helps you get the Imperea ready for use:
What to do Section
Connect Imperea with your iOS device Assemble Your Imperea
Remove your iOS device from Imperea Disassemble Your iOS Device from Imperea
Fully charge battery before rst use Charge Imperea with a Single Charger
Software required to run Imperea with an iOS device Developing Applications
Operating the Imperea Using Your Imperea
Note:
The barcode scanning feature requires the installation of software. Contact your Innite Peripherals account representative for available software via our
SDK.

User Manual | Imperea
7
Product Description
Camera
scanner
Battery latch
4 LEDs
Mute Ringer
Volume Control
USB Type-A connector
Scan button
Right/Left sides

User Manual | Imperea
8
Assemble Your Imperea
1. Remove the Imperea from the box, and then carefully twist a penny or the ply tool inside the bottom notch.
2. Twist the coin along the metal inside bottom notch to release the snap ttings on the bottom of the cover.
3. After the cover is loose, pull the remaining snap ttings with the coin along the top cover.
4. Place the unit on a at surface, and then slide the iPhone downwards towards the Lightning™ connector.
5. Once the iPhone is engaged with the Lightning connector, gently press the iPhone onto the unit.
6. Ensure the iPhone is seated property and ush with the rubber seals.
7. Place the front cover onto the unit with the snaps fully engaged.

User Manual | Imperea
9
Dissemble Your iOS Device from Imperea
1. Remove the Imperea from the box, and then insert a penny horizontally into the bottom notch.
2. Press rmly and twist a penny along the metal inside the bottom notch to release the snap ttings on the bottom of the
cover.
3. Once the bottom part of the cover is loose, carefully pull on the remaining snap ttings along the top cover.
4. With the top cover removed, take the Imperea and locate the camera opening on the reverse side.
5. Through the camera opening, press gently on the iPhone to release it from the rubber enclosure.
6. Once the top iPhone is released, slide the iPhone upwards, removing it from the Lightning connector.
7. Gently snap the top cover into place for safekeeping.

User Manual | Imperea
10
Charge Imperea with the Single Charging Station
Battery Status
To check the battery status, open the application on your iOS device and view the data. Your iOS device must be connected to
the Imperea before you can check the battery status.
Note:
When the status is above 20%, set the automated charge functionality to automatically charge the iOS battery.
Developing Applications
Software is not provided with your Imperea. Please contact your reseller or Innite Peripherals for Third Party software
solutions. Integrating the Imperea into your iOS application requires the use of the Innite Peripherals Universal Software
Developers Kit (SDK).
The SDK incorporates an API specically for developing applications to use Imperea functionality.
For additional details on using the Innite Peripheral Universal SDK, please refer to the appropriate SDK documentation.
For the latest Innite Peripheral Universal SDK, please visit our developer portal at:
https://developer.ipcmobile.com
Use the included power adapter when charging Imperea with the single charging station. The charging time is approximately
3 hours and 30 minutes to charge a fully depleted unit.
• For the charger to perform effectively, use the power adapter provided.
• To prevent electrical damage to the unit and/or battery, only use an approved USB Type-A cable.
1. Plug the USB-A end of the charging cable into the provided adapter. The top LED ashes green.
Note:
To prevent damage to the unit, do not plug the cable into a USB port on a computer or other adapter.
2. Place the unit on a single station charger, lining up the bump on the base of the charger with the bottom notch on the
Imperea.
3. Ensure the unit is centered on the charger, and then wait to hear the charging beep.
• This signals the Qi charging is starting.
• The LED light on the station blinks green when the unit is charging.

User Manual | Imperea
11
Programmable Options
Congure these optional settings via the SDK.
Charging Current
Charging current may be set to 500mA (default) or 1000mA.
Set Charging
The Imperea can charge the iPhone using its internal battery by enabling the “setCharging” setting. When the Imperea battery is above 20%, it will then start
to charge the iOS device battery.
Enable Scan Button
Select the Enable Scan button in the SDK.
Scan Mode
Imperea supports the following scan modes:
Single Scan
Scanning a single barcode by pressing and releasing either Scan button.
Multi Scan
Scanning multiple barcodes by pressing and holding either Scan button.
Motion-Detect
Scanner is activated automatically when barcode is placed near the barcode engine.
Multi-Scan without Duplicates
Scanning multiple barcodes without duplicates.
Pass-Through Sync
When enabled and the USB Type-A cable is plugged in, the iOS device is synced with a Windows computer or an Apple MacOS.
When syncing is required, enable the Pass-Through Sync setting in the SDK. When this setting is disabled and the USB cable is plugged in, the Imperea only
charges, but does not scan.
To use the scanner again, the USB Type-A cable must be removed.
Idle Time
Default setting: 5400 seconds (90 minutes).

User Manual | Imperea
12
Scan Barcodes
1. Point the camera on the back of the unit at the
barcode.
2. Press the scan button.
Using Your Imperea
1. Remove the tape on the battery contacts before
rst use.
2. Turn on the Imperea.
3. If the battery indicator on the upper right-hand
corner of the iPhone screen is not green with a
lightning bolt, then press and hold the battery
status button on the back of the unit for 5 seconds.
Note:
These steps enable a back-up charge for your iOS device.

User Manual | Imperea
13
Servicing the Imperea
Replacing the Battery
The 2100mAh battery in the Imperea can be removed and recharged. Wireless charging is available using the custom Qi
charging pad and 5V, 3A power adapter.
Note:
Replace the battery only with a new, original battery.
1. On the back on the Imperea, slide the battery cover latch to one side, and then pull up the battery cover.
2. Remove the old battery by pulling it up carefully.
3. Insert the side of the new battery with the contacting pads, and then press it down gently.
4. Before closing the battery cover, press the battery cover latch down, and then press the battery cover in place.
5. Slide the latch to lock the battery cover.

User Manual | Imperea
14
Troubleshooting
Issue Possible Cause
Imperea does not scan barcode • Battery is too low.
• Software is not powering on the unit.
Data/partial data not returned during
scanning
• Unreadable barcode.
• Battery is too low.
• Faulty scan engine.
• Software decoding incorrectly.
Unable to perform multi-scanning • Multi-scan not enabled.
• Multi-scan not supported by software.
Unable to scan specific barcodes • Barcode type not enabled.
• Barcode type not supported.
• Refer to Technical Specications for additional information.
Note:
If problems persist with your Imperea, contact a Mobility Expert at https://ipcmobile.com/devices/imperea

User Manual | Imperea
15
Warranty
Innite Peripherals does not warrant, and is not responsible for, any damage to the Imperea (“Product”) or the assembled iOS
device as a result of liquid or solid particle intrusion into the Product, or damaged caused by dropping the Product with the
assembled iOS device. If a material or workmanship defect arises with regard to any Innite Peripherals product, and a valid
claim is received within the Warranty Period, Innite Peripherals (at our sole discretion) will repair the Product using new or
refurbished parts, or replace the Product with a new or refurbished Product.
For purposes of this limited warranty, “refurbished” means a product or part that has been substantially returned to its
original specications. In the event of a defect, these are your exclusive remedies.
Disclaimer
NO WARRANTY. This technical documentation is provided AS-IS. Further, the documentation does not represent a
commitment on the part of. Innite Peripherals, Inc does not warrant that it is accurate, complete or error free. Any use of the
technical documentation is at the risk of the user. Innite Peripherals, Inc reserves the right to make changes in specications
and other information contained in this document without prior notice, and the reader should in all cases consult Innite
Peripherals, Inc to determine whether any such changes have been made. Innite Peripherals, Inc shall not be liable for
technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the
furnishing, performance, or use of this material. Innite Peripherals, Inc does not assume any product liability arising out of
or in connection with the application or use of any product or application described herein.
Product Returns and Servicing
Use the link in step 1 to create an account and gain access to our Knowledge Base and online support services. Through our
online support center, you’ll be able to download les, open a Support Ticket, manage your RMAs, view your account Prole
and subscribe to Alerts.
To request a RMA
1. Create a user account in the RMA Support Portal at http://ipcmobile.com/support/rma/
2. Login to your user account, and then click Create RMA Request.
3. Read the instructions provided and complete the online request form.
4. Note the assigned RMA number and write it clearly on your shipping carton.
5. Ship your equipment back to us using the address provided.

User Manual | Imperea
16
Symbols
Symbol Description
Refer to the instructions before using this product
Manufacturer
Manufacture Date
Caution
Serial Number
P/N Part Number
Waste Electrical and Electric Equipment
Complies with part 15 of the FCC rules

User Manual | Imperea
17
Federal Communications Commissions
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modications not expressly approved by the part responsible for compliance could void
the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference that may cause undesired operation of the device.
FCC RF Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must
follow the specic operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
