Infinite Peripherals Infinea X IX-I2DBTR-PH5-WH User manual

QUICK START GUIDE
*Also available in black
INFINEA®X
12
3
6
5
4
9
4
8
12
3
4
5
67
FRONT SPEAKER
iOS ON/OFF BUTTON
SCAN BUTTON
STATUS LEDs
SPEAKER TOGGLE BUTTON
1.
2.
3.
4.
5.
MICROPHONE
HOME BUTTON
BATTERY STATUS BUTTON
VOLUME BUTTONS
6.
7.
8.
9.
iOS CAMERA OPENING
BARCODE SCANNER
RFID ANTENNA
BATTERY PACK
BATTERY LATCH
1.
2.
3.
4.
5.
REAR SPEAKER6.
ABOUT YOUR INFINEA X
ASSEMBLY
Secure the cover by inserting
(6) torx screws. Do not over
tighten screws.
3
Close the top cover, being careful
not to pinch the wires, while
maintaining the position of the
protective rubber bumper.
2
1Open the Infinea X by loosening the
torx screws and gently flipping open
the top cover. Slide the iOS product
onto the Lightning™ Connector and
audio jack until it clicks into place.
CAUTION: Please take care that the rubber bumper is properly aligned between the top and bottom covers. Failure to do so will compromise the liquid protection
features of the Infinea X. If you have any questions about installation of the rubber bumper, please contact your sales representative.
Lightning™ Connector
Audio Jack

iOS device will not sync to iTunes
• Infinea X is not configured for sync.
Swipe gestures not detected by iOS device
• Top cover is not properly installed.
Audio playback not heard from front speakers
• iOS device is not connected to audio jack.
• Innea X front speaker cable is damaged or
disconnected.
Audio playback not heard from rear speakers
• iOS device is not connected to audio jack.
• Rear speaker not powered.
iOS device does not charge
• AC adapter may not meet charging
requirements
• Pass Through Sync is enabled.
Integrating the Infinea X into your iOS
application requires the use of the Infinite
Peripherals mobile device SDK. For the latest
Infinite Peripherals mobile device SDK, please
visit our developer portal ipcmobile.com/
developer.
TROUBLESHOOTING
1. Attach the charging cup to the bottom
of the Infinea X.
2. Plug the USB end into an AC wall
Adapter.
Note: The AC adapter must support at least 2.1
amps
.
CHARGING
BATTERY STATUS
The Infinea X portable barcode scanner is
designed specifically for use with iPod Touch®/
iPhone® by allowing the iPod and iPhone to
sync with iTunes® through the Infinea X while
connected.
1. Ensure that Pass Through Sync option is
enabled in the SDK.
2. Connect the Infinea X to a computer using
the Charging Cup.
SYNCING
ACCESSORIES
Please visit our Accessories page at
ipcmobile.com, or contact your Infinite
Peripherals sales representative for more
information about available chargers and
battery packs for the
Infinea X.
100% - 75%
74% - 50%
49% - 25%
24% - 10%
9% - 1%
LEDs solid green
LEDs blink green
LEDs blink orange
LEDs blink red
One LED blinks red/
emergency low battery
Press the battery status button to view LEDs.
•
