Emerson PanelGuard 65 User manual

Surge Protection
For Business-Critical Continuity™
The Liebert PanelGuard Extension is
an add-on device for integration with
panelboards a
at tt th he ej jo ob bs si it te efor
enhanced surge suppression.
Liebert PanelGuard Extension
minimizes data corruption, errors,
system re-boots and component
failure. Sine wave tracking circuitry
filters high frequency electrical line
noise. Patented component level
monitoring, including neutral to
ground, allows status detection in
real time.
Features & Benefits
Flexible mounting (top or bottom)
to virtually any panelboard.
Universal panelboard application —
can be used with most major
manufacturers.
UL 1449 and UL 1283
Surge current capacity levels from
130kA per phase to 200kA per phase.
Standard features include all modes
of protection, unit status indicators
and isolated form C dry contacts.
Options include: audible alarm,
transient counter.
Liebert®PanelGuard™ Extension
Clean Power Distribution For Electronic Panelboards

Emerson Network Power.com
Emerson Network Power.
The global leader in enabling
Business-Critical Continuity™.
AC Power
Connectivity
DC Power
Embedded Computing
Embedded Power
Monitoring
Outside Plant
Power Switching & Controls
Precision Cooling
Racks & Integrated Cabinets
Services
Surge Protection
Liebert Corporation
1050 Dearborn Drive
P.O. Box 29186
Columbus, Ohio 43229
800 877 9222 Phone (U.S. &
Canada Only)
614 888 0246 Phone (Outside U.S.)
614 841 6022 FAX
Via Leonardo Da Vinci 8
Zona Industriale Tognana
35028 Piove Di Sacco (PD)
Italy
39 049 9719 111 Phone
39 049 5841 257 FAX
Emerson Network Power Asia Pacific
7/F., Dah Sing Financial Centre
108 Gloucester Rd, Wanchai
Hong Kong
852 25722201 Phone
852 28029250 FAX
liebert.com
Technical Support
800 288 6169 Toll-Free
607 724 2484 Phone
607 722 8713 Fax
UL 1449 RATINGS
Line to Line to Line Neutral
System Voltage Neutral Ground to Line to Ground
120/208 or 120/240 400 V 400 V 800 V 400 V
208, 240, 277 or 277/480 800 V 800 V 1500 V 800 V
Specifications
Surge Current Capacity
Minimum Tested Single Pulse Surge Current Capacity
Protection Mode Impulses Per Mode Model 100 Model 80 Model 65
Line-to-Neutral > 3,500 > 100,000 A > 80,000 A > 65,000 A
Line-to-Ground > 3,500 > 100,000 A > 80,000 A > 65,000 A
Neutral-to-Ground > 3,500 > 100,000 A > 80,000 A > 65,000 A
Line-to-Line > 3,500 > 100,000 A > 80,000 A > 65,000 A
Per Phase > 7,000 > 200,000 A > 160,000 A > 130,000 A
Enclosure
NEMA 1 rated.
Surface mount dimensions are 12” x 20” x 6”.
Flush mount unit is 12” x 21.5” x 6”.
Weight is 15 lbs.
EMI/RFI Noise Rejection Values
Single Unit Frequency System Installation
34 dB 100 kHz 51 dB
51 dB 1 MHz 94 dB
54 dB 10 MHz 114 dB
48 dB 100 MHz 120 dB
How To Order Liebert Liebert PanelGuard™Extension
Duty life cycle tested to survive 20kV, 10kA, IEEE C62.41 Category C3 surge current
with less than 5% degradation of clamping voltage.
All systems EMI-RFI noise or attenuation rejection values are in compliance with test
and evaluation procedures outlined in NEMA LS 1-1992, paragraphs 2.2.11 and 3.11.
Phase configuration Code
1 Ph, 3W+G. 120/240 VAC 120S
3 Ph, 4W+G. 120/208 VAC 120Y
3 Ph, 4W+G. 277/480 VAC 277Y
Other phase configurations available.
Please consult factory.
kA per mode/per phase Code
65 kA per mode, 130 kA per phase 65
80 kA per mode, 160 kA per phase 80
100 kA per mode, 200 kA per phase 100
Trim typeCode
Surface mount trim S
Flush mount trim F
Monitoring options Code
Standard Status LEDs only -00
LEDs, Audible Alarm, Counter -01
LEDs, Audible Alarm -02
LEDs, Counter -03
How to construct a Liebert PanelGuard
Extension (LPGE) model # Code
1. Liebert PanelGuard Extension LPGE
2. Phase configuration 120S
3. kA per mode/per phase 65
4. Trim type: surface mount S
5. Monitoring options -01
Sample model #: LPGE120S65S-01
