InFocus Tab F1 Instruction sheet

Product Instruction
New Tab F1

Thanks for Choosing InFocus
InFocus (Shenzhen) Digital Technology Co.,Ltd (hereinafter referred as InFocus) , focusing
on independent research and development, and manufacturing of digital technology
products, is committed to providing its customer with good user experience and outstanding
product service. Adopting InFocus latest technology and strictly following related national
standards, we exert the greatest effort to bring you this tablet product. Please rest assured
to use.
•Please use the accessories provided with your tablet for battery charging, data access,
etc.
•Please be care of using other accessories as they may be incompatible with your tablet,
and even induce accident.
•Please carefully read the product instruction.
Diagrams Description
Warning-Condition that may be harmful toyour safety and others;
Caution-Condition that may damage this or other product;
Note-Remark or reminder.

Content
1.Product Specifications and Packaging List ············································· 1
2.Get to Know Your Product ·································································· 4
3.Power On/Off ··················································································· 5
4.Charge the Battery ············································································ 7
5.Lock and Unlock Screen ···································································· 8
6.Set Date and Time ············································································ 8
7.Touch Panel Operation ······································································ 9
8.Wireless Network ·············································································· 9
9.Applications Overview ········································································ 11
10.Connect to the Computer ··································································· 14
11.Get More Help ················································································· 14
12.Personal Information and Data Security ················································ 14
13.Safety Precautions and Tips ······························································· 16
14.Federal Communications Commission (FCC) Notice (U.S. Only)···················21
15.Hazardous Substances ······································································ 23

- 1 -
1.Product Specification and Packaging List
Specification
Dimensions Wireless Connection
266(L) x 170(W) x 9.7(H)mm Wi-Fi 802.11 b/g/n,Bluetooth
Display I/O Ports
10.1" 1280×800 (IPS) Display Micro USB / Microphone / Earphone / Micro SD
Processor GPU
1.0GHz,Cortex-A7 Quad Core SGX 544MP2
System Memory Speaker
oerets2xW7.03RDDBG2
Storage Capacity Build-in Sensor
rosneSepocsoryG,rosneSthgiL,rosneSGBG61
Storage Extension Location
Micro SD card (able to be extended to 32G) Assisted GPS & GLONASS
Operation System Battery Capacity
hAm00072.2.4diordnA

Front Camera Weight
g085M0.2
Back Camera Frame Material
muisengaMmunimulAM0.5
Images Accessories
Support JPEG , PNG ,BMP ,GIF Adapter, USB Cable, Product Instruction，
Warranty Card,Quick Start Guide.
Video
Support HD Video,H.264,WEBM,VP8,VC-1,MPEG4,H.263,MPEG2
Audio
SupportAAC-LC,ACC,AAC+,eAAC+, MP3,WAVE,AMR-NB,AMR-WB
- 2 -

- 3 -
Packaging List
InFocus Tablet
USB Cable PowerAdapter Product Instruction
Quick Start Guide
Warranty Card
s cPlea e
Quick Start Guide
New Tab F1
arefully read Safety Warning and Precautionsof the product instructions beforeinitial using.

- 4 -
2.Get to Know Your Product
Side View Back View
Microphone
Light Sensor
Front Camera
Volume +/- Button
Power Button
Speaker
Back Camera
Speaker
TF Micro SD Card Slot
Micro USB Port
3.5mm Earphone Jack

3.Power On/Off
3.Power On/Off
Power On
Make sure your tablet is either with adequate power or correctly connected to power
supply before booting.Press and hold on the Power Button to connect power supply and
start it up. Your tablet is successfully powered if there appear InFocus logo and booting
animation on the screen as shown below:
- 5 -

If you don’t need to use your tablet temporarily, please slightly press the upper right
side of the Power Button to change the tablet into standby mode for energy saving.
If your tablet is under standby mode, please slightly press the upper right side of the
Power Button to wake the screen and get it back to the usable state.
Power Off
Please press and hold on the Power Button, select and click on “power off” in the popped
up dialog box, and click “OK” to turn off the tablet.
- 6 -

4.Charge the Battery
Your tablet must be charged before initial using. Please connect one end of the USB cable
to the power adapter, another end to the Micro USB port, and then plug the adapter into
an electronic outlet. To prevent the battery from aging due to overcharge, please unplug
the adapter when there is a notice showing the tablet is fully charged on the screen. See
below diagram:
Please use the power adapter supplied with your tablet.
- 7 -

5.Lock and Unlock Screen
Lock Screen
Press “Power Button” to turn off and lock the screen when the tablet is on; if the tablet is
left idle longer than the set inactive interval, the screen will be automatically locked.
When the tablet is left idle or the screen needs to be cleaned, turning off or locking
the screen can not only save energy but also prevent accidental operation.
Set Screen Timeout Interval
Enter ”Settings>Display>Screen timeout” to set the interval. When the tablet is left idle
longer than the set inactive interval, the screen will automatically enter into standby and
locked mode.
Unlock Screen
Press Power Button to light the screen and unlock it according to the pre-set unlock
pattern, and return tothe page you quit last time from the standby and locked mode.
- 8 -
Please make one side with USB logo down when connect the Micro USB port to the tablet.

6.Set Date and Time
When your tablet is accessible to internet, the default date and time are from the internet.
You can enter “Settings>Date and time” toset it.
If you often travel or your residential zone adopts Daylight Saving Time (DST), and
your tablet can get access to the internet, please inactive “Automatically set date and
time” in this menu, then your tablet will automatically set date and time according to
the information from internet.
7.Touch Panel Operation
- 9 -
Scroll right/left Scroll up/down Zoom out Zoom in Click

8.Wireless Network
Your tablet can be connected to Wi-Fi and Bluetooth.
Manage Wi-Fi Connection
If the tablet is not connected to Wi-Fi network, please enter “Settings> Wireless and
network>Wi-Fi” toset Wi-Fi connection.
If Wi-Fi is off, please click Wi-Fi icon to turn it on. After the tablet scans and detects the
ambient wireless networks, click your network and input your security pin (if you have set
it) to connect Wi-Fi.
Please turn off Wi-Fi function when you don’t need it to extend the battery life.
Manage Bluetooth
Please enter “Settings>Wireless and network>Bluetooth”, click it to search and scan
ambient applicable Bluetooth equipment.
- 10 -

9.Applications Overview
Applications installed in the tablet are shown on the homepage. Based on the source of
applications, they can be classified into two different types: one is originally included in the
tablet, another is downloaded from Play Market.
Applications are sorted by the sequence of installation. If you have more applications,
they will be automatically sorted to the next page. If you think some applications are
frequently used, you can press and hold on the particular application icons to move
to anywhere you’d like to. Some applications are shown as below:
- 11 -
Chrome Play store Maps Google+ Google Keep Play Books YouTube Play Movien
Play Magezines Play Music Hangouts Gmail Messenger Navigation Local Calendar
them

Download Applications
You can download various additional programs and applications on Play Market on
the homepage to enhance the function of your tablet. When you use Play Market for the
first time, you need to read and accept “Terms of Service” firstly and then you can either
browse the Market according tothe classifications or click the Search icon to search for the
undetermined application.
After selecting the application, click the Download icon to download and install it. In the
meantime, the system will remind you that what kind of services (e.g. contact information,
wireless access, GPS, etc.) will be needed to keep the application running smoothly. If
above services can be normally applied, click “Confirm” to install it.
Uninstall Applications
Browser
You can use your browser to view web pages and search for information and data on
the internet. Click to enter the browser page, and then click the input box, type in the
website using the popped up soft keyboard, and click to get into the web page.
Please make sure your tablet is connected to wireless network before using.
- 12 -
Go
If you don’t need some applications, you can uninstall them as following: Enter “Settings>
Applications>Downloaded”, click the application you are going to uninstall, slightly click “
Uninstall”, and finally click “Confirm” to uninstall it.

E-mail
You can receive/send and display your e-mail by linking directly to your internet email
account.
Gallery
Gallery supports display and edit of photos and videos, and you can find all the pictures
and videos you took. It also supports a slideshow function and other playback operations.
Camera
Click on the application interface to enter the preview interface with the view you are
taking on the screen.
Take a photo: Under the photo-taking preview interface, click icon to quickly take a
photo.
Shoot a video: Switch the photo-taking interface to video shooting interface, click icon
to start and click to stop it.
Calculator
Click on the application interface to easily open your calculator.
- 13 -

10.Connect to the Computer
Connect one end of the USB cable to the USB port of the tablet, and another end to that
of the computer. After a short delay, all the files in the tablet can be accessible through the
computer.
11.Get More Help
If you’d like to get more help on the tablet instructions, you may visit InFocus’ website
www.infocus.com.cn for more user guides and skills. You can also leave messages to us
on the website, and our technicians will answer you at the first time.
12.Personal Information and Data Security
To avoid personal information and data leaks or loss due to improper operation or other
reasons, please carefully read below contents and enforce your personal information
protection as suggested below:
•Please put the tablet in a safe area when not using it to prevent unauthorized using of
it.
•Please set screen-lock on your tablet and the unlock code or pattern should not be too
simple.
- 14 -

• Do not open and read the undetermined e-mails or information from strangers to avoid
computer viruses attack.
• Try not to visit the website with potential security risk when you are surfing on the
internet to avoid personal information theft and viruses attack.
• Install antivirus software to regularly watch the security of the tablet, and immediately
activate the software to restore the tablet when there is viruses attack.
• Set a password when using such functions as wireless sharing, Bluetooth, etc to avoid
unauthorized access, and turn off these functions as soon as you don’t need them.
• When downloading the third-party applications, clearly get the pattern security, and
scan the viruses before downloading to make sure the application is safe to download.
• Please install or upgrade the security software or patch from InFocus or the third party.
• The tablet may feedback the detection or diagnosis information to InFocus to help
InFocus improve its product and service.
• When the tablet needs to be repaired, please backup your personal information or data
in it, and delete your personal private information and important files to avoid unilateral
access and theft.
If you have questions or problems on personal information and date security, please
immediately contact our customer service central or leave message on our website:
www.infocus.com.cn.
www.infocus.com.cn.
