Infra-Slim BODY SHAPING SYSTEM Simple manual

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
Dear Customer,
Many thanks for purchasing our product,please kindly read the manual
instructions carefully and operate the system in the correct way.

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
2
Working Principle
This system combines functions of Far-infrared ray heating and Airpressure
massage therapy.Airpressure therapy is also called pressotherapy that aims to
massage the whole body so that to promote blood circulation、eliminate body muscle
tiredness 、 tighten skin and improve body metabolism.Far infrared heating further
helps speeding up body discharges sweat so that to get rid of toxins,quickly burns
redundant fatness/cellulite.Both combination, it can achieve the effects of weight
loss、body contouring and health-keeping.
Main Effects
Lymphatic drainage.
Burning fat to lose weight.
Contouring body and keeping fit.
Perspiration detoxification,discharge heavy metals along with sweat,promote
the metabolism.
Relieve rheumatism and cold,unclog the meridian,reducing body fatigue and
relieving stress.
Activate,purificate and optimize the blood cells and body tissues,improve body
immunity.
Stimulate body circulation system, promote blood circulation, strengthen and
cultivate Viscera.
Enhancing medication/nutrition lead-in and obsorption.

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
3
Panel Introduction
1.TIMER
2,3.TIME UP/DOWN
4.AirPressure INTENSITY
5.INTENSITY select
6.Airpressure ON/OFF
7.Massage PARTS
8.PARTS select
9.MODE select
10.Massage Mode
11,12.Temp. UP/DOWN
13.Infra ON/OFF
14.Temperature Display
15.Infra select
16.LEGS Infrared
17.WAIST Infrared
18.ARMS Infrared

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
4
Outlets Introduction
1.Airpressure outlet
2.ARM Infrared output
3.WAIST Infrared output
4.LEGS Infrared output
Operation Steps Of AIRPRESSURE
Step 1: Connect the airpipes to the machine and costume.
Step 2: Connect the power cord,then press power switch to start the machine.
Step 3: Set the TIME using ▲and▼arrows.
When the controller is turned on, the default time is 30 minutes.
The maximum adjustable time is 90 minutes.
The recommended time for each use is 35-40 minutes.
It is recommended to use it every other day.
Step 4: Choose the PARTS:
Choose 1LEGS and FEET are massaged.

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
5
Choose 2WAIST is massaged.
Choose 3ARMS are massaged.
Choose 4LEGS、WAIST and ARMS are massaged circularly.
Step 5: Choose the MODE
Choose 1-The airpressure squeezes 2 seconds,then relieves 1 second.
Choose 2-The airpressure squeezes 4 seconds,then relieves 1 second.
Choose 3-The airpressure squeezes 6 seconds,then relieves 1 second.
Choose 4-The airpressure squeezes 8 seconds,then relieves 1 second.
Choose 5-The airpressure squeezes 10 seconds,then relieves 1 second.
Choose 6-The airpressure squeezes 12 seconds,then relieves 1 second.
Step 6: Choose the INTENSITY
There are 1-7 levels for selection.
Step7: Press ON/OFF,the airpressure begins to work.
Step 8: Press ON/OFF again,the airpressure is paused.

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
6
Operation Steps Of Infrared-Heat
1. Connect the costume to the controller.
If shows EO on the controller,it means the wrong connection, temperature can
not be set.
2. Set TIME using the▲and▼arrows.
When the controller is turned on, the default time is 30 minutes.
The maximum adjustable time is 90 minutes.
The recommended time for each use is 35-40 minutes.
It is recommended to use it every other day.
3. Press INFRAR SELECT, the indicator lamp of AMRS is on,quickly set the temperature.
The recommended temperature for ARMS is 55℃-60℃.
4. Press ON/OFF，the infrared-heat of arms begins to work.
Press again ON/OFF, the infrared-heat of arms is paused.
5. Press INFRAR SELECT,the indicator lamp of waist is on, quickly set the temperature.
The recommended temperature for WAIST is 60℃-65℃.
6. Press ON/OFF，the infrared-heat of waist begins to work.
Press again ON/OFF, the infrared-heat of waist is paused.
7. Press INFRAR SELECT,the indicator lamp of legs is on, quickly set the temperature.
The recommended temperature for LEGS is 65℃-70℃.
8. Press ON/OFF，the infrared heat of lges begins to work.
Press again ON/OFF, the infrared heat of legs is paused.
9. After making above operations,temperature of each part is going up,slowly you can
feel the heat.

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
7
10. Turn off the power when stop using the system ,pull off the accessories and store
the product well.
Operational Considerations
Do not use the system in places with strong static and magnetic fields.
Do not contact with rain or liquid.
Must be well grounded before use in case of lightning strike.
Do not pull out the power cord or other wires as the machine is power on.
Before doing therapy, customers must take down the sharp objects,
which would probably puncture the costume and cause seriouse consequences.
Stop using the system once the costume cracks to avoid the danger of electric
shock.
Non-company professionals shall not dismantle the machine for maintenance
or attempt to modify the mechanical or electronic properties of the product.
Forbidden Crowd
Pregnant women.
Women have not completely recovered from childbirth.
Women with menstruation.
The persons with high blood pressure.
The persons with heart disease and serious diabetes.
The persons with serious skin diseases.
The persons with metal rack inside the body.
Minors are prohibited from using it.
Do not use in patients with internal injury.

Infra-Slim BODY SHAPING SYSTEM Manual Instrucitons
8
Technical Parameter
Voltage Supply
AC220V-240V/50Hz
OR
AC100-110v/60Hz
Power Supply
600W
Max Time
90 minutes
Temperature Range
35°C to 80°C,optional
AirPressure INTENSITY
1-7 levels,adjustable
Massage PARTS
LEGS、FEET、WAIST、ARMS
Massage Mode
1，2，3，4，5，6
Gross Weight
14.0KGS(All accessories included)
Packing Dimension
56CM(L)x37CM(W)x37CM(H)
Packing List
Item Name
Quantity
Remarks
Controller
1 (set)
Costume
1 (piece)
One-piece
AirPipes
1 (set)
Power Cord
1 (piece)
Spare Fuse
2 (piece)
English Manual Instructions
1 (copy)
