Nicefeel FC2520 Series User manual

After-sales Service
Thank you for purchasing Nicefeel oral irrigator.
Please read the following precautions:
Warranty Record
Customer name Tel
Product model
Maintenance date
Mailing address
Date of purchase
Product color
Where the product is
purchased (seller)
1. Please ask the seller for a valid sales document as the basis
for the warranty when purchasing the oral irrigator.
2. The product is covered by free maintenance for failure due to
non-human factors within one year according to relevant state
regulations (subject to the date on the purchase invoice date);
3: Costs and service fees will be charged as appropriate during
the warranty period in the following cases:
(1). Damage caused by improper use, maintenance and
storage by the consumers;
(2). Damage caused by dismantling of unauthorized repairer;
(3). No relevant sales document and it has been over one year
after the production date;
(4). Damage caused by commercial use;
(5). Damage caused by force majeure (earthquakes, fires, etc.).
4. Please fill in the form below with care, and send it together
with the product to be repaired to the service site designated by
the manufacturer.
Shenzhen Fly Cat Electric Appliance Co., Ltd.
Address: Building 4, Xianyuxing Industrial Park, Gonghe Community,
Shajing Street, Baoan District, Shenzhen, China
Tel: [phone]
Fax: 0755-272733465
Website: www.fly-cat.com.cn
Oral Irrigator
FC2520 Series
Instruction Manual
P

Important Safety Precautions
Please keep this User Manual!
Please read all the outlined instructions before using
Dangers
To reduce the risk of electric shock, please pay attention to the
following items:
·DO NOT handle the charger with wet hands.
·DO NOT immerse the product in water or any other liquid.
·DO NOT use the product while taking a bath.
·DO NOT place or store the product in a place where it may fall into
the bathtub, shower or sink.
·DO NOT pick up the product falling into the water immediately, make
sure it is unplugged immediately before taking any other action.
·Check whether the adaptor is damaged before using the product for
the first time after purchase.
In order to reduce the risk of ambustion, electric shock,
fire, serious injury or damage:
·DO NOT plug the product into an adapter that does not meet the
specified voltage.
·DO NOT use the product if the cable or plug is broken. If it does not work
normally or is immersed in any liquid, please contact your local dealer.
·DO NOT lead the water flow under your tongue, or into your ear, nose or
other minor organs. This product is capable of producing pressure that
may cause serious damage to these organs. Please refer to the operating
instructions for proper use.
·Please follow the instructions or recommendations from dental profes-
sionals when using the product.
·A small amount of bleeding is normal when using the product for the first
time. If the bleeding is serious, stop using and ask your dentist for advice.
·Fill the reservoir with water or other solutions recommended by the
dental professionals.
·DO NOT drop or insert any foreign objects into the product.
·Keep chargers and wires away from hot surfaces.
·DO NOT operate the product in places where oxygen or aerosol sprays
are used.
·DO NOT use mouthwash or rinse solution containing iodine or disinfec-
tant.
·DO NOT use the product when wearing dental accessories, which should
be remove before use.
·DO NOT use the product if there is an open wound on the tongue or in
the mouth.
·If your doctor recommends you to take antibiotics before surgery, please
consult a dentist before using the product or any other oral hygiene
adjuvant.
·For household use only. DO NOT use the product outdoor.
·Children and individuals with special needs should be closely guided and
supervised for using the product properly.
·Children should be supervised to ensure proper use of the product.
1 2
Basic safety precautions should be followed when using electrical
products, especially when there are children in the house.

3 4
Traditional toothbrushes cannot
remove food debris and harmful
bacteria hiding deeply.
Remove harmful bacteria
hiding deep in the crevices
between teeth and below the
gum line.
They can only reach a limited
part below the gum line.
Traditional oral care:
Nicefeel Oral Irrigator
Thank you for purchasing our Oral Irrigator!！ Table of Content
Thank you for purchasing our oral irrigator!
Welcome to use Nicefeel oral irrigator, which will give you healthier teeth
and brighter smile!
Cleaning teeth with pulse water flow, the oral irrigator can remove harmful
bacteria hidden deep in the crevices between teeth and below the gum
line, where cannot be cleaned by brushing teeth only.
The Company reserves the right of final interpretation for any error in or
misunderstanding of the content of this User Manual; any product or
data update will be incorporated into the new version without prior
notice; and in case of any change in the appearance and color of the
product, the product inside the package shall prevail.
Important Safety Precautions--------------------------------1
Contents----------------------------------------------- 4
Product Structure---------------------------------------- 5
Function nozzle------------------------------------------6
Using Instruction for Product--------------------------------7
Using Instruction for Professional Nozzles---------------------11
Cleaning and Maintenance-------------------------------- 13
Common Failures and Handling Methods----------------------14

56
Product Structure
Ordinary high-
pressure nozzle Periodontal
pocket nozzle
Dental plaque
nozzle Orthodontic brush Tongue Cleaner
* Ordinary high-pressure nozzle: comprising three colored rings for
three persons. (Family Pack)
* For the using instructions of other four special nozzles (tongue
scraper, periodontal pocket nozzle, orthodontic brush and dental
plaque nozzle), please refer to pages 11-12 of the Manual.
Gum bleeding is normal due to different tolerance when using the
water flosser for the first time. Please feel free to use!
1. Nozzle combination 2. Water tank (hidden) 3. Remotely controlled handle
4.
Body 5. Base 6. Base suction cup
7. key 8.
Gear display 9. Turn-down button
10.
Turn-up button 11. On/off and pause button 12. Nozzle removal button
13.
360° rotating nozzle

7 8
Plug the wire into the socket. If the socket is controlled by a wall switch,
make sure the switch is turned on. The on/off and pause buttons and two
gear buttons are in the front of the product handle, and the latter (pause
button) can remotely control the gear so as to control the water pressure.
After the power is connected, a small display screen on the left side of
the device’s body will display ‘P (Pause)’.Press the On/Off button to turn
on, and gears 01-10 will be displayed on the screen, from which you can
choose one to control the water pressure during use. A timing of 3 minutes
is set between turning-on and off (Note: You need to press the On/off
button again to operate the product after it is turned off by timing).
Remove the water tank cap from the
top of the device. After filling the
tank with warm water, put the cap
back and press it firmly. The water
tank is hidden inside the body, on
the right side of which there is a long
window where you can clearly see
the water level inside the water tank.
The surface of the large body is
marked with capacity in ounces and
milliliters.
Using Instruction
Insert the nozzle into the middle of the knob at the top of the handle of the
water flosser. If the nozzle is locked in place, the colored ring shall be flush
with the end of the knob. To remove the brush from the handle, please
press the nozzle eject button and pull the nozzle out of the handle.
When using the product for the first time,
please adjust the pressure gear on the
handle of the product to the minimum value
(the gear displayed on the body can be
adjusted in gears 01-10). Start from the
lowest gear, turn on the switch on the
handle, and gradually increase the pressure
after the oral cavity adapts to it. You can
also increase the pressure under the
guidance of a professional dentist.
Insert and remove the nozzle
Adjust pressure settings
Preparing water tank
P
P

P
910
Lean over the sink and place the injector head into the mouth. Align the
nozzle to your teeth. Turn on the pushing switch on the handle to adjust
the water pressure to the desired value. Control the direction of water flow
by turning the knob on the top of the handle.
Using Oral Irrigator
Adjust the water jet flow to 90
degree to the gum line. Close your
lips to prevent the water from
flowing sideways while allowing the
water in your mouth to flow freely
into the sink. For best effect, start
cleaning from the molar teeth (back
teeth) towards the front teeth. Slide
the injector head along the gum line
with short pauses between teeth. DO
NOT stop until the areas around the
gums and among the teeth are
cleaned.
Use Tips
You can turn off the ON/OFF button on the handle of the oral irrigator
at any time and put the handle back on the body to temporarily stop the
water flow.
Pause control
Turn off the product, pour off the liquid left in the tank, and pull off the
plug. When the device is turned on again, it will restore the gear before
turning off based on the memory of the main body.
After using
On/off and pause button
P

11 12
Using Instruction for Nozzles
High-pressure nozzle
Rinses deep into the mouth thoroughly
to clean the parts hard to be cleaned
with toothbrush. More effective than
floss and making the gums healthier.
Periodontal pocket brush
Tongue Cleaner
The periodontal pocket brush can inject
water or antibacterial fluid into specific
parts below the gum line. When using the
periodontal pocket brush, please lean
over the wash basin, place the soft brush
head against the teeth at an angle of 45
degrees, and gently place the brush head
into the teeth socket below the gum line.
Turn on the device and minimize the
pressure, gently place the brush on the
crevice between teeth, and then clean it
along the direction of the gum line.
Continue to move along the gum line
until the flushing is completed.
Lean over the wash basin. Place the
tongue cleaner on the tongue and start the
oral irrigator: use the lowest pressure first
and then increase the pressure based on
the degree of comfort. Gently place the
tongue cleaner in the middle of the back
part of the tongue and gently pull it to the
front against the tongue.
Orthodontic nozzle
The special orthodontic nozzle is designed to wipe and rinse the areas
hard for braces and other dental appliances to reach. When using the
orthodontic nozzle, lean over the wash basin to wash your teeth with the
nozzle, and water flow will take the debris away.
Dental plaque nozzle
Align the water with the gums at an angle of 90 degrees and slightly
close your lips to prevent water from splashing while allowing the water
to flow out from the corners of the mouth to the wash basin. Start
flushing from the molar teeth (back teeth) and gradually to the front
teeth. The nozzle shall be close enough to the teeth so that the bristles
can gently touch the teeth. Gently move the nozzle along the gums with
a short pause between two teeth to allow the water to pass between the
teeth. Repeat the same procedure on each side of the teeth until all the
part between the teeth as well as the front, back, top and bottom of the
teeth are cleaned.

Cleaning: Common Failures and Handling Methods
Maintenance
Replace handle battery
Leakage between the
nozzle or the tongue
cleaner and the handle knob
Cracking of periodontal
pocket brush
The brush is seriously
worn Replace a new brush
Pressure is not enough
Device cannot start Motor does not run
Confirm whether there is
power input, or contact the
seller for repair
Buttons on the handle
cannot be used
Check whether the
battery fails or is
assembled incorrectly
Assemble or replace a
new battery
We guarantee that this product is free of defects in materials and
processes, and the warranty period is one year from the date of
purchase. Please keep your receipt as proof of the date of purchase. If
the product is not abused, misused, altered or damaged after purchase
but used in accordance with the User Instruction, we will replace any
defective part(s) of the product at our sole discretion. This Limited
Warranty does not cover the attachments such as standard nozzles,
tongue scrapers, periodontal pocket brushes, orthodontic nozzles or
dental plaque nozzles. This warranty gives the user a clear legal rights,
and you may also have other appropriate rights depending on country of
residence.
Thank you again for purchasing Nicefeel Oral Irrigator!
Improper installation
of the water tank
Reinstall the water tank
and press on the water
tank firmly
Leakage on the hose
connecting the base to the
handle of the oral irrigator
Hose damage
Replace it by yourself
or contact dealer for
after sale service
Water tank leaking
The spring is not
installed or is installed
at incorrect position
Install the spring in the
correct position, or contact
the dealer for repair
The brush does not fit
well with the handle
Remove the brush and
insert it well
If any special solution is used in the water tank, please rinse the device
properly. Fill some warm water into the water tank.
Point the nozzle toward the wash basin. Turn on the device and do not
stop it until the water tank is empty. This will help to prevent blockage of
the nozzle and extend the service life of the device.
Clean the product with a soft cloth and a mild non-abrasive cleaner
should be used when needed.
Be sure to pull off the plug from the power socket before cleaning.
Remove the water tank and run the oral irrigator till there is no residue left.
1、Each time after using, be sure to pull off the power plug and place the water
tank upside down on a flat surface. After the water has been completely drained
and wiped dry, place the water tank in a cool and dry place together with the
cleaned main body. When not in use for a long time, the product shall be stored
in a packing box or a carton with a similar storage function.
2、In case of machine failure, you can consult with the seller or call the Company
to inquire about the repair method.
3、Do not disassemble or attempt to dissolve the product by yourself, as the
damage caused by such behavior is not covered by the Company's warranty.
4、When the power cord is damaged, please go to the maintenance place
designated by the Company or the repair shop with relevant qualification for
repair. DO NOT replace the power cord or plug by yourself.
5、 If the warranty period expires, the company will still provide relevant service,
with appropriate material cost and labor fees charged.
If the battery requires replacement, use
the key to align the locking hole on the
bottom of the handle, and then turn it.
The battery in the handle pops out. Each
time you change the battery, the
pressure is the same as the last time. If
it is not used for a long time, remove the
battery if the battery fluid damages the
handle.
13 14
Phenomenon Reason Handling Method
