Inge SIGMA FSL LED D/I DALI LS/PD User manual

SIGMA FSL LED D/I DALI LS/PD
SIGMA FSL LED D/I DALI LS/PD
INSTALLATION INSTRUCTION

SIGMA FSL LED D/I DALI LS/PD
1 2
3 4 5
68
a
b
b
c
7
INSERT THE
CONNECTOR INTO
THE POLE
CONNECT THE POWER
SUPPLY CONNECTOR
FIX THE BASE TO THE POLE
WITH TWO SCREWS REMOVE THE COVER
PLUG INTO A SOCKET
USE ALLEN KEY
5mm
USE ALLEN KEY
5mm
DO NOT TOUCH
THE LEDBOARDS
IF NECESSARY ADJUST HORIZONTAL
POSITION OF THE HEAD PUT THE UPPER COVER BACK

SIGMA FSL LED D/I DALI LS/PD
PUSH
BUTTON
flashes
LUMINAIRE CONTROLS AND SETTINGS
910
SENSOR
BUTTON
11

SIGMA FSL LED D/I DALI LS/PD
Caution:
- the luminaire is intended for indoor use with normal ambient temperature 25°C only
- the power cable must be connected inside the terminal block in the luminaire only
- do not place any cables or wires on the top of the luminaire
- the luminaire can not be covered by any insulating material
- the mains voltage must comply with standard values 230V/50Hz
never be disconnected!
- please follow the instructions of manufacturers of electronic ballasts such as www.osram.cz
For the luminaire we provide standard quarantee of 24 months and for lighting sources LED we provide 24 months unless
the period mentioned above.
DATE OF MANUFACTURE:
DATE OF SALE:
SHOP STAMP, SIGNATURE:
Conditions for the provision of warranty repairs:
1) In compliance of the common use, operation and maintenance of the product, we
guarantee that the product will have during the entire warranty period features and
characteristics as issued by standard technical norms and conditions.
2) If during the guarantee period defect occurs, which was not caused by the user, the product will be repaired free of
charge if it is not agreed otherwise.
buyer.
4) Warranty period is extended of the time during which the product was repaired.
7) For more information please visit www.inge.cz – General delivery Terms and Conditions.
