Injoy – STREET RACING STARS MDX
OPERATOR Service Manual
1. INTRODUCTION ......................................................................................3
2. SPECIFICATIONS.....................................................................................4
2.1 INJOY–STREETRACINGSTARS MDX MOTION BASE..................4
3. INSTALLATION........................................................................................5
3.1 SERVICE KIT.........................................................................................5
3.2 SETUPINSTRUCTIONS...................................................................... 5
3.2.1 PRE-INSTALL PREREQUISITES/CAUTIONS .......................5
3.2.2 INSTALLSIDE STEPS.................................................................6
3.2.3 INSTALLHEAD LAMP...............................................................8
3.2.4 SET COIN ACCEPTOR ...............................................................9
3.2.5 DEBIT CARD INSTALL ............................................................ 11
3.2.6 POWER INPUT...........................................................................12
4. GAME INTRODUCTION AND SETTING ..........................................13
4.1 GAME SETTING(OPERATOR MENU)...........................................13
4.1.1 COIN OPTIONS..........................................................................14
4.1.2 GAME OPTIONS........................................................................15
4.1.3 PEDAL SETTING .......................................................................16
4.1.4 LANGUAGE SETTING..............................................................18
4.1.5 SYSTEM TIME SETTING.........................................................18
4.1.6 VOLUME SETTING...................................................................19
4.1.7 DEVICE TEST.............................................................................19
4.1.8 SOFTWARE UPGRADE ............................................................20
4.1.9 STATISTIC...................................................................................24
4.1.10 SAVE & EXIT ............................................................................25
4.2 GAME INTRODUCTION.................................................................... 26
4.2.1 GAME CONTROL......................................................................26
5. MAINTENANCE......................................................................................27
5.1 CHASSIS ELECTRONIC COMPONENTS ......................................27
5.2 CABINETELECTRONIC COMPONENTS ..................................... 28
5.3 COCKPITELECTRONIC COMPONENTS..................................... 29
5.4 MAINTENANCE.................................................................................. 30
6. TROUBLE SHOOTING..........................................................................31
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
3
1. INTRODUCTION
Thank you for purchasing the Injoy-STREET RACING STARS MDX “@Motion
System” developed by Injoy that are well distributed in many markets and territories. This
manual will guide you through the set-up and operation of Injoy- STREET RACING STARS
MDX, an ultimate game motion system for arcade environments. This unit is different from
any other machines of its kind you have ever owned. A fully interactive coin- and swipe
card-operated motion simulator, Injoy- STREET RACING STARS MDX creates a virtual
reality environment and provides a truly unique game experience for players. Capable of any
motion through 2.0 degrees of freedom (also known as D.O.F.) movement (pitch and roll), this
system enables realistic simulation needed for any software program. Rather than pneumatic or
hydraulic actuators that require much more maintenance and have been used to power most
motion simulators in the past, Injoy- STREET RACING STARS MDX is powered by electric
motors and with IMON’s patented design, a powerful, mini-motion based platform with
physics-based motion dynamics, known as the Hex-Glider. Players will experience realism to
an extent that they can “feel” all the exciting actions in a synchronized way as they indulge in
the game.
IMON/Injoy is devoted to offer you the most advanced cost-economical and rewarding
motion arcade system available. You are welcome to contact us for any questions you may
have or for any service we can be of.
Asia-Pacific
Address: No.6-1, Datong St., Tucheng City, Taipei County 236, Taiwan, R.O.C.
Telephone: [phone]
Fax: [phone]
E-mail: [e-mail]
Technical Support: [phone] Ext. 283
E-mail: [e-mail] or [e-mail]
Website: www.imon.com.tw, www.injoymotion.com
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
4
2. SPECIFICATIONS
An Injoy- STREET RACING STARS MDX includes a complete Motion Base.
The dimensions given below are Injoy–STREET RACING STARS MDX’s installed footprint.
Injoy–STREET RACING STARS MDX @Motion System Unit
US & GB: 86.62” x 53.94”
Minimum Installed Footprint Metric: 2.20cm x 1.37cm
2.1 INJOY–STREET RACING STARS MDX MOTION BASE
Injoy–STREET RACING STARS MDX Motion Base Simulator
No Item Specification
1 Installed Dimensions / Weight
(LxWxH)
z86.62” x 53.94” x 87.42”
z220cm x 137cm x 222cm
2 Motion system z2.0 degree motion (D.O.F.) mini-motion
based: AC powered, Motor Driven Actuators
3 Control inputs/feedback
zSteering Wheel
zGear
zFuel Pedal / Brake Pedal
zYellow Button for Start / Turbo
zRed Button for View
zMotion Stop Switch
4 Player Weight Limit z150 kgs
5 Center of Gravity zDirectly over 2 axis
6 Motors z3Φ220VAC x 2 motors
7 Power Requirements – Plugs located
at the bottom of the motion base
behind the monitor.
zPower requirements in USA: 110 VAC, 24.6
Amps, 50/60 Hz (Transformer needed)
zPower requirements in EURO: 220 VAC, 12.3
Amps, 50/60 Hz.
8 Max Watt Consumed
Rated Watt Consumed
z1707 W
z1365 W
9 Audio
z30 watts Speakers x 2, 4 ohm
z1 Sub-Woofer
z2 Super Sub-Woofer under seat
10 Monitor z42” LCD Monitor
z15 pin DB Connection
11 Computer System zWindows Embedded Operating System
zHigh Resolution Graphics Accelerator Card.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
5
3. INSTALLATION
3.1 SERVICE KIT
The following items should be included with the shipment of your Injoy–STREET
RACING STARS MDX:
Service Kit
Description Qty
Injoy–STREET RACING STARS MDX Service Manual 1
Maintenance Box Key 1
Coin Box Key 1
Special Wrench 1
3.2 SET UP INSTRUCTIONS
3.2.1 PRE-INSTALL PREREQUISITES/CAUTIONS
Injoy–STREET RACING STARS MDX is designed for indoor use only. To ensure
trouble-free and safe operation, the following conditions are recommended:
1. The motion system must be located out of direct exposure to sunlight, high humidity,
dust, salt mist, high heat, or extreme cold. If installed in an extremely hot location,
allow additional clearance between ventilation slots in the game and any structure or
object that would tend to restrict air circulation.
2. The motion system produces tremendous forces onto the motion base, which may be
moved around on the floor if not properly installed. Before placing STREET RACING
STARS MDX motion system on the ground, make sure the floor space is flat and before
operating the game, make sure the brackets are tightly installed. If you have questions
regarding any installation requirements, .contact our tech support ([phone]
Ext. 283 or E-mail: [email protected].tw) at Injoy before proceeding.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
6
3.2.2 INSTALL SIDE STEPS
Please follow the steps to install Side Step.
Step Description & Diagram
Adjust unit stands by hex wrench to make sure STREET RACING START MDX
motion system is placed flat on the ground and the brackets are tightly installed.
2
Place the two side steps and the back lamp near the base, and then connect Light
connectors.
3
Find the two connectors: one is located under the motion base in the front right hand
side. The other connector is located in the right side of the side step(under coin box).
Then connect them.
4
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
7
Push the two side steps and the back lamp close to the base, and then fix them by L
type plate
5
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
8
3.2.3 INSTALL HEAD LAMP
Please follow the steps to install the Head Lamp.
Note: Be careful when installing the Acrylic Sheet. Don’t damage it.
Step Description & Diagram
Connect the power connectors of the Head Lamp as shown in the Figure below.
1
Place the Head Lamp on top of the LCD screen, and then fasten it with fixing as
shown in Figure A and Figure B
2
Figure A
Figure B
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
9
Place the Acrylic Sheet on the Light Box, and then fasten it with four fixing screws.
3
3.2.4 SET COIN ACCEPTOR
Please follow the steps to set-up the coin acceptor.
Step Description & Diagram
Pull up the slider of the coin acceptor1
Insert the coin into the coin acceptor.2
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
10
Push down the slider to fix the coin acceptor.3
The coin acceptor is set up then, and can take the coin you want.4
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
11
3.2.5 DEBIT CARD INSTALL
Figure 4 below illustrates the connection of the debit card reader if it or other device
needs to install.
Steps Description & Diagram
Find “Coin 1” connector located inside the Coin Box1
Follow the signal connection as shown in below the Figure to install.2
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
12
3.2.6 POWER INPUT
STREET RACING STARS MDX has a single power cord. The motion base requires one
dedicated (25-Amp) circuit for (1Φ210~230VAC) power source. NEUT to GND voltage
should be less than 1 VAC.
MAIN AC POWER PLUG
NEUT
GND LINE
Note: 1. AC Power Wire Diameter must be greater then 2.0mm
2. No other appliance or game should share this power source on
this circuit, otherwise STREET RACING STARS MDX will
break down.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
13
4. GAME INTRODUCTIONAND SETTING
4.1 GAME SETTING (OPERATOR MENU)
To access OPERATOR MENU, after the Power is switched ON and the screen shows
“insert coin”, find the OPERATOR SWITCH located inside the coin box door, move it to
“ON” position (Figure 4-1), and continue in the OPERATOR MENU (Figure 4-2).
Figure 4-1 Operator Switch
From the OPERATOR MENU, you have direct access to game and operator settings.
From sub-menus (listed below), you have access to general game control settings. The
definitions of the Operator Menu and its sub-menu are detailed below:
Figure 4-2 Operator Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
14
4.1.1 COIN OPTIONS
The “Coin Options” sub-menu allows you to set all coin options on your Injoy- STREET
RACING STARS MDX (Figure 4-3).
1. “Coins per Play” allows you to set how many coins it will take for a player to start a
game. The factory default setting value is 4 coins per play.
2. “Coins per Continue”allows you to charge a different price for continue-play from the
first game play. The factory default setting value is 4 coins per play.
3. “Currency Type” is not to select the currency of a country, but allows selection of the
forms of currency i.e. coins or bills you wish your Injoy- STREET RACING STARS
MDX accepts. The factory default setting is Coin (combined into one setting) and
another setting is the Bill Acceptor or Debit Cards. The coin acceptor is an industrial
standard product.
4. “Coins per Pulse (Coin Acceptor 1) (Figure 4-4)” allows you to adapt different
currency acceptors that are pulse specific to your Injoy- STREET RACING STARS
MDX. The default value is 1.
5. “Coins per Pulse (Coin Acceptor 2) (Figure 4-4)” allows you to adapt different
currency acceptors that are pulse specific to your Injoy- STREET RACING STARS
MDX. The default value is 1.
6. “Winner Continue” allows you to set up “insert coin to continue or free to continue” if
Winner wants to continue game. This setup is for the single player mode.
7. “Winner Continue (Net)” allows you to set up “insert coin to continue or free to
continue” if Winner wants to continue game. This setup is for the single player mode.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
15
Figure 4-3 “Coin Options”sub-menu
Figure 4-4 Coin Acceptor Number
4.1.2 GAME OPTIONS
“Game Options” sub-menu offers settings that you can adjust for each individual software
title installed on your Injoy- STREET RACING STARS MDX (Figure 4-5).
1. “Continue Timer Length”adjusts the amount of time for the player to decide to
continue playing after their game has ended. This can be adjusted by using the “+” or
“-” buttons as shown in Figure 4-5.
2. “Game Show Operation” enables free game play by pressing “Switch” button.
Figure 4-5 “Game Options” sub-menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
16
4.1.3 PEDAL SETTING
To calibrate the Throttle, follow the directions on the screen and go through these steps
(Figure 4-6 ~ Figure 4-9):
1. Hold the “Calibrate” button on the Panel to calibrate the pedal and brake.
2. Release the Brake and Pedal, then press “Next” button.
3. Press the Brake and Pedal to limit and then press “Next” button.
4. After finishing the calibration, press the “Exit” button to exit calibration.
Figure 4-6 Pedal Setting
Figure 4-7 Calibrate Pedal
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
17
Figure 4-8 Calibrate Pedal
Figure 4-9 Finish calibration
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
18
4.1.4 LANGUAGE SETTING
Language can be adjusted using the “+” or “-” buttons (Figure 4-10) to change game
language. Currently, English and Chinese are available.
Figure 4-10 “Language Setting” sub-menu
4.1.5 SYSTEM TIME SETTING
Setting the system time can be accomplished using the “switch” button to choose, followed
by the “+” or “-” buttons (Figure 4-11) to change date or time. Time is displayed in 24 hour
or military time.
Figure 4-11 “System time Setting” sub-menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
19
4.1.6 VOLUME SETTING
“Volume setting” can adjust the system volume (Figure 4-12).
Figure 4-12 “Volume Setting” sub-menu
4.1.7 DEVICE TEST
“Device Test” tests whether “Coin Acceptor, Free Play button” can work or not (Figure
4-13).
Figure 4-13 “Device Test”sub-menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Injoy Motion Corp.
STREET RACING STARS MDX Service Manual
20
4.1.8 SOFTWARE UPGRADE
Any software upgrades and/or new software game titles will be downloaded to your Injoy -
STREET RACING STARS MDX through the use of USB Flash Disk provided by Injoy or
your distributor. The following explains this simple procedure, found in the Operator
Menu.
1. Unfasten the screws (arrows as shown in the Figure 4-14), and then remove the case
(Figure 4-15).
Figure 4-14 unfasten the screws
Figure 4-15 Remove the case
2. Locate the system’s PC (Industrial PC): Referring to Figure 4-16, open the front case of
the chassis located at the bottom of the motion base. You can see the PC is installed at
the left corner.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200
