Bay Tek Games Goal Rush User manual

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

BAY TEK GAMES INC.
Pulaski Industrial Park
1077 East Glenbrook Drive
Pulaski, WI 54162 U.S.A.
www.baytekgames.com
JOIN SERVICE FIRST NETWORK!
This free service is intended to keep you up to
date on the latest game information, early
notification of parts specials, pertinent technical
bulletins, updates on retro fit parts, software
upgrades, & much more. Log on to:
www.baytekgames.com/parts
& then click on the Service First icon.
8 AM - 5 PM C.S.T. MON - FRI
Our Vision:
We aspire to be the
best in the world at
developing and
manufacturing coin
operated games for
our customers.
SALES
P: 920.822.3951
F: 920.822.8936
[e-mail]
PARTS
P: 920.822.3951 x 1101
F: 920.822.1496
[email protected]
SERVICE:
P: 920.822.3951 X 1102
F: 920.822.1496
[email protected]
All games proudly manufactured at our factory in Pulaski, Wisconsin U.S.A.
FACTORY CONTACT INFORMATION
2
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

TABLE OF CONTENTS
FACTORY CONTACT INFORMATION 2
INTRODUCTION 4
SPECIFICATIONS 5
SAFETY PRECAUTIONS 5
QUICK SET-UP 6-7
DIP SWITCH SETTINGS 8
MAIN MENU OPERATIONS 9
COINS PER PLAY 10
GAME VOLUME 10
ATTRACT MODE VOLUME 10
ATTRACT MODE TIMING 11
TICKET PATTERNS 11-12
MERCY TICKETS 13
DIVIDE BY 2 TICKET DISPENSING 13
FIXED TICKET PAYOUT 13
BALL TIMEOUT 14
BALLS PER GAME 14
STORED CREDITS/ TICKETS OWED 15
NEXT GAME START DELAY 15
GAME STATISTICS 16
RESET STATISTICS 16
DIAGNOSTICS MODE 17
TROUBLESHOOTING GUIDE
PINOUT DIAGRAMS 23-25
MAINTENANCE LOG 26
TECH SUPPORT 27
WARRANTY 28
RESTORE FACTORY SETTINGS 17
3
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

GAME INSPECTION
Inspect the game for any damaged, loose, or missing parts. If damage is found,
please contact your freight carrier first. Then, contact Bay Tek Games
Service Department at 920.822.3951 or e-mail them at
[email protected] for further assistance.
WELCOME TO: GOAL RUSH!
GOAL!
Shoot and score with Bay Tek’s new soccer/football-themed alley bowler,
Goal Rush!
With a completely redesigned cabinet, playfield and graphics package,
Goal Rush is sure to punt your game room into the future!
With a shortened ramp and smaller overall footprint, this new-age alley
bowler provides all the kicks while taking up less room. The game set-
tings controls are now readily accessible right at the front of the game,
making it simple and quick to adjust to your needs!
Pair up the Goal Rush with our hip, newly redone Alley Ooop Street Ball
of Fireball Fury to round out your alley lineup, and add a sleek updated
progressive sign to rack up the revenue!
Please take a moment to read through this manual and be sure to
contact our factory if you have any questions, or would like some more
information.
Your business is important to us and we hope you enjoy this game as
much as we do!
Your Friends at Bay Tek Games
4
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

SAFETY PRECAUTIONS
SPECIFICATIONS
Be sure the electrical power matches the game requirements. See the serial num-
ber decal located on the back of the game cabinet. Always plug game into a
grounded circuit. If the supply cord is damaged, it must be replaced by a special
cord or assembly available from the manufacturer or its
service agent.
ATTENTION
Lifting heavy objects can cause back, neck, or other injuries. Be sure
adequate lifting and moving devices are available when unloading,
unpacking, and moving this game.
DO NOT perform repairs or maintenance on this game with the power ON. Unplug
the unit from the wall outlet or shut off the power at the power strip located inside
the game cabinet.
Use of flammable substances can cause severe burns or serious injury.
Always use NON-FLAMMABLE solvents for cleaning.
DO NOT use gasoline, kerosene, or thinners.
WARNING
CAUTION
DANGER
WEIGHT
WEIGHT 675 lbs.
SHIP WEIGHT 755 lbs.
DIMENSIONS
WIDTH 30”
DEPTH 114”
HEIGHT 80”
POWER REQUIREMENTS
INPUT VOLTAGE RANGE 110 to 120 VAC or 220 to 240 VAC
INPUT FREQUENCY RANGE 50 HZ to 60 HZ
MAX START UP
CURRENT
1.6 AMPS @ 115 VAC
0.8 AMPS @ 230 VAC
OPERATING
CURRENT
1.3 AMPS @ 115 VAC
.65 AMPS @ 230 VAC
OPERATING TEMPERATURE
80 - 100 Degrees Fahrenheit
26.7 - 37.8 Degrees Celsius
5
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

QUICK SET-UP GUIDE
1. Place the target cabinet in its desired
location
2. Push the ramp cabinet to about a foot
from the front of the target cabinet
3. Plug in the 3 cables to connect the
target and ramp cabinets
4. Push the ramp up flush against the
target
5. Drop the 9 balls into the playfield
6
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

QUICK SET-UP GUIDE
7
Congratulations! You’re Ready To Roll!
7. Slide the acrylic faceplates into the
grooves in the display portion of the
target cabinet
8. Plug the power cord into the target
cabinet and into a standard 110v
electrical wall outlet
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

DIP SWITCH SETTINGS
Access the dip switches on the main board inside the front door of the ramp.
*Factory default settings are highlighted in gray.
DIP 4 ON OFF
DIP 3 ON OFF
DIP 2 ON OFF
DIP 1 ON OFF
DO NOTADJUST
DO NOTADJUST
JERSEY– SINGLE CREDIT/
SAVED TICKETS
PROGRESSIVE SIGN ENABLE
(REQUIRES SOFTWARE UPDATE)
8
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

DETAILED OPERATIONS
MAIN MENU
1. Access the main menu by pressing the
“MENU BUTTON” inside the front door of
the ramp and holding down for 4 seconds.
2. Scroll through the menu options shown on
the 4-digit display by pressing the “MENU
BUTTON” repeatedly.
3. Press the “MENU SELECT” button to enter
and scroll through sub-menus (defined
below).
9
n1 Coins Per Play n14 0- [N/A]
n2 Game Volume n15 0- [N/A]
n3 Attract Mode Volume n16 1- [N/A]
n4 Attract Mode Timing n17 Ball Timeout
n5 Ticket Patterns n18 0- [N/A]
n6 Mercy Tickets n19 0- [N/A]
n7 Divide By Two
Ticket Dispense n20 Next Game Start Delay
n8 Fixed Ticket Payout
(New Jersey) n21 Display Last Score
n9 Stored Credits/ Tickets Owed n22 Statistics
n10 Balls Per Game n23 Reset Statistics
n11 0- [N/A] n24 Diagnostics
n12 0- [N/A] n25 Restore Factory Settings
n13 0- [N/A]
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

N1– COINS PER PLAY
CREDITS
PER PLAY 1 2 3 4 5 6 7 8
PRICE
PER PLAY $.25 $.50 $.75 $1.00 $1.25 $1.50 $1.75 $2.00
Scroll through the n1 menu with the “menu select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
N2– GAME VOLUME CONTROL
Scroll through the n2 menu with the “menu select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
0
(OFF) 1 2 3 4 5 6 7
This control is for the volume of the game while it is being played,
or after a coin has been inserted.
A “boink” noise will play an example volume while scrolling through
the volume levels.
N3– ATTRACT VOLUME CONTROL
Scroll through the n3 menu with the “menu select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
0
(OFF) 1 2 3 4 5 6 7
This control is for the volume of the game
while it is NOT being played.
This game plays fun sounds to lure customers to play.
A “boink” noise will play an example volume while scrolling through
the volume levels.
10
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

N4– ATTRACT SOUND TIMING
ATTRACT
SOUNDS
PLAY
EVERY:
OFF SECONDS MINUTES
0 30 1 5 10 15
Scroll through the n4 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
PATTERN
#
SCORE: (in thousands– k)
0
–
9k
10k
–
14k
15k
–
19k
20k
–
24k
25k
–
29k
30k
–
34k
35k
–
39k
40k
–
44k
45k
–
49k
50k
–
59k
60k
–
69k
70k
–
79k
80k
–
89k 90k
TICKETS:
0
1 1 2 3 4 5 6 7 8 9 10 11 12 13 14
2 1 2 3 4 5 6 7 8 9 10 25 50 75 100
3 1 2 3 4 5 6 7 10 15 25 50 100 150 1000
4 1 3 5 7 9 11 13 15 17 20 25 50 75 100
5 2 4 6 8 10 12 14 16 18 20 30 40 50 100
6 2 4 5 6 10 12 14 16 18 25 50 75 100 1000
7 3 4 5 6 7 8 10 15 20 30 50 100 250 1000
8 4 5 6 7 8 9 10 15 20 25 35 50 100 1000
NO TICKETS (enables printer if connected)
N5– TICKET PATTERNS
Scroll through the n5 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
11
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

PATTERN
#
SCORE: (in thousands– k)
0
–
9k
10k
–
14k
15k
–
19k
20k
–
24k
25k
–
29k
30k
–
34k
35k
–
39k
40k
–
44k
45k
–
49k
50k
–
59k
60k
–
69k
70k
–
79k
80k
–
89k 90k
TICKETS:
9 6 8 10 12 15 20 30 50 70 100 200 300 500 1000
10
11
12
13
14
15
16
17
18 0 0 1 1 1 2 2 3 4 6 10 20 30 50
19 0 1 1 2 2 2 3 3 3 4 5 10 20 50
20 1 1 2 2 3 3 4 4 5 6 7 8 9 500
21 1 1 2 3 4 5 6 7 8 9 10 15 23 25
22 1 2 3 4 5 6 7 8 9 10 15 20 25 50
23 2 3 4 5 6 7 8 9 10 11 12 15 20 1000
24 2 3 4 5 6 8 10 12 14 16 18 20 25 30
25 3 4 5 6 7 8 9 10 12 14 16 20 25 30
4 8 10 16 20 24 28 32 36 40 60 80 100 200
4 8 10 12 14 18 20 25 30 35 50 75 100 1000
6 8 10 16 20 22 24 26 30 35 50 100 120 1000
6 8 10 12 14 16 20 30 40 60 100 200 500 2000
8 16 20 24 28 36 40 50 60 70 100 150 200 2000
12 16 24 32 40 44 48 52 60 70 100 200 240 2000
8 10 12 14 18 22 30 35 40 50 60 70 80 100
8 10 12 14 16 18 20 22 24 26 28 30 50 250
N5– TICKET PATTERNS, CONT
12
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

N6– MERCY TICKETS
N7– DIVIDE BY 2 TICKET DISPENSE
Scroll through the n7 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
This setting is used when a facility places a value of “2” on each individual ticket
dispensed. This game truncates the ticket value to the lower number
(for example: 5tickets won/value of 2= 2 physical tickets)
OFF ON
0 1
Scroll through the n6 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
Mercy tickets are given per game, no matter what the player scores.
01 2 3 4 5 6 7 8 9
N8– FIXED TICKET PAYOUT
Scroll through the n8 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
0 5 6 7 8 9 10 11 12 13 14 15
In areas where it is required, when enabled, the game will give only the specified
amount of tickets per game.
This setting will override any ticket pattern (n5) or mercy tickets (n6) selected.
13
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

N9– STORED CREDITS/ TICKETS OWED
Scroll through the n9 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
This function enables the game to remember credits available and tickets owed when
the game is powered off and turned back on.
*this option is overridden and always enabled if DIP 2 is ON (see page 8)
0 1
OFF ON
N10– BALLS PER GAME
N11– LEAGUE FREE PLAY
N12– SCORE FOR REWARD COUPON #1
N13– SCORE FOR REWARD COUPON #2
N14– SCORE FOR REWARD COUPON #3
N15– SCORE FOR REWARD COUPON #4
[0]- Does not apply to Goal Rush
[0]- Does not apply to Goal Rush
[0]- Does not apply to Goal Rush
[0]- Does not apply to Goal Rush
[0]- Does not apply to Goal Rush
Scroll through the n10 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
3 4 5 6 7 8 9
14
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

N20– NEXT GAME START DELAY
Scroll through the n20 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
This setting will wait the selected number of seconds after a game is completed
before starting another game or returning to attract mode.
5 6 7 8 9 10
SECONDS
N17– BALL TIMEOUT
Scroll through the n17 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
*Factory default settings are highlighted in gray.
OFF SECONDS
0 30 1 2 3 5
MINUTES
This setting will cause the game to score a zero for an unrolled ball if not rolled within
the set amount of time.
This only goes into effect after the game has been coined up.
N18– PRINT SCORE OPTION
[0]- Does not apply to Goal Rush
N19– GAME START BUTTON OPTION
[0]- Does not apply to Goal Rush
N16– PRINTER CUTTER ON/0FF
[0]- Does not apply to Goal Rush
15
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

N22– GAME STATISTICS
Scroll through the n22 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
N23– RESET STATISTICS
Hold down the “select” button for 3 seconds to clear the statistics in n16.
The display will show the status of the statistics clear.
Once the statistics are reset, all stats 1-17 will be cleared to 0.
S1 Total Games Played
S2 Total Tickets Dispensed
S3 Average Tickets per Game
S4 Scoring Bucket 1 (0-9K points)
S5 Scoring Bucket 2 (10K-14Kpoints)
S6 Scoring Bucket 3 (15K-19K points)
S7 Scoring Bucket 4 (20K-24K points)
S8 Scoring Bucket 5 (25K-29K points)
S9 Scoring Bucket 6 (30K-34Kpoints)
S10 Scoring Bucket 7 (35K-39Kpoints)
S11 Scoring Bucket 8 (40K-44Kpoints)
S12 Scoring Bucket 9 (45K-49K points)
S13 Scoring Bucket 10 (50K-59K points)
S14 Scoring Bucket 11 (60K-69K points)
S15 Scoring Bucket 12 (70K-79K points)
S16 Scoring Bucket 13 (80K-89K points)
S17 Scoring Bucket 14 (90K points)
S18 N/A
S19 N/A
S20 N/A
S21 N/A
N21– DISPLAY LAST SCORE
0 1
OFF ON
Scroll through the n21 menu with the “select” button.
Make your selection by pressing the “menu button” and scrolling
through the remaining menus past n25 to exit the menu.
When enabled, this setting will display the last score rolled during attract mode
instead of scrolling zeros
16
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

N24– DIAGNOSTICS MODE
Sensor/ Component Display Reading
1000 point target 1
2000 point target 2
10000 point target 3
2000 point target 4
5000 point target 5
4000 point target 6
4000 point target 7
Ball trough b
Ball release r
Low ticket switch L
Game start button o
Coin acceptor switch C
Dollar bill acceptor d
N25– RESTORE FACTORY SETTINGS
In the N25 menu, hold down the “select” button for 3 seconds to restore all settings to
factory default.
The display will show the status of the reset.
-- dEF
NOT RESET RESTORED
DISPLAY
READS:
STATUS:
Diagnostics mode allows each target and ball counter to be tested for sensor function.
When a sensor or switch is activated, it’s specified number will appear on the display.
No switches closed displays a dash ‘-’ and should be the default.
If more than one switch is closed, the display will cycle through them.
17
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

MAINBOARD PINOUT
Ground +12V Low Side Driver High Side Driver +3.3V TTL Logic +3.3V
SPI Out - Display - (J10) Chase Lights (J11,J12,J13,J14)
Pin 1 & Pin 3 - +12V Pin 1 - Chase Output Pin 2 - SCLK_BUS2 Pin 2 - Chase Output Pin 4 - SMOSI_BUS2 Pin 3 - +12V Pin 5 & Pin 7 - Ground Pin 4 - Chase Output Pin 6 - SCS2_BUS2 Pin 5 - Chase Output Pin 8 - SMISO_BUS2 Pin 6 - +12V
18
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

MAINBOARD PINOUT GUIDE
BayTek Alley Bowler NEWGEN1 Hardware REV D Pinout - Version 1 Pin Type Purpose Ref Pin #
=Low Side Driver
LOWSIDE #1,w diode Mechanical Count #1 Game J22 1 =High Side Driver LOWSIDE #2, w diode Mechanical Count #2 Ticket J22 2 = TTL Input/Output LOWSIDE #3 *Acrylic Lighting RED Color J22 3 = LED Constant Current Drive LOWSIDE #4 *Acrylic Lighting GREEN Color J22 4 = 12 Volts LOWSIDE #5 *Acrylic Lighting BLUE Color J22 5 = Ground LOWSIDE #6 Unused J22 6 LOWSIDE #7 Unused J22 7 Pin Type Purpose Ref Pin # LOWSIDE #8 J22 8 Ground J24 1 LOWSIDE #9 J22 9 Ground J24 2 +12 Volts Mechanical Count #1 Game +12V J22 11 +12 Volts J24 3 +12 Volts Mechanical Count #2 Ticket +12V J22 12 +12 Volts J24 4 +12 Volts J22 13 PB7 Ball Release Sensor J24 5 +12 Volts J22 14 LOWSIDE #12 Ball Release Motor/Solenoid J24 6 +12 Volts J22 15 PX29 Ball Trough Sensor J24 7 +12 Volts J22 16 HIGHSIDE #10 Ball Release Motor/Solenoid J24 8
HIGHSIDE #11 Game Start Light J24 9
* = Attract Mode Lights TBD
3.3V J24 10 PX37 Ticket Notch #1 J5 1
Ground Ground for Ticket Dispensor J5 2
HIGHSIDE #13 J25 1 PB18 Ticket Motor #1 J5 3 HIGHSIDE #14 J25 2 +12 Volts Power for Ticket Dispensor J5 4 PX10 Service Button #1 J25 3 PX11 Service Button #2 J25 4 PB16 Low Ticket Switch J9 1 Ground Ground for Service Buttons J25 5 Ground Ground for Low Ticket Switch J9 2 Ground J25 6 PB17 Unused J9 3
+12 Volts J9 4
+12 Volts Coin Door Power J6 1 PA05 Coin Input J6 2
PA06 DBA Input J8 1
Ground Coin Ground J6 3 +12 Volts NOTE-MISLABELED as J9 J8 2
Ground This Connector is next to J6 J8 3
Ground J8 4
19
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

MAINBOARD PINOUT GUIDE
***All Chase Lights TBD***
PB19 1000 Point Sensor– Blue J21 1 Driver 1 To AACB9101 Speaker Chase Lights J12 1 PX39 2000 Point Sensor– Yellow J21 2 Driver 2 To AACB9101 Speaker Chase Lights J12 2 PX00 10000 Point Sensor– Pink J21 3 +12 Volts To AACB9101 Speaker Chase Lights J12 3 PX01 2000 Point Sensor– Grey J21 4 Driver 3 To AACB9101 Speaker Chase Lights J12 4 PB20 5000 Point Sensor– Black J21 5 Driver 4 To AACB9101 Speaker Chase Lights J12 5 PX02 4000 Point Sensor– Tan J21 6 +12 Volts To AACB9101 Speaker Chase Lights J12 6 PB21 4000 Point Sensor– Purple J21 7 PB22 Not Used J21 8
Driver 5 To AACB9101 Speaker Chase Lights J11 1
PB23 Not Used J21 9 Driver 6 To AACB9101 Speaker Chase Lights J11 2 PB24 Jersey Coin Lockout J21 10 +12 Volts To AACB9101 Speaker Chase Lights J11 3 Ground J21 11 Driver 7 To AACB9101 Speaker Chase Lights J11 4 Ground J21 12 Driver 8 To AACB9101 Speaker Chase Lights J11 5 Ground J21 13
+12 Volts To AACB9101 Speaker Chase Lights J11 6
Ground J21 14 +12 Volts J21 15 Driver 9 J13 1 +12 Volts J21 16 Driver 10 J13 2 +12 Volts J21 17 +12 Volts J13 3 +12 Volts J21 18 Driver 11 J13 4 PB25 Not Used J21 19 Driver 12 J13 5 PB26 Not Used J21 20
+12 Volts J13 6
Driver 13 J14 1 Driver 14 J14 2 +12 Volts J14 3 Driver 15 J14 4 Driver 16 J14 5 +12 Volts J14 6
20
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200
