9.7” LED Monitor Manual
inM497-1

1
1 Introduction and Package Contents
Introduction
Congratulations on your purchase. You can expect only the
sharpest and most brilliant color images from this monitor.
Featuring easy to use OSD controls and built in speakers, you will
find this monitor both easy to use and a pleasure to view.
Package Contents
•12V DC Power Supply
•D-Sub 15-pin VGA connector Cable
•User Manual
•Remote Control
•2.5mm to 2.1mm Power Adaptor Plug
(The 2.5mm adaptor is required to be used, insert into DC
power port then plug the 12vdc power supply into the
adaptor.)
Hardware Installation
The following sections in this guide give clear, step-by-step
descriptions of the installation process and explain how to use
the monitor for optimum results.
Please pay attention to the Regulations and Warnings Section of
this user’s manual before setting up the display monitor. Failure
to do so may inadvertently result in personal injuries or machine
damage.

2
Specifications
Model
inM497-1
General
Diagonal size
9.7"
Panel type
TFT LCD
Aspect ratio
4:3
Number of pixels
1024 x 768
Pixel pitch
0.192 x 0.192 mm
Color depth
262K Colors
Backlight
LED
Optical (typ.)
Brightness
400 cd/m2
Contrast ratio
1000:1
Response time
( Tr + Tf)
4 ms
Viewing angle Vertical -89°~89° / Horizontal -89°~89°
Operation
Input Interface VGA x 1, HDMI x 2, PC Audio x 1, Micro USB x 1,BNC x 1,RCA x 2
Output Interface
BNC x 1
Display mode
VGA / HDMI 1/ HDMI 2 / AV / USB
OSD
PICTURE, SOUND,OPTION
OSD Languages Chinese,English,Japanese,Spanish,German,Italian,Russian,French,Polish,Dutch,Czech
Speaker
1.5 W x 2
Remote control
YES
Composite Video
System
PAL / NTSC
Video processing Motion Adaptive 3D De-Interlace and DNR, 4H Comb filter Y/C separation
Electrical
AC power
AC 100-240V 50/60HZ
Power consumption
17W Max. in “ON” Mode
Under 0.5W in Power Saving Mode (100 VAC)
Under 0.5W in Power Saving Mode (240 VAC)
Power supply
External power adapter
Mechanical
Case material Metal
Color Normally black, other colors are available (for quantity up to 100pcs per model)
Dimensions
( W x H x D)
244 x 190 x 30 mm
Mounting interface VESA mount 75 x 75 mm
Net weight 0.94Kgs(2.07 lbs)
Environment
Temperature Operation: 0°~40°C(32° ~104°F)
Storage: -10°~60°C(14° ~140°F)
Humidity
20%-90%
Standards
Safety FCC, CE, ROHS
Pixel defect policy
ISO13406-2 Compliant, LCD panel class 2
Delivery set Carry Bag(Optional),Lithium Battery(Optional), Lithium Battery charger(Optional),
Monitor, Power Supply, VGA Cable, Stand, Remote Control, User Manual

3
VGA Timing
Item Resolution H Freq.(kHz) V Freq.(Hz) Note
1 640x400@70 31.460 70.080
2 640x480@60 31.469 59.940
3 640x480@72 37.861 72.809
4 640x480@75 37.500 75.000
5 720x400@70 31.460 70.080
6 800x600@56 35.156 56.250
7 800x600@60 37.879 60.317
8 800x600@72 48.077 72.188
9 800x600@75 46.875 75.000
10 1024x768@60 48.363 60.004
11 1024x768@70 56.476 70.069
Note:
The timings with presetting are recommended.
Users have to adjust the timing manually, if it is not included in the presetting list

4
MSA
Menu Select -+Auto Power
-
2 Monitor and OSD Control
Monitor and OSD Control
The LED color monitor has a simple control layout for controlling
the monitor and OSD (On Screen Display) functions. The table
below summarizes the control keys and their related functions.
6-Key feature
Keys Function Description
Power
To turn the power ON or OFF. Please wait for 6 seconds
before the display appears.
A / Auto
Automatically adjusts H-Position, V-Position, Pixel Clock
and Phase for an optimal image in PC mode only.
Switch setting item.
Increase the value of the chosen item.
Switch setting item.
Decrease the value of the chosen item.
S / Select
Switch mode “PC”, “HDMI 1”, “HDMI 2”, “USB”,“AV”.
M / Menu
Enter the main menu of the on-screen display (OSD).
Source Select
Press the Select button to bring up source selection
+

5
Use the Select keys to advance to the proper selection and
press －OR ＋keys button to confirm the setting.
Note:
The message will be displayed on the
screen if there’s no VGA signal detected in VGA mode, and the
power will be off automatically after 10 seconds. Please press the
power button again to restart the monitor.
LED Status Display
The following table describes the various power states of the LED monitor as
represented by different LED color.
Remote Controller
Power State LED Color
On Green
Standby Red
No power Blank

6
SOUND Mode
1. Volume
Press - OR + to adjust volume level.
2.Mute
Press - OR + to adjust Mute.
“ Off , On”.
3
OSD Control Function List
PICTURE Mode
1.Picture Mode
Press - OR +to select the picture mode
“User, Normal, Vivid, User, Movie”
2. Color Temp.
Press - OR + to adjust the color tones.
“ User, Cool , Warm , Normal “
3. Scale Mode
Press - OR +to adjust the Aspect Ratio.
“ 4:3, 16:9 , Under Scan“(For AV Mode, When you look at
the image, it will be relatively narrow; and that is if the TV
set over the part, will be displayed in a black background. )
4. DNR High
Press - OR + to adjust the Noise Reduction
“ Off , Low , Middle , High. “

7
OPTION Mode
1. Language
Press - OR +( Left
，
Right),Select(Up
，
Down) to select language.
2.Key Lock
Press - OR + to adjust Key Lock.
“ Off , On”.( Key unlocking method, pressing the Select button for
5 to 10 seconds after seeing flashing lights completed.)
3.OSD_Reset
Press - OR + to adjust OSD_Reset.
“ Yes, No”.
OSD Language Options
Press the – (left) or + (right) and select key (down) to choose the OSD
language , Pressing menu to go to main menu.
Reset Instructions
After selecting Reset OSD will appear if you want to reset the options,
select the button "-" to YES, select the button "+" Back to the OSD.

8
USB Mode (Button operation)
1. Access to multimedia, Press – (left) or + (right) and Menu key (confirm) to
choose – photo, music , movie and text function.
To press menu key to execute USB data “ FAT32”
2. Going back to upper level , Press the – (left) or + (right) to move to Return ,
and then press menu key.
1. Press the – (left) or + (right) to move to target photos, music , films. To select
the target , please press “ menu” key.
2. After selecting the target photos, you may press “ Auto “ key to display the
photos automatically. “ Auto “ key to play and pause.

9
3. Under auto display photos function, to press menu to show the operation
menu. To press “ Power “ key to release the Auto display photos function
USB multimedia player to meet the following format
(MEPG、JPEG、PNG、FLV、DAT、AVI、MKV、MP3、RMVB、MP4、BMP、VOB)

10
Charging the Battery Pack
1. Plug charging adaptor into the battery pack then plug the
adaptor into a 110 Volt AC socket.
2. Flip the switch on the battery to the on position
a. When charging the battery light should show red (If the
LED is not lit then the battery is not charging)
b. When charging the plug in charging adaptor light will
show red until the battery is fully charged then it will
switch to green.
3. Once the battery is charged unplug it from the charger and
flip the switch on the battery to the off position.
NOTE: The battery pack provides 1800mA so it will last about one
hour when in use.
Connecting the Battery Pack to the Monitor
1. Plug one end of the power cable into the battery pack and
plug the other end into the 2.5mm power adaptor, then plug
into the monitor.
2. Turn the battery to the on position
3. Turn the monitor to the on position and select the correct
input to view on the screen.
4 Accessory Option / Carry Bag and Battery

11
5 Dimensions

12
Caring for your LED Monitor
The LED color monitor is a sensitive piece of electronic
equipment. Proper care can prevent accidentally damaging
the LED panel or the monitor itself. By following these guidelines
you can ensure many years of trouble free use.
4. The LED monitor's metal casing and LED glass panel can be
cleaned with a soft, lint-free cloth. Never use scrub pads or
other cleaning materials with abrasive surfaces to clean your
LED monitor!
a. A slightly damp cloth or newspaper may be used to
clean the glass plate of fingerprints or smudges.
b. For the metal case, a mild detergent may be used to
clean the surface. However, you should ensure not to
use too much detergent or water as this could leak into
the interior of the casing.
5. Do NOT use cleaning fluids based on alcohol, methylated
spirit, or ammonia. The glass plate has a hard surface coating
to prevent scratches. However, the use of strong chemical
cleaning agents may damage this coating. Use only a mild
soap or detergent and water or specially formulated cleaners
made for cleaning glass panels.
6. Avoid direct contact with water or other liquids. Never use
the LED monitor in or around areas where water may pose a
potential hazard to normal operation.
7. Only use the LED monitor indoors, and avoid monitor contact
with oil, vapor, steam, moisture and dust. The LED monitor
should be used in a clean and low humidity environment.
8. Keep the LED monitor away from heaters or other heat
sources such as lighting equipment or direct sunlight.
9. Keep the LED monitor screen away from sharp objects such
as fingernails and pencils.
WARNING: Any unauthorized modification to this equipment
could result in the revocation of the authorization to operate the
equipment and void the product warranty.
6 Caring for Your LED Monitor

13
6 Frequently Asked Questions
Power button does not respond
•Check the power cord to ensure that it is securely plugged
into the monitor base and also into the electrical outlet.
•Ensure there is electrical power coming from the AC outlet.
Use another device to check for power.
•Unplug the power cord of the monitor from the AC outlet;
wait a few minutes, then to plug the power cord into the AC
outlet again. This will reset the monitor and power supply.
No image on the screen
•Ensure that the DB-15 signal cable is properly connected to
the display card/computer.
•Check the DB-15 signal cable connector on both ends for
bent or pushed-in pins.
•The display card should be properly seated in its card slot.
•Ensure that the computer's power switch is ON.
•Ensure that the monitor's power switch is ON.
•Unplug the power cord of the monitor from the AC outlet;
wait a few minutes, then to plug the power cord into the AC
outlet again. This will reset the monitor and power supply.
Power LED is RED (with no image on the screen)
•Check the DB-15 signal cable to ensure that it is properly
attached to the graphics display card.
•Check the DB-15 signal cable on both ends for bent or
pushed-in pins.
•Make sure the computer is not in a power-saving mode
(move the mouse or press a key on the keyboard).
No sound coming from the audio speakers
•The audio cable should be connected to the lineout on the
audio card and the line-in on the monitor. Ensure that the
audio cable is properly connected.
•Inspect the audio cable for any apparent damage. Double
check by switching to another audio cable to see if the
audio works.

14
7 Regulations and Maintenance
FCC compliance
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generation, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment to an outlet on an electrical circuit
different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
Precautions
＊Read all of these instructions and save them for later use.
＊Follow all warnings and instructions on the product.
＊Product
-Do not cover or block the vent holes in the case.
-Do not insert sharp objects or spill liquid into the LED monitor through cabinet
slots. They may cause accidental fire, electric shock or failure.
-Disconnect the power plug from the AC outlet if you will not use it for an
indefinite period of time.
-Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage potentials or other risks.
-Do not touch the screen directly with your fingers. You may damage the screen,
and oil from your skin is difficult to move.
-Do not apply pressure to the screen. The LED is very delicate.
＊Power
-Use the type of power indicated on the marking label.

15
＊Plugs
-Do not remove any of the prongs of the monitor’s three-pronged power plug.
-Disconnect the power plug from the AC outlet under following conditions:
◎If you will not use it for an indefinite period time.
◎When the power cord or plug is damaged or frayed.
◎If the product does not operate normally when the operation instructions are
followed. Adjust only those controls that are covered by the operating
instructions. Improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the
product to normal operation.
◎If the product has been dropped or the cabinet has been damaged.
◎If the product exhibits a distinct change in performance, indicating a need for
service.
＊Power and extension cords
-Do not allow anything to rest on the power cord.
-Do not locate this product where persons will walk on the cord.
-Use the proper power cord with correct attachment plug type. If the power
source is 120 V AC, use a power cord that has UL and C-UL approvals. If the
power source is a 240 V AC supply, use the tandem (T blade) type attachment
plug with ground conductor power cord that meets the respective European
country’s safety regulations, such as VDE for Germany.
-Do not overload wall outlets or power cords. Ensure that the total of all units
plugged into the wall outlet does not exceed 10 amperes.
-Ensure that the total ampere rating of all units plugged into the extension cord is
not over the cord’s rating.
-If the power supply cord, which came with your monitor, is to be connected to
the PC instead of the wall outlet, this equipment is to be used with UL/TUV
approved computers with receptacle rated 100~240V AC, 50/60Hz,
2.0A(minimum).
＊Environment
-Place the monitor on a flat and level surface.
-Place the monitor in a well-ventilated place.
-Keep the monitor away from:
Extremely hot, cold or humid places, places directly under sunlight, dusty surroundings,
equipment that generate strong magnetic fields.
