User Manual
Instruction Manual
Induction Hob
MODEL:ICONTFT90
Induction
Flexl-zone Flexl- zo ne

03
11
04
06
10
35
Preparation
Safety
Installation
Before you start
Use
Care and Maintenance
Technical Specification
38

[01] x 1
[02] x 1
x1
Induction
Flexl-z on e Fl exl-z on e
3

The appliance is not to be used by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
Children being supervised not to play with the appliance.
The appliance incorporates an earth connection for functional purposes only.
WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock.
WARNING:A steam cleaner is not be used.
Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can
get hot.
After use, switch off the hob element by its control and do not rely on the pan detector.
The appliance is not intended to be operated by means of external timer or separated remote-control system.
Danger of fire: Do not store items on the cooking surfaces.
CAUTION:The cooking process has to be supervised. A short term cooking process has to be supervised
continuously.
WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in a fire.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agentor similarly qualified
persons in order to avoid a hazard.
WARNING: Before obtaining access to terminals, all supply circuits must be disconnected.
This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. children shall
not play with the appliance. cleaning and user maintenance shall not be made by children without supervision.
WARNING: The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless continuously supervised.
NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame
e.g. with a lid or a fire blanket.
WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
The use of inappropriate guards can cause accidents.
Ensure the Power cord isn’t accessible after installation.
Safety
This instructions are for your safety. Please read them thoroughly prior to installation and retain them for future
reference.
4

Caution:
•The induction hotplate must be installed by qualified personnel or technicians. Please never conduct the
operation by yourself.
•The hob must not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer,
as the humidity may damage the hob electronics.
•This hob must not be installed directly above a kitchen drawer used to store cutlery or other metal items
due to the proximity of its magnetic field.
•Do not attempt to dismantle the appliance, there are no user serviceable parts inside.
•At the end of its life, the appliance should not be disposed of in household waste; contact your Local
Authority for guidance.
Caution:
•This hob must be connected to the mains power supply only by a suitably qualified person.
•Before connecting the hob to the mains power supply, check that:
1.the domestic wiring system is suitable for the power drawn by the hob.
2.the voltage corresponds to the value given in the rating plate.
3.the power supply cable sections can withstand the load specified on the rating plate.
•To connect the hob to the mains power supply do not use adapters, reducers, or branching devices, as they
can cause overheating and fire.
•The power supply cable must not touch any hot parts and must be positioned so that its temperature will not
exceed 75°C at any point.
•The work surface is square and level, and no structural members interfere with space requirements.
•The work surface is made of a heat-resistant material.
•If the hob is installed above an oven, the oven has a built-in cooling fan.
•The installation will comply with all clearance requirements and applicable standards and regulations.
•A suitable isolating switch providing full disconnection from the mains power supply is incorporated in the
permanent wiring, mounted and positioned to comply with the local wiring rules and regulations. The isolating
switch must be of an approved type and provide a 3 mm air gap contact separation in all poles (or in all
active [phase] conductors if the local wiring rules allow for this variation of the requirements).
•The isolating switch will be easily accessible to the customer with the hob installed.
•You consult local building authorities and by-laws if in doubt regarding installation.
•You use heat-resistant and easy-to-clean finishes
(such as ceramic tiles) for the wall surfaces surrounding the hob.
•When you have installed the hob, make sure that:
•The power supply cable is not accessible through cupboard doors or drawers.
•There is adequate flow of fresh air from outside the cabinetry to the base of the hob.
•
•
•
If the hob is installed above a drawer or cupboard
space, a thermal protection barrier is installed below the base of the hob.
The isolating switch is easily accessible by the customer. The hob should be fixed into the worktop using
the fixing brackets and sealing tape supplied with the appliance. Do not use silicone sealant or PVA to
secure the hob. Doing so will prevent an engineer removing the appliance to facilitate a repair.
Safety
5

Caution! Before drilling it is extremely important to check the wall for hidden pipes,
electrical cables etc using an appropriate detection device.
Warning: Good ventilation is required around the appliance for easier dissipation of heat
and low power consumption. Sufficient clearance is required around the appliance. The
safety distance for an angled glass hood should be at least 550mm between the hotplate
and the lowest point where it is mounted on the wall.
150mm
520mm
900mm
28mm
760mm
150mm
550mm
Induct ion
Flexl-z one Flexl -zone
Installation
6

The induction hob must be well ventilated and the air inlet and outlet must not be blocked.
Ensure you select a heat-resistant work surface to mount the induction hob.
Cut an aperture in the worktop using a jigsaw as shown. The worktop should be at least
12.5mm thick and made of a heat resistant material.
900mm
875mm
≥20mm
Installation
7

Seal the cut edge of the worktop using silicone sealant or PVA adhesive.
MPORTANT: ensure that either product is fully cured as per the manufacturers'
instructions before you commence installation of the hob. This hob MUST NOT be sealed
into the worktop.
Stretch out and stick the supplied tape along the underside edge of the hob, ensuring
the ends overlap. Trim off any excess tape and dispose of it.
[02] x 1
Installation
8

[01] x 1
Once the worktop edge has cured, and the tape is fitted, position the hob into the
cutout in the worktop. Apply gentle downwards pressure onto the hob to push it into
the worktop ensuring a good seal around the outer edge.
Induc tion
Flexl -zone F lexl-z one
Induction
Flexl-zone F lexl-zone
Installation
9

WARNING: Read the instructions before using the appliance
When the power is switched on at the isolation switch, the hob will beep once and the display will be blank for a few
seconds before 3 dots appear indicating that the software is initiating. Once the process is complete the display will show
an initial date and time, the appliance is now ready for system set up.
01 Induction Cooking
Induction cooking is a safe, advanced and efficient cooking technology. It works by generating electromagnetic radiation
in a suitable pan that then cooks the food. There is no direct heat from the glass, though the surface will get hot due to
convection heating from the pan itself; this is perfectly normal.
My new induction hob makes a lot of different noises. Does this mean that it is faulty?
•Crackling sounds. These noises can normally be attributed to the pans and the different materials used in their construction.
The pan base will be a composition of different materials which will expand at different rates as the pan heats.
•Clicking noises. These are normally created by the electronic components within the appliance as they switch on and off.
•Whistling noises. These can be caused when one or more cooking zones are in operation at a high power level and as
a result of the cookware being constructed of different materials.
•Humming noises. These noises can be created when a high power level is selected i.e. boost function. Noises related
to high power levels will reduce as the pans heat to temperature and the power level is reduced.
•Hissing/humming noises. These noises can be normally heard when the hob’s cooling fan is in operation.
All of the noises listed above are quite normal and do not indicate a fault. Contact Customer Services shown in the
Care & maintenance section below if you need further guidance.
02 Cookware
Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the
bottom of the pan.
•You can check whether your cookware is suitable by carrying out a magnet test. Move a magnet towards the base of
the pan. If it is attracted, the pan is suitable for induction.
•If you do not have a magnet:
1. Put some water in the pan you want to check.
2. Select any zone, the default power level will be set at 5 which is indicated on the display. Place your pan on the selected
zone and if a question mark (?) and the words “Cookware not detected” is displayed then the pans are not suitable for this
appliance.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Use
pans whose diameter is as large as the graphic of the zone selected. You will get maximum efficiency by matching the
pan size to the cooking zone and ensuring it is central. Small pans less than 12cm may not be detected.
Before you start
10

1. Iron pot
2. Magnetic circuit
3. Ceramic glass plate
4. Induction coil
5. Induced currents
IMPORTANT: Always lift pans off the cooking surface! Do not slide or drag to avoid
damaging the glass.
1
2
3
4
5
Use
11

Power level The heating zone shuts down automatically after
1-3 6 hours
4-6 3 hours
7-8 2 hours
9 90 minutes
The hob will automatically switch off after one minute once the pan has been removed from the cooking zone.
Detection of Small Articles
If the hob detects an unsuitable pan or small article (e.g. cutlery, keys) on the cooking zone, it will automatically switch off
after one minute.
WARNING: People with a heart pacemaker should consult with their doctor before using this unit.
01 Description of the hob
Heating Zone Normal Power Boost Power
Pan Diameter
Minimum Maximum
Front Left Zone 2000 W 2800 W Ø120mm Ø200mm
Rear Left Zone 1500 W 2000 W Ø120mm Ø200mm
Left Flexible Zone 3000 W 3600 W Width: <190mm
Length: <380mm
Central Zone 2300 W 3000 W Ø180mm Ø280mm
Front Right Zone 2000 W 2800 W Ø120mm Ø200mm
Rear Right Zone 1500 W 2000 W Ø120mm Ø200mm
Right Flexible Zone 3000 W 3600 W Width: <190mm
Length: <380mm
Touch Control Panel
A
B
C
D
E
F
G
H
19:37
A
B
C
D
E
F
G
H
Thursday 12th January
Indu ctio n
Flex l-z one Fl exl- zone
Use
Functions & Settings
Protection from over-heating
When the built-in sensor detects an excessive temperature, the hob will be switched off automatically.
Residual heat indicator
WARNING: The display will show the letter “H” in the relevant zone to indicate that the appliance is too hot to touch. This will
be due to heat transferred to the glass from the pan by convection, and is perfectly normal for an induction hob.
Auto shutdown
If you forget to switch off a cooking zone, the appliance will automatically shutdown after a certain time.
The default shutdown times are shown in the table below:
12

02 Description of the control panel
Your induction hob control panel is fully touch sensitive. When the date and time is displayed on the Standby Screen,
touch the panel anywhere to access the Home Screen with the induction hob controls.
Stand By Screen
1 Master On / Off Key
Home Screen
Child Lock Icon
Cooking Zones Control Panel
Cooker Hood Control Panel (optional
when connected to additional products,
sold separately)
Slider Control Key
Master Display Key
Cooking Zones
Main Menu
2 Time Display 3 Date Display
4
5
6
7
8
9
10
6
7
8
10
54
12
3
Thursday 12th January
9
且、
Use

5
13

Cooking Zones Control Panel
Cooker Hood Control Panel
Stop Icon
Boost Icon
12
14
Pause Icon
Timer Control Icon
Child Lock Icon
11
13
15
17 Lighting Control Icon
Auto Extraction Control Icon
Stop Icon
16
18
5
11 12 13 14 15
1716 18
且、
Use
Level
5
3
且、
@0
®
�
14

Timer Control Panel
Alarm Icon
Automatic Switch Off Icon
Stop Icon
Settings Control Panel
26 27 28 29
22 23 24 25
Settings
Language Icon
Date Icon
Time Icon
Brightness Icon
Volume Icon
Reset Icon
Connect Icon
Stand By Icon
22
23
24
25
26
27
28
29

Use
0:15
Timer
15

Switch on the power at the Residual Current Device and the hob will start up as shown.
·Select your language as required and touch the Tick Icon to confirm.
·Select the date and time as required and touch the Tick Icon to confirm.
Your hob is ready for use.
In the event of a power cut, the date and time will need to be reset.
Date set
Time set
30 December 2017
31 January 2018
01 February 2019
02 March 2020
03 April 20121
Language set
Thursday 12th January
Using your hob for the first time
Use
16

1. Touch the Master On / Off Key for two
seconds and the display shows the current
date and time. Touch the screen anywhere
to proceed.
2. Touch the Main Menu Icon and then touch the Language Icon to set the desired language.
You can set different options in the system interface such as volume and brightness at anytime
as follows.
Thursday 12th January
Settings
Settings
Settings
Language
Language set
且、
�
System Setup
Use
0
17

3. Touch the Date icon to set the date.
4. Touch the Time icon to set the correct time.
30 December 2017
31 January 2018
01 February 2019
02 March 2020
03 April 20121
Settings
Settings
Date
Date set
Settings
Settings
Time set
Time
Use
18

5. Touch the Brightness icon to set the desired brightness level. The default brightness is set at 8
and is adjustable from 1-15.
6. Touch the Volume icon to set the sound volume level. The default volume is set at 10 and is
adjustable from 0-15.
Settings
Settings
Brightness
Brightness set
Settings Volume
Settings
Volume set
Use
Brightness
8
10Level
19

7.Touch the Reset icon to restore the hob to the default settings.
8. Touch the Connect key to initiate the pairing sequence to connect your hob to your cooker
hood, if purchased separately. Please refer to the section "Controlling a cooker hood remotely"
found later in this manual.
9. Touch the Stand By icon to set the amount of time before the Control Panel reverts to the Stand
By Screen.
(a) By default the Stand By Screen time is set to 5 minutes and can be adjusted from 0.5 to 59
minutes.
(b) The Stand By Screen will automatically switch off after 2 minutes and is not adjustable.
Stand by
Minutes
Stand By set
Settings
Settings
Settings Reset
Restore default settings
Settings
Default settings restored
Use
20
