EMP2/EGP2 SERIES
mPCIe/M.2 to Serial COM
User Manual
Rev 1.5

i
2005-2017 © Innodisk Corporation. All Rights Reserved
Copyright Information
2005-2018 ©Innodisk Corporation. All Rights Reserved
Innodisk™ is trademark or registered trademark of Innodisk Corporation.
This document is subject to change and revision without notice. No part of this
document may be reproduced in any form by any photographic, electronic,
mechanical or other means, or used in any information storage and retrieval
system, without prior written permission from Innodisk Corporation.
All other product and brand names in this document are trademarks or
registered trademarks of their respective owners.
版權說明
2005-2018 ©宜鼎國際股份有限公司
Innodisk™ 是宜鼎國際股份有限公司之註冊商標。
本文件得不經通知即更改或修訂。本文件中出現任何文字敘述、文件格式、圖形、
照片、方法及過程等內容，除另特別註明，版權均屬宜鼎國際股份有限公司所有，
受到相關之智慧財產權保護法之保障。任何個人、法人或機構未經宜鼎國際股份
有限公司的書面（包括電子文件）授權，不得以任何形式複製或引用本文件之全
部或片段。
其他出現在本文件的品牌或產品乃歸屬原公司所有之商標或註冊。

ii
2005-2017 © Innodisk Corporation. All Rights Reserved
Revision History
Revision
Date
Description
1.0
2015/10/21
Initial Release
1.1
2016/10/4
Add products of EMP2-X4S1& EMP2-X4S2
1.2
2017/05/31
Remove EMP2-X401
1.3
2017/11/30
1. Add the product of EGP2-X401
2. Add a NOTE of Windows embedded in
section 1.1.
1.4
2018/03/08
Add NOTE of digital certificate for Windows
7 driver installation in section 1.1.
1.5
2018/4/11
Change file name to EMP2/EGP2.
1.6
2019/5/13
Modify 1.4, Half to Half/Full

iii
2005-2017 © Innodisk Corporation. All Rights Reserved
Table of Contents
Revision History..................................................................................................................ii
Table of Contents ...............................................................................................................iii
Overview..............................................................................................................................1
Windows.........................................................................................................................2
1.1. Install Driver .............................................................................................................2
1.2. Switch Mode by Software (for EMP2-X404/X801, EGP2-X401).................................4
1.3. Switch Mode by Hardware (for EMP2-X202/X402) ....................................................6
1.4. Enable RS-485 checkbox for RS-485 Half/Full Duplex Mode ....................................6
Linux...............................................................................................................................7
2.1. Install Driver.............................................................................................................7
2.2. Install EMP2 Mode-Control Tool................................................................................7
2.3. Switch Mode by Software (for EMP2-X404/X801, EPG2-X401).................................8
2.4. Switch Mode by Hardware (for EMP2-X202/X402) ....................................................9
Contact us .........................................................................................................................10

1
2005-2017 © Innodisk Corporation. All Rights Reserved
Overview
This manual describes how to implement EMP2 mPCIe to serial COM cards of
the following products.
Product No.
RS232
RS485HD
RS485FD
Switch Method
EMP2-X202
X
O
O
Hardware
EMP2-X402
X
O
O
Hardware
EMP2-X203
O
X
X
N/A
EMP2-X403
O
X
X
N/A
EMP2-X801
O
O
O
Software
EMP2-X404
O
O
O
Software
EMP2-X4S1
X
X
O
N/A
EMP2-X4S2
X
O
O
N/A
EGP2-X401
O
O
O
Software
Note: HD: Half Duplex, FD: Full Duplex

2
2005-2017 © Innodisk Corporation. All Rights Reserved
Windows
1.1. Install Driver
This section is applicable to ALL products.
Please notice that the driver name including “Adj” is for EMP2 -X404/X801 and
EGP2-X401. The driver name including “Fixed” is for
EMP2-X202/X203/X402/X403/X4S1/X4S2.
Double click the driver package to start. If driver is already existed in the OS, it
will be removed automatically before installation.

3
2005-2017 © Innodisk Corporation. All Rights Reserved
NOTE1: If you encounter an error while executing the driver, please download “Microsoft
Visual C++ Redistributable Package” then install first.
https://www.microsoft.com/en-us/download/details.aspx?id=29
NOTE2: Please confirm Window Embedded has included “windows generic multifunction card
driver” inbox driver.
This package would be “WinEmb-INF-mf.cab”.
You can add it by dism command online or WES ICE tool offline. Also you can modify the
existed template directly to add mf driver section.
NOTE3: Drivers for Windows 64bit need to be signed with digital certificate. The driver is
signed with SHA-2 certificate
Windows 7 must be installed the hotfix KB3033929 to support SHA-2 code signing.
https://technet.microsoft.com/en-ie/library/security/3033929

4
2005-2017 © Innodisk Corporation. All Rights Reserved
1.2. Switch Mode by Software (for EMP2-X404/X801,
EGP2-X401)
This section is applicable to following products.
Product No.
RS232
RS485HD
RS485FD
Switch Method
EMP2-X404
O
O
O
Software
EMP2-X801
O
O
O
Software
EGP2-X401
O
O
O
Software
In Device Manager, right click the mouse to enter “properties” in
“InnodiskMPIO-Access Device”.

5
2005-2017 © Innodisk Corporation. All Rights Reserved
In “COM Settings”, you can select different mode among RS232, Loopback,
RS485HD and RS485FD.

6
2005-2017 © Innodisk Corporation. All Rights Reserved
1.3. Switch Mode by Hardware (for EMP2-X202/X402)
This section is applicable to following products
Product No.
RS232
RS485HD
RS485FD
Switch Method
EMP2-X202
X
O
O
Hardware
EMP2-X402
X
O
O
Hardware
Switch mode between RS485 Half Duplex and Full Duplex by using DIP switch.
Please refer to the following picture:
1.4. Enable RS-485 checkbox for RS-485 Half/Full Duplex Mode
This section is applicable to ALL products.
In Device Manager, right click the mouse to enter “properties” in “Innodisk’s
Communications Port (COM“N”)”. (“N” depends on the setting of real
environment.)
In “Port Settings”, please check RS-485 checkbox when using RS-485 Half
and Full Duplex Mode
