Innotek Spray Bark Control User manual

INNOTEK®
Spray Bark Control
Operating Guide
Please read this entire guide before beginning.

2 1-800-826-5527
Quick Start Guide
Step 1 Adjust the collar
Step 2 Power Up
Proper Fit: e collar t should be snug, yet loose
enough to allow one nger to t between the strap
and the dog’s neck. Fit is important because a loose
collar may cause inconsistent performance. Trim any
excess strap length.
e collar should be o the dog for this step.
Insert battery, positive (+) side out.
Step 3 Fill the collar
e collar should be o the dog for this step. Be certain the collar
is turned OFF. Hold the Lemon Spray can upright and press nozzle
rmly into the Rell Port. Hold for 15 seconds and remove.
Step 4 Using the collar
Press the On/O button until the green LED illuminates; release the button.
Put the collar on your dog, with the spray nozzle facing toward the dog’s
snout and fasten the strap. Allow your dog to wear the collar for several
minutes then recheck the t. You should notice a reduction in your dog’s
barking within the rst couple of days that he wears the collar.
Important: e Bark Control Collar should not be worn for more
than 8 hours out of every 24 hour period.
15 seconds

www.innotek.net 3
Register Your Product:
Your product can be registered on our website at www.innotek.net.
IMPORTANT ADVICE
1. Read the complete manual and follow all directions. If you have any questions, please call
1-800-826-5527.
2. is device is intended for use only on dogs. Never attempt to use it for any purpose not
described in this manual.
3. An electronic collar should only be used under close supervision by the dog’s owner.
KEEP OUT OF THE REACH OF CHILDREN
4. Never perform set-up procedures while the collar is on your dog.
5. Any collar worn for extended periods can cause a condition similar to bedsores, known as
Pressure Necrosis. To reduce the possibility, you must do the following:
• Never leave the collar on the dog for more than 8 consecutive hours.
• Examine the dog’s neck daily for any signs of a rash or a sore.
• Supervise your dog closely during the rst 2 days of training.
• Check the t to prevent excessive pressure; you should be able to insert one nger
between the collar strap and your dog’s skin.
• Wash the dog’s neck area and the probe of the collar weekly with a wash cloth.
• If the condition persists beyond 24 hours, see your veterinarian.
6. Do not attempt to dismantle or repair any components of this system; doing so will void the
warranty in full. e computerized circuitry should be serviced only by an authorized expert.
7. is Product is designed for use with pets where training is desired. e specic
temperament of your pet may not work with this Product. We recommend that you not
use this Product if your pet is aggressive. If you are unsure whether this is appropriate for
your pet please consult your veterinarian or certied trainer.
Proper use includes reviewing the entire Guide provided with your Product and any
specic Caution statements.

4 1-800-826-5527
Table of Contents
Components............................................................................................ 5
Features.................................................................................................... 5
How the INNOTEK® Spray Bark Control Collar Works................... 6
Key Denitions ....................................................................................... 6
Fit the Bark Control Collar ................................................................... 7
Ensure a Proper Spray Pattern.............................................................. 8
To Insert and Remove the Battery........................................................ 8
Modes of Operation ............................................................................... 9
To Fill and Rell the Lemon Spray....................................................... 9
What to Expect During Use of the Bark Control Collar................. 10
Regular Maintenance ........................................................................... 10
Accessories ............................................................................................ 11
Frequently Asked Questions................................................................11
Troubleshooting.....................................................................................12
Terms of Use and Limitation of Liability........................................... 13
Product Warranty................................................................................. 13

www.innotek.net 5
Components
6-volt Alkaline
Battery (RFA-18)
INNOTEK®Bark
Control Collar
Operating Guide
Lemon Spray
(RFA-164)
INNOTEK
™
SprayBark Control
OperatingGuide
Pleasereadthis entireguide beforebeginning.
Features
• Nano Technology–the smallest Spray Bark Control Collar available
• Patented Perfect Bark™ detection ensures your dog’s bark is the only sound that will
cause the correction
• Adjustable collar for neck sizes up to 28"
• For dogs of all sizes
• All-natural lemon scent is safe and eective
• Waterproof
• Good/Low battery indicator
• 40 sprays per rell
• Low spray indicator
• On/O button

6 1-800-826-5527
How the INNOTEK® Spray Bark Control Collar Works
e INNOTEK® Spray Bark Control Collar eectively stops barking when it is worn. e Bark
Control Collar has a unique patented sensor that provides the most reliable bark detection
available. e Bark Control Collar uses both vibration and sound sensors (dual-detection) to
discriminate each bark from other external noises. A burst of lemon-scented spray is emitted to
deter barking only if both the vibration from vocal chords and the sound from the bark match
the same criteria.
Important:
• DO NOT attach a leash to the Bark Control Collar. You may put a
separate non-metallic collar on your dog’s neck and attach a leash. Note:
Be sure the extra collar does not interfere with the Sensor Probe.
• Your dog may wear a harness for attaching a leash and/or tags while
using the Bark Control Collar.
• Before playing with your dog, turn the unit o and remove the Bark
Control Collar. e activity may cause your dog to bark, which could
lead to him associating the play with the burst of spray.
• Never leave the Bark Control Collar on for more than 8 consecutive
hours.
_______________________________________________________
Key Denitions
Spray Nozzle: Where the spray
ejects when your dog’s bark is
detected.
Sound Activated Sensor: Detects
the sound of your dog’s bark.
Rell Port: Where the spray is
relled.
Yellow LED: Low spray indicator
Two Color LED: Shows good or
low battery
Spray Nozzle
Refill PortSound
Activated Sensor
On/Off Button
Two Color LED
Yellow LED
Sensor Probe
On/O Button: Turns the collar on and o, and resets the spray counter.
Sensor Probe: Detects the vibrations of your dog’s bark.
Note: e Sensor Probe is not adjustable.

www.innotek.net 7
Fit the Bark Control Collar
Important: e proper t and placement of your Bark Control Collar is important for
eective operation.
To assure a proper t, please follow these steps:
1. Make sure that the Bark Control Collar is turned o.
2. Start with your dog standing comfortably.
3. Place the Bark Control Collar high on your dog’s neck close to the ears.
Center the Sensor Probe underneath your dog’s neck, touching the skin.
Make sure the INNOTEK® logo in the front of the unit is upright.
YES
NO
Note: It is sometimes necessary to trim the hair around the
Sensor Probe to make sure that contact is consistent.
4. Check the tightness of the Bark Control Collar by inserting
one nger between the collar and the back of the dog’s neck.
e t should be snug but not constricting.
5. Allow your dog to wear the collar for several
minutes, then recheck the t. Check the t
again as your dog becomes more comfortable
with the Bark Control Collar.
6. Trim the collar as follows:
a. Mark the desired length of the collar with a
pen. Allow for growth if your dog is young
or grows a thick winter coat.
b. Remove the Bark Control Collar from
your dog and cut o excess.
c. Before placing the Bark Control Collar
back onto your dog, seal the edge of the
cut collar by applying a ame along the
frayed edge.
Important: e Bark Control Collar should
not be worn for more than 8 hours out of
every 24-hour period.

8 1-800-826-5527
Ensure a Proper Spray Pattern
For the INNOTEK® Spray Bark Control Collar to perform properly, the nozzle must be
positioned correctly and there must be a clear path from the Spray Nozzle to your dog’s snout.
Follow these steps:
1. Make sure the INNOTEK® logo on the front of the unit is
upright and the Spray Nozzle is angled out and pointing up
towards the dog’s snout.
2. For long-haired dogs, it may be necessary to trim the neck
hairs along the path of the spray. It is important that the
spray reaches the dog’s snout to be eective.
______________________________________________________________________________________
To Insert and Remove the Battery
Note: Do not install the battery while the Bark Control Collar is on your dog.
A replacement INNOTEK® battery (RFA-18) can be found at many retailers. Contact
the Customer Care Center at 1-800-826-5527.
Battery Life
Average battery life is 2 to 4 months, depending on how oen your dog barks.
However, due to greater use during your dog’s training, your rst battery may not last
as long as replacement batteries.

www.innotek.net 9
Modes of Operation
• To activate the unit, press the On/O Button until the
Green LED Light comes on and release. e Green LED
Light will ash once every 5 seconds.
• To turn the unit o, press the On/O Button and hold until
the Red LED Light ashes.
Note: e Yellow LED Light will ash briey before the Red
LED Light appears. is indicates the reset sequence.
Function and Response Table
Function LED Light Response
Unit is on Green LED Light ashes once every 5 seconds
Low battery condition Red LED Light ashes 3 times every 5 seconds
Low spray warning Yellow LED Light appears
_______________________________________________________
To Fill and Rell the Lemon Spray
• Remove the collar from your dog.
• Turn the unit o.
• Hold the Lemon Spray can upright and rmly press the
nozzle down into the Rell Port. Hold for 15 seconds
and remove. Note: If spray leaks out, you may need to
press harder to complete the seal.
• Turn the unit on.
Important: To reset the Spray Counter, press the On/O
Button until the Yellow LED Light comes on, and release
the button. e Green LED Light will resume to 1 ash
every 5 seconds.
15 seconds
Note: It is important that the On/Off Button be released immediately after theYellow
LED Light comes on or the unit will be turned off.

10 1-800-826-5527
What to Expect During Use of the Bark Control Collar
Important: Do not leave your dog alone the rst few times he wears the Bark
Control Collar.
Place the Bark Control Collar properly on your dog and wait nearby until he barks.
Most dogs will understand very quickly that the Bark Control Collar is disrupting
their urge to bark and will relax and stop barking. Because the burst of Lemon Spray
from the Bark Control Collar may be surprising or startling at rst, some dogs may
bark more at the initial correction.
On rare occasions, a dog may get into a bark-spray-bark-spray cycle. If this happens,
reassure your dog with calm, soothing tones. As your dog relaxes, he will understand
that if he becomes quiet, he will not receive any more spray bursts. e small minority of
dogs that have this reaction should only have it the rst time they wear the Bark Control
Collar.
You should notice a reduction in your dog’s barking within the rst couple of days
that he wears the Bark Control Collar. At this point, it is important to remember the
learning process is still not complete. Dogs will “test” this new learning experience and
will increase their attempts to bark. is usually occurs during the second week a dog
wears the Bark Control Collar. If this does occur, remain consistent and do not alter
your use of the Bark Control Collar. You must place the Bark Control Collar on your
dog in every situation when you expect him to be quiet. If your dog is not wearing the
Bark Control Collar, he may resume barking and his learning would suer a setback.
_______________________________________________________
Regular Maintenance
• For comfort, safety, and eectiveness of this product, please ensure that you check
the t of your pet’s collar frequently.
• e Bark Control Collar should not be worn for more than 8 hours out of every
24-hour period to prevent irritation. If any skin irritation is observed, discontinue
the use of the collar for a few days. If the condition persists beyond 48 hours, see
your veterinarian.
• e spray from the Bark Control Collar may stick to the hair under your dogs
snout. Clean your dog’s hair weekly with a washcloth and a mild hand soap. Rinse
and dry your dog’s neck thoroughly.
• If the spray accumulates on the Bark Control Collar, wipe the receiver clean with a
damp cloth and dry thoroughly.

www.innotek.net 11
Accessories
To purchase additional accessories for your INNOTEK® Bark Control Collar, contact
the Customer Care Center at 1-800-826-5527.
Component Part Number
Battery - one pack RFA-18
Lemon Spray Canister
(MSDS sheet available upon request)
RFA-164
Replacement Collar RFA-276
Frequently Asked Questions
Will my dog stop barking
completely?
• e Bark Control Collar eectively stops barking when it is
worn. It should only be worn during periods of unwanted
barking.
Will another dog’s bark set
o the Bark Control Collar?
• No.
Is the Bark Control Collar
safe and humane?
• Yes. e Bark Control Collar is designed to get your dog’s
attention, not to punish him.
Will the Bark Control Collar
work for my dog?
• e Bark Control Collar is safe and eective for all breeds
and sizes of dogs.
Is the spray harmful? • e lemon spray uses a lemon fragrance that dogs nd
unpleasant. It dissipates quickly and is safe for humans and
pets.
Will this work with long-
haired dogs?
• Yes. It may be necessary to trim the hair on your dog’s neck
so it does not block the spray from reaching his snout.
Does the spray need to hit
my dog’s nose?
• No. e spray is very ne and simply creates a mist in the
region of the snout.

12 1-800-826-5527
Troubleshooting
e Bark Control Collar
does not spray.
• Ensure that the battery is properly installed.
• Replace the battery.
• Rell the Lemon Spray.
• If the Bark Control Collar still does not spray, contact
the Customer Care Center at 1-800-826-5527.
My Bark Control Collar
sprays, but my dog
keeps barking (does not
respond to the burst of
spray).
• Tighten the Bark Control Collar and make sure the
Sensor Probe is centered on the front of the dog’s neck.
• Check to make sure the Spray Nozzle points towards
the dog’s snout.
• Make sure your dog’s hair does not block the spray. If
so, trim the hair so the spray can reach the snout area.
• If your dog still does not respond, contact the
Customer Care Center at 1-800-826-5527.
When I try to rell the
Lemon Spray, the spray
leaks out around the
Spray Nozzle.
• Hold the Lemon Spray can upright. If it is held at an
angle, it will not create a good seal.
• Press rmly on the Lemon Spray can to create a good
seal.
• If the spray continues to leak, contact the Customer
Care Center at 1-800-826-5527.

www.innotek.net 13
Terms of Use and Limitation of Liability
1. Terms of Use
is Product is oered to you conditioned upon your acceptance without modication
of the terms, conditions and notices contained herein. Usage of this Product implies
acceptance of all such terms, conditions, and notices.
2. Proper Use
is Product is designed for use with pets where training is desired. e specic
temperament of your pet may not work with this Product. We recommend that you not use
this Product if your pet is aggressive. If you are unsure whether this is appropriate for your
pet please consult your veterinarian or certied trainer.
Proper use includes reviewing the entire Guide provided with your Product and any
specic Caution statements.
3. No Unlawful or Prohibited Use
is Product is designed for use with pets only. is pet training device is not intended to
harm, injure or provoke. Using this Product in a way that is not intended could result in
violation of Federal, State or local laws.
4. Limitation of Liability
In no event shall Radio Systems® Corporation be liable for any direct, indirect, punitive,
incidental, special or consequential damages, or any damages whatsoever arising out of or
connected with the use or misuse of this Product. Buyer assumes all risks and liability from
the use of this Product.
5. Modication of Terms and Conditions
Radio Systems Corporation reserves the right to change the terms, conditions and notices
under which this Product is oered.
_______________________________________________________
Product Warranty
Please register your product online at www.innotek.net. All parts are covered under warranty
for ten (10) years. Labor is covered for the rst year of ownership. ereaer, there is a
minimum service charge for the repair or replacement of the product. Misuse, loss, damage
by pet or improper use or handling is not covered. INNOTEK® will not pay for loss of time,
inconvenience, loss of use of your product or any incidental or consequential damage.
Warranty void if product resold.
Please contact the Customer Care Center at 1-800-826-5527, if you need service or for
help in troubleshooting and, if needed, to arrange a repair or replacement for your product
(a service charge may apply). Also, please visit our website at www.innotek.net for Frequently
Asked Questions and Troubleshooting Tips.

14 1-800-826-5527

www.innotek.net 15

1-800-826-5527
www.innotek.net
Radio Systems Corporation
10427 Electric Avenue
Knoxville, TN 37932
1-800-826-5527
www.innotek.net
400-947/2
© 2007, Radio Systems Corporation
