innowi IWCHTB101 Troubleshooting guide
www.innowi.com
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
Note:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
Specific Absorption Rate (SAR) information:
This CB_UWA6N4C_47 meets the government's requirements for
exposure to radio waves. The guidelines are based on standards
that were developed by independent scientific organizations
through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure
the safety of all persons regardless of age or health.
FCC RF Exposure Information and Statement
Battery Service and Recycling
All rechargeable batteries have a limited lifespan and may
eventually need to be serviced or recycled. If the device needs to
be disposed for any reason, the device should be returned to
Innowi or its authorized dealer for proper decommissioning.
Support
For any question and comments, please contact your provider or
Mobile Badge
Quick Startup Guide
Mobile Workforce Solution
Wi-Fi 2.4G/5G, BT 4.0/5.0
Smart. Secure. Sophisticated. Simplified.
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue.
Device types: CB_UWA6N4C_47 (FCC ID: 2AO2Y-IWCHTB101) has also been
tested against this SAR limit. The highest SAR value reported under
this standard during product certification for use at the body is
1.241W/kg .This device was tested for typical body-worn operations
with the product kept 0mm from the body. To maintain compliance with
FCC RF exposure requirements, use accessories that maintain 0mm
separation distance between the user's body and the product.
The use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of accessories
that do not satisfy these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
Body-worn Operation
This device was tested for typical body-worn operations.
To comply with RF exposure requirements, a minimum separation
distance of 0mm must be maintained between the user’s body
and the device, including the antenna. Third-party belt-clips,
holsters, and similar accessories used by this device should
not contain any metallic components. Body-worn accessories that
do not meet these requirements may not comply with RF exposure
requirements and should be avoided. Use only the supplied or an
approved antenna.
www.innowi.com
mBadge © 2020 Innowi, Inc.
Setup
Quick Start Operations Guide
a) First connect the power adapter cable to the mBadge USB-C
connector and plug-in to the socket
b) Turn on the device by pressing the power button for a few
seconds. You will see the “Innowi” display screen turns on and
the device begins to power up
c) For queries related to device application please visit Innowi
website www.innowi.com
mBadge Features
Power Button
Volume Down Button
5" Display
Earpiece
Volume UP Button
Power LED
Rear Camera
Loud Speaker
Recommended Usage
mBadge device is recommended to be held in the dominant hand
and used with single hand for standard operations.
