5.25.17 06287I © Inovonics, 2017 - www.inovonics.com 3
6.6 RF network compatibility
EchoStream Commercial Mesh Network
6.7 Input Requirements
Caution: Input levels must not exceed 3.3 V.
Open When an active source (open collector or dry contact) is used to drive
the alarm or tamper input, the voltage should be between 0.75xVcc and
Vcc. A passive input should have an impedance of greater than 5.1k ohm
between the input and ground.
Closed When an active source is used, the voltage should be less than
0.25xVcc. A passive input should have an impedance of less than 240
ohm.
6.8 LED Requirements
The LED output is an active output from the microprocessor, with a 1k
series resistor to limit current draw. Default state is low, and the LED pin is
pulled high during transmit.
7 Specifications
Output power: 25mW.
Firmware revision: 90650, v3.1.
Countries in which Inovonics European products can be distributed:
Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Greece, Hungary, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania,
Slovakia, Slovenia, Spain, Sweden, United Kingdom.
8 Compliance Requirements
8.1 UL and cUL Requirements
The module holds a UL and cUL Recognized Component Mark and is
intended to be factory installed in another device, system or end-product.
The suitability of the module for use in a UL and/or cUL listed (certified)
device, system or end-product, is restricted as follows:
• The EN1941 was evaluated as a UL/cUL Recognized Component
compliant to selected requirements from UL639, ULC-S306-03,
UL1076, ULC/ORD-C1076 and UL1610 as specified in the Conditions
of Acceptability of the UL Report.
• The Supply Line Transient tests shall be added to the RAC UL
evaluation program if it is powered by an AC/DC adapter rather than a
low voltage battery.
• If intended use includes UL1610, UL1076 or UL639 installations, the
RAC shall be evaluated for Short Range RF Device tests.
• Compatible UL receivers (except for UL 2560) include EN4216MR,
EN4232MR and EN7285. Refer to the EN4216MR Installation and
Operation Manual, the EN4232MR Installation and Operation Manual
or the EN7285 Installation Instructions.
• The EN1941-60 is a UL2560 unlisted component.
• The compatible receivers for UL 2560 installations are the EN6080
area control gateway and EN6040-T network coordinator. Refer to the
EN6080 Area Control Gateway Installation Instructions and the
EN6080 Area Control Gateway User Manual, or the EN6040-T
Network Coordinator Installation Instructions.
• The compatible repeater for UL 2560 installations is the EN5040-20T.
• When selecting frequency band, only devices set for use in North
America are configured for UL and cUL installations.
• In a UL 2560 installation, the EN1941-60 one-way binary RF module
may be used with completed emergency call systems for assisted
living and independent living facilities
• For UL 2560 certified system installations, the following Inovonics
EchoStream devices are approved for installation within maximum
system configuration limits defined in section 1.1 of this document:
- EN6080 area control gateway or EN6040-T network coordinator.
- EN5040-20T high power repeater.
- End devices (transmitters) with a minimum 60-minute check-in
interval, as follows:
Fundamental devices which are subject to UL2560 certification
(pendant transmitters and OEM products using the Inovonics RF
module)
Supplemental devices which are not subject to UL2560 system
certification but which may be used within a UL2560 certified
system (e.g. universal transmitters and activity sensors)
• Users that have achieved certification and will install UL 2560 certified
systems are responsible for labeling all fundamental devices with the
UL 2560 system certification mark.
8.2 FCC Requirements for the RF Module
The one-way binary RF module has received a Limited Modular Grant,
requiring Inovonics to retain control of the final installation to ensure
compliance to FCC/IC regulations. The integrator is responsible to test the
final installation to verify compliance to FCC/IC regulation for unintentional
emissions. Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Prior to marketing the product, the integrator must complete and submit to
Inovonics a compliance review form and documentation, and, if requested,
a functional product sample for approval. If this is not possible, the
integrator must perform the testing themselves and submit proof to
Inovonics of compliance to Part 15 of the FCC Rules and Industry Canada
RSS-210.
At the end of this guide is an Inovonics compliance review form to be filled
out by the integrator.
The integrator is also responsible for properly labeling the product
containing the one-way binary RF module. Labels must be placed on the
outside of the product, and must include a statement indicating that the
product contains the module, along with the FCC and IC number.
Example 1 “Contains One-Way Binary RF Module
FCC ID: HCQ3B6OT9OEM; IC ID: 2309A-OT9OEM (EN1941-IC)”
Example 2 “Contains FCC ID: HCQ3B6OT9OEM; IC ID: 2309A-OT9OEM
(EN1941-IC)”
8.3 Television and Radio Interference
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
9 FCC Part 15 and Industry Canada Compliance
This device complies with part 15 of the FCC Rules and Industry Canada
license-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
9.1 CE Label Requirements for EE1941
Inovonics Wireless has received European Telecommunications Standards
Institute approval to market one-way binary RF modules, and they are
manufactured to be RoHS compliant. The integrator is responsible for
properly labeling the product containing the one-way binary RF module.
Labels must be placed on the outside of the product, and must include the
CE logo.
Note: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
10 Simplified Declaration of Conformity
Hereby, Inovonics declares that the radio equipment type EE1941 is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following
Internet address: www.inovonics.com
