Insignia NS-37L760A12 User manual

Composite video
and analog audio
AUDIO/VIDEO
OUT
CABLE
Identifying cables
YourTV has several connection types for connecting devices. For the best video quality,
connect a device to the best available connection.
You can use the HDMI 1 jack to connect a DVI device to yourTV. You need to attach an
HDMI-to-DVI adapter to the end of the HDMI cable that connects to the DVI device’s jack.
Connection type Video quality Cable connector
HDMI video/audio Best
Component video
and analog audio
Better
Good
OR
OR
AUDIO/VIDEO
OUT
Front features
Installing the stand
1Carefully place yourTV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2A lign and insert the base into the stand.
3 Secure the stand to TV with the four provided screws.
Installing a wall-mount bracket
1 Carefully place yourTV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2 Remove the four screws that secure the base to the stand, then remove the base.
3 Remove the four screws that secure the stand column, then remove the column.
4 Attach the wall-mount bracket to yourTV using
the mounting holes on the back of yourTV. See
the instructions that came with the wall-mount
bracket for information about how to
correctly hang yourTV.
Connecting a DVD or Blu-ray
player, cable box, satellite receiver, camcorder,
or game station
Using an HDMI cable (best)
Using component cables (better)
Using composite cables (good)
Connecting an antenna/cable wall jack
Connect a coaxial cable (not included) to the ANT/CABLE jack on the back of
yourTV and to the Antenna/Cable wall jack.
37" 1080p LCD HDTV
QUICK SETUP GUIDE
NS-37L760A12
Thank You
for purchasing this ne Insignia television. We hope you
enjoy the quality and reliability of this product for years
to come.
_______________________________
Remote control
and 2 AAA
batteries
Component
Video Cable
TV stand and 4 screws
Audio cable
Power cable
WE ARE GOING GREEN!
A copy of your User Guide is not provided in
the box but is available online.
Go to www.insigniaproducts.com, click
Support & Service, enter your model
number in the Product Search eld,
then click Search.
Remote
control sensor
Power
indicator
This apparatus is intended to be
supported by a UL Listed
wall mount bracket.
Warning
Please Note: Video cable(Yellow)
connects to Y/Video (Green).
Cleaning cloth

37" 1080p LCD HDT V IQUICK SETUP GUIDE I NS-37L760A12
AUDIO IN
OPTICAL
AUDIO IN
Antenna or
cable TV
(no box)
Blu-ray player/DVD player/VCR Cable or satellite TV box
AV receiver
Game console
or camera
USB ash drive
Computer
OK
ENTER
MENU EXIT
PICTURE AUDIO CHANNELS SETTINGS USB
Mode
Brightness
Contrast
Color
Tint
Sharpness
Energy Savings
48
50
60
0
+10
MOVE EXIT
PREVIOUS
SELECT
Adjust settings to affect picture quality
OK
ENTER
MENU EXIT
Reduces total power consumption
Home Mode
Retail Mode
MOVE EXIT
PREVIOUS
SELECT
Choose Your Picture Mode
OK
ENTER
MENU EXIT
Digital Channels
Analog Channels
Scan for digital channels
Choose Your TV Source
Antenna
Cable
Cable/Satellite Box
0
MOVE EXIT
PREVIOUS
SELECT
Channel scan may take 20+ minutes
0
OK
ENTER
MENU EXIT
Mode
Time Zone
Daylight Savings
Year
Month
Day
Time
If Automatic, options are automatically set by TV source
MOVE EXIT
PREVIOUS
SELECT
Choose Your Time Setting
Manual
Pacific
On
2011
Jan
1
12:25 AM
OK
ENTER
MENU EXIT
English
Français
Español
Choose Your Menu Language
MOVE EXIT
PREVIOUS
SELECT
Set menu language to English, Français, or Español
TV
VGA
HDMI 1
HDMI 2
USB
Input Source
Component/AV
HDMI 3
Universal remote TV codes
Universalremotecontrols Cable/Satellite/Set-topboxes
One for All Philips RCA Sony Cablevision Charter Comcast Cox Direct TV Dish Network Time Warner Tivo Verizon
0054 0198,
0490 135
1326,
1463
0198,
0490
400, 450, 461, 456,
10463, 1463, 0463
0091
068, 069, 078,
096, 100, 164,
168, 229, 026
2002, 1204, 1423, 1517,
0171, 1963, 0463, 1463,
0842, 1326, 167, 415,
424, 450, 456, 461, 507,
523, 567, 577, 586
10171, 11204,
11326, 11517,
11564, 11641,
11963, 12002
720
068, 069,
078, 096,
100, 164,
168, 229,
026
10171, 11204, 11326,
11463, 11517, 11641,
11780, 11785, 11892,
11963, 12002
Connecting a HomeTheater System
Using Digital audio
Using Analog audio
Connecting power
Plug the AC power cord into the AC IN jack on the back of yourTV,
then plug the other end of the
cord into a power outlet.
Two-year limited warranty
Visit www.insigniaproducts.com for details.
Need additional help?
See your Online User Guide! This
comprehensive guide includes everything from
basic how-to steps to more advanced features.
A copy of your User Guide is not provided in
the box but is available online. Go to
www.insigniaproducts.com, click Support
& Service, enter your model number in the
Product Search eld, then click Search.
Check out our online community forum at
www.insigniaproducts.com for helpful
information from other InsigniaTV owners.
We’re here for you
www.insigniaproducts.com
For customer service, call:
877-467-4289 (U.S./Canada markets)
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richeld, MN USA
55423-3645
© 2011 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions,
Inc. Registered in some countries. All other products and
brand names are trademarks of their respective owners.
ENGLISH 11-0056
Setting up and using your remote control
1Press the release button on the back of the remote to remove the battery compartment cover.
2Insert two AAA batteries into the battery compartment. Make sure that the + and – symbols on the batteries match the + and – symbols in the battery compartment.
3Replace the cover.
Turning on your TV for the rst time
1Connect the power cord to yourTV and to a power outlet, then press （power）.
The power indicator turns blue and the Choose Your Menu Language screen opens.
2
Press ▲or ▼ to highlight a language, then press ENTER.
The Choose Your Time Setting screen opens with Mode highlighted.
3 Press ◄or ► to select Auto or Manual. If you select Auto, the date and time are
set automatically from a digitalTV signal. If you select Manual, you can manually
set the date and time. Press ENTER. The Choose Your Picture Mode screen opens.
4Press
▲or ▼ to highlight Home Mode or Retail Mode, then press ENTER. If
you select Retail Mode, a message asks you to conrm your selection. Select Yes
or No. Retail Mode
is not an energy-saving mode. The ChooseYourTV Source screen opens.
5 Press ▲or ▼ to highlight Antenna, Cable, or Cable/Satellite box. If you select
Antenna or Cable, your TV scans for available channels. The scan may take
several minutes. If you select Cable/Satellite box, yourTV does not
scan for channels.
RECALL
Returns to the previous channel.
Arrows
Navigate in on-screen menus.
EXIT
Closes the on-screen menu.
INFO
Opens a TV status banner.
CCD
Turns closed captioning on or o.
FAVORITE
Opens the Favorite Channel list.
MUTE
Mutes the sound.
Channel
Changes theTV channels.
Selects the video modes.
MTS/SAP
Cycles through mono, stereo, and
secondary audio for analog programs.
AUDIO
Selects the audio modes.
Programming your remote control
To program your universal remote control to work with your new InsigniaTV, see the table for common codes. If you have problems programming your remote or
need a dierent remote control code, visit www.insigniaproducts.com for the latest remote control code information.
Power
Turns yourTV on or o.
Quick Launch Inputs
Selects another source
connected to yourTV.
Numbers
Enter channel numbers.
.
Enter a digital sub-channel
number (such as 4.1).
ENTER
Conrms selections or
changes.
MENU
Opens the on-screen menu.
GUIDE
Displays the program guide.
INPUT
Opens the source list.
CH-LIST
Opens the channel list.
Volume
Changes the volume.
SLEEP
Sets the sleep timer.
ZOOM
Changes how the picture
displays on the screen.
Connecting a home theater system with multiple devices
When connecting to an AV receiver
with ARC function, we recommend
that you connect the AV receiver’s
HDMI OUT jack to yourTV’s HDMI2
(ARC) jack by using an HDMI-ARC
compliant cable.
In the following situations, the
HDMI cable will route Dolby Digital
audio to the AV receiver, so you do
not need to connect a separate
digital audio cable:
• Have a game console connected
to one of yourTV’s
HDMI 1/HDMI3 jacks.
• When you watch a program
through an antenna or cable
TV connected to the
ANT/CABLE jack.
Media Controls
Controls HDMI-CEC devices
connected to yourTV.
Normal:
Displays the original aspect ratio with black bars
vertical on the left and right hand side of the screen.
Display 4:3 if input source is 480i, 480p
Display 16:9 if input source is 720p, 1080i,1080p
Zoom:
Expands the image to ll the screen. The top and bottom of the
image may be cropped.
Wide:
Use this option to view content recorded in a 16:9 (wide-screen) aspect ratio.
Cinema:
Stretches the image at the edges, but keeps a clear image in the center.
Auto:
Automatically adjusts the image based on the screen size and the TV
program. Note: Auto is only available when Auto Zoom in the
CHANNELS menu is set to On.
Aspect ratio options
