Insignia NS-BBBT20 User manual

Before using your new product, please read these instructions to prevent any damage.
USER GUIDE
Multi-Function Stereo
Boombox with Bluetooth
NS-BBBT20

www.insigniaproducts.com
2
Contents
Welcome. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting up your boombox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using your boombox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Maintaining your boombox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Welcome
Congratulations on your purchase of a high-quality Insignia product. Your
NS-BBBT20 represents the state of the art in boomboxes and is designed for
reliable and trouble-free performance.
Safety information
To prevent fire or shock hazard, do not plug the power cord into an extension
cord, receptacle, or other outlet unless the blades can be fully inserted to prevent
blade exposure. To prevent fire or shock hazard, do not expose this boombox to
rain or moisture.
Surge protectors:
We recommend that you use a surge protector when you use the AC power cord
with this boombox. Lightning and power surges ARE NOT covered under the
warranty for this product.
The lightning flash with arrowhead symbol within a triangle is
intended to alert you to the presence of uninsulated dangerous
voltage within your boombox’s enclosure that may be of sufficient
magnitude to constitute risk of electric shock to persons.
CAUTION: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer
servicing to qualified service personnel.

3
Multi-Function Stereo Boombox with Bluetooth
www.insigniaproducts.com
The exclamation point within a triangle is intended to alert you to the
presence of important operating and maintenance (servicing)
instructions in the literature accompanying your boombox.
Read instructions
Read all of the safety and operating instructions before you use your boombox.
Retain instructions
Retain the safety and operating instructions for future reference.
Follow warnings and instructions
Follow all warnings on your boombox and in the operating instructions. Follow all
operating and use instructions.
Placement
When placing your boombox on a lacquered or natural finish, protect your
furniture with a cloth or other protective material.
Avoid exposure to direct sunlight, temperature extremes, and moisture.
Your boombox uses a Class 1 laser to read
Compact Discs. Your boombox is equipped
with safety switches to avoid exposure when
the CD door is open and the safety interlocks
are defeated. Invisible laser radiation is
present when the CD door is open and the
system's interlock has failed or been
defeated. You should avoid direct exposure
to the laser beam at all times. Do not attempt
to defeat or bypass the safety switches.
WARNING: To reduce the risk of fire or electric shock, do not expose your
boombox to rain or moisture.
WARNING: Any use of the controls or an adjustment to the procedures other
than those specified herein may result in hazardous radiation.
CAUTION: Any change or modification to your boombox not expressly
approved by Insignia or its authorized parties could void your authority to
operate your boombox.
CAUTION: Your boombox should not be exposed to water (dripping or
splashing) and no objects filled with liquids, such as vases, should be placed on
it.

4
NS-BBBT20
www.insigniaproducts.com
Ventilation
Slots and openings in the cabinet and the back or bottom are provided for
ventilation, reliable operation, and protection from overheating. These openings
must not be blocked or covered. Do not block the openings by placing your
boombox on a bed, sofa, rug, or other similar surface.
Water and moisture
Do not use your boombox near water. For example, do not use it near a bath tub,
wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming
pool.
Do not let water splash or drip onto your boombox. Do not place objects
containing liquids, such as a vase, on top of your boombox.
Disconnecting power
The AC adapter is used as the disconnect device. It should remain readily
accessible and should not be obstructed during use. To completely disconnect
power, the AC adapter should be unplugged from the AC power outlet
completely.
The rating label of the boombox is located on the bottom.
Features
• Features Bluetooth, AM/FM radio, CD player, cassette player, and 3.5 mm
auxiliary input for the ultimate playback flexibility
• Blue backlit display for input and status
• Powerful stereo speakers for great sound, along with a headphone jack for
private listening
• 10 preset stations each for AM and FM radio
• CD player plays CD-R/RW media
• Can be powered by AC adapter (included) or 6 D-cell batteries (not included)
• Compact form factor allows for easy transportation and fits in tight spaces
Package contents:
• Boombox
• AC Adapter
• User Guide
• Quick Setup Guide

5
Multi-Function Stereo Boombox with Bluetooth
www.insigniaproducts.com
Front panel
# ITEM DESCRIPTION
1MEM button In radio mode, press to create/select preset stations.
2(stop/pairing) button • In CD mode, press to stop playback.
• In Bluetooth (BT) mode, press to initiate pairing.
Press again to turn Bluetooth off.
3(play/pause) button Press to begin CD or Bluetooth playback. Press
again to pause playback.
4Standby/ON button Press to turn on your boombox. Press again to
return your boombox to standby mode.
5(source) button Press to cycle through the sound sources
(CAS>AUX>RADIO>CD>BT>CAS).
6 Cassette tape control
buttons
These buttons control tape playback. See Top panel
on page 7 for additional information.
7VOLUME–/+ button Press to lower or raise the volume. Press and hold to
lower or raise the volume quickly.
VOLUME

6
NS-BBBT20
www.insigniaproducts.com
8(next) button In radio mode, press to tune to the next higher
station.
In CD or Bluetooth mode, press to search/skip to
the next track.
9(previous) button In radio mode, press to tune to the next lower
station.
In CD or Bluetooth mode, press to search/skip to
the previous track.
10 BAND/PLAY MODE
button
In radio mode, press to select the radio band (AM or
FM).
In CD mode, press to cycle through the playback
modes (repeat 1, repeat all, or random).
11 Display Shows the radio band, playback mode, program
mode, source, volume level, and radio frequency.
For additional information, see Display on page 9.
12 Cassette door Open to insert a cassette tape into the boombox for
playback.
13 Left and right speakers Produce sound so you can listen to your boombox.
# ITEM DESCRIPTION

7
Multi-Function Stereo Boombox with Bluetooth
www.insigniaproducts.com
Top panel
#Item Description
1 PAUSE button Press to pause the cassette tape playback. Press
again to resume playback.
2 STOP/ EJECT button Press to stop cassette tape playback. Press
again to open the cassette door.
3FWD button Press to fast forward the cassette tape.
4REW button Press to rewind the cassette tape.
5PLAY button Press to begin cassette tape playback.
6 PRESS TO OPEN Press to open the CD door.
7 CD door Open to place a CD on the spindle for playback.
8 REC button Press to begin cassette tape recording.

8
NS-BBBT20
www.insigniaproducts.com
Back panel
# Item Description
1 FM antenna wire Provides an improved FM signal. Do not
connect to an outside antenna.
2AUX IN jack Connect an external audio device to this jack.
3 Headphone jack Connect headphones to this jack to listen to
radio/playback through your headphones.
4AC IN jack Connect the AC adapter (included) to this jack
to operate your boombox on AC power.
5 Battery compartment Insert six (6) “D” sized alkaline batteries (not
included) into this compartment to operate
your boombox on battery power.
AC ~

9
Multi-Function Stereo Boombox with Bluetooth
www.insigniaproducts.com
Display
In CD mode—the display shows the current track time elapsed (during playback)
and the total number of tracks (in stop mode).
In Radio mode—the display shows the preset selected and the frequency.
In Tape mode—the display shows “CAS.”
In Bluetooth mode—the display shows “BT.”
In AUX mode—the display shows “Aud.”
Setting up your boombox
Connecting the AC adapter
1Make sure that your local AC power source matches the voltage shown on the
plate located on the bottom of the boombox. If it does not, consult your
dealer or service center.
2Insert the small connector at the end of the AC adapter into the AC IN jack on
the back of your boombox.
3Plug the AC adapter into a wall power outlet.
Installing the batteries
1Turn your boombox over, then open and remove the door to the battery
compartment.
CAUTION: To protect your boombox during thunderstorms, unplug the AC
adapter from the AC power outlet.
Notes:
Unplug the AC adapter when not in use.
The batteries are automatically bypassed when the AC adapter is used.
- Power Electrical Specs: 120V ~ 60 Hz
- Device Electrical Specs: 10 VAC, 1.0 A
Radio band
Random
playback
activated
Radio program mode
activated
Repeat mode:
On (1)–repeat current
track
On (no 1)–repeat all
tracks
Tuner frequency unit
Source, volume level, or program
FM Stereo
signal
indicator

10
NS-BBBT20
www.insigniaproducts.com
2Insert six (6) “D”size alkaline batteries into the battery compartment. Make
sure that you match the + and – symbols on the batteries with the + and –
symbols in the battery compartment.
3Reinstall and close the battery compartment door and return your boombox
to the upright position.
Connecting headphones
• Plug the headphones (not included) into the headphone jack on the back of
your boombox.
Using your boombox
Playing the radio
1Press (Standby/ON) to turn on the boombox.
2Press (source) repeatedly to select RADIO mode, then press BAND to
select AM or FM.
3Press (next) or (previous) to tune the radio to a higher or lower
frequency.
4Press and hold (next) or (previous) for two seconds to automatically
tune to the next or previous station.
5Adjust the volume to a comfortable level by pressing either the VOLUME + or
VOLUME – button.
6Press (Standby/ON) to turn off the boombox.
Note: The AC adapter must be disconnected from both the AC IN jack on the
back of your boombox and the AC power outlet in order for your boombox to
operate on battery power.
CAUTIONS:
Follow these precautions when using batteries in this device:
• Use only the size and type of batteries specified.
• Make sure that you follow the correct polarity as indicated in the battery
compartment when installing batteries. Reversed batteries may cause
damage to your boombox.
• Do not mix different types of batteries together (for example, alkaline,
rechargeable, and carbon zinc), or semi-used batteries with fresh ones.
• If your boombox is not to be used for a long period of time, remove the
batteries to prevent damage or injury from possible battery leakage.
• Do not try to recharge batteries not intended to be recharged, because they
can overheat and rupture. (Follow battery manufacturer’s directions.)
• Do not throw batteries into a fire. Dispose of used batteries as hazardous
waste.
CAUTION: Listening to music with the volume too loud can damage your
hearing. Before you connect headphones, turn the volume down. After you put
on the headphones, gradually increase the volume to a comfortable level.
