Insignia NS-42E470A13A User manual

Y / VIDEO
P B P R L R
Y / VIDEO
P B P R L R
Y / VIDEO
P B P R L R
Video
COMPONENT
OUT
AUDIO/VIDEO
OUT
Note: Cable is not provided.
Note: Cables are not provided.
Connect
the yellow
connector to the
green Y/VIDEO jack. Note: Cable is not provided.
Front features
Installing the stand
1Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2
Hook the slot in the base onto the tab on the stand column (A), then push the base into place (B).
3 Secure the base to the stand column with the four short screws (provided).
Installing a wall-mount bracket
1 Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2
Remove the four screws that secure the stand column to the TV screen, then
remove the stand.
3 Secure the stand cover to the back of the TV screen using the four screws you just
removed.
4
Attach the wall-mount bracket to your TV using the mounting holes on the back of your
TV. See the instructions that came with the wall-mount bracket for information about
how to correctly hang your TV.
Connecting a DVD or Blu-ray player, cable box,
satellite receiver, camcorder, or game station
Using an HDMI cable (best)
Using component cables (better)
Using a composite cable (good)
Connecting to an antenna/cable wall jack
Connect a coaxial cable (not included) to the ANT/CABLE IN jack on the
back of your TV and to the Antenna/Cable wall jack.
Connecting a Home Theater System
Using digital audio
Using analog audio
Connecting power
Plug the AC power cord into the AC IN jack on the
back of your TV, then plug the other end
of the cord into a power outlet.
42" 1080p LED HDTV
QUICK SETUP GUIDE
NS-42E470A13A
Thank You
for purchasing this ne Insignia television.
We hope you enjoy the quality and reliability
of this product for years to come.
_______________________________
Remote control
and 2 AAA
batteries
Remote
control sensor
Power
indicator
TV stand
CABLE
Note: Cable is not provided.
WE ARE GOING GREEN!
A copy of your User Guide is not provided
in the box but is available online.
Go to www.insigniaproducts.com,
click Support & Service, enter your model
number in the Product Search eld,
then click Search.
Stand cover
Power cord
Identifying cables
Your TV has several connection types for connecting devices. For the best video quality,
connect a device to the best available connection.
You can use the HDMI 1/DVI jack to connect a DVI device to your TV. You need to attach an
HDMI-to-DVI adapter to the end of the HDMI cable that connects to the DVI device’s jack.
Connection type Video qualityCable connector
HDMI video/audio Best
Component video
and analog audio
Better
Good
OR
OR
This apparatus is intended to be supported by a UL Listed wall mount bracket.
Warning
Composite video
and analog audio
M4 (12 mm) screws (4)
A
B

Y / VIDEO
P B P R L R
Programming your remote control
To program a universal remote control to work with your new Insignia TV, see the table for common codes. If you have problems programming your remote or need a
dierent remote control code, visit www.insigniaproducts.com/remotecodes for the latest remote control code information.
Universal remote TV codes
42" 1080p LED HDTV IQUICK SETUP GUIDE I NS-42E470A13A
Antenna or
cable TV
(no box)
Blu-ray player/DVD player/VCR Cable or satellite TV box
AV receiver
Game console
or camera
USB ash drive
Computer
OPTICAL
AUDIO IN
Universal remote TV codes
Universal remote controls Cable/Satellite/Set-top boxes
One for All Philips RCA Sony Cablevision Charter Comcast Cox Direct TV Dish Network Time Warner Tivo Verizon
0054 0198,
0490 135
1326,
1463
0198,
0490
400, 450, 461, 456,
10463, 1463, 0463
0091
068, 069, 078,
096, 100, 164,
168, 229, 026
2002, 1204, 1423, 1517,
0171, 1963, 0463, 1463,
0842, 1326, 167, 415,
424, 450, 456, 461, 507,
523, 567, 577, 586
10171, 11204,
11326, 11517,
11564, 11641,
11963, 12002
720
068, 069,
078, 096,
100, 164,
168, 229,
026
10171, 11204, 11326,
11463, 11517, 11641,
11780, 11785, 11892,
11963, 12002
Note: Cable is not provided.
Note: Cable is not provided.
Front features
Installing the stand
1Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2
Hook the slot in the base onto the tab on the stand column (A), then push the base into place (B).
3 Secure the base to the stand column with the four short screws (provided).
Installing a wall-mount bracket
1 Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2
Remove the four screws that secure the stand column to the TV screen, then
remove the stand.
3 Secure the stand cover to the back of the TV screen using the four screws you just
removed.
4
Attach the wall-mount bracket to your TV using the mounting holes on the back of your
TV. See the instructions that came with the wall-mount bracket for information about
how to correctly hang your TV.
Connecting a DVD or Blu-ray player, cable box,
satellite receiver, camcorder, or game station
Using an HDMI cable (best)
Using component cables (better)
Using a composite cable (good)
Connecting to an antenna/cable wall jack
Connect a coaxial cable (not included) to the ANT/CABLE IN jack on the
back of your TV and to the Antenna/Cable wall jack.
Connecting a Home Theater System
Using digital audio
Using analog audio
Connecting power
Plug the AC power cord into the AC IN jack on the
back of your TV, then plug the other end
of the cord into a power outlet.
ENGLISH 12-0535
Connecting a home theater system with multiple devices
One-year limited warranty
Visit www.insigniaproducts.com for details.
Need additional help?
See your Online User Guide! This
comprehensive guide includes everything from
basic how-to steps to more advanced features.
A copy of your User Guide is not provided in
the box but is available online. Go to
www.insigniaproducts.com, click Support
& Service, enter your model number in the
Product Search eld, then click Search.
Check out our online community forum at
www.insigniaproducts.com for helpful
information from other Insignia TV owners.
We’re here for you
www.insigniaproducts.com
For customer service, call:
877-467-4289 (U.S./Canada markets)
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richeld, MN USA 55423-3645
© 2012 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions,
Inc. Registered in some countries. All other products and
brand names are trademarks of their respective owners.
