EVOLUTION SEPTIC ASSIST
FOOD WASTE DISPOSER DESIGNED FOR SEPTIC SYSTEM
TRITURADOR DE DESPERDICIOS DE ALIMENTOS DISEÑADO PARA SISTEMAS SÉPTICOS
®
www.insinkerator.com
®
75497 Rev A

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
! Read all warnings before proceeding.
! Lea todas las advertencias antes de continuar.
Dimensions/Dimensiones
8 3/4”
5 3/4”
12 5/8”
4”
6 11/16”
2
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
SoundSealTM
Technology
Quiet Collar®Sink Baffle
Anti-Vibration Mount®
Anti-Vibration
Tailpipe Mount™
SoundLimiter™Insulation
GrindShear Ring®
Quick-Lock®Sink Mount
Stainless Steel
Grind Components
3/4 HP Heavy Duty
Dura-Drive®Motor
Bio-Charge®Technology
Multi GrindTM
Technology
Sound SealTM
Deflector del fregadero
Quiet Collar®
Anti-Vibration Mount®
Anti-Vibration
Tailpipe Mount™
Aislamiento SoundLimiter™
GrindShear Ring®
Montaje del fregadero
Quick-Lock®
Componentes de trituración
de acero inoxidable
Motor Dura-Drive®de
3/4 HP para trabajos pesados
Bio-Charge®Tecnología
Multi GrindTM
Tecnología
Tecnología
The Evolution Series® by InSinkErator® is a new standard in sound and grind performance. Featuring exclusive
patented SoundSeal™ and MultiGrind™ technologies, no food waste disposer grinds more with less noise.
Evolution Series® de InSinkErator® es el nuevo estándar dentro de la tecnología de conductos y trituración. Con
las exclusivas tecnologías SoundSeal™ y MultiGrind™, ningún triturador de desperdicios tritura más con menos
ruido.

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
A
N
M
B
D
E
F
I
G
Includes/Incluye
O
Stopper
Tapón
Quiet Collar®
Sink Baffle
Deflector del
fregadero Quiet Collar®
CSink Flange
Brida del fregadero
Fiber Gasket
Junta de fibra
Backup Flange
Brida de apoyo
Mounting Ring
Anillo de montaje
1 1/2” Screws
Tornillos de 1 1/2”
(3,81 cm)
H1 1/8” Screws
Tornillos de 1 1/8"
(2,85 cm)
Snap Ring
Anillo de cierre
Discharge Tube
Tubo de descarga
Discharge Tube
Tubo de descarga
Bio-Charge®Bottle
Botella Bio-Charge®
Lower Mounting Ring
Anillo de montaje inferior
Anti-Vibration Mount®
Anti-Vibration Mount®
Dishwasher Inlet
Entrada del lavavajillas
Anti-Vibration
Tailpipe Mount™
Anti-Vibration
Tailpipe Mount™
Plumbers putty
Masilla de plomería
Wire Nuts
Tuercas para conectores
Cable Connector
Conector para cable
Not Included/No incluidos
Tools and Materials/Herramientas y materiales
KJam-Buster™ Wrench
Llave Jam-Buster™
Spring Type Hose Clamp
Abrazadera de manguera
tipo resorte
L
Failure to use the spring type
hose clamp provided voids warranty./
La garantía pierde validez si no usa la
abrazadera de manguera tipo resorte
incluida.
Disposer/Triturador
J
3

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
4
Disconnect drain trap from waste discharge
tube. Disconnect dishwasher if connected to
the disposer.
Desconecte la trampa de desagüe del tubo
de descarga de desperdicios. Desconecte el
lavavajillas si está conectado al triturador.
SHOCK HAZARD
Turn off electric power at fuse box or
circuit breaker.
PELIGRO DE DESCARGA ELÉCTRICA
Desconecte el suministro eléctrico
desde la caja de fusibles o del
interruptor de circuito.
WARNING
If you are replacing an
existing disposer, continue
to Step 2. If there is no
existing disposer, disconnect
sink drain and skip to Step 10.
Si tiene que reemplazar un triturador
existente, continúe con el Paso 2. Si no
existe un triturador, desconecte el
desagüe del fregadero y continúe con
el Paso 10.
1
Support disposer, insert end of Jam-
Buster™ Wrench (K) into right side of
mounting lug, and turn. Disposer will fall
free.
Apoye el triturador, inserte el extremo
de la Llave Jam-Buster™ (K) en el lado
derecho de uno de los salientes de
montaje y gire. El triturador se liberará.
*WARNING: SHOCK HAZARD
With the electrical supply turned off, flip
disposer over and remove electrical cover
plate. Save cable connector if applicable.
*ADVERTENCIA: PELIGRO DE
DESCARGA ELÉCTRICA. Con la energía
eléctrica apagada, voltee el triturador y
retire la placa de la cubierta eléctrica.
Guarde el conector del cable si corre-
sponde.
*WARNING: SHOCK HAZARD
With the electrical supply turned off,
disconnect the disposer wires from the
electrical supply.
*ADVERTENCIA: PELIGRO DE DESCARGA
ELÉCTRICA. Con la energía eléctrica
apagada, desconecte los cables del
triturador del suministro eléctrico.
2
!
Peligro de caída
Falling Hazard
WARNING
3
K
4!*
5!*
Removal of old disposer/Extracción del triturador viejo

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
5
If the new disposer mounting is the
same as the old one, you can go to
step 15.
Note: For sinks thicker than 3/8”,
you will need to replace existing 1 1/2”
screws with 1 1/8” screws (H). See
step 14.
Si el montaje del triturador nuevo
es el mismo que el viejo, puede ir al
Paso 15.
Nota: Para los fregaderos con espesor
mayor de 3/8” (0,95 cm), deberá
reemplazar los tornillos existentes de
1 1/2” (3,81 cm) por tornillos de 1 1/8”
(2,85 cm) (H). Consulte el Paso 14.
Using a screwdriver, remove the snap ring.
Retire el anillo de cierre con un
destornillador.
Loosen the 3 screws on the mounting
assembly.
Afloje los 3 tornillos en el conjunto de
montaje.
Remove flange from sink.
Retire la brida del fregadero.
Remove old plumber’s putty from sink
with putty knife.
Retire la masilla de plomería vieja del
fregadero con una espátula.
89
7
6

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
6
Press flange (C) firmly into sink drain.
Remove excess putty.
Presione la brida (C) firmemente en el
desagüe del fregadero. Retire la masilla
sobrante.
Installation/Instalación
12 C
D
E
F
G
11
C
10
C
Evenly apply 1/2” thick rope of plumber’s
putty around flange (C).
Aplique una tira gruesa de masilla de
plomería, de 1/2” (1,27 cm), en forma
uniforme alrededor de la brida (C).
Insert fiber gasket (D), backup flange (E)
and mounting ring (F). Hold in place while
inserting snap ring (I).
Inserte la junta de fibra (D), la brida de
soporte (E) y el anillo de montaje (F).
Sosténgalos en su lugar mientras inserta
el anillo de cierre (I).
Optional/Opcional
13 I
> 3/8”
1-1/8”
H
EF
< 3/8”
1-1/2”
G
F
E
14 15
J
!
*
Stop and read
Deténgase y lea
Place a weight such as the disposer on the
sink flange to hold it in place. Use a towel
to prevent scratching sink. Pull snap ring
open and press firmly until it snaps into
place.
Coloque un peso, por ejem-plo el
triturador, sobre la brida del fregadero
para mantenerla en su lugar. Utilice una
toalla para evitar que se raye el fregadero.
Abra el anillo de cierre y presione
firmemente hasta que se coloque en el
lugar.s’enclenche.
Tighten 1 1/2” screws (G) evenly and firmly
against backup flange. Use shorter 1 1/8”
screws (H) if sink is more than 3/8” thick.
Ajuste los tornillos de 1 1/2” (3,81 cm) (G)
en forma uniforme y firme contra la brida
de soporte. Utilice tornillos más cortos de
1 1/8” (2,85 cm) (H) si el fregadero tiene
más de 3/8” (0,95 cm) de espesor.
*CAUTION: DISHWASHER CONNECTION
ONLY If you do not need to attach the
dishwasher, go to step 17. Turn disposer (J)
onto side and insert screwdriver into
dishwasher inlet.
*PRECAUCIÓN: SÓLO PARA CONEXIÓN
DEL LAVAVAJILLAS. Si no es necesario
conectar el lavavajillas, pase al Paso 17.
Voltee el triturador (J) sobre un lado e
introduzca el destornillador en la entrada
del lavavajillas.

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
7
!
*
16
*CAUTION: DISHWASHER CONNECTION
ONLY Knock out drain plug and remove
plug from inside of disposer.
*PRECAUCIÓN: SÓLO PARA LA
CONEXIÓN DEL LAVAVAJILLAS.
Extraiga de un golpe el tapón de desagüe
del interior del triturador.
17 !*
*WARNING: SHOCK HAZARD.
Turn disposer over and remove electrical
cover plate. Pull out wires. DO NOT
REMOVE CARDBOARD SHIELD.
*ADVERTENCIA: PELIGRO DE
DESCARGA ELÉCTRICA. Dé vuelta el
triturador y retire la placa de cubierta
eléctrica. Saque los cables. NO RETIRE
LA PROTECCIÓN DE CARTÓN.
18 !*
1
19
2
!*
DO NOT cut or disconnect any wires.
NO corte ni desconecte ningún cable.
Ne couper ou débrancher AUCUN fil.
*WARNING: SHOCK HAZARD.
With electrical supply turned off, insert
cable connector (not included) and run
electrical cable through access hole on
bottom of disposer. Tighten cable connector.
*ADVERTENCIA: PELIGRO DE DESCARGA
ELÉCTRICA. Con la corriente eléctrica
apagada, introduzca el conector del cable
(no incluido) y pase el cable eléctrico a
través del orificio de acceso en la parte
inferior del triturador. Ajuste el conector
del cable.
*WARNING: SHOCK HAZARD. Connect
white wire from disposer to neutral (white)
wire from power source and black wire from
disposer to hot (black, red) wire from power
source with wire nuts (not included); ground
wire to green grounding screw. Unit must be
grounded for safe and proper installation.
*ADVERTENCIA: PELIGRO DE DESCARGA
ELÉCTRICA. Conecte el cable blanco del
triturador al cable neutro (blanco) de la
fuente de energía, y el cable negro del
triturador al cable vivo (negro, rojo) de la
fuente de energía, use para ello tuercas
para cable (no incluidas); finalmente, una el
cable de conexión a tierra con el tornillo
verde conectado a tierra. La unidad debe
estar conectada tierra para una instalación
segura y adecuada.
20
Push wires into disposer (do not displace
cardboard shield) and replace electrical
cover plate.
Coloque los cables dentro del triturador
(no retire la protección de cartón) y
reemplace la placa de la cubierta
eléctrica.

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
8
22
21
M
N
L*
Hang disposer by aligning 3 mounting tabs
with slide-up ramps on mounting ring.
Sostenga el triturador y alinee los 3
apéndices de montaje con rampas
deslizables sobre el anillo de montaje.
Place tube (M or N) into Anti-Vibration
Tailpipe Mount™. Use provided tubes for
best results. Secure with spring type hose
clamp (L). *Important: Failure to use the
spring type hose clamp provided voids
warranty.
Coloque el tubo (M o N) dentro del Anti-
Vibration Tailpipe Mount™. Utilice los
tubos provistos para obtener mejores
resultados. Fije con la abrazadera de
manguera tipo resorte (L). *Importante:
La garantía pierde validez si no usa la
abrazadera de manguera tipo resorte
incluida.
23
Turn mounting ring until all 3 mounting tabs
lock over the ridges on the slide-up ramps.
Gire el anillo de montaje hasta que los 3
apéndices de montaje se cierren sobre los
bordes de las rampas deslizables.
24
N
M
You may need to trim tube for proper fit.
Reconnect plumbing (and dishwasher
connection if used). Make sure Anti-
Vibration Tailpipe Mount™ is straight.
Es posible que deba recortar el tubo para
una colocación adecuada. Reconecte la
plomería (y la conexión del lavavajillas, si
utiliza uno). Asegúrese de que el Anti-
Vibration Tailpipe Mount™ esté derecho.
05081500028
05081500028
Model Evolution
Model Evolution
18005585700
18005585700
AMPS 8.1 HP 3/4
Volts 120 Hz 60 1PH
InSinkErator
Emerson Electric
Racine, WI 53406
25
Detach removable portion of spec label
and place on a visible location.
Corte la parte desmontable de la etiqueta
de especificaciones y colóquela en un
lugar visible.
26
Insert Quiet Collar® Sink Baffle into sink
opening. Fill sink with water, then test for
leaks. Install Bio-Charge® Bottle. See
following section.
Inserte el deflector del fregadero Quiet
Collar® en la abertura del fregadero. Llene
el fregadero con agua y luego verifique
que no haya fugas. Instale la botella Bio-
Charge®. Vea la sección siguiente.

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
9
ENGLISH
Installing and Replacing the Bio-Charge® Bottle
Installing Bio-Charge® Bottle
Use only InSinkErator® Bio-Charge®. See Changing Bio-Charge® Bottle for safety instructions and information on obtaining Bio-Charge®
replacements. Do not squeeze the Bio-Charge® Bottle; squeezing the bottle may cause Bio-Charge® to discharge and spill.
Unscrew Bio-Charge®
dispenser cap nozzle
counterclockwise until
nozzle pops upward to
dispensing position. Do
not remove dispenser
cap nozzle.
Aligning bottle with
concave side toward
disposer, insert bottle
up into holder until
you hear a click and
bottle snaps into
place. Pull bottle down
slightly to ensure it is
engaged.
Replacing Bio-Charge® Bottle
To keep your septic system operating at peak efficiency, replace the Bio-Charge® Bottle when it is empty. To change Bio-Charge® Bottle:
Make sure disposer is off. Press button
on disposer just above bottle and pull
bottle down to remove it. (Do not refill
or reuse empty bottle.)
Bio-Charge® is available wherever
InSinkErator® Septic Assist is sold.
For Bio-Charge® reorder, questions, or
comments call toll free 1 [phone].
4 YEAR IN-HOME FULL SERVICE WARRANTY
This warranty covers all replacement parts and repair labor to
correct defects in disposer material and workmanship for the full
warranty period from the date of installation in your home. If
warranty service is required during the warranty period, contact an
authorized InSinkErator® service center to replace or repair the unit
in your home at no cost to you. If you have questions concerning
your disposer or determining when service is needed, please call the
toll free InSinkErator® AnswerLine® to obtain the name of the
authorized service center nearest you. The toll free number is
1 [phone], or visit our website at www.insinkerator.com.
This warranty gives you specific legal rights and you may also have
other rights which vary from state to state. If the manufacturer
determines the unit should be replaced rather than repaired, the
warranty on the replacement unit will be limited to the unexpired
term of the original warranty. No other express warranty, written
or oral, applies.
If your disposer does not operate, follow these steps in order:
1. Check the things you can do yourself. Be sure the disposer is
connected to the electric power and the fuses or circuit breakers
are in working order. Reread the instruction book to ensure that
you are operating the disposer correctly.
2. Call InSinkErator®, or visit our website for information or for
the location of the authorized service center nearest you. The
toll free number is 1 [phone], or visit our website at
www.insinkerator.com.
3. Write to us if a satisfactory solution is not reached in steps 1
and 2. Our address is:
InSinkErator®
Service Department
4700 21st Street
Racine, Wisconsin 53406 USA
When writing or calling, supply the following information: date,
your name, your address, and your phone number. Describe
the product by model number, serial number, date purchased,
place purchased, and service history (including name and
address of service agent). Clearly describe the problem and
service required.
NOTE: Warranty is determined by unit serial number and date of
installation. Purchase or installation receipt may be required to
verify warranty status.
The foregoing warranty does not apply to damage or inoperation
resulting from accident, alteration, misuse, abuse, improper
installation, installation not in accordance with these instructions
or local electrical and plumbing codes. Warranty will be voided if
installed in a commercial or industrial application.

Evolution Septic Assist®
Food Waste Disposer Designed for Septic System/Triturador de Desperdicios de Alimentos Diseñado para Sistemas Sépticos
10
Figure A Figure B
1. Remove stopper from sink opening and run strong flow of cold water.
2. Turn on wall switch to start disposer.
3. Slowly insert food waste into disposer. CAUTION! Position stopper to minimize possible ejection of material while grinding.
4. After grinding is complete, turn disposer off and run water for a few seconds to flush drain line.
OPERATING INSTRUCTIONS
DO...
• First turn on a moderate to strong flow of cold water and then turn
on the disposer. Continue running cold water for a few
seconds after grinding is completed to flush the drain line.
• Grind hard materials such as small bones, fruit pits, and ice.
A scouring action is created by the particles inside the grind
chamber.
• Grind peelings from citrus fruits to freshen up drain smells.
• Use a disposer cleaner, degreaser, or deodorizer as necessary to
relieve objectionable odors caused by grease build-up.
DON'T...
• Pour grease or fat down your disposer or any drain. It can build
up in pipes and cause drain blockages. Put grease in a jar or can
and dispose in the trash.
• Use hot water when grinding food waste. It is OK to drain hot
water into the disposer between grinding periods.
• Fill disposer with a lot of vegetable peels all at once. Instead,
turn the water and disposer on first and then feed the peels in
gradually.
• Grind large amounts of egg shells or fibrous materials like corn
husks, artichokes, etc., to avoid possible drain blockage.
• Turn off disposer until grinding is completed and only sound of
motor and water is heard.
CAUTION
Regularly inspect disposer and plumbing fittings for water leaks, as
water leaks can cause property damage. Manufacturer cannot be
held responsible for property damage as a result of water leaks.
USER-MAINTENANCE INSTRUCTIONS
CLEANING DISPOSER
Over time, food particles may accumulate in the grind chamber and baffle. An odor from the disposer is usually a sign of grease and food
buildup, caused by insufficient water flow during and after disposer use. To clean disposer:
1. Turn off disposer and disconnect power supply.
2. Place stopper in sink opening and fill sink halfway with warm water.
3. Mix 1/4 cup baking soda with water. Turn disposer on and remove stopper from sink at same time to wash away loose particles.
4. Remove Quiet Collar® Sink Baffle and clean by hand or in dishwasher. Do not operate disposer without Quiet Collar® Sink Baffle in place.
Disposers may also be cleaned with Disposer Care®. This product is not sold by InSinkErator®, but is generally available in major
home centers, hardware, and grocery stores. For more information on Disposer Care®, contact Summit Brands at 1-888-476-6688 or
www.summitbrands.com.
RELEASING DISPOSER JAM
If motor stops while disposer is operating, disposer may be jammed. To release jam:
1. Turn off disposer and water.
2. Insert one end of self-service Jam-Buster™ Wrench into center hole on bottom of disposer (see Figure A). Work Jam-Buster™ Wrench back
and forth until it turns one full revolution. Remove Jam-Buster™ Wrench.
3. Reach into disposer with tongs and remove object(s). Allow disposer motor to cool for 3 - 5 minutes, then lightly push red reset button on
disposer bottom (see Figure B). (If motor remains inoperative, check service panel for tripped circuit breakers or blown fuses.)
