InstaBox i90 User manual

Getting started with the i90 InstaBox
Installing the battery in the remote
The diagram inside the remote is not very specific. You must install the battery with the positive
(+) side up. Note: The i90 comes with a CR2025, 3-volt Li cell. If you want longer life for your
remote, use a CR2032. The only difference is that the CR2032 is a tiny bit thicker but it still fits
nicely in the remote control. When installing the battery ensure that the positive contact pin is
located next to the rim of the battery and not forced below the disc. See illustration below:

Setting the calendar and clock
1. Press and hold the Mode button for 3 sec then release.
2. Use the Volume knob to adjust settings, then press and release Mode button to select settings
3. Set current year
4. Set the month
5. Set the day
6. Set the hour
7. Set the minutes
After setting the clock choose the desired Sleep time for the i90. Choices available are:
OFF, 30, 60, 90, 120 minutes.
Setting the alarm
The Instabox i90 has four convenience alarms that can be set independently. Once set, the alarms
will repeat twice daily.
1. Press Mode to get to the time function then press and hold Play for 3 seconds.
2. Press Mode to set the hour. Use the volume control to select the desired hour.
3. Press Mode and repeat the same steps to set the minutes.
4. Press Mode to confirm setting. The Alarm sign will be flashing.

5. Press Play to turn the alarm On or Off. When On is selected the alarm sign will remain on the
screen.
To set additional alarms follow the steps above. After step 1, use the Volume Control to choose
which of the four alarms to set –then follow the remaining steps.
Using the FM Radio
The Instabox i90 can store 50 preset radio stations (P01-P50). You can step through saved stations
using the forward and back buttons on the front panel or on the remote. Select any previously
stored channel by pressing the number (1-50) and then press Play. If no station has been saved in a
selected channel Err will display.
You may select any FM station directly by entering the station frequency, then press Play.
(105.1MHz = Press 1051 + Play). You can also hold the forward or back button to scan through
available radio stations. To save a selected station, press and hold ‘0’. Your selection is saved in the
next available preset position.
To momentarily mute the radio press the Play button on the remote or on the front panel.
Playing music from a micro-SD card or a Flash drive
Ports are provided on the rear panel of the i90 for a Micro-SD card and for a USB Flash drive. When
either type of device is plugged into the i90, TF or USB will appear on the screen and MP3 format music
will begin to play. The i90 supports memory sources up to 32GB at a maximum bit rate of 320kbps.
Press the forward or back button to play the next or previous selection.
Press and hold the forward or back button to fast-forward or rewind a selection
Press the play button to pause/play the music.
You can use the remote to numerically select a track. (Press 30 + Play= Play song 30)
Press and hold ‘0’ to select one of six different sound profiles:
NORMAL / ROCK / POP / CLASS / JAZZ / BASS
You can record segments of a selection for a playback repeat. Press A-B. “P—A” will show on the
display as the segment is saved. End the segment by again pressing A-B, “P—B” will display. The
segment will now play repeatedly until A-B is pressed again. The segment will stop and “P—E”
will display.
Using the External Auxiliary Input
Using the external audio cable provided, you can play audio from any external source using the rear
panel Aux audio input port. “AUX” will display on the front panel when the cable is used. Use the play
button to mute the input.

Bluetooth and InstaBox i90
1. The InstaBox i90 supports Bluetooth version V4.0+EDR
2. Press the Mode button or ‘m’ on the remote to turn on Bluetooth. ‘blue’ appears on the screen.
When you hear ‘DO-DI’ the Bluetooth is on and ready to pair.
3. Turn on the Bluetooth on your device and search for D90.
4. The i90 will connect in about 20 seconds and the external device content will begin to play.
5. Press the play button to play/pause the device playback
6. If the device content has tracks use the forward or back controls to play next or previous tracks.
7. The i90 will receive phone call audio and display ‘HP’ during a call. Press and hold the Play
button to disconnect or auto-connect a call
Battery Charging Management
The battery indicator on the upper right of the screen displays the amount of battery charge
The i90 is charge from a micro USB connector on the rear panel. It requires DC 5v
600MA for charging. The battery reaches full charge in 4 to 6 hours. The charge light on
the rear panel changes from red to green when the battery is fully charged.
The battery has a capacity of 1800 mAH. You can also use this battery as an emergency
backup for charging a cell phone. Plug your USB phone charging cable into the USB
audio input on the back of the i90 and your phone will commence charging.
