Intaride S-3 User manual

1 INTARIDE LTD 2018
INTARIDE S-3 MANUAL
BASIC FUNCTIONS:
Power-ON:
Press and hold ‘Funcon’ wheel AND the ‘Intercom’ buon unl the (Main) LED indicator ashes blue.
Power-OFF:
Press and hold ‘Funcon’ wheel AND the ‘Intercom’ buon unl the (Main) LED indicator ashes red.
Funcon Channel Pairing: (these are not technical terms, just terms we use to idenfy each connecon)
Press and hold the ‘Funcon’ wheel to start searching sequence (fast Red/Blue ash).
Intercom Channel Pairing: (these are not technical terms, just terms we use to idenfy each connecon)
Press and hold the ‘Intercom’ buon to start searching sequence (slow Red/Blue ash).
Volume Up:
Rotate ’Funcon’ wheel an-clockwise to raise the volume.
Volume Down:
Rotate ’Funcon’ wheel clockwise to lower the volume.
Reset Pairings:
Press and hold the ‘Previous’ buon and the ‘Funcon’ wheel at the same me, the LED indicator will ash purple (red & blue).
CONNECTION INDICATION:
When there is a blue light in the connecon indicaon crescent, this means the units are paired and connected.
‘B Unit’‘A Unit’
MODULAR PAIRING SEQUENCE
THE ‘M’ (MASTER) UNIT SHOULD ALWAYS BE IN THE CENTER OF THE ‘CHAIN’
(As displayed above, the A unit is connected to the M unit, which is then connected to the B unit this ensures that there is equal distance between the rst unit, Master
unit and last unit).
CONNECTING TWO UNITS:
A Unit - Press and hold the ‘Funcon’ wheel (fast Red/Blue ash).
M Unit - Press and hold the ‘Intercom’ buon (slow Red/Blue ash).
‘A Unit’ and ‘M Unit’ are now paired and connected.
CONNECTING THREE UNITS:
M Unit - Press and hold the ‘Funcon’ wheel (fast Red/Blue ash).
B Unit - Press and hold the ‘Intercom’ buon (slow Red/Blue ash).
‘M Unit’ and ‘B Unit’ are now paired and connected.
To connect more units (up to eight units manufacturer rated, we recommend six) on the last unit paired press and hold the ‘Funcon’
wheel (fast Red/Blue ash), while on the new unit you want to add to the ‘chain’, Press and hold the ‘Intercom’ buon (slow Red/Blue
ash).
When you turn o your units, when you turn them back on, press and release the ‘Intercom’
buon on the ’M unit’ to reconnect them all.
‘Next’ buon
‘Previous’ buon
Connecon indicaon
Main LED indicator
Charging port and cover
Funcon/volume wheel
Intercom buon
‘M Unit’

2 INTARIDE LTD 2018
1. Turn your S-3 units on.
2. Press and hold the funcon buon/wheel unl the LED indicator is ashing red/blue alternately.
3. Go to your phone/GPS Bluetooth sengs and search/scan for SCS S-3.
4. Select and pair to the S-3.
To switch between intercom (talking to rider/pillion via S-3) and your phone/GPS
(music etc) press and release the intercom buon.
Switching between songs:
Previous buon:
Previous Song.
Next buon:
Next Song.
Note: Give the unit some me to send and receive AVRCP, if the song doesn't change instantly.
PAIRING TO GPS/PHONE
PAIRING TO BIRD-1
1. Turn your S-3 unit on.
2. Make sure the S-3 IS NOT connected (It can be paired but there should be no audio between any other unit AND no connecon
indicaon light).
3. Press and hold the intercom buon unl the LED indicator is ashing red/blue alternately.
4. While the BIRD-1 is powered OFF, press and hold the on buon unl the BIRD-1’s LED indicator is ashing red/blue alternately.
5. The BIRD-1 and S-3 will automacally pair to each other.
To switch between intercom (talking to rider/pillion via S-3) and your BIRD-1
(radio channel communicaon) press and release the intercom buon.
SPRING CLIP INSTALLATION
1. Retrieve your S-3 dock and spring clip.
2. Look at the boom of the S-3 dock and noce 2 rectangular slots.
3. Squeeze the spring clip and push into place.
