Intec car vision CVD650LCD Guide

1
2
3
The following instructions will guide you through the steps required to replace your older Car Vision® system with a new Car Vision® system
using the existing cable. Please read and understand all the instructions before proceeding with the installation.
Removing the existing monitor:
Disconnect Ground from the vehicle battery.
Unplug the monitor pigtail from the main cable.
Cut the power (red), ground (black), and reverse trigger (blue) wires about a foot from the monitor.
Remove the monitor.
Install the new CVS100M controller:
Using the CV1F92MF93MM adapter plug the 15 pin end into the main cable. Plug the other end into the CVS100M controller camera
connection. Note: The controller can be installed anywhere inside the coach as long as it is within the 6 meter length of the CVDC6MA
controller to display cable. Refer to the wiring diagram on page 2 for additional information.
Plug the CVS100MP3M power harness into the controller.
Plug the CVDC6MA cable into the controller.
Connect to power by splicing the CVS100MP3M power harness to the existing power wires; red to red, black to black, and blue to blue.
Install the new display and remote:
Prepare the dash to install the new display. For flush mount installations see the chart on page 3 and modify your dash or overhead
opening accordingly. For bracket mount installations follow the directions on the quick installation guide provided with your new display.
Attach the CVDC6MA cable to the display’s Controller (inside) connector. Refer to the graphic on page 2.
Connect the CVR100 remote to the display’s Remote (outside) connector. Refer to the graphic on page 2.
Temporarily install the new display and remote.
Install the new camera:
Remove the existing camera from the rear of the coach and unplug it from the main cable.
Determine how the new camera will be installed. If bracket mounted determine location and secure bracket. If flush mounted determine
location and cut or enlarge the opening, if necessary, to accommodate the new flush mount enclosure.
When installing a CVC400 series camera use the CV1F92MM93MF adapter. Plug the 15 pin end into the main cable. Plug the other end
into the camera connector.
When installing a CVC500AH series camera use the 313-02-02-000 adapter. Plug the 15 pin end into the main cable. Plug the other end
into the camera connector.
Test the system and Complete the installation:
Reconnect the vehicles battery ground.
Turn the system on and adjust as needed.
Secure the new display, remote, controller and camera.
1
Original 9200 Series System
Item Quantity Part Number Description
1 1 9200 Series Car Vision Monitor
2 1 CV9260F Cable
3 1 9200 Series Car Vision Camera
ON SB
CHANGE
CONT
BRIGHT
15
10
5
2
1
9200 Series to CVD/CVC Series
Replacement Instructions
Single Camera System

Power Connection Table – CVS100
Color Function
Red Power (+11 to +32 VDC)
Black Ground
Blue Reverse Trigger (+11 to +32 VDC)
Green Source Alarm Out (Functional Only
with Optional Radar Component)
DISPLAY VIDEO OUT/IN CAMERA POWER
2
Controller Connection Detail
Upgraded System
Item Quantity Part Number Description
1 1 CVDxxxLCD Car Vision Display
2 1 CVDR5MA Optional Remote Extension Cable
3 1 CVR100 Remote Control
4 1 CVDC6MA Six Meter Display to Controller Cable
5 1 CVS100M Controller – Molex Version
6 1 CVS100MP3M Power Harness for Molex Controller
7 1 CV1F92MF93MM Adapter – Cable to Controller
8 1 CV9260F Existing Coach Cable
9 1 CV1F92MM93MF Adapter – Cable to CVC400
10 1 CVC400(FM) M Series (Flush Mount) Camera
1
2
3
4
5
6
7
8
DISPLAY CVD640LCD
Controller Remote
Display Connection Detail
10 9
See The Power Connection Table
Below For Wire Connection Details
10a
9a
CVC400 Series Option
CVC500AH Series Option
Item Quantity Part Number Description
9a 1 313-02-02-000 Adapter – Cable to CVC500AH
10a 1 CVC500AH(FM) H Series (Flush Mount) Camera

Your Camera – Dimensions do not include the mounting bracket. Recommended Camera - Flush Mount Dimensions
Camera
9124 5 7/16” wide X 8 3/4” long with a 3 7/8” to 4 1/4” Dia.
2112 5 7/16” wide X 8 3/4” long with a 3 7/8” to 4 1/4” Dia.
9200 5 7/16” wide X 8 3/4” long with a 3 7/8” to 4 1/4” Dia.
CVC400FM
CVC500AHFM
2 1/2” wide x 2 3/4” high
3 5/8” wide X 2 3/4” high
Your Monitor – Dimensions do not include the mounting bracket. Recommended Display – Dimensions do not include the mounting bracket.
Monitor Dimensions Display Dimensions
9124 7 11/16” wide X 5 5/16” high
9112 7 11/16” wide X 5 5/16” high
9200 7 11/16” wide X 5 5/16” high
CVD650LCD Outside 7 5/8” wide X 5 1/2” high
(Back bump out 6 3/8” wide X 4 1/4” high)
Dimensional Charts and Reccomendations.
3
For additional information, please visit www.intecvideo.com/support.html
You may also call us toll free at 800‐468‐3254 (West) or 800‐522‐5989 (East) or e‐mail [email protected] with any questions.
