Integra Dtr-20.4 User manual

AV Receiver

DTR-20.4

Instruction Manual

En-2

Safety Information and Introduction

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If

the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand,

tripod, bracket, or table

specified by the manufacturer,

or sold with the apparatus.

When a cart is used, use

caution when moving the

cart/apparatus combination to

avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Damage Requiring Service

Unplug the apparatus from the wall outlet and refer

servicing to qualified service personnel under the

following conditions:

A. When the power-supply cord or plug is damaged,

B. If liquid has been spilled, or objects have fallen

into the apparatus,

C. If the apparatus has been exposed to rain or water,

D. If the apparatus does not operate normally by

following the operating instructions. Adjust only

those controls that are covered by the operating

instructions as an improper adjustment of other

controls may result in damage and will often

require extensive work by a qualified technician to

restore the apparatus to its normal operation,

E. If the apparatus has been dropped or damaged in

any way, and

F. When the apparatus exhibits a distinct change in

performance this indicates a need for service.

16. Object and Liquid Entry

Never push objects of any kind into the apparatus

through openings as they may touch dangerous voltage

points or short-out parts that could result in a fire or

electric shock.

The apparatus shall not be exposed to dripping or

splashing and no objects filled with liquids, such as

vases shall be placed on the apparatus.

Don’t put candles or other burning objects on top of

this unit.

17. Batteries

Always consider the environmental issues and follow

local regulations when disposing of batteries.

18. If you install the apparatus in a built-in installation,

such as a bookcase or rack, ensure that there is

adequate ventilation.

Leave 20 cm (8") of free space at the top and sides and

10 cm (4") at the rear. The rear edge of the shelf or

board above the apparatus shall be set 10 cm (4") away

from the rear panel or wall, creating a flue-like gap for

warm air to escape.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPARATUS TO RAIN OR

MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within

the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

RISQUE DE CHOC ELECTRIQUE

NE PAS OUVRIR

AVIS

PORTABLE CART WARNIN

S3125A

Safety Information and Introduction

En-3

Precautions

1. Recording Copyright—Unless it’s for personal use

only, recording copyrighted material is illegal without

the permission of the copyright holder.

2. AC Fuse—The AC fuse inside the unit is not user-

serviceable. If you cannot turn on the unit, contact the

dealer from whom you purchased this unit.

3. Care—Occasionally you should dust the unit all over

with a soft cloth. For stubborn stains, use a soft cloth

dampened with a weak solution of mild detergent and

water. Dry the unit immediately afterwards with a

clean cloth. Don’t use abrasive cloths, thinners,

alcohol, or other chemical solvents, because they may

damage the finish or remove the panel lettering.

4. Power

WARNING

BEFORE PLUGGING IN THE UNIT FOR THE

FIRST TIME, READ THE FOLLOWING SECTION

CAREFULLY.

AC outlet voltages vary from country to country. Make

sure that the voltage in your area meets the voltage

requirements printed on the unit’s rear panel (e.g., AC

230 V, 50 Hz or AC 120 V, 60 Hz).

The power cord plug is used to disconnect this unit

from the AC power source. Make sure that the plug is

readily operable (easily accessible) at all times.

For models with [Power] button, or with both

[Power] and [On/Standby] buttons:

Pressing the [Power] button to select OFF mode does

not fully disconnect from the mains. If you do not

intend to use the unit for an extended period, remove

the power cord from the AC outlet.

For models with [On/Standby] button only:

Pressing the [On/Standby] button to select Standby

mode does not fully disconnect from the mains. If you

do not intend to use the unit for an extended period,

remove the power cord from the AC outlet.

5. Preventing Hearing Loss

Caution

Excessive sound pressure from earphones and

headphones can cause hearing loss.

6. Batteries and Heat Exposure

Warning

Batteries (battery pack or batteries installed) shall not

be exposed to excessive heat as sunshine, fire or the

like.

7. Never Touch this Unit with Wet Hands—Never

handle this unit or its power cord while your hands are

wet or damp. If water or any other liquid gets inside

this unit, have it checked by the dealer from whom you

purchased this unit.

8. Handling Notes

• If you need to transport this unit, use the original

packaging to pack it how it was when you originally

bought it.

• Do not leave rubber or plastic items on this unit for a

long time, because they may leave marks on the

case.

• This unit’s top and rear panels may get warm after

prolonged use. This is normal.

• If you do not use this unit for a long time, it may not

work properly the next time you turn it on, so be sure

to use it occasionally.

For U.S. models

FCC Information for User

CAUTION:

The user changes or modifications not expressly approved

by the party responsible for compliance could void the

user’s authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer from whom you purchased this unit or

an experienced radio/TV technician for help.

For Canadian Models

NOTE: THIS CLASS B DIGITAL APPARATUS

COMPLIES WITH CANADIAN ICES-003.

For models having a power cord with a polarized plug:

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

Modèle pour les Canadien

REMARQUE: CET APPAREIL NUMÉRIQUE DE LA

CLASSE B EST CONFORME À LA NORME NMB-003

DU CANADA.

Sur les modèles dont la fiche est polarisée:

ATTENTION: POUR ÉVITER LES CHOCS

ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS

LARGE DE LA FICHE DANS LA BORNE

CORRESPONDANTE DE LA PRISE ET POUSSER

JUSQU’AU FOND.

Safety Information and Introduction

En-4

Supplied Accessories

Make sure you have the following accessories:

*In catalogs and on packaging, the letter at the end of the product

name indicates the color. Specifications and operations are the

same regardless of color.

■Installing the batteries

Note

• If the remote controller doesn’t work reliably, try replacing the

batteries.

• Don’t mix new and old batteries or different types of batteries.

• If you intend not to use the remote controller for a long time,

remove the batteries to prevent damage from leakage or

corrosion.

• Remove expired batteries as soon as possible to prevent damage

from leakage or corrosion.

■Aiming the remote controller

To use the remote controller, point it at the AV receiver’s

remote control sensor, as shown below.

Indoor FM antenna (➔page 17)

AM loop antenna (➔page 17)

Power cord (➔page 17)

Speaker cable labels (➔page 12)

Speaker setup microphone (➔page 31)

Remote controller (RC-835M) and two batteries (AA/R6)

Batteries (AA/R6)

Remote control sensor

AV receiver

Approx. 16 ft. (5 m)

Thank you for purchasing an Integra AV receiver.

Please read this manual thoroughly before making

connections and plugging in the unit.

Following the instructions in this manual will

enable you to obtain optimum performance and

listening enjoyment from your new AV receiver.

Please retain this manual for future reference.

Safety Information and Introduction

En-5

Table of Contents

Safety Information and Introduction

Important Safety Instructions ......................................2

Precautions ...................................................................3

Supplied Accessories...................................................4

Table of Contents..........................................................5

Features .........................................................................6

Front & Rear Panels......................................................7

Front Panel..................................................................7

Display ........................................................................8

Rear Panel ..................................................................9

Remote Controller.......................................................10

Controlling the AV Receiver ......................................10

Connections

Connecting the AV Receiver......................................11

Connecting Your Speakers .......................................11

About AV Connections..............................................13

Connecting Components with HDMI .........................14

Connecting Your Components ..................................15

Connecting Integra/Onkyo RI Components ..............16

Connecting the Antennas..........................................17

Connecting the Power Cord ......................................17

Turning On & Basic Operations

Turning On/Off the AV Receiver ................................18

Turning On ................................................................18

Turning Off ................................................................18

Initial Setup..................................................................19

Selecting the Language

for the Onscreen Setup Menus...............................19

Audyssey 2EQ: Auto Setup.......................................19

Source Connection....................................................20

Remote Mode Setup .................................................20

Network Connection..................................................20

Terminating the Initial Setup .....................................20

Playback ...................................................................... 21

Playing the Connected Component .......................... 21

Controlling Contents of USB or Network Devices.....22

Understanding Icons on the Display .........................23

Playing an iPod/iPhone via USB............................... 23

Playing a USB Device............................................... 24

Listening to vTuner Internet Radio............................ 24

Registering Other Internet Radio ..............................25

Changing the Icon Layout

on the Network Service Screen.............................. 25

Playing Music Files on a Server ...............................26

Remote Playback...................................................... 26

Listening to AM/FM Radio ........................................27

Playing Audio and Video from Separate Sources.....29

Using Basic Functions ............................................... 30

Using the Automatic Speaker Setup.........................30

Using the Listening Modes .......................................33

Using the Home Menu .............................................. 38

Using the Sleep Timer .............................................. 39

Setting the Display Brightness..................................39

Displaying Source Information..................................39

Changing the Input Display....................................... 39

Muting the AV Receiver ............................................ 40

Using Headphones ................................................... 40

Advanced Operations

On-screen Setup.........................................................41

Using the Quick Setup .............................................. 41

Using the Audio Settings of Quick Setup..................42

Using the Setup Menu (Home) ................................. 44

About the Hybrid Standby indicator .......................... 45

Setup menu items..................................................... 45

Input/Output Assign .................................................. 46

Speaker Setup ..........................................................48

Audio Adjust.............................................................. 49

Source Setup ............................................................ 51

Listening Mode Preset ..............................................55

Miscellaneous ........................................................... 56

Hardware Setup........................................................ 58

Remote Controller Setup .......................................... 61

Lock Setup................................................................ 61

Zone 2 ..........................................................................62

Making Zone 2 Connections ..................................... 62

Setting the Zone 2 Out..............................................62

Controlling Zone 2 Components ...............................62

Using the 12V Triggers ............................................. 63

Using the Remote Controller

in Zone 2 and Multiroom Control Kits.....................64

Controlling Other Components

iPod/iPhone Playback via Onkyo Dock .................... 65

Using the Onkyo Dock.............................................. 65

Controlling Your iPod/iPhone ................................... 66

Controlling Other Components................................. 67

Preprogrammed Remote Control Codes .................. 67

Looking up for Remote Control Codes ..................... 67

Entering Remote Control Codes............................... 68

Remapping Colored Buttons .................................... 68

Remote Control Codes for Integra/

Onkyo Components Connected via RI................... 69

Resetting the Remote Mode Buttons........................ 69

Resetting the Remote Controller .............................. 69

Controlling Other Components ................................. 69

Appendix

Troubleshooting ......................................................... 72

Firmware Update ........................................................ 78

Connection Tips and Video Signal Path .................. 82

Using an RIHD-compatible TV, Player,

or Recorder .............................................................. 84

About HDMI................................................................. 86

Network/USB Features............................................... 87

License and Trademark Information ........................ 90

Specifications ............................................................. 91

To reset the AV receiver to its factory defaults, turn it

on and, while holding down CBL/SAT, press

8On/Standby (➔page 72).

Safety Information and Introduction

En-6

Features

Amplifier

• 80 Watts/Channel @ 8 ohms (FTC)

• 130 Watts/Channel @ 6 ohms (IEC)

• 160 Watts/Channel @ 6 ohms (JEITA)

• Optimum Gain Volume Circuitry

• H.C.P.S. (High Current Power Supply) Massive High

Power Transformer

Processing

• Incorporates Qdeo™ technology for HDMI Video

Upscaling (to 4K Compatible)

• HDMI (Audio Return Channel, 3D, DeepColor,

x.v.Color, Lip Sync, DTS-HD Master Audio, DTS-HD

High Resolution Audio, Dolby TrueHD, Dolby Digital

Plus, DSD and Multi-CH PCM)

• Dolby Pro Logic IIz

• Non-Scaling Configuration

• A-Form Listening Mode Memory

•DirectMode

• Music Optimizer for Compressed Digital Music files

• 192 kHz/24-bit D/A Converters

• Powerful and Highly Accurate 32-bit Processing DSP

• Jitter Cleaning Circuit Technology

Connections

• 7 HDMI Inputs and 1 Output

• Integra/Onkyo pfor System Control

• 4 Digital Inputs (2 Optical/2 Coaxial)

• Component Video Switching (2 Inputs/1 Output)

• Banana Plug-Compatible Speaker Posts

• Zone 2 Pre/Line Out

• IR Input/Output and 12 V Triggers

• RS232 Port for Interface Control

• Internet Radio Connectivity

• Network Capability for Streaming Audio Files

• 2 USB Inputs (Front/Rear) for Memory Devices and

iPod®/iPhone®models (Enables Display of Album

Artwork)

*Only the front-panel USB input is compatible with

iPod/iPhone.

Miscellaneous

• 40 FM/AM Presets

• Audyssey 2EQ®to correct room acoustic problems

• Audyssey Dynamic EQ®for loudness correction

• Audyssey Dynamic Volume®to maintain optimal

listening level and dynamic range

• Crossover Adjustment

(40/45/50/55/60/70/80/90/100/110/120/130/150/200 Hz)

• A/V Sync Control Function (up to 800 ms)

• Auto Standby Function

• On-Screen Display via HDMI

• Preprogrammed u-Compatible Remote

Safety Information and Introduction

En-7

Front & Rear Panels

For detailed information, see the pages in parentheses.

a8On/Standby button (18)

bHybrid Standby indicator (45)

cTone and Tone Level buttons (42)

dRemote control sensor (4)

eDisplay (8)

fListening Mode buttons (33)

gDimmer button (North American models) (39)

hMemory button (28)

iTuning Mode button (27)

jDisplay button (39)

kSetup button (44)

lTuning q/w(27), Preset e/r(28), cursor and

Enter buttons

mReturn button

nMaster Volume control (21)

oZone 2, Off buttons (62)

pZone 2 Level q/wbuttons (62)

qPhones jack (40)

rInput selector buttons (21)

sUSB port (15)

tAUX Input Video/Audio jack (15)

uSetup Mic jack (31)

vRT/PTY/TP button (Australian models) (28)

Front Panel

(North American models) (Australian models)

a c

ghi jklmn

Safety Information and Introduction

En-8

For detailed information, see the pages in parentheses.

aZ2 (Zone 2) indicator (62)

b3D indicator

This lights when a 3D input signal is detected.

cHeadphone indicator (40)

d1, 3and cursor indicators (23)

eListening mode and format indicators (33)

fAudyssey indicator (30, 51)

Dynamic EQ indicator (51)

Dynamic Vol indicator (52)

gM.Opt indicator (43)

hTuning indicators

RDS indicator (excluding North American models)

(28)

AUTO indicator (27)

TUNED indicator (27)

FM STEREO indicator (27)

iMUTING indicator (40)

jInput indicators (83)

HDMI indicator (59)

DIGITAL indicator

kARC indicator (59)

lUSB indicator (23, 24)

mNET indicator (24 to 26, 61)

nMessage area

oSLEEP indicator (39)

pChannel/Unit indicators

ch indicator

Hz indicator

m/ft indicator

dB indicator

qASb indicator (60)

Display

jd n o qkm pjl

dce hg

fabi

Safety Information and Introduction

En-9

aDIGITAL IN COAXIAL and OPTICAL jacks

bCOMPONENT VIDEO IN and OUT jacks

cUSB port

dETHERNET port

eFM ANTENNA jack and AM ANTENNA terminal

fHDMI IN and OUT jacks

gRS232 jack

Terminal for control.

hIR IN and OUT jacks

i12V TRIGGER OUT jacks

jAC INLET

kuREMOTE CONTROL jack

lComposite video and analog audio jacks

(BD/DVD IN, CBL/SAT IN, GAME IN, PC IN,

TV/CD IN)

mMONITOR OUT V jack

nZONE 2 PRE/LINE OUT jacks

oPRE OUT jacks

(SURR BACK or FRONT HIGH, SUBWOOFER)

pSPEAKERS terminals

(CENTER, FRONT, SURROUND)

Rear Panel

a eb dc f g h i j

klmn o p

See “Connecting the AV Receiver” for connection

(➔pages 11 to 17).

Safety Information and Introduction

En-10

Remote Controller

For detailed information, see the pages in parentheses.

a8Receiver button (18)

bRemote Mode/Input Selector buttons (21)

cq/w/e/rand Enter buttons

dQ Setup button (41)

eListening Mode buttons (33)

fDimmer button (39)

gMuting button (40)

hDisplay button (39)

iVOL q/wbutton (21)

jReturn button

kHome button (38)

lSleep button (39)

■Controlling the tuner

To control the AV receiver’s tuner, press AM or FM (or

Receiver).

aq/wbuttons (27)

bD.TUN button (28)

cDisplay button

dCH +/– button (28)

eNumber buttons (28)

*1 To control a component, you must first enter the remote

control code.

See “Entering Remote Control Codes” for more details

(➔page 68).

Controlling the AV Receiver

To control the AV receiver, press Receiver to select

Receiver mode.

You can also use the remote controller to control

Integra/Onkyo Blu-ray Disc/DVD player, CD player,

and other components.

See “Entering Remote Control Codes” for more

details (➔page 68).

En-11

Connections

Connecting the AV

Receiver

Speaker Configuration

The following table indicates the channels you should use

depending on the number of speakers that you have.

No matter how many speakers you use, a powered

subwoofer is recommended for a really powerful and solid

bass.

To get the best from your surround sound system, you need

to set the speaker settings automatically (➔page 30) or

manually (➔page 48).

*1 If you’re using only one surround back speaker, connect it to

the SURR BACK or FRONT HIGH L PRE OUT terminals.

*2 Front high and surround back speakers cannot be used at the

same time.

Connecting the Speaker Cables

The following illustration shows how to connect the

speakers to each pair of terminals.

Tip

• You can specify whether surround back or front high speakers are

connected in the “Speaker Configuration” menu (➔page 48) or

during Audyssey 2EQ®Room Correction and Speaker Setup

(➔page 30).

Connecting Your Speakers

Number of speakers 2 3 4 5 6 7 7

Front speakers ✔✔✔✔✔✔✔

Center speaker ✔✔✔✔✔

Surround speakers ✔✔✔✔✔

Surround back speaker*1*2 ✔

Surround back speakers*2 ✔

Front high speakers*2 ✔

■7.2-channel playback

Connect your Power amplifier’s analog audio input jacks

to the AV receiver’s SURR BACK or FRONT HIGH

L/R PRE OUT jacks with audio cables.

If you’re using only one surround back speaker, connect it

to the SURR BACK or FRONT HIGH L PRE OUT

terminals.

■Screw-type speaker terminals

Strip 1/2" to 5/8" (12 to 15 mm) of insulation from the ends

of the speaker cables, and twist the bare wires tightly, as

shown.

■Banana Plugs (North American models)

• If you are using banana plugs, tighten the speaker

terminal before inserting the banana plug.

• Do not insert the speaker code directly into the center

hole of the speaker terminal.

AUDIO

INPUT

Front left Center

urroun

right

Front right

Surround back/

Front high right

Surround back/

Front high left

urroun

left

Power amplifier

1/2" to 5/8" (12 to 15 mm)

Connections

En-12

Attaching the Speaker Cable Labels

The speaker terminals are color-coded for identification

purpose.

The supplied speaker cable labels are also color-coded and

you should attach them to the positive (+) side of each

speaker cable in accordance with the table above. Then all

you need to do is to match the color of each label to the

corresponding speaker terminal.

Speaker Connection Precautions

Read the following before connecting your speakers:

• You can connect speakers with an impedance of between

6 and 16 ohms. If you use speakers with a lower

impedance, and use the amplifier at high volume levels

for a long period of time, the built-in amp protection

circuit may be activated.

• Disconnect the power cord from the wall outlet before

making any connections.

• Read the instructions supplied with your speakers.

• Pay close attention to speaker wiring polarity. In other

words, connect positive (+) terminals only to positive (+)

terminals, and negative (–) terminals only to negative (–)

terminals. If you get them the wrong way around, the

sound will be out of phase and will sound unnatural.

• Unnecessarily long, or very thin speaker cables may

affect the sound quality and should be avoided.

• Be careful not to short the positive and negative wires.

Doing so may damage the AV receiver.

• Make sure the metal core of the wire does not have

contact with the AV receiver’s rear panel. Doing so may

damage the AV receiver.

• Don’t connect more than one cable to each speaker

terminal. Doing so may damage the AV receiver.

• Don’t connect one speaker to several terminals.

Using Powered Subwoofers

To find the best position for your subwoofer, while playing

a movie or some music with good bass, experiment by

placing your subwoofer at various positions within the

room, and choose the one that provides the most satisfying

results.

You can connect the powered subwoofer with two

SUBWOOFER PRE OUT jacks respectively.

The same signal is output from each jack.

Tip

• If your subwoofer is unpowered and you’re using an external

amplifier, connect the subwoofer pre out jack to an input on the

amplifier.

Speaker Color

Front left, Front high left White

Front right, Front high right Red

Center Green

Surround left Blue

Surround right Gray

Surround back left Brown

Surround back right Tan

LINEINPUT

LINE INPUT

Powered subwoofer

Corner

position

1/3 of wall

position

Connections

En-13

Connecting AV components

• Before making any AV connections, read the manuals

supplied with your AV components.

• Don’t connect the power cord until you’ve completed and

double-checked all AV connections.

• Push plugs in all the way to make

good connections (loose connections

can cause noise or malfunctions).

• To prevent interference, keep audio

and video cables away from power

cords and speaker cables.

AV Cables and Jacks

■HDMI

HDMI connections can carry digital video and audio.

■Component video

Component video separates the luminance (Y) and color

difference signals (PB, PR), providing the best picture

quality (some TV manufacturers label their component

video sockets slightly differently).

■Composite video

Composite video is commonly used on TVs, DVDs, and

See also:

• “Connection Tips and Video Signal Path” (➔page 82)

• “Using an RIHD-compatible TV, Player, or Recorder”

(➔page 84)

• “About HDMI” (➔page 86)

Tip

• To listen to the audio of a component connected via HDMI

through your TV’s speakers, enable “HDMI Through”

(➔page 59) and set the AV receiver to standby mode.

Note

• In the case of Blu-ray Disc/DVD players, if no sound is output

despite following the above-mentioned procedure, set your Blu-

ray Disc/DVD player’s HDMI audio settings to PCM.

■Audio Return Channel (ARC) function

The Audio Return Channel (ARC) function enables an

HDMI capable TV to send the audio stream to HDMI OUT

on the AV receiver.

• This function can be used when:

– Your TV is ARC capable, and

–TheTV/CD input selector is selected, and

–“HDMI Control(RIHD)” is set to “On”(➔page 58), and

–“Audio Return Channel” is set to “Auto” (➔page 59).

Connecting Components with HDMI

Game console

TV, projector, etc.

Satellite/cable set-top box, etc.

Blu-ray Disc/DVD player

Personal computer

Jack Components

IN1 Blu-ray Disc/DVD player ✔

IN2 Satellite/cable set-top box, etc. ✔

IN3 Game console ✔

IN4 Personal computer ✔

IN5 Other components ✔

IN6 Other components ✔

IN7 Other components ✔

OUT TV, projector, etc.

Connections

En-15

Connect your components to the appropriate jacks. The

default input assignments are shown below. See

“Connection Tips and Video Signal Path” for more

information (➔page 82).

✔: Assignment can be changed (➔page 47).

Note

*1 Do not connect the AV receiver’s USB port to a USB port on

your computer. Music on your computer cannot be played

through the AV receiver in this way.

*2 When the USB input is selected, you can input video signals

from the AUX Input Video jack. Video signals input from

AUX Input Video will be output from the MONITOR OUT

and HDMI output jacks.

*3 Connect a turntable (MM) that has a phono preamp built-in. If

your turntable (MM) doesn’t have it, you’ll need a

commercially available phono preamp.

If your turntable has a moving coil (MC) type cartridge, you’ll

need a commercially available MC head amp or MC

transformer as well as a phono preamp. See your turntable’s

manual for details.

• With connection D, you can enjoy Dolby Digital and

DTS. (To listen in Zone 2 as well, use Dand H.)

• With connection H, you can enjoy audio from external

components while you are in Zone 2.

• With connection H, if your Blu-ray Disc/DVD player

has both the main stereo and multichannel outputs, be

sure to connect the main stereo.

Connecting Your Components

B CA

DGHIEFA

The on-screen menus appear only on a TV that is

connected to HDMI OUT. If your TV is connected to

other video outputs, use the AV receiver’s display

when changing settings.

No. Jack/Port Components

AUSB*1 iPod/iPhone, MP3 player,

USB flash drive

BUSB, AUX Input Video*2 iPod/iPhone (video

playback)

CAUX Input

Video Camcorder, etc.

Audio L/R

DDIGITAL IN

OPTICAL 1 (GAME) Game consoles ✔

OPTICAL 2 (TV/CD) TV, CD player ✔

COAXIAL 1 (BD/DVD) Blu-ray Disc/DVD player ✔

COAXIAL 2 (CBL/SAT) Satellite/cable set-top box,

RI dock, etc.

✔

ECOMPONENT VIDEO

IN 1 (BD/DVD) Blu-ray Disc/DVD player,

RI dock

✔

IN 2 (CBL/SAT) Satellite/cable set-top box,

RI dock, etc.

✔

OUT TV, projector, etc.

FETHERNET Router

GVIDEO IN

IN 1 (BD/DVD) Blu-ray Disc/DVD player ✔

IN 2 (CBL/SAT) Satellite/cable set-top box,

etc.

✔

IN 3 (GAME) Game console, RI dock ✔

IN 4 (PC) Personal computer ✔

HAUDIO IN

BD/DVD IN Blu-ray Disc/DVD player

CBL/SAT IN Satellite/cable set-top box,

etc.

GAME IN Game console, RI dock

PC IN Personal computer

TV/CD IN TV, CD player, cassette

tape deck, MD, CD-R,

Turntable*3, RI dock

IMONITOR OUT TV, projector, etc.

No. Jack/Port Components

Connections

En-16

With u(Remote Interactive), you can use the following

special functions:

■System On/Auto Power On

When you start playback on a component connected via

u, while the AV receiver is on standby, the AV

receiver will automatically turn on and select that

component as the input source.

■Direct Change

When playback is started on a component connected via

u, the AV receiver automatically selects that

component as the input source.

■Remote Control

You can use the AV receiver’s remote controller to

control your other u-capable Integra/Onkyo

components, pointing the remote controller at the AV

receiver’s remote control sensor instead of the

component. You must enter the appropriate remote

control code first (➔page 69).

Note

•Useonlyucables for uconnections. ucables are supplied

with Integra/Onkyo components.

• Some components have two ujacks. You can connect either

one to the AV receiver. The other jack is for connecting

additional u-capable components.

• Connect only Integra/Onkyo components to ujacks.

Connecting other manufacturer’s components may cause a

malfunction.

• Some components may not support all ufunctions. Refer to the

manuals supplied with your Integra/Onkyo components.

• While Zone 2 is on, the System On/Auto Power On and Direct

Change ufunctions do not work.

Connecting Integra/Onkyo RI

Components

1Make sure that each Integra/Onkyo component is

connected with an analog audio cable (connection H

in the hookup examples) (➔page 15).

2Make the uconnection (see the illustration).

3If you’re using an RI Dock, or cassette tape deck,

change the Input Display (➔page 39).

ANALOG

AUDIO OUT

ANALOG

AUDIO OUT

e.g., cassette tape deck

RI Dock

Connections

En-17

This section explains how to connect the supplied indoor FM antenna and AM loop antenna.

The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use

the tuner.

Note

• Once your AV receiver is ready for use, you’ll need to tune into a radio station and position the antenna to achieve the best possible

reception.

• Keep the AM loop antenna as far away as possible from your AV receiver, TV, speaker cables, and power cords.

Tip

• If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available outdoor FM antenna instead.

• If you cannot achieve good reception with the supplied indoor AM loop antenna, try using it with a commercially available outdoor AM

antenna.

Connecting the Antennas

Thumbtacks, etc.

Insert the plug fully

into the jack.

Insert the plug fully

into the jack.

North American models Australian models

Push. Insert wire. Release.

Assembling the AM loop antenna

Indoor FM antenna (supplied)AM loop antenna (supplied)

Caution

• Be careful not to injure yourself

when using thumbtacks.

Note

• Before connecting the power cord, connect all of your

speakers and AV components.

• Turning on the AV receiver may cause a momentary power surge

that might interfere with other electrical equipment on the same

circuit. If this is a problem, plug the AV receiver into a different

branch circuit.

• Do not use a power cord other than the one supplied with the AV

receiver. The supplied power cord is designed exclusively for use

with the AV receiver and should not be used with any other

equipment.

• Never disconnect the power cord from the AV receiver while the

other end is still plugged into a wall outlet. Doing so may cause

an electric shock. Always disconnect the power cord from the

wall outlet first, and then the AV receiver.

Connecting the Power Cord

1Connect the supplied power cord to the AV

receiver’s AC INLET.

2Plug the power cord into an AC wall outlet.

To AC wall outlet

En-18

Turning On & Basic Operations

Turning On/Off the AV

Receiver

Tip

•TheHybrid Standby indicator may light depending on the

status of settings (➔page 45).

• For details on power management settings, see “Auto Standby”

(➔page 60).

8Receiver

Receiver

8On/Standby

Turning On

1Press 8On/Standby on the front panel.

Press Receiver followed by 8Receiver on the

remote controller.

The AV receiver comes on and its display lights.

Turning Off

1Press 8On/Standby on the front panel.

Press Receiver followed by 8Receiver on the

remote controller.

The AV receiver will enter standby mode. To prevent

any loud surprises when you turn on the AV receiver,

always turn down the volume before you turn it off.

■Smooth Operation in a Few Easy Steps

(Initial Setup)

To ensure smooth operation, here’s a few easy steps to

help you configure the AV receiver before you use it for

the very first time. These settings only need to be made

once. See “Initial Setup” for details (➔page 19).

■If the “Firmware Update Available” window

appears.

When a new version of the firmware is available, the

notification window “Firmware Update Available”

pops up. This notification only appears when the AV

receiver is connected to your home network

(➔page 87). To perform the firmware update, follow

the instructions on screen.

Use q/wand Enter on the AV receiver or remote

controller to select one of the options.

`Update Now:

Starts the firmware update.

Refer to “Firmware Update” (➔page 78).

`Remind me Later:

The update notification will pop up again the next

time you turn the AV receiver on.

`Never Remind me:

Disables the automatic update notification.

Tip

• The update notification window can be enabled or disabled in

“Update Notice” (➔page 61).

Turning On & Basic Operations

En-19

Initial Setup

This section explains the settings that we recommend you

to make before using the AV receiver for the very first

time. A setup wizard is launched upon first-time use to let

you perform those settings.

This step determines the language used for the onscreen

setup menus. See “Language” in “OSD Setup”

(➔page 57).

Tip

• Pressing Home will close the setup wizard. To restart the initial

setup, select “Initial Setup” in the “Hardware Setup” menu

(➔page 61).

After selecting the language for on-screen setup menus, a

welcome screen is displayed.

This step performs the automatic speaker setup.

The on-screen menus appear only on a TV that is

connected to HDMI OUT.

Selecting the Language for the

Onscreen Setup Menus

1Use q/won the AV receiver or remote controller to

select one of the following options, and then press

Enter.

`Yes:

Continues to “Audyssey 2EQ: Auto Setup”.

`No:

Skips the settings and terminates the initial

setup. The setup wizard goes to “Terminating the

Initial Setup”. You can always restart the initial

setup by selecting “Initial Setup” in the

“Hardware Setup” menu (➔page 61).

1st Step : Audyssey 2EQ: Auto Setup

2nd Step : Source Connection

3rd Step : Remote Mode Setup

4th Step : Network Connection

Yes

Exit

Initial Setup

HOME

Welcome to initial setup. Have you connected all the speakers and devices?

Before starting, please connect speakers and sources.

Now, would you like to start initial setup?

Audyssey 2EQ: Auto Setup

1Use q/wto select one of the following options, and

then press Enter.

`Do it Now:

The automatic speaker setup is performed

following instructions on screen. Refer to step 2

of “Using the Automatic Speaker Setup”

(➔page 31). When this setting is complete, the

setup wizard continues to “Source Connection”.

`Do it Later:

Skips this setting.

Press Enter and continue to “Source

Connection”.

Turning On & Basic Operations

En-20

This step checks the connection of source components. With this step, you can enter remote control codes for the

components you want to operate.

This step checks your network connection.

This step ends the initial setup process.

Source Connection

1Use q/wto select one of the following options, and

then press Enter.

`Yes, Continue:

Performs the checkings.

`No, Skip:

Skips this step and continues to “Remote Mode

Setup”.

2Select the input selector for which you want to

check the connection and press Enter.

The picture of the corresponding source should appear

on screen with a verification prompt.

3When prompted, use q/wto select one of the

following options and then press Enter.

`Yes:

Confirms that the source is properly displayed.

`No:

Displays an error report. Follow the

troubleshooting instructions and recheck the

source.

4Use q/wto select one of the following options, and

then press Enter.

`Yes:

Returns to step 2.

`No, Done Checking:

The setup wizard continues to “Remote Mode

Setup”.

Remote Mode Setup

1Use q/wto select one of the following options, and

then press Enter.

`Yes:

Performs the remote control code input. Refer to

step 5 of “Looking up for Remote Control

Codes” (➔page 67).

`No, Skip:

Skips this step and continues to “Network

Connection”.

2When you’re finished, select one of the following

options and press Enter.

`Yes, Done:

The setup wizard continues to “Network

Connection”.

`No, not yet:

You can enter other remote control codes.

Network Connection

1Use q/wto select one of the following options, and

then press Enter.

`Yes:

Performs the checkings.

`No, Skip:

Skips this step and terminates the initial setup.

Note

• If you use both wired and wireless network connections, the

wireless will take priority.

For further details, see the instruction manual provided with

your wireless device.

2Follow the instructions on screen to perform the

network checking.

The checking is complete when the message

“Successfully connected.” appears at the middle of

the screen. Press Enter to terminate the initial setup.

3If an error message appears, select one of the

following options and press Enter.

`Retry:

Performs the checking again.

`No, Do it Later:

Skips this step and terminates the initial setup.

The setup wizard goes to “Terminating the

Initial Setup”.

Terminating the Initial Setup

1Press Enter.

To restart the initial setup, select “Initial Setup” in

the “Hardware Setup” menu (➔page 61).
