Integrated Technical Vision iPR-A2RS Series User manual

http://www.itvsystems.com.ua IntegratedTechnicalVisionLtd 1
Proximityreader
iPR-A2RSx, iPR-A2W2x,iPR-A2W3x,iPR-A2W4x,iPR-A2WSx,iPR-A2TMx
usermanual
Introduction
The proximity reader PR-x06 is intended to
be applied in different access control sys-
tems, using RS232, Wiegand 26, Wiegand
37, Wiegand 42, Wiegand with automatic
choice or TouchMemory interface.
The interface type is to be changed by spe-
cial PC programm. If you need to change the
interface type please call your distributor.
The reader is placed in elegant plastic case
with two colour LED indicator on front panel.
Types of cards
Integrated Technical Vision ltd manufacturies
readers operating with amplitude modulation
(ASK) proximity cards and tags.
Benefits
Case
Material ABS plastic
Dimensions 150 х45 х22 mm
Weight 50 g
Ambient Conditions
Oper. temp. -35 0С... +55 0С;
Stor. temp. -30 0С… +80 0С;
Humidity 95% rel. at +25 0C
Electrycal
Voltage +8. . . +18 VDC
Current up to 50 mA
Max current up to 80 mA
Voltage ripple up to 500 mVp-p.
Distance of reading
Typical reading distance is 120 mm and depends on tag type used with
it. This parameter is valid for power supply voltage range from +8 to +18
VDC and ripple up to 150 mVp-p.

2Integrated Technical Vision Ltd http://www.itvsystems.com.ua
Wiring
Reader has 8 wire cable for connecting to the access control panel.
Table 1. The wires assignment.
SW/4W/3W/2WSW/4W/3W/2W SW/4W/3W/2W SW/4W/3W/2WSW/4W/3W/2W232SR232SR 232SR 232SR232SRyromeMhcuoTyromeMhcuoT yromeMhcuoT yromeMhcuoTyromeMhcuoT
ruoloCtnemngissA
neerG0ataDxRnottuBi
etihW1ataDxT
–
deRV+V+V+
kcalBDNGDNGDNG
nworBdeLdeR–deLdeR
egnarOdeLneerG–deLneerG
eulBpeeB–peeB
wolleYdloHdloHdloH
AWG22 multiwire signal cable is recommended. Using this cable the
maximum length of 100 meters can be obtained*.
Type of interfaces
The proximity reader is intended to apply in different access control
systems, using RS232, Wiegand 26, Wiegand 37, Wiegand 42, Wie-
gand with automatic choice** or TouchMemory interface.
Mounting
It is recommended to mount the reader on a wall closely to a door at
appropriate height.
Do not place the reader on the metal surfaces, since it causes decreas-
ing of reading distance.
If more than one reader is used in the system, place them not closer
than 50 cm one from another, otherwise a reading distance will be
decreased.
- Remove the cover from the reader.
- Prepare all wires for connection and connect them to the reader in
accordance with Table 1 and User Manual of the access control panel to
be utilized.
- Mount the reader to the wall using the fixturing provided.
- Secure cover to the reader. Ensure that all locking tabs are securely
engaged.
The Reader Operation
The RFID Card Code Reading
The card code reading is annunciated by built-in buzzer and LED lamp
according to interface type and annunciation mode (see Section «Data
* Not for RS232 interface
** For FSK cards only

http://www.itvsystems.com.ua IntegratedTechnicalVisionLtd 3
transfer and Annunciation»).
Repeated reading will be available after 0.75 sec if the card is removed
from the reader sensing area.
Hold Mode
Reader is turned to the hold mode while yellow wire is closed to ground.
In this mode reader does not read cards, thus current consumption
decreases.
Do not apply voltage to yellow wire!
Data transfer and control of annunciation
The reader is provided with two-colour LED indicators and buzzer. LED
and buzzer function according to interface type programmed and an-
nunciation mode.
Wiegand or TouchMemory Interface
Engaging of LED and buzzer is possible automatically or by grounding
of corresponding wire according to the table 2.
Table 2. Annunciation mode:
rezzuBDELdeRDELneerG
00daerdracnopeeBgnidaertaffohctiws,noyllamronDELgnidaertagniknilB
10edistuomorflortnoCgnidaertaffohctiws,noyllamronDELgnidaertagniknilB
20daerdracnopeeBffohctiwSgnidaertagniknilB
30edistuomorflortnoCffohctiwSgnidaertagniknilB
40daerdracnopeeBgnidaertaffohctiws,noyllamronDELtsohmorflortnoC
50edistuomorflortnoCgnidaertaffohctiws,noyllamronDELtsohmorflortnoC
60daerdracnopeeBtsohmorflortnoCtsohmorflortnoC
70edistuomorflortnoCtsohmorflortnoCtsohmorflortnoC
Data transmission from reader comply with standard Wiegand26, Wie-
gand37, Wiegand42 or TouchMemory protocols. Protocol for TouchMem-
ory interface from family 01 (to satisfy the requirements DS1990).
Interface RS232
To control annunciation send control packet to the reader. Packets should
be transmitted with 2 400 baud rate, 8 bit data, no parity, 1 stop bit.
Packet format:
etybfo#01234
noitanitseDh700000etyblortnoC00
Control byte:
tib7654321 0
noitanitseD DELgniknilb00 tilDELrezzub
derneergderneergyrotaslupyldetpurretninu
1 – corresponds LED or buzzer switched on. LED blinking and buzzer
pulsatory control bits have highest priority.

4Integrated Technical Vision Ltd http://www.itvsystems.com.ua
Annunciation does not change until next control packet received.
Reader transmits data as follows:
etybfo#001...11121
noitanitseDh32atadmuskcehchD0
data:
tib76543210
eulaV0011xxxx
Checksum: exclusive OR of low nibbles of bytes from 1 to 10, high
nibble of always must be 3h.
Example:Card code 7E000460AA will be send as:
23h, 37h, 3Eh, 30h, 30h, 30h, 34h, 36h, 30h, 3Ah, 3Ah, 3Bh, 0Dh.
Limited Warranty
Integrated Technical Vision Ltd. warrants that for a period of eighteen
months from the date of purchase, the product shall be free of defect in
materials and workmanship under normal use and that in fulfilment of
any breach of such warranty, Integrated Technical Vision ltd. shall, at
its option, repair or replace the defective equipment upon return of the
equipment to its repair depot. This warranty applies only to defects in
parts and workmanship and not damaged incurred in shipping or hand-
ing, or damaged due to causes beyond the control of Integrated Techni-
cal Vision Ltd. such as lightning, excessive voltage, mechanical shock,
water damage, or damage arising out of abuse, alteration or improper
application of the equipment.
The foregoing warranty shall apply only to the original buyer, and is and
shall be lieu of any and all other warranties, whether expressed or im-
plied and of all other obligations or liabilities on the part of Integrated
Technical Vision Ltd. This warranty contains the entire warranty. Inte-
grated Technical Vision Ltd. neither assumes, nor authorizes any other
person purporting to act on its behalf to modify or to change this warran-
ty, nor to assume for it any warranty or liability concerning this product.
In no event shall Integrated Technical Vision Ltd. be liable for any direct,
indirect or consequential damages. Loss of anticipated profits, loss of
time or any other losses incurred by the buyer in connection with the
purchase, installation or operation or failure of this product.
