Intel®PRO/100
LAN+Modem56 CardBus
Adapter
User's Guide

How to UseThis Manual
This Users Guide contains installation and configuration information for
Microsoft Windows* 95, Windows 98, and Windows NT*, and general
diagnostics and troubleshooting information.
Additional Information
For information on IBM OS/2*, 32-bit ODI* drivers, and Windows 3.x,
supplementary information on Windows 95, and modem command
reference information, see the text file README.TXT on the Intel CD-
ROM.
Visit the Intel support website at support.intel.com for software updates
and supplementary technical information.
See Appendix A for worldwide access to Intel Customer Support.
Copyright © 1998 Intel Corporation. All rights reserved.
Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, Oregon 97124-6497
Intel Corporation assumes no responsibility for errors or omissions in this guide. Nor does
Intel make any commitment to update the information contained herein.
*Other product and corporate names may be trademarks of other companies and are
used only for explanation and to the owners’ benefit, without intent to infringe.
First edition June 1998 717438-001

Contents
Hardware Installation........................................ 1-1
Windows 95 and 98 Installation........................ 2-1
Plug and Play Installation ......................................................... 2-1
Installing under Windows 95 and 98 ........................................ 2-1
Windows 95 and 98 Driver Parameters Reference.................. 2-2
Troubleshooting Modem Installation ........................................ 2-4
Windows NT Installation................................... 3-1
Installing under NT 4.0.............................................................. 3-1
Windows NT Driver Parameters ............................................... 3-3
Utilities, Diagnostics, and Troubleshooting ....... 4-1
Making a Floppy Disk ............................................................... 4-1
LAN Diagnostics ....................................................................... 4-2
Troubleshooting Checklist ........................................................ 4-2
Keyword Reference (All Drivers) .............................................. 4-3
Appendix A.......................................................A-1
A. Customer Support ................................................................A-2
B. Specifications .......................................................................A-3
C. Lifetime Limited Warranty ....................................................A-5
D. Regulatory Agency Notices..................................................A-6
E. Software License Agreement ...............................................A-8
Note: Windows 3.x, IBM OS/2, 32-bit ODI
Installation and troubleshooting information for the Windows 3.x,
OS/2, and 32-bit ODI see the README.TXT file on the Intel CD-
ROM. Modem command reference information can be found in the
Windows Help file HELPDOCS.HLP on the Intel CD-ROM.

iv Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide

CHAPTER 1
Hardware Installation
The PRO/100 LAN+Modem56 adapter supports both 10 Mbps and
100Mbps Ethernet networks and modem speeds up to 56Kbps for high-
performance connectivity in any environment. It plugs into your
computers Type II PC Card slot to connect to an Ethernet LAN and to
the telephone network.
Installation Overview
Follow the instructions in this chapter to install the PRO/100
LAN+Modem56 adapter hardware and network and modem cabling.
Then proceed to the software installation chapter for your operating
system environment, as follows:
Chapter 2. Windows 95 and 98 Installation
Chapter 3. Windows NT Installation
Chapter 4. Diagnostics and Troubleshooting
Installation and troubleshooting information for the Windows 3.x,
OS/2, and 32-bit ODI see the README.TXT file on the Intel CD-
ROM. Modem command reference information can be found in the
Windows Help file HELPDOCS.HLP on the Intel CD-ROM.
The PRO/100 LAN+Modem56 adapter provides access to both 10Mbps
and 100Mbps networks with a single adapter cable, and auto-negotiates
10Mbps or 100Mbps network speed.
Category 5 (data grade) unshielded twisted pair (UTP) cabling is
required for 100Mbps or Category 3 or 5 for 10Mbps.

1-2 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide
Power-Saving Modes
The PRO/100 LAN+Modem56 adapter includes battery saving technology
for maximum battery life on the road. When the LAN cable is detached,
the adapter senses the change and enters low-power mode. Normal power
is restored when the cable is reattached.
Before Installing Hardware
Check Package Contents:
 Intel® PRO/100 LAN+Modem56 CardBus adapter
 Ethernet adapter cable with a 16-pin PC Card connector at one end
and a female RJ-45 connector at the other
 Modem cable with a 26-pin PC Card connector at one end and a
female RJ-11 modular telephone connector at the other
 RJ-11 modular telephone cable
 Software, User's Guide and online documentation on CD-ROM
 Quick Installation booklet
Please fill out the Product Registration Card and mail or fax it
immediately to the Intel office indicated on the card.
Verify Other Required Equipment
To install the PRO/100 LAN+Modem56 adapter, you need the following:
1A mobile PC with a CardBus slot.
2A local area network supporting 10 or 100Mbps Ethernet and a
network operating system supported by the PRO/100 LAN+Modem56
adapter.
Since the PRO/100 LAN+Modem56 adapter automatically detects
the speed of the network to which it is connected, it may be safely
connected to either a 100Base-TX or 10Base-T network, as specified
in items 3 and 4 below.
3For connection to a 100Base-TX 100Mbps Ethernet network, a
Category 5 (data grade) unshielded twisted pair (UTP) network cable

Hardware Installation 1-3
terminating in a male RJ-45 connector and connected to a 100Mbps
hub or switch.
4For connection to a 10Base-T twisted pair Ethernet network, a
network cable terminating in a male RJ-45 connector and connected to
a 10Mbps hub or switch.
5For modem operations: an analog telephone line, RJ-11 modular
telephone cable (supplied), and if needed, an RJ-11 adapter for the local
telephone system. Communications software is also required for
modem and fax operations.
Do not connect to a digital telephone line or digital PABX system.
In case of inadvertent connection to a digital line, special circuitry
protects your modem.
Determine System Requirements
During installation of the PRO/100 LAN+Modem56 adapter hardware, d
your operating system software should be loaded. If configured to do so,
your system will detect the PRO/100 LAN+Modem56 adapter. For details
on how to install driver software, see the chapter for your operating
system environment.
The PRO/100 LAN+Modem56 adapter hardware is compatible with
Types II and III PC Card slots that support CardBus technology.
Installation and removal procedures may vary on different
computers.

1-4 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide
Installing the Hardware
Insert the PRO/100 LAN+Modem56 adapter
1Grasp the CardBus adapter by the edges with the Intel label facing
upward and the wide connector next to the CardBus slot.
2Insert the card into a CardBus slot and push it in until firmly seated.
The CardBus adapter can only be used in CardBus-compliant PC
Card slots.
Intel® PRO/100
Mobile Adapter
10/100
LAN
+
56K
Modem
CardBus
Inserting the CardBus into the Computer

Hardware Installation 1-5
Connecting the LAN Adapter Cable to the Card
 Attach the 16-pin connector at the end of the adapter cable to the
matching receptacle on the left side of the PRO/100
LAN+Modem56 adapter. Press the connector gently into the
receptacle on the card until its firmly in place. Do not force the
connection.
Intel® PRO/100
Mobile Adapter
10/100
LAN
+
56K
Modem
CardBus
Connecting the LAN Adapter Cable to the CardBus Adapter
Disconnecting Adapter Cable from the Card
 Grasp the small connector with the thumb and forefinger and gently
pull it free of the card.
Connecting the Network Cable to the LAN Adapter
Cable
 Plug the network cable into the female RJ-45 connector, as shown
in the figure.
Connecting to the Network Cable to LAN Adapter Cable
LINK INTEGRITY LED
ORANGE - 100Mbps
GREEN - 10Mbps
TRANSMISSION
ACTIVITY LED

1-6 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide
Connecting the Modem Cable to the Adapter
 Attach the 26-pin connector at the end of the Intel modem cable to
the matching receptacle on the right side of the PRO/100
LAN+Modem56 adapter. Press the connector gently into the
receptacle on the card until its firmly in place. Do not force the
connection.
Intel® PRO/100
Mobile Adapter
10/100
LAN
+
56K
Modem
CardBus
Attaching the Modem Cable to the CardBus Adapter
Disconnecting Modem Cable from the Adapter
 Grasp the small connector with the thumb and forefinger and gently
pull it free of the card.
Connecting the Modem Cable to the Telephone Line
 Plug one end of the RJ-11 modular telephone cable into the RJ-11
receptacle on the modem cable, and the other end into an analog
(single-line) RJ-11 telephone wall jack.
Connecting the Telephone Cable to the Modem Cable
The PRO/100 LAN+Modem56 adapter will not work with digital
telephone lines or digital PBX systems. Special circuitry protects
your modem against damage from inadvertent connection to a
digital line.

Hardware Installation 1-7
MODEM CABLE
TELEPHONE
CABLE CARRIER
DETECT
TRANSMIT
RECEIVE

1-8 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide

CHAPTER 2
Windows 95 and 98 Installation
Plug and Play Installation
Plug and play installation of the PRO/100 LAN+Modem56 adapter is
supported under Windows 95 OSR2 (version 950b or later) and Windows
98. Installation with these versions of Windows is described in this
chapter.
If you are using an earlier version of Windows 95 (versions 950 or
950a), see the README.TXT file on the Intel CD-ROM for
installation information.
Drivers Available
The following drivers for Windows 95 OSR2 and Windows 98 are
supplied with the PRO/100 LAN+Modem56 adapter:
 NDIS3 driver (M32A.SYS)
 NDIS4 driver (M32A4.SYS)
The NDIS3 driver M32A.SYS is installed by default using the procedures
in this chapter. For NDIS4 instructions, see the README.TXT file on
the Intel CD-ROM.
Software Installation for Windows 95 OSR2
Note: if your laptop computer does not have a CD-
ROM drive, see "Making a Floppy Disk,"in Chapter 4.
1With Windows running, insert the PRO/100 LAN+Modem56 adapter
into the CardBus slot and connect cables as shown above.
2Windows detects a PCI Ethernet controller and displays the Update
Device Driver Wizard. In this procedure, the LAN driver will be
installed first and then the modem driver. Insert the Intel CD-ROM

2-2 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide
and click Next to start the procedure. (If the New Hardware Found
window does NOT appear, proceed to step 8.)
3Windows confirms the device name. Click Finish. This installs the
LAN driver. Windows may prompt you for the location of Windows
networking files. Usually these are located in
C:\windows\options\cabs or on your Windows 95 installation disk. If
prompted for the M32A.SYS file, change the path back to your Intel
CD-ROM. If prompted to restart, click No.
4Windows detects the modem portion of the adapter and repeats the
process above for the modem component. If prompted for other files,
try changing the path to the Intel CD-ROM.
Note: Windows may display a message indicating some VXD
files are out of date. To determine if this affects operation of
your computer, restart and check the modem. If it will not
function, see the README.TXT file for detailed information.
5For most networks, you will need to configure properties for your
protocols, computer identification, and preferred servers. Contact
your network administrator for details if you need assistance.
6Restart the computer for the configuration to take effect.
7When the computer restarts, the Country Identifier utility runs.
Specify your location and Save or Exit.
8If the New Hardware Found window does NOT appear, you may
need to enable CardBus support in your computer BIOS. See your
computer's manual for information or check their website.
Software Installation for Windows 98
Note: if your laptop computer does not have a CD-
ROM drive, see "Making a Floppy Disk" in Chapter 4.
1With Windows running, insert the PRO/100 LAN+Modem56 adapter
into the CardBus slot and connect cables as shown above.
2Windows detects a PCI Ethernet Controller and displays the Add New
Hardware Wizard. Click Next to continue. In this procedure, the LAN
driver will be installed first and then the modem driver. (If the New
Hardware Found window does NOT appear, proceed to step 13.)
3On the next screen, Windows prompts for a driver search. Choose
"Search for the best driver (Recommended)" and click Next.

Windows 95 and 98 Installation 2-3
4Insert the Intel CD-ROM or floppy disk and click Next to continue.
If necessary, specify the path to your CD-ROM or floppy drive and
click Next.
5Windows confirms the device name and location of the LAN driver
(NETM32A.INF). Click Next to continue. Windows may prompt you
for the location of Windows networking files. Usually these are
located in C:\windows\options\cabs or on your Windows 98
installation disk.
6A message confirming successful LAN driver installation appears.
Click Finish.
7Do not restart your computer yet. When prompted to do so, click No.
8Windows detects the modem portion of the adapter and repeats the
process above for the modem (driver name is MDMM32A.INF). At
the end of this process, a small dialog appears reminding you to
restart. Click OK to close.
9The Country Identifier utility also runs at this time. Specify your
location and click Exit or Save.
10 If the New Hardware Found wizard is present, click Finish.
11 For most networks, you will need to configure properties for your
protocols, computer identification, and preferred servers. Contact
your network administrator for details if you need assistance.
12 Restart the computer to complete installation.
13 If the New Hardware Found window does NOT appear, you may
need to enable CardBus support in your mobile computer's BIOS. See
your computer's manual for information or check their web site.

2-4 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide
Windows 95 and 98 Driver Parameters Refer-
ence
M32A.SYS (NDIS3) and M32AN4.SYS (NDIS4) Driver
Settings
M32A.SYS is an NDIS3 driver. M32A4.SYS is an NDIS4 driver. Both
conform to the Microsoft Network Driver Interface Specification (NDIS).
Required files for using M32A.SYS with Windows 95 and 98 include:
NETM32A.INF Installation file for Windows 95 and 98
M32A.SYS NDIS3 driver for Windows 95 and 98
There are user-configurable parameters to the M32A.SYS and M32A4.SYS
drivers which can be modified using the Network Control Panel built into
Windows 95 and 98. This applet queries the user for parameter selections
and sets the corresponding parameters in the registry. User-configurable
parameters are as follows (for descriptions see Chapter 4):
Parameter Valid Values Reg. Value
Adapter LEDs OFF 0
ON 1
Address Mode IO IO
MEMORY MEMORY
Cable Detect OFF 0
ON 1
Early Receive OFF 0
ON 1
Early Transmit OFF 0
ON 1
Line Mode AutoDetect 0
Half-Duplex 1
Full-Duplex 2
Line Speed AutoDetect 0
10 Mbps 1
100 Mbps 2
Link Integrity OFF 0
ON 1

Windows 95 and 98 Installation 2-5
Network Address See Network Administrators note below.
Receive Buffer Size 0-100 same
Transmit Buffer Size 0-100 same
For Network Administrators Only. The network node address can be
modified by specifying a value for Network Address such as
00A0C9112233. If the user does NOT specify a Network Address, then
the M32A.SYS driver uses the network node address contained in the
PRO/100 LAN+Modem56 adapter Card Information Structure.
Troubleshooting Modem Installation
Review this section if any of the following problems occur:
 Modem initialization errors occur when attempting to dial-out using
a communications application.
 Connection fails or other problems occur.
It may be necessary to define a modem type within your communications
application. If the Intel modem is not listed, choose a Generic Hayes
compatible device.
If your computer is equipped with an infrared communications port, you
may need to disable this port. These ports often use COM port resources
required for other communications devices. Disable the infrared port both
in the computers CMOS or BIOS setup program and the Windows 95
Device Manager, as follows:
1Some computers use a hardware setup utility to configure the infrared
port in the BIOS. See your computer documentation.
2To disable the infrared communications port in Windows 95, go to
Device Manager tab under System in the Control Panel.
3Double-click the Ports (COM & LPT) entry and the IR Serial Port
entry. Check the Disable in this Hardware Profile option to disable the
device.

2-6 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide
4 You may also need to comment out any "device=" lines containing
TRANXIT in the SYSTEM.INI file. Use a semicolin at the beginning
of the line to comment out the line.
Use the Modem Diagnostics Tool to verify the computer-to-modem
interface.
1In the Modems option in Control Panel, click Diagnostics.
2In Diagnostics properties, highlight the COM port associated with the
Intel modem and click the More Info button. This causes Windows 95
and 98 to send commands to and read responses from the modem and
display information about the modem and its COM port. The Port
Information box should display the following information:
 The IRQ and I/O address of the modems COM port. These
should match the physical configuration of the port or modem
adapter.
 Modem responses to various AT commands. The Intel modem
may return ERROR for some AT commands that are not
supported. This does not indicate a failure.
3The Record a Log File option in the Modems option can also help
identify modem problems by recording modem commands and
responses in a MODEMLOG.TXT file. To create the
MODEMLOG.TXT file, go to Control Panel, Modems, Properties,
Connection, Advanced. In the Advanced Connection Settings window,
place a check mark in the Record a log file option box. A
MODEMLOG.TXT file will be created in the C:\WINDOWS
directory the next time the modem is used.

CHAPTER 3
Windows NT Installation
The PRO/100 LAN+Modem56 adapter supports manual installation
under Microsoft Windows NT 4.0. Plug and Play installation and hot
swapping of CardBus adapters are not directly supported by Windows NT.
When the CardBus Adapter is installed, the other PC Card slot is available
for use by another PC Card.
Drivers Available
The following drivers for Windows NT can be found on the Intel CD-
ROM:
 OEMSETNT - Installation file
 M32A.SYS - NDIS3 driver
 M32A4.SYS - NDIS4 driver
 M32MENT4.SYS - modem enabler
For the latest information on CardBus support in Windows NT,
review the README.TXT file on the Intel CD-ROM or visit the
Intel support web site at support.intel.com.
Software Installation for Windows NT
1Before powering-up your mobile computer, insert the PRO/100
LAN+Modem56 adapter into the CardBus slot, as shown on page 1.
2With the adapter in the CardBus slot, power-up the computer, click
Start, click Settings, and select the Control Panel. The Control Panel
opens.
3Double-click the Network icon. The Network Settings window opens.
4Click the Adapters tab. The Network Adapters window opens.
5Click Add. The Select Network Adapter window opens.

3-2 Intel®PRO/100 LAN+Modem56 CardBus Adapter User’s Guide
6Click Have Disk, insert the Intel CD-ROM, and specify the correct
path for the CD.
7Click OK. The Select OEM Option window opens, showing the
PRO/100 LAN+Modem56 adapter.
8Click OK. The Windows NT Setup window briefly displays.
9The Intel PRO/100 LAN+Modem56 Settings window opens,
displaying the default settings.
Note: In most circumstances, the default settings will properly
operate the adapter. However, some computers may require
changes to the defaults.
10 Click OK. The Network Settings window redisplays.
11 Click Close. Complete any relevant dialog boxes that appear such as
TCP/IP settings. Contact your Network Administrator for help if
necessary.
12 When the Network Settings Change window opens, click Yes to
restart the computer.
Modem Setup
13 After the computer has been restarted, select Modems from the
Control Panel.
14 At the Install New Modem screen make sure that the Dont detect my
modem; I will select it from a list checkbox is NOT checked. Click Next.
NT will query the COM ports looking for the Intel modem. Once the
Intel modem is found, click Next. If a Standard Modem is found, click
Change. On the next screen, click Have disk. Type in the path to your
CD-ROM drive and click OK.
15 The Country Identifier utility automatically starts. Make the appropri-
ate country selection (United States or Canada is the default).
16 At the Install New Modem screen click Finish.
17 At the Modems Properties screen click Dialing Properties to set up
dialing properties (not necessary if a modem had been previously
installed). Click Close.
