Intel NUC 11 Performance User manual

1
NUC11ATKC2
User Guide - January 2022
Intel® NUC 11 Essential Mini PC -NUC11ATKC2
User Guide
January 2022
You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning Intel products
described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter drafted which includes subject
matter disclosed herein.

2
NUC11ATKC2
User Guide - January 2022
No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.
All information provided here is subject to change without notice. Contact your Intel representative to obtain the latest Intel product
specifications and roadmaps.
The products described may contain design defects or errors known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Copies of documents which have an order number and are referenced in this document may be obtained by calling 1-800-548-4725 or by
visiting: http://www.intel.com/design/literature.htm.
Intel technologies' features and benefits depend on system configuration and may require enabled hardware, software or service activation.
Performance varies depending on system configuration. No computer system can be absolutely secure.
Intel and the Intel logo are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2022, Intel Corporation. All rights reserved.

3
NUC11ATKC2
User Guide - January 2022
Contents
1.0 Introduction ............................................................................................................................. 5
1.1 Before You Begin ........................................................................................................................................... 5
1.2 Installation Precautions ............................................................................................................................. 5
1.3 Observe Safety and Regulatory Requirements ......................................................................... 6
2.0 Open the Chassis ................................................................................................................... 7
3.0 Upgrade System Memory .................................................................................................. 8
3.1 Upgrade to Different Memory ............................................................................................................... 8
4.0 Install an M.2 SSD ...............................................................................................................10
5.0 Close the Chassis .................................................................................................................12
6.0 Use the VESA Bracket (Optional) ...............................................................................13
7.0 Connect Power ......................................................................................................................15
8.0 Set Up Microsoft® Windows® 11 ..............................................................................17
9.0 Install the Latest Device Drivers and Software ................................................18

4
NUC11ATKC2
User Guide - January 2022
Revision History
Date Revision Description
January 2022 1.0 Initial release.

5
NUC11ATKC2
User Guide - January 2022
1.0 Introduction
This User Guide provides step-by-step installation instructions for these products:
 Intel® NUC 11 Essential Mini PC - NUC11ATKC2
1.1 Before You Begin
CAUTIONS
The steps in this guide assume you’re familiar with computer terminology and
with the safety practices and regulatory compliance required for using and
modifying computer equipment.
Disconnect the computer from its power source and from any network before
performing any of the steps described in this guide.
Failure to disconnect power, telecommunications links, or networks before you open
the computer or perform any procedures can result in personal injury or equipment
damage. Some circuitry on the board can continue to operate even though the front
panel power button is off.
Follow these guidelines before you begin:
 Always follow the steps in each procedure in the correct order.
 Create a log to record information about your computer, such as model,
serial numbers, installed options, and configuration information.
 Electrostatic discharge (ESD) can damage components. Perform the
procedures described in this chapter only at an ESD workstation using an
antistatic wrist strap and a conductive foam pad. If such a station isn’t
available, you can provide some ESD protection by wearing an antistatic wrist
strap and attaching it to a metal part of the computer chassis.
1.2 Installation Precautions
When you install and test the Intel NUC, observe all warnings and cautions in the
installation instructions.
To avoid injury, be careful of:
 Sharp pins on connectors

6
NUC11ATKC2
User Guide - January 2022
 Sharp pins on circuit boards
 Rough edges and sharp corners on the chassis
 Hot components (such as SSDs, processors, voltage regulators, and heat sinks)
 Damage to wires that could cause a short circuit
Observe all warnings and cautions that instruct you to refer computer servicing
to qualified technical personnel.
1.3 Observe Safety and Regulatory Requirements
If you don’t follow these instructions, you increase your safety risk and the possibility
of noncompliance with regional laws and regulations.

7
NUC11ATKC2
User Guide - January 2022
2.0 Open the Chassis
Unscrew the four corner screws on the bottom of the chassis and lift the cover.

8
NUC11ATKC2
User Guide - January 2022
3.0 Upgrade System Memory
The Intel® NUC 11 Essential Mini PC - NUC11ATKC2 has two 260-pin DDR4 SO-DIMM
memory slots
Pre-installed memory
NUC11ATKC2 4GB memory module
To upgrade memory, be sure to select memory modules that meet these requirements:
1.2V low voltage memory
 2933 MHz SO-DIMMs
 Non-ECC
 Up to 32 GB total (2x 16GB memory modules)
Find compatible system memory modules at the Intel® Product Compatibility Tool:
 NUC11ATKC2
3.1 Upgrade to Different Memory
1. Observe the precautions in "Before You Begin" in Section 1.1.
2. Turn off all peripheral devices connected to the computer.
3. Turn off the computer and disconnect the power cord.
4. Remove the computer’s bottom chassis cover.
5. Remove the pre-installed memory module
a. Gently spread the retaining clips at each end of the memory socket, which
causes the module to pop out of the socket (C).
b. Holding the module by the edges, lift it away from the socket, and
store it in an anti-static package.
6. Install the new memory modules
a. Align the small space at the bottom edge of the memory module
with the key in the socket.
b. Insert the bottom edge of the module at a 45-degree angle into
the socket (A).
c. When the module is inserted, push down on the outer edges of
the module until the retaining clips snap into place (B). Make sure
the clips are firmly in place (C).

9
NUC11ATKC2
User Guide - January 2022

10
NUC11ATKC2
User Guide - January 2022
4.0 Install an M.2 SSD
Intel® NUC 11 Essential Mini PC - NUC11ATKC2 supports 80mm and 42mm SSDs.
Find compatible M.2 SSDs at the Intel® Product Compatibility Tool:
 NUC11ATKC2
If you’re installing an 80mm M.2 SSD:
1. Remove the small silver screw from the 80mm metal standoff on the
motherboard.
2. Align the small notch at the bottom edge of the M.2 card with the key in the
connector.
3. Insert the bottom edge of the M.2 card into the connector.
4. Secure the card to the standoff with the small silver screw.
If you’re installing a 42mm M.2 SSD:
1. Remove the small silver screw from the metal standoff on the motherboard.
2. Move the standoff from the 80mm position to the 42mm position.
3. Align the small notch at the bottom edge of the M.2 card with the key in the
connector.

11
NUC11ATKC2
User Guide - January 2022
4. Insert the bottom edge of the M.2 card into the connector.
5. Secure the card to the standoff with the small silver screw.

12
NUC11ATKC2
User Guide - January 2022
5.0 Close the Chassis
After all components have been installed, close the Intel NUC chassis. Intel
recommends this be done by hand with a screwdriver to avoid over-tightening and
possibly damaging the screws.

13
NUC11ATKC2
User Guide - January 2022
6.0 Use the VESA Bracket (Optional)
Follow these instructions to attach and use the VESA mount bracket:
1. Using the four small black screws that were included in the box, attach the
VESA bracket to the back of the monitor or TV.
2. Attach the two slightly larger black screws to the bottom chassis cover of the
Intel NUC.

14
NUC11ATKC2
User Guide - January 2022
3. Slide the Intel NUC onto the VESA mount bracket.

15
NUC11ATKC2
User Guide - January 2022
7.0 Connect Power
Country-specific power plug attachments are included in the box.
1. Choose the attachment for your region.
2. Connect AC power.
Each Intel NUC model includes either a region-specific AC power cord or no AC power
cord (only the power adapter).
Product codes Power cord type
BNUC11ATKC20RA0 No power cord included. An AC power cord needs to
be purchased separately. Power cords are available at
many Internet sites for use in multiple countries. The
connector on the power adapter is a C5 type
connector.

16
NUC11ATKC2
User Guide - January 2022
BNUC11ATKC20RA1
US power cord included.
BNUC11ATKC20RA2
EU power cord included.
BNUC11ATKC20RA3
UK power cord included.
BNUC11ATKC20RA4
Australia/New Zealand power cord included.
BNUC11ATKC20RA6
China power cord included.

17
NUC11ATKC2
User Guide - January 2022
8.0 Set Up Microsoft® Windows® 11
Microsoft Windows* 11 is already installed on the Intel NUC. The first time you start
the computer, you are guided through the Windows* 11 setup steps, including:
 Selecting your region and language.
 Accepting the Microsoft Windows license terms.
 Personalizing Windows and assign a PC Name.
 "Get Online" dialog to pick a wireless network (this step is optional).
 Choosing Express Settings or Customize.
 Assigning a User Name and Password.
Reinstalling the Operating System
If you upgrade or replace the computer’s drive, you may need to install a new version
of the operating system. See these resources:
 Supported Operating Systems
 Operating System Installation for Intel® NUC

18
NUC11ATKC2
User Guide - January 2022
9.0 Install the Latest Device Drivers and Software
Here are the options for keeping device drivers current:
 Allow the Intel® Driver & Support Assistant (Intel® DSA) to detect out-of-
date drivers
 Manually download drivers, BIOS, and software from Download Center:
o NUC11ATKC2
The following device drivers and software are available.
 Intel® Chipset Device Software
 Intel® HD Graphics
 Intel® Management Engine
 Realtek* 10/100/1000 Ethernet
 Intel® Wireless
 Intel® Bluetooth
 Intel® GNA Scoring Accelerator
 Intel® Serial IO
 Realtek* High-Definition Audio
