Intel W660DI User manual

Notebook PC
User’sGuide
Model: W660DI/ W660UI
First Edition: October 2008

User's Guide
Page II
Specifications and information found in this guide are subject to change
without notice. Any changes therefore will be incorporated in future
editions. The manufacturer assumes no responsibility for errors or omissions
in this document.
Windows™is the trademark of Microsoft Corporation.
Intel® is the trademark of Intel Corporation.
Bluetooth® is the trademark owned by its proprietor.
Other trademarks are properties of their respective owners.
NOTICE
TRADEMARKS

User's Guide
Page III
The following standards are adopted throughout this guide:
Notebook in boldface (with or without capitalization) refers to the notebook
computer that you have purchased.
Boldface type is also used to highlight important information in this
document.
Whenever extra caution is called for, the information will be boxed in a dark
frame preceded by "Note:" or "Warning:".
Standards

User's Guide
Page IV
This page is left blank intentionally.

User’sGuide Contents
Page V
CHAPTER 1 BEFORE YOU BEGIN ................................................1-1
1.1 CHECKING WHAT YOU RECEIVED..................................................................1-1
1.2 EXAMINING YOUR COMPUTER.......................................................................1-2
1.3 THE FOUR SYSTEM LEDS..............................................................................1-7
1.4 THE FOUR STATUS LEDS...............................................................................1-8
1.5 THE POWER BUTTON .....................................................................................1-9
1.6 THE TWO COMMUNICATION BUTTONS.........................................................1-10
1.7 THE FOUR MEDIA BUTTONS ........................................................................1-11
1.7 ATTENTION ON PCI EXPRESS AND MEDIA CARD SLOTS .............................1-12
1.8 OPERATING TEMPERATURE..........................................................................1-13
1.9 THE FINGERPRINT READER ..........................................................................1-14
1.10 THE AC ADAPTER (FOR DI SERIES).............................................................1-15
1.11 THE AC ADAPTER (FOR UI SERIES).............................................................1-16
1.12 THE <FN>KEY............................................................................................1-17
CHAPTER 2 BATTERY.....................................................................2-1
2.1 BATTERY PACK..............................................................................................2-1
2.2 RECHARGING THE BATTERY PACK ................................................................2-1
2.3 QUESTIONS AND ANSWERS............................................................................2-2
2.4 BATTERY MAINTENANCE...............................................................................2-3
2.5 POWER CONSUMPTION...................................................................................2-3
2.6 REDUCING POWER CONSUMPTION .................................................................2-4
2.7 REMOVING THE BATTERY PACK....................................................................2-4
CHAPTER 3 MEMORY .....................................................................3-1
3.1 LIMITATION OF 32-BIT WINDOWS™OS ........................................................3-2
3.2 REMOVING MEMORY MODULE......................................................................3-3
CHAPTER 4 TURBO MEMORY MODULE (OPTIONAL) ..........4-1
4.1 REMOVING TURBO MEMORY.........................................................................4-1
CONTENTS

Contents User's Guide
Page VI
CHAPTER 5 MINI-PCI EXPRESS MODULE.................................5-1
5.1 REMOVING MINI-PCI EXPRESS MODULE.......................................................5-1
CHAPTER 6 WWAN MODULE (OPTIONAL)...............................6-1
6.1 REMOVING WWAN MODULE........................................................................6-1
6.2 INSERTING THE SIM CARD.............................................................................6-3
CHAPTER 7 DIGITAL TV TUNER MODULE (OPTIONAL)......7-1
7.1 REMOVING DIGITAL TV TUNER MODULE......................................................7-1
7.2 THE DIGITAL TV TUNER MODULE ANTENNA ................................................7-3
CHAPTER 8 THE HARD DISK DRIVE...........................................8-1
8.1 REMOVING THE HARD DISK DRIVE...............................................................8-1
APPENDIX A - AGENCY REGULATORY NOTICES .................A-1
APPENDIX B - ADDENDUM............................................................B-1

User's Guide Before You Begin
Page 1-1
Chapter 1 Before You Begin
Please read this section before you start using your computer.
1.1 Checking What You Received
Your notebook package should contain the following items:
(a)
(a) The Notebook.
(b) AC Adapter.
(c) AC Power Cord.
(d) CD Disc (Including Drivers, and User’s
Guide).
(e) Battery Pack.
(f) Optional TV Antenna
(b)
(c)
(d)
(e)
(f)
Note: You should keep the original factory carton and packing materials in case you
need to ship the unit back for servicing.

Before You Begin User's Guide
Page 1-2
1.2 Examining Your Computer
Before you start using your computer, you need to get acquainted with your notebook's
main features and interfaces:
Panoramic View
Web Cam Lens
ODD Drive
Web Cam Sliding Door
Fingerprint Reader
Two Internal Microphones
LCD Screen
Battery Pack
Power Button
Two Communication Buttons
Four Speakers
Four Status LEDs
Four System LEDs
DC Jack
Touch Pad
Keyboard
Four Media Buttons

User's Guide Before You Begin
Page 1-3
Front View
Two Speakers
IEEE1394a Connector
Four Media Buttons
Microphone Jack
Infrared Ray Receiver
Headphone Jack (SPDIF)
Media Card Slot (MMC/ SD/ MS/ MS-Pro
Cards)
Four System LEDs
Rear View
Battery Pack

Before You Begin User's Guide
Page 1-4
Left View
PCI Express Card Slot
VGA Connector
USB Connector
Ventilation Holes
HDMI Connector
Kensington Lock
Right View
DC Jack
Digital TV Antenna Connector
RJ45 LAN Connector
ODD Drive
USB/e-SATA Connector
ODD LED
USB Connector
Eject Button
Note: This USB/ e-SATA Connector supports connection to industry standard USB
devices or e-SATA devices.
