Intel I865PE User manual

TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 3.0
April 09, 2004
User’User’
User’User’
User’ss
ss
s
ManualManual
ManualManual
Manual
6000002PDA330
IntelIntel
IntelIntel
Intel i865PEi865PE
i865PEi865PE
i865PE mainboardmainboard
mainboardmainboard
mainboard
for Intel Socket 478 processorfor Intel Socket 478 processor
for Intel Socket 478 processorfor Intel Socket 478 processor
for Intel Socket 478 processor

ii
DISCLAIMER OF WARRANTIES:
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE OF THE MANUFACTURER LIMITED
WARRANTY. THE MANUFACTURER EXPRESSLY EXCLUDES ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING ITS
PRODUCTS; INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
NONINFRINGEMENT. THIS DISCLAIMER OF WARRANTIES SHALL
APPLY TO THE EXTENT ALLOWED UNDER LOCAL LAWS IN THE
COUNTRY PURCHASED IN WHICH LOCAL LAWS DO NOT ALLOW
OR LIMIT THE EXCLUSION OF THE IMPLIED WARRANTIES.

iii
80 Port Frequently Asked Questions
Below is a list of some basic POST Codes, possible problems, and solutions. For
more detailed information about POST Codes, refer to Appendix E in this manual.
POST CODE Problem Solution
FFh or CFh 1.BIOS chip inserted
incorrectly
2. Incorrect BIOS update
version
3. Mainboard problem
4. Add-on card inserted
incorrectly.
1. Reinsert the BIOS
chip
2. Download the correct
BIOS version update
from the manufacturer's
Web site.
3. Replace mainboard
4. Remove and replace the
add-on card
C1h - C5h 1. Memory module
inserted incorrectly
2. Memory compatibility
problem
3. Memory module
damaged
1. Reinsert memory
module
2. Replace memory
with correct type
3. Replace memory
module
2Dh 1. Error occured in VGA
BIOS
2. VGA card inserted
incorrectly
1. Replace VGA card
2. Reinsert the VGA
card
26h Overclock error Clear CMOS or press the insert
key to power on the system
07h - 12h 1. Init keyboard
controller error
2. RTC error
1. Ensure that the keyboard and
mouse are connected
correctly.
2. Replace the RTC battery.
Initial Keyboard

iv
Table of Contents
Section 1 Introduction
Package Contents ...................................................... 1- 1
Mainboard Features ................................................... 1- 2
System Block Diagram ............................................... 1- 5
Section 2 Specification
Mainboard Specification ............................................ 2- 1
Section 3 Installation
Mainboard Layout ..................................................... 3- 2
Easy Installation Procedure ....................................... 3- 3
CPU Insertion ............................................................. 3- 3
Jumper Settings .......................................................... 3- 5
System Memory Configuration .................................. 3- 6
Expansion Slots .......................................................... 3- 9
Device Connectors..................................................... 3-11
Power-On/Off (Remote) .............................................. 3-18
External Modem Ring-in Power ON and
Keyboard Power ON Function (KBPO) ..................... 3-18
ACPI S3 (Suspend To RAM) Function ...................... 3-19
Section 4 BIOS Setup
Main Menu ................................................................ 4- 1
Standard CMOS Setup ............................................... 4- 2
Advanced BIOS Features .......................................... 4- 3
Advanced Chipset Features ...................................... 4- 6
Integrated Peripherals ................................................ 4- 8
Power Management Setup ......................................... 4- 13
PNP/PCI Configuration Setup .................................... 4-16
PC Health Status ........................................................ 4-18
Power BIOS Features ................................................. 4-20
Page

v
Defaults Menu ........................................................... 4-23
Supervisor/User Password Setting ............................ 4-24
Exit Selecting .............................................................. 4- 25
Section 5 Driver Installation
Easy Driver Installation .............................................. 5- 1
Realtek Sound Manager Quick User guide ................ 5- 2
Appendix Appendix A
Realtek Media Player User’s Guide ............................ A-1
Appendix B
Update Your System BIOS ......................................... B- 1
Appendix C
EEPROM BIOS Remover ........................................... C-1
Appendix D
GHOST 7 Quick User’s Guide (Optional) ................... D- 1
Appendix E
POST Codes ............................................................... E-1

vi
Page Left Blank

Introduction
Page 1-1
Section 1
INTRODUCTION
1-1 Package Contents
Contents
A. Mainboard
B. User’s manual
C. Floppy drive cable
D. HDD drive cable
E. CD (drivers and utilities)
F. I/O Shield
G. Game port cable
H. S-ATA data and power cable
Optional Items
I. Extra USB2.0 port cable
J. S/PDIF Module
B
A
C
D
USER’S
MANUAL
E
F
G
I
HJ
If you need the optional item, please
contact your dealer for assistance.

Introduction
Page 1-2
1-2 Mainboard Features
Brief Introduction
2Intel®Pentium®4 processors
The Pentium 4 processor is designed to deliver performance across applications
and usages where end-users can truly appreciate and experience the
performance. The Pentium 4 processor delivers this world-class performance for
consumer enthusiasts and business professional desktop PC users as well as for
entry-level workstation users.
Intel adds support for Hyper-Threading Technology to the Pentium 4 processor
family. HT Technology allows a single, physical Pentium 4 processor to function
as two logical processor for next generation multi threaded application.
For more information about all the new features the Pentium 4 delivers, check out the
Intel website at http://www.intel.com
2Chipset
This board is designed with Intel®865PE (Springdale-PE) chipset. The Intel®
865PE chipset consists of the Memory Controller Hub (MCH) and the I/O
Controller Hub (ICH5).
2Accelerated Graphics Port (AGP)
The AGP slot on the board is compliant with the new AGP 3.0 specification. This
new specification enhances the functionality of the original AGP specification
by allowing 8X data transfers ( 8 data samples per clock) resulting in maximum
bandwidth of 2.1GB/s. Only 1.5V AGP cards are supported.
2Ultra ATA100
The mainboard provides an Ultra ATA100 Bus Master IDE controller. This
controller supports Ultra ATA100 protocols which are ideal to support demanding
applications such as real-time video, multimedia, and a high performance operating
system. A new IDE cable is required for Ultra ATA100.
2Hardware Monitoring
Hardware monitoring enables you to monitor various aspects of the system
operation and status. This includes CPU temperature, voltage and fan speed in
RPMs.

Introduction
Page 1-3
210/100 LAN
This mainboard is mounted with an ethernet LAN PHY. It allows the mainboard to
connect to a local area network by means of a network hub.
2GbE LAN (For High-end model only)
This mainboard is optionally mounted with a Gigabit ethernet LAN chipset. The
new Gigabit Ethernet LAN allows data transmission at 1,000 megabits per second
(Mbps), which runs 10 times faster than conventional 10/100BASE-T Ethernet
LANs.
2Serial ATA
Support Serial ATA, an evolutionary replacement for Parallel ATA IDE storage
interface .Increases the peak data transfer speed up to 150MB/sec and allows
future enhancements to the computing platform.
2USB2.0
A popular USB standard for plugging in peripherals with up to 480Mbps transfer
speed while maintaining backward compatibility with older USB1.1 device.
26ch
Delivers 6 channel audio to bring you the latest in audio realism from DVD
movies and games. Perfect for your home theatre system.

Introduction
Page 1-4
Special Features
&80 Port
An onboard LED-display trouble-shooting device, facilitating user to detect
boot-up problems.
&QuickSPDIF
On board SPDIF-out connector for quick connection to multi-channel speakers.
Not only removes cable cluttering but also delivers loss-free digital audio to let
you enjoy DVD movies and games with crystal clear sound.
&Magic Health
Reports your system hardware status for every boot-up to help detect faults
early. Monitor hardware status including CPU temperature, CPU/Memory/AGP
voltage, fan RPM speed for chassis fan, CPU fan & Power supply fan.
&EZ-Boot
Simply press “ESC” to select your bootable device. No more hassle to search the
BIOS menu, change and re-start.
&PowerBIOS
Supporting a full range of overclocking setting via BIOS. Various adjustable
feature include FSB/AGP/Memory voltage tweaking.

Introduction
Page 1-5
Figure 5: System Block Diagram
1-3 System Block Diagram

Introduction
Page 1-6

Features
Page 2-1
Section 2
FEATURES
Mainboard Features
Processor
Socket 478 Intel®Pentium®4 and Celeron®processors up to 3.4+ GHz
Supports the following System Bus and Memory combination:
FSB400 / DDR266 (PC2100)
FSB533 / DDR266 and DDR333 (PC2100/PC2700)
FSB800 / DDR333 and DDR400 (PC2700/PC3200)
* When configured to FSB800/DDR333, adaptive synchronization aligns to the
closest FSB to memory clock ratio, setting memory channel to 320MHz.
Supports Hyper-Threading Technology
To enable the Hyper-Threading Technology function on your computer
system requires ALL of the following platform components:
)CPU: An Intel®Pentium®4 Processor with HT Technology.
)Chipset: An Intel®Chipset that supports HT Technology.
)BIOS: A BIOS that supports HT Technology and has it enabled.
)OS: An operating system that supports HT Technology.
Performance will vary depending on the specific hardware and software
you use. See <http://www.intel.com/info/hyperthreading> for information
including details on which processor support HT Technology.
Chipset
Intel 865PE Chipset (865PE + ICH5)
Main Memory
Four 184-pin DDR DIMM sockets for PC2100/PC2700/PC3200 (DDR266/
333/400) DIMMs
Supports 128-bit dual channel memory architecture
Supports up to 4GB memory size

Features
Page 2-2
BIOS
Flash EEPROM with Award BIOS
- ACPI v2.0 compliant
- S3 (Suspend to DRAM) sleep-state support
- SMBIOS (System Management BIOS) v2.2 compliant
- Supports Power failure recovery
- Able to wake the computer from specific states by LAN, Power switch,
PME#, RTC alarm, USB, PS2 K/B, PS2 Mouse, Modem Ring-in COM#1…
Onboard PCI Devices
LAN --> Integrates 10/100Mbps Fast Ethernet controller with onboard
Realtek RTL8100C LAN Chipset, or
Integrates 1Gbps Fast Ethernet controller with onboard
Marvell 88E8001 LAN Chipset (for high-end model only)
Legacy IO Controller
Winbond W83627HF LPC IO controller with keyboard, mouse, floppy,
printer, game, serial and IR interface
Supports Hardware Monitoring function
Audio
Six channel audio with analog and digital output using Realtek ALC655
AC’97CODEC
- AC’97 v2.3 compliant
- Supports CD-In, Aux-In and S/PDIF-in/out interface
- Supports Line-out and Mic-In for front panel
- Supports automatic “jack-sensing”
- Rear panel audio jacks configuration:
roloCkcaJoiduA lennahc2 lennahc6
eulBthgiLni-eniLtuo-oeretsraeR
emiLtuo-eniLtuo-oeretstnorF
kniPni-ciMrefoowbuS&retneC

Features
Page 2-3
Peripheral Interfaces
))
))
)At Rear Panel
PS/2 keyboard and mouse ports
One Parallel (printer) port
One S/PDIF-Out Coaxial jack
One S/PDIF-Out Optical (Optional)
One Serial port
One RJ45 LAN connector
Four USB2.0 ports
Three Audio jacks
))
))
)Onboard connector and pin-header
One floppy drive connector
Two IDE connectors supporting ATA-100
Four extra USB2.0 ports
One CD-IN and One AUX-IN connector
One Front Panel Audio connector
One S/PDIF-in/out connector
One IR connector
One Game port connector
One COM2 connector
Two S-ATA connectors
Three Fan connectors
Front Panel Controller
Supports Reset & Soft-Off switches
Supports HDD & Power LEDs
Supports PC speaker
Expansion Slots
One AGP slot supporting 1.5v 4X/8X AGP card
- AGP v3.0 compliant

Features
Page 2-4
Five PCI slots with Bus Master support
- PCI v2.2 compliant
Other BIOS Features
Magic Health – A quick “dashboard” display at POST to show hardware
status. Helps to detect faults early.
EZ Boot – An easy way let end-user can choose to boot from hard drive,
CD-ROM, floppy, …
KBPO – Keyboard power on, turn on the computer from keyboard
PowerBIOS for excellent Overclocking capabilities through
- subtle voltage tuning for CPU, Memory, AGP
- subtle frequency tuning on FSB with 1MHz increment
- Supports complete Asynchronous FSB/Memory and Asynchronous FSB/
AGP, PCI scheme for overclocking
P80P for system debugging
Form Factor
305mm x 225 mm ATX size

Installation
Page 3-1
Section 3
INSTALLATION

Installation
Page 3-2
Mainboard Layout

Installation
Page 3-3
Easy Installation Procedure
The following must be completed before powering on your new system:
3-1. CPU Installation
3-2. Jumper Settings
3-3. System Memory Configuration
3-4. Expansion Slots
3-5. Device Connectors
3-1 CPU Installation
Step 1
Open the socket by raising the actuation
lever.
<Figure 1>
Step 2
Align pin 1 on the CPU with pin 1 on
the CPU socket as shown in the
illustration above. The CPU is keyed to
prevent incorrect insertion. Don’t force
the processor into the socket. If it does
not go in easily, check for mis-orienta-
tion and reinsert the CPU.
Make sure the processor is fully
inserted into the socket.
<Figure 2>
Pin 1

Installation
Page 3-4
<Figure 3>
Step 4
Apply thermal compound to the top of
the CPU and install the heatsink as
shown.
Step 5
Install the cooling fan assembly. Press
the two clips in the direction of the
arrows shown in Figure 5 to secure the
assembly to the CPU socket.
Step 6
Plug the CPU fan power into the
mainboard’s CPU fan connector.
The installation is complete.
<Figure 4>
<Figure 5> <Figure 6>
NOTES:
• Installing with incorrect CPU fan and heatsink assemblies may damage
the Intel Pentium®CPU. Use Intel’s design thermal solution shown in the
illustrations above: an active heatsink; an extruded aluminum heatsink
base; and a fan attached to the top of the fin array.
• Apply heatsink thermal compound or paste to the CPU to avoid CPU
overheating and damage.
• In accordance with Intel guidelines specifications, do not install a CPU
over 50 times to avoid bending the pins and damaging the CPU.
Step 3
Close the socket by lowering and
locking the actuation lever.
