Intel SS4200-E - Entry Storage System NAS Server Configuration guide

Intel®Entry Storage System
SS4200-E
Technical Product Specification
(Hardware)
Intel Order E22057-003
Revision 1.1
Storage Systems Group Marketing

Table of Contents Intel® Entry Storage System SS4200-E
Revision History
Date Revision
Number Modifications
17 Sep 2007 0.5 Initial draft for review
28 Sep 2007 0.7 Review comments added and additional information corrected.
12 Oct 2007 0.9 Review comments added and additional information corrected.
24 Oct 2007 1.0 Review comments added and items remaining removed until data available.
Ready for publication.
28 Feb 2008 1.1 Updated graphic showing shroud removed, updated spare parts list, corrected
MTBF numbers, corrected drive retention bracket locking, updated tables in
fan control section.
Disclaimers
Information in this document is provided in connection with Intel®products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's
Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any
express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make
changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or
"undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or
incompatibilities arising from future changes to them.
This document contains information on products in the design phase of development. Do not finalize a design with
this information. Revised information will be published when the product is available. Verify with your local sales
office that you have the latest datasheet before finalizing a design.
The Intel®Entry Storage System SS4200-E may contain design defects or errors known as errata that may cause the
product to deviate from published specifications. Current characterized errata are available on request.
Intel system boards contain a number of high-density VLSI and power delivery components that need adequate
airflow to cool. Intel’s own chassis are designed and tested to meet the intended thermal requirements of these
components when the fully integrated system is used. It is the responsibility of the system integrator that chooses not
to use Intel developed system building blocks to consult vendor datasheets and operating parameters to determine
the amount of air flow required for their specific application and environmental conditions. Intel Corporation cannot be
held responsible if components fail or the system board does not operate correctly when used outside any of their
published operating or non-operating limits.
Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation.
*Other brands and names may be claimed as the property of others.
Copyright © Intel Corporation 2007, 2008.
ii Revision 1.1

Intel® Entry Storage System SS4200-E Table of Contents
Table of Contents
1. Feature Summary.................................................................................................................1
1.1 System Components ...............................................................................................6
1.2 System Board Feature Set ......................................................................................9
1.3 Serial ATA (SATA)...................................................................................................9
1.4 Enclosure Management...........................................................................................9
1.4.1 Fan Connector and Control ...................................................................................10
1.4.2 Voltage Monitoring.................................................................................................11
1.4.3 Hard Disk Drive LEDs............................................................................................11
1.5 Chassis Dimensions and Weight...........................................................................12
1.6 Back Panel I/O Ports and Features.......................................................................13
1.7 Front Panel and Hard Disk Drive Retention Bracket Assembly.............................13
1.7.1 Front/Rear Panel Controls and Indicators .............................................................15
2. Power Sub-System.............................................................................................................18
2.1 Power Supply.........................................................................................................18
2.1.1 Power Supply Outputs...........................................................................................20
2.1.2 Efficiency, Standby Efficiency and Overshoot .......................................................20
2.2 Output Power / Currents........................................................................................20
2.3 Voltage Regulation ................................................................................................21
2.4 Protection Circuits..................................................................................................21
2.4.1 Over Voltage Protection (OVP)..............................................................................21
2.4.2 Short Circuit Protection (SCP)...............................................................................21
3. System Cooling Fans.........................................................................................................22
3.1 Fan Control............................................................................................................22
4. Hard Disk Drive Retention Assembly...............................................................................23
4.1 Hard Disk Drives....................................................................................................24
4.1.1 Hard Disk Drive Retention Bracket Assembly .......................................................24
5. System Interconnection.....................................................................................................26
5.1 Chassis Internal Connectors..................................................................................26
5.2 I/O Panel Connectors ............................................................................................26
5.3 SATA Connectors..................................................................................................27
5.3.1 SATA Connector....................................................................................................27
5.3.2 Power Connectors.................................................................................................28
Revision 1.1 iii

Table of Contents Intel® Entry Storage System SS4200-E
5.3.3 Front Panel Connector...........................................................................................30
6. Regulatory Information......................................................................................................31
6.1 Product Regulation Requirements.....................................................................................31
6.1.1 Product Safety Compliance...................................................................................31
6.1.2 Product EMC Compliance – Class B Compliance.................................................31
6.1.3 Certifications / Registrations / Declarations...........................................................32
6.2 Product Regulatory Compliance Markings ............................................................33
6.2.1 Component Regulation Requirement Need to Support System Level Certifications33
6.2.1.1 Product Ecology Requirements.............................................................................34
7. Environmental Limits.........................................................................................................36
7.1 System Office Environment ...................................................................................36
7.2 System Environmental Testing..............................................................................36
7.3 Environmental Limits .............................................................................................37
8. Serviceability and Availability...........................................................................................38
9. Calculated MTBF ................................................................................................................39
Appendix A: Spares and Accessories ...................................................................................41
Upgrade and Accessory Parts.................................................................................................41
Glossary.....................................................................................................................................42
iv Revision 1.1

Intel® Entry Storage System SS4200-E List of Figures
List of Figures
Figure 1. Intel®Entry Storage System SS4200-E in optional orientations....................................2
Figure 2. Intel® Entry Storage System SS4200-E Block Diagram ................................................6
Figure 3. System Board Connectors.............................................................................................7
Figure 4. System Components .....................................................................................................8
Figure 5. Chassis Rear – showing feet both for vertical and horizontal orientation....................13
Figure 6. Chassis Front...............................................................................................................13
Figure 7. Hard Disk Drive Retention Bracket Assembly .............................................................14
Figure 8. Front Panel..................................................................................................................16
Figure 9. Rear Panel...................................................................................................................17
Figure 10. Power Supply Enclosure............................................................................................19
Figure 11. Disk Drive Insertion and Removal .............................................................................23
Figure 12. Drive Ordering ...........................................................................................................24
Figure 13. Hard Drive RVR (Rotational Vibration Reduction) Screw..........................................25
Figure 14. Chassis Rear I/O Connectors....................................................................................26
Figure 15. SATA Data and Power Connectors...........................................................................27
Revision 1.1 v

List of Tables Intel® Entry Storage System SS4200-E
List of Tables
Table 1. Intel®Entry Storage System SS4200-E Hardware Feature Summary...........................3
Table 2. System Board Components............................................................................................7
Table 3. Hardware Monitor Features..........................................................................................10
Table 4. Analog Voltage Monitor.................................................................................................10
Table 5. Fan Connector Pin-out..................................................................................................10
Table 6. Voltage Sensor Locations and Lower and Upper Bounds............................................11
Table 7. HDD and Disk Activity LEDs States..............................................................................11
Table 8. Chassis Dimensions and Weight..................................................................................12
Table 9. Front and Rear Control Button Functions.....................................................................15
Table 10. Front Panel LED Indicators.........................................................................................15
Table 11. AC Input Line Voltage Ranges....................................................................................18
Table 12. Power Supply Output Summary (250W 10 second peak ratings)...............................20
Table 13. DC Output Load Ratings.............................................................................................20
Table 14. DC Output Voltage Regulation Ratings ......................................................................21
Table 15. Over Voltage Protection (OVP) Limits ........................................................................21
Table 16. Thermal Sensor Locations and Temperature Bounds................................................22
Table 17. Fan Speed Lower and Upper Bounds.........................................................................22
Table 18. Thermal Sensor Soft Shutdown Thresholds...............................................................22
Table 19. SATA Connector Pin-out.............................................................................................27
Table 20. 2x12 Main Board Power Connector Pin-out................................................................28
Table 21. 2x12 CPU Power Connector Pin-out ..........................................................................29
Table 22. Front Panel Power Connector.....................................................................................30
Table 23. Intel® Entry Storage System SS4200-E System Office Environment Summary..........36
Table 24. Intel® Entry Storage System SS4200-E Operating and Non-Operating Environmental
Limits...........................................................................................................................37
Table 25. Intel®Entry Storage System SS4200-E Component MTBF Numbers ........................39
Table 26. Intel® Entry Storage System SS4200-E Upgrade and Accessory Parts......................41
vi Revision 1.1

Intel® Entry Storage System SS4200-E Feature Summary
1. Feature Summary
This Technical Product Specification provides detailed information about the hardware
components of the Intel®Entry Storage System SS4200-E.
The Intel®Entry Storage System SS4200-E includes a chassis, Intel®Celeron®M 420
Processor based board, with a single Intel Celeron M 420 processor, four Serial ATA hard disk
drive ports, one Intel®82573 Gigabit Ethernet Network controller, 512MB of DDR2 SDRAM
memory and a single 250 W power supply. Intel®-based system boards and chassis have
feature sets designed to support the high-density storage market.
The Intel Celeron M 420 Processor based board that is installed in the Storage System SS4200-
E chassis is a printed circuit board with features that were designed to support the storage
system market. The architecture is based on the Intel Celeron M Processor family.
Revision 1.1 1

Feature Summary Intel® Entry Storage System SS4200-E
Figure 1. Intel®Entry Storage System SS4200-E in optional orientations
2 Revision 1.1

Intel® Entry Storage System SS4200-E Feature Summary
Table 1. Intel®Entry Storage System SS4200-E Hardware Feature Summary
Storage Capacity Expandable to 4.0 TB – using four 1000 GB drives
NOTE: For specific drive family and capacities supported,
please refer to the SS4200-E Tested Hardware and OS List
(THOL)
Disk Drives 4 Serial ATA (SATA)
Hard Disk Drives Supported 3.5 inch SATA 1.5 Gb/s and SATA 3.0 Gb/s
NOTE: For specific drive family and capacities supported,
please refer to the SS4200-E Tested Hardware and OS List
(THOL)
Processor A single Low Voltage Intel® Celeron® M 420 processor
operating @ 1.6 GHz
Memory Capacity 1 GB maximum, using 32-bit DDR2 SDRAM
System ships with 512MB DDR2 SDRAM memory
NOTE: Only qualified service personnel should service system
memory.
Memory Type Synchronous Dynamic Random Access Memory (SDRAM),
PC4200 – system ships with 512 MB memory
NOTE: For specific memory recommendations please refer to
the Tested Hardware and OS List (THOL). Only qualified
service personnel should service system memory.
DIMM Slots One 240-pin DIMM socket
SATA Compliance SATA 3.0Gb/s
Client Connectivity Client Connectivity via Gigabit Ethernet
Front Panel
LEDs Network Port, Disk Status / Fault (per disk drive), System
Status, Power, Global Disk Activity
Power Power button
Connectivity 2 USB 2.0 ports
Back Panel
Buttons and Switches Reset / Recovery button
I/O Connectors 1 RJ-45 Ethernet port
2 USB 2.0 ports
2 e-SATA ports
Power Receptacle 1x IEC AC per installed power supply module
Chassis
Form Factor Custom chassis
Motherboard 183 mm x 242 mm (7.2” x 9.54”)
Height 122 mm (4.8”)
Width across body of enclosure 406 mm (16”)
Depth from flange to rear of enclosure
body 336 mm (13.23”)
Weight As shipped (zero drives): approximately 6.69 kg, 14.57
pounds
Fully configured (four drives): approximately 9 kg, 20
pounds
Color Black
System Cooling
Fans Chassis includes two single rotor 70mm x 70mm x 15mm
system fans for cooling the hard drives, baseboard and other
internal components.
Revision 1.1 3

Feature Summary Intel® Entry Storage System SS4200-E
The power supply enclosure contains a 40mm x 40mm x
20mm fan.
Power
Configuration 250 W continuous power supply. Intel Entry Storage System
SS4200-E ships with one 250 W power supply
Nominal AC input current (PS
Enclosure) 1.5 Amperes at 115 Vrms, 0.75 Amperes at 230 Vrms
Max +3.3 V output current
(PS Enclosure) 4.0 A
(total combined power for the +3.3 V and +5 V outputs
should not exceed 60 W steady state).
Max +5 V output current
(PS Enclosure) 12.0 A
(total combined power for the+3.3 V and +5 V outputs should
not exceed 60 W steady state).
Max +12 V output current
(PS Enclosure) 17.0 A
(total combined power for the+3.3 V, +5 V and +12 V outputs
should not exceed 234 W).
Max -12 V output current
(PS Enclosure) 0.5 A
Max +5 V Standby output current
(PS Enclosure) 2 A
Environment
Ambient Temperature Operating: +10 degrees Celsius to +35 degrees Celsius, with
maximum change not to exceed 10 degrees Celsius per
hour; non-operating (system): -40 degrees Celsius to +70
degrees Celsius.
Relative Humidity Non-operating: 90%, @ +35 degrees Celsius non-
condensing
Operating: 0-80% @ 0 degrees Celsius to +40 degrees
Celsius non-condensing
Acoustics
Electrostatic Discharge ±12 Kilovolt (KV) per Intel® Environmental test specification
System Cooling Requirement in
British Thermal Units (BTU) per Hour < 341 BTU/hour @ 100W
Safety Compliance
Argentina IRAM
Canada UL60950 – CSA (60950 (UL and cUL)
China GB4943- CNCA Certification
Europe, CE Mark EN60950 (complies with73/23/EEC)
Germany GS License
International IEC60950 (CB Report and Certificate)
Nordic Countries EMKO-TSE (74-SEC) 207/94
Russia GOST 50377-92
United States UL– 60950 – CSA 60950 (UL and cUL)
Electromagnetic Capability (Class B)
(EMC)
Australia/New Zealand AS/NZS 3548 (based on CISPR 22)
Canada ICES-003
China GB 9254 - CNCA Certification
GB 17625 - (Harmonics) CNCA Certification
Europe, CE Mark EN55022; EN55024 & EN61000-3-2;-3-3 (complies with
4 Revision 1.1

Intel® Entry Storage System SS4200-E Feature Summary
89/336/EEC)
International CISPR 22
Japan VCCI
Korea RRL MIC 1997-41 & 1997-42
Russia GOST 29216-91 & 50628-95
Taiwan CNS13438
United States FCC, Part 15
Revision 1.1 5

Feature Summary Intel® Entry Storage System SS4200-E
1.1 System Components
A block diagram of the storage system’s functional components is shown below.
Celero ®M 420 Processor
LGA775
945GZ
GMCH
ISL6713A
FSB800
VCCP
IDTCV110P
ICS9DB102
CLK
ICH7R
South Bridge
DMI
4X
2.5G
DDR2
533/400
82573E
USB 2.0
USB 2.0
USB 2.0
USB 2.0
eSATA
eSATA SIL3132
eSATAcontroller
DOM IDE
PCI-E
SCH5027D
SIO
RS232
FWH
SATA
SATA
SATA
SATA
SATA2
PCI -E x1
82573E
PCI -E x1
XDP
LPC
DDR2 533/400
Figure 2. Intel® Entry Storage System SS4200-E Block Diagram
6 Revision 1.1

Intel® Entry Storage System SS4200-E Feature Summary
The following diagram shows the system board’s connectors.
Figure 3. System Board Connectors
The components included with this storage system are diagrammed below.
Table 2. System Board Components
A Reset / Recovery Button K DIMM slot
B LAN Ethernet Port / USB 2.0
Ports L Left Chassis Fan Connector
C Right Chassis Fan Connector M IDE DOM Connector
D eSATA Ports N USB Header
E RS-232 Debug Port O CMOS Battery
F PCI-e Debug Port P SATA4 Connector
G Front Panel Connector Q SATA3 Connector
H CPU Power Connector R SATA2 Connector
I CPU S SATA1 Connector
J Main Power Connector
Revision 1.1 7

Feature Summary Intel® Entry Storage System SS4200-E
Figure 4. System Components
8 Revision 1.1

Intel® Entry Storage System SS4200-E Feature Summary
1.2 System Board Feature Set
The Intel®Entry Storage System SS4200-E Board provides the following feature set, as
implemented in the Intel®Entry Storage System SS4200-E.
Feature Description
Processor Single 1.6GHz Intel® Celeron M Processor 420
Memory Unregistered Non-ECC DDR2 533/400
Supports 256MB, 512MB & 1GB
NOTE: The Intel Entry Storage System SS4200-E ships with 512MB memory.
Only qualified service personnel should service system memory. For specific
memory recommendations please refer to the Tested Hardware and OS List
(THOL).
Peripheral
Interfaces 1 PCI-e x1 bus providing connection for:
•2 10/100/1000 Megabits per second (Mb/s) Ethernet LAN ports
•1 Serial ATA 4 port controller operating at 3.0 Gigabits per second
1 PCI bus providing connection for:
•4 USB 2.0 ports
NOTE: The system board contains only a single LAN port connector at this
time. The board as designed can support a 2nd LAN port connector.
LAN Intel®82573E 10/100/1000 Megabits per second (Mb/s) Ethernet Local Area
Network (LAN) Controller.
NOTE: The system board contains only a single LAN port connector at this
time. The board as designed can support a 2nd LAN port connector.
Fans Support for two system fans
1.3 Serial ATA (SATA)
The Intel® Entry Storage System SS4200-E ships with an ICH7R part which has an integrated 4
port SATA controller. The SATA controller provides the following feature set:
Feature Description
Number of ports 4
Serial ATA Bus Speed 3.0 Gb/s
Serial ATA Data Transfer rate 300 MB/s
PCI-e Bus x1
Hot Swap Not implemented
RAID Management Tools Yes, via Intel®Storage Management Software using the user interface
Please refer to http://www.intel.com/design/chipsets/datashts/307013.htm for
more information.
1.4 Enclosure Management
The Intel® Entry Storage System SS4200-E contains thermal sensors, primarily to regulate fan
speeds but also to provide an indication of system and enclosure health. Included sensors are
an internal CPU thermal sensor and a thermal sensor on the baseboard near the north bridge.
Revision 1.1 9

Feature Summary Intel® Entry Storage System SS4200-E
Proper operation of the thermal sensors is critical to system health and availability and
protection of user data. The power supply fan cannot be monitored.
Enclosure management is performed by a SMSC SCH5027D part with an integrated hardware
monitor controller. The SMSC component monitors various aspects of the storage enclosure.
The enclosure management controller supports the following features:
Table 3. Hardware Monitor Features
Item Specification
Voltage
4x Monitoring:
V_5P0_STBY\G
V_1P5_CORE
+12V VCCP
FAN 3x Fan Tachometers 3 PWM
Fan Speed Control
Temperature 1x for CPU Temperature
1x for System Temperature
Table 4. Analog Voltage Monitor
Item Item Name Pin No. String in BIOS Remarks
V1 V_1P5_CORE PIN 1 MON_V_1P5_CORE 1.5V
V2 +12V PIN 2 MON_12V 12V
V3 VCCP PIN 127 VCCP VCCP
V4 V_5P0_STBY\G PIN 128 V_5P0_STBY\G 5V
1.4.1 Fan Connector and Control
The 4-pin fan connector supports a standard fan with integrated fan speed control on the fan
itself for better fan life. The first 3 pins of this 4-pin fan connector are backward compatible with
a traditional 3-pin fan connector without PWM fan speed control but a 3-pin fan should not be
used in the Intel® Entry Storage System SS4200-E. A fan spare kit is available from your
supplier which contains the correct fan.
Table 5. Fan Connector Pin-out
Pin Signal Name
1 GND
2 +12V
3 Tachometer
4 Fan PWM (Speed) Control
Fan control is managed through the SMSC SCH5027D Super I/O and enclosure management
component. In the event of a fan failure the system will shutdown to prevent an over
temperature situation. For additional information refer to Section 3, System Cooling Fans.
10 Revision 1.1

Intel® Entry Storage System SS4200-E Feature Summary
1.4.2 Voltage Monitoring
The storage system is designed to allow the voltage to be monitored at several points on the
system board. This information can be used by the system management software and reported
to the user. Any action taken as a result of a possible value being outside of the specification is
determined by the software provider. Consult the user manual for the software in use for this
information.
The table below shows voltage sensor locations and the lower and upper bounds on values for
a system operating within normal range.
Table 6. Voltage Sensor Locations and Lower and Upper Bounds
Voltage Sensor Location Lower Bound Upper Bound
V_5P0_STBY/G U17
Pin128 4.75V 5.25V
MON_V_1.5V CORE U17 Pin1 1.425V 1.575V
Monitor 12 Volts U17 Pin2 11.4V 12.6V
VCCp U17
Pin127 0.980V 1.358V
VCC3 U17 Pin4 3.135V 3.465V
V_3P0_BAT_VREG U17 Pin32 2.0V 3.6V
V_3P3_STBY\G U17 Pin91 3.135V 3.465V
1.4.3 Hard Disk Drive LEDs
The Intel®Entry Storage System SS4200-E contains one LED for each of the four hard disk
drives. In addition there is a disk activity LED on the front panel. The states for the LEDs are
documented in the following table.
Table 7. HDD and Disk Activity LEDs States
HDD LEDs States
Drive Status LED State
Drive Unavailable Solid Off
Drive Available Solid Blue
Drive is Rebuilding Blinking Amber
Fault Condition Solid Amber
Disk Activity State
Any of HDDs Active Blinking Blue
Revision 1.1 11

Feature Summary Intel® Entry Storage System SS4200-E
1.5 Chassis Dimensions and Weight
Table 8. Chassis Dimensions and Weight
Height 122 mm 4.8 inches
Width across body of enclosure 406 mm 16 inches
Depth from flange to rear of enclosure body 336 mm 13.23 inches
Weight Chassis - as shipped (0 drives)
Chassis - fully configured (4 drives)
6.69 kilograms
9 kilograms
14.57 pounds
20 pounds
12 Revision 1.1

Intel® Entry Storage System SS4200-E Feature Summary
1.6 Back Panel I/O Ports and Features
At the rear of the chassis is one 10/100/1000 Local Area Network connector, two USB 2.0 ports
and two eSATA expansion connectors. The Input/Output (I/O) connectors are integrated into the
back panel. The figure below shows the rear of the storage system.
Figure 5. Chassis Rear – showing feet both for vertical and horizontal orientation
1.7 Front Panel and Hard Disk Drive Retention Bracket Assembly
The front panel contains 2 2.0 USB ports for additional connectivity and LED indicators for
status of disk drives and network connectivity. The power button is also located on the front
panel. See figure 8 for the specific LED locations. The hard disk drive retention bracket
assembly has been designed to minimize the effects of rotational vibration on disk drive
performance.
Figure 6. Chassis Front
Revision 1.1 13

Feature Summary Intel® Entry Storage System SS4200-E
Figure 7. Hard Disk Drive Retention Bracket Assembly
14 Revision 1.1
