Intelbras LSWM2QP2P User manual

Intelbras
LSWM2QP2P
Interface Card User
Manual

2
Intelbras LSWM2QP2P
Interface Card User Manual
Overview
The LSWM2QP2P interface card provides two QSFP+ ports.
The switch models that the LSWM2QP2P interface cards is applicable to may change over me. For the most
up-to-date list of applicable switch models, contact Intelbras Support or markeng sta.
The restricons for using the LSWM2QP2P vary by device model. For more informaon, see the installaon
guide or hardware informaon and specicaons for the device.

3
Intelbras LSWM2QP2P
Interface Card User Manual
Installing and removing the card
Prepare the following tools before you install or remove the card: Phillips screwdriver, at-blade screwdriver,
and ESD wrist strap.
No installaon tools are provided with the device. Prepare these tools yourself.
1 - Safety precauons
Before you install or remove the card, wear an ESD wrist strap and make sure the strap makes good skin
contact and is reliably grounded.
To avoid device damage, do not use excessive force when you install or remove the card.
2 - Installing the card
Remove the ller panel (if any) from the target slot before installing the card. Keep the removed screw and
ller panel secure for future use.
(1) Unpack the card. Insert the card slowly into the slot along the guide rails.
(2) Rotate inward the ejector lever unl the card is in close contact with the switch.
(3) Use the Phillips screwdriver to ghten the capve screw on the card.
12
3

4
Intelbras LSWM2QP2P
Interface Card User Manual
3 - Removing the card
To avoid cable damage, remove the cables from the card before removing the card.
If you are not to install a new card aer removing the original one, install a ller panel In the slot to prevent
dust and ensure good venlaon in the device.
Place the removed card on an an-stac mat or in an an-stac bag.
(1) Use a Phillips screwdriver to loosen the capve screw on the card.
(2) Hold the ejector lever to pull the card outward unl the card is disconnected from the connectors.
(3) Hold the card with both hands and take it out slowly.
(4) Installing and removing transceiver modules and cables
Verifying the installaon
Aer the installaon is complete, determine whether the card is operang correctly. If the card fails to operate
correctly, perform the following steps:
Reinstall the card following the installaon procedures described in this document.
If the problem persists, contact Intelbras Support.
2
3
1

5
Intelbras LSWM2QP2P
Interface Card User Manual
Ports
You can install QSFP+ transceiver modules, QSFP+ cables, and QSFP+ to SFP+ cables in the SFP ports.
Intelbras transceiver modules and cables available for the card are subject to change over me. For the most
recent list of Intelbras transceiver modules and cables available for the card, contact Intelbras Support or
markeng sta.
LEDs
The QSFP+ port LEDs are not aected by the port LED mode switching buon on your switch. For more
informaon about the port LED mode switching buon, see the installaon guide for the switch.
LED Status
Description
Steady green
A transceiver module is installed in the port. The port is operating at 40 Gbps, and a link is present on
the port.
Flashing green
The port is sending or receiving data at 40 Gbps.
Steady yellow
A transceiver module is installed in the port. The port is operating at 10 Gbps, and a link is present on
the port.
Flashing yellow
The port is sending or receiving data at 10 Gbps.
Off
No transceiver module is installed in the port, or no link is present on the port.
