INT-1X4B-1H Quick Install Guide
This guide is for quick installa on only.
For complete owners manual go to www.libav.com or use a QR reader to access the
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet

INT-1X4B-1H Quick Guide
2
The Intelix INT-1X4B-1H 1:4 HDBaseT distribuon amplier accepts a single HDMI input and splits
into four HDBaseT outputs. The INT-1X4B-1H is designed with an HDMI loop out which is intended
to cascade to addional INT-1X4B-1H units to distribute to mulple displays via HDBaseT. It supports
video resoluons up to 4K@60Hz / 4:2:0 / 8bit deep color and all HDMI audio formats. It can extend
1080p signals on each output up to 229 feet (70 meters) and 4K signals up to 131 feet (40 meters)
over a single CAT6 Ethernet cable. It supports Power over HDBaseT (PoH), which allows the compable
receivers to be powered from the splier over the Ethernet cables. It supports bidireconal IR and
RS232 pass-through and loop output.
The Intelix INT-HD70-RX and INT-HDX100-RX are compable Intelix receivers with the INT-1X4B-1H
distribuon amplier.
Product Overview
Package Contents
• INT-1X4B-1H 1:4 HDBaset Distribuon Amplier
• Quick Install Guide
• (1) 3-pin to 3-pin RS232 Cable (for RS232 cascading)
• (1) 3-pin to DB9 RS232 Breakout Cable
• (1) 3.5mm Audio Cable (for IR cascading)
• (1) IR Emier
• (4) IR Broadband Receivers (30-55KHz)
• (1) DC24V 2.71A power supply with US power plug
• (2) Mounng clips with mounng screws
• (4) Plasc Cushions

INT-1X4B-1H Quick Guide
3
Front Panel View
1 2 3 4 5
1. POWER LED - Illuminates solid RED when power is properly applied
2. INPUT LED - Illuminates solid GREEN when there is an ACTIVE HDMI source
3. OUTPUT LEDS
• HDMI - Illuminates solid GREEN when here is an HDMI output link
• LINK - Each LINK LED illuminates solid GREEN when there is a valid connec on between the distribu on amps
HDBaseT output and a compa ble HDBaseT receiver
• HDCP - Each HDCP LED illuminates solid GREEN when the corresponding receiver supports HDCP and blinks
GREEN when the corresponding receiver does not support HDCP. Each LED is o when there is no connected
corresponding receiver
4. EDID - Dip switch se ng for EDID management
• L.RES - The INT-1X4B-1H reads EDID from all connected displays, and then the source device will automa cally
obtain the EDID which contain the lowest resolu on
• DEFAULT - Reset to the default EDID to distribute 4K@30Hz video
• H.RES - The INT-1X4B-1H reads EDID from all connected displays, and then the source device will automa cally
obtain the EDID which contain the highest resolu on
5. FIRMWARE - USB port for  rmware upgrade procedure

INT-1X4B-1H Quick Guide
4
Back Panel View
1 2
3
456
1. HDMI IN - HDMI input port for connec ng HDMI source
2. OUTPUTS
• HDMI - HDMI loop output for connec ng to a local display or cascading the same HDMI source to another
INT-1X4B-H
• HDBT 1-4 - Four HDBaseT RJ45 jacks with PoH support for connec ng four compa ble HDBaseT receivers
• IR IN - Four 3.5mm IR input jacks for connec ng up to four IR receivers
3. IR CONTROL - 3.5mm IR input port for connec on to IR receiver or 3rd party IR system
• IR ALL IN/LOOP IN - 3.5mm IR IN jack for connec ng an IR receiver or cascading to a previous INT-1X4B-1H in
a cascading topology
• IR OUT - 3.5mm IR OUT jack for connec ng an IR emi er
• IR LOOP OUT - A 3.5mm IR LOOP output jack for cascading to another INT-1X4B-H
4. RS232 CONTROL - 3.5mm IR output port for connec on to IR emi er
• RS232 IN - 3-pin RS232 connector for 3rd party control
• RS232 OUT - If cascading mul ple units, use the supplied 3-pin to 3-pin cable to connect the output to the
RS232 IN on the next INT-1X4B-1H in a cascading topology
5. ID PRESET - Assigns a single digit ID to the INT-1X4B-1H when cascading mul ple INT-1X4B-1H units and using
RS232 control, therefore each spli er must have a unique ID. Use a small, fl athead screwdriver to set the ID.
There are sixteen posi ons, with 0 at the fully counterclockwise posi on and F at the fully clockwise posi on.
A er se ng the ID, the device must be restarted for the new ID to take e ect.
6. DC 24V - Locking power supply port

INT-1X4B-1H Quick Guide
5
Connecvity Instrucons
1. Verify all components included with the INT-1X4B-1H set are present before installaon.
2. If the INT-1X4B-1H is going to be permanently mounted to a surface, aach the included mounng
brackets with the supplied screws.
3. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instrucons.
4. Connect Category 6 F/UTP cabling or greater twisted pair cable with RJ45 connectors between
the HDBaseT transmier outputs of the INT-1X4B-1H and the compable receivers (sold separately).
TIA/EIA-568B straight-through wiring connecons must be used with all HDBaseT receivers.
5. Connect an HDMI cable that is less to or equal to 5 meters in length between the displays and the
connected compable receivers HDMI outputs
6. Connect the source device to the HDMI input using HDMI cables that are less than or equal to 5
meters in length. For source devices that are further away, an HDMI extension device will be required
to complete the connecon.
7. Connect a display device or second INT-1X4B-1H to the HDMI output using an HDMI cable that is
less than or equal to 5 meters in length. For a display that further away, it is highly recommended to
ulize the HDBaseT outputs.
8. Connect IR or RS232 control accessories between the display and the connected compable
receivers (oponal)
NOTE: A list of RS232 commands for this unit is available in the owners manual online at
www.libav.com under the DOCUMENTATION tab of the INT-1X4B-1H product page
9. Set EDID mode on front panel of unit
10. Connect the included power supply to the INT-1X4B-1H and lock the power supply to the power
connector by twisng the locking collar clockwise.
11. Power on aached audio/video devices.
Passing IR Signals:
The INT-1X4B-1H is capable of passing IR signals between 33 and 55 KHz. To prevent
damage to any of the electronics, the INT-1X4B-1H should be powered o while insert-
ing or removing any IR components. Inserng an IR transmier into the IR IN port may
damage the IR circuit for that extender.
To pass 3rd party IR system signals through the INT-1X4B-H, such as a control system,
use the IR-AC IR coupling cable (sold separately).

INT-1X4B-1H Quick Guide
6
Cabling Wiring Requirements
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connec on between send and receive
units.
RS232 Wiring
Some controllers may not have a DB9 port available for RS232
communica on, but may have removable terminal block connec ons.
Consult the manual of the control device(s) to determine which pins the
TX/RX signals are carried on. Be sure to always connect TX to RX and RX
to TX.
HDBaseT Cabling
To ensure proper performance of the INT-1X4B-H, it is recommended that you use solid
core, shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may perform
well but may not support power over HDBaseT reliably over longer distances.
For op mized HDBaseT performance use the following Liberty Wire and Cable branded
cabling;
Category 6 plenum; 24-4P-P-L6SH
Category 6A plenum; 24-4P-P-L6ASH
Category 6 NON-plenum; 24-4P-L6SH
Category 6A NON -plenum; 24-4P-L6ASH
When using shielded category cabling ALWAYS...
....use shielded connectors
....properly ground the category cable
Tx
Rx
RXD
GND
TXD
INT-1X4B-1HController
Rx
Tx
TXD
GND
RXD
HDBT RECEIVER Display

INT-1X4B-1H Quick Guide
7
Technical Specicaons
Input/Output Connecons
HDMI Input One (1) HDMI Type A Receptacle Connector
HDBaseT Outputs Four (4) Shielded RJ45 Female
HDMI Output One (1) HDMI Type A Receptacle Connector
RS232 In One (1) 3-Pole/3.5mm Euroblock
RS232 Out One (1) 3-Pole/3.5mm Euroblock
IR ALL IN Input One (1) 3.5mm TRS
IR Loop Out One (1) 3.5mm TRS
IR Out One (1) 3.5mm TRS
24V DC Power One (1) Locking Barrel (5.5 mm OD, 2.1 mm ID)
Supported Audio, Video, and Control
Maximum Video Compability at 70 m up to 1080p
Maximum Video Compability at 40 m up to 4K@60Hz / 4:2:0 / 8 bit deep color
Maximum Passive HDMI Cable Distance 5 m (16.4 )
Video Compliance HDMI 2.0 and HDCP 2.2
Embedded Audio Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio
Input DDC Signal 5.0 volts p-p (TTL)
Input Video Signal 0.5 to 1.0 volts p-p
RS232 Baud Rate 2400, 4800, 9600, 19200, 38400, 57600, or 115200
IR Carrier Frequency Range 33-55kHz at 5 volts
HDBaseT Signal Characteriscs
Maximum Distance 70 m (up to 1080p) , 40 m (up to 4K@60Hz / 4:2:0 / 8 bit deep color)
Cable Requirements Solid core shielded Category 6 F/UTP cable or greater with TIA/EIA-568B crimp paern
Bandwidth 10.2 Gbps
Chassis and Environmental
Enclosure Painted Aluminum
Dimensions 44 mm x 220 mm x 148 mm (1.73 in x 8.66 in x 5.83 in) – 1RU
Shipping Weight 725g (1.48 lbs.)
Operang Temperature 0° to +55° C (+32° to +131° F)
Operang Humidity 10% to 90%, Non-condensing
Storage Temperature -20° to +70° C (+14° to +158° F)
Storage Humidity 10% to 90%, Non-condensing
Power, ESD, and Regulatory
Power Supply Input 100V-240VAC / 50-60 Hz
Power Supply Output 24VDC / 2.71A
Power Consumpon 45 was (max)
ESD Protecon 15kV
Product Regulatory FCC, CE, RoHS
Power Supply Regulatory CE, RoHS
Other
Standard Warranty 5 years
Diagnosc Indicators Power LED, HDMI Input LED, HDMI Output LED, HDBaseT Link LEDs, HDBaseT HDCP LEDs
Included Accessories Quick Install Guide, Power Supply with US power plug, (1) 3-pin to 3-pin RS232 Cable,
(1) 3-pin to DB9 RS232 Breakout Cable,(1) 3.5mm IR Cascade Cable, (1) IR Emier, (4) IR
Receivers, Shelf Feet with Screws, Mounng Rails with Screws
Oponal Accessories DIGIB-EMT (IR Emier), DIGIB-EYE (IR Receiver) and IR-AC IR Coupling cable
Compable Receivers (AV and PoE) INT-HD70-RX, INT-HDX100-RX
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF and electrical interference, and cable
patches.
