Intellex DV16000 User manual
Intellex DV16000 Digital Video Management
System
Installation and Operating Instructions
Version 3.1
Part Number8200-0334-9900 A0
Installation and Operating Instructions
ii
Notice
The information in this manual was current when published. The manufacturer reserves the right to revise
and improve its products. All specifications are therefore subject to change without notice.
Copyright
Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated
or reduced to any electronic medium or machine-readable form, in whole or in part, without prior written
consent of Sensormatic Electronics.
© Copyright 1997–2003 Sensormatic Electronics Corporation
Video Systems Division
6795 Flanders Drive
San Diego, CA 92121-2903 U.S.A.
Trademarks
Intellex®is a registered trademark of Sensormatic Electronics Corporation. IntelleCord™and Smart
Search™are trademarks of Sensormatic Electronics Corporation. Windows®is a registered trademark of
Microsoft Corporation. PS/2®is a registered trademark of International Business Machines Corporation.
Sony®is a registered trademark of Sony Corporation.
Trademarked names are used throughout this manual. Rather than place a symbol at each occurrence,
trademarked names are designated with initial capitalization. Inclusion or exclusion is not a judgment on the
validity or legal status of the term.
Thank you for using American Dynamics products. We support our products through an extensive
worldwide network of dealers. The dealer through whom you originally purchased this product is your point
of contact if you need service or support. Our dealers are empowered to provide the very best in customer
service and support. Dealers should contact American Dynamics at (800) 507-6268 or (561) 912-6259 or on
the Web at www.americandynamics.net.
Intellex DV16000 Digital Video Management System
iii
WARNINGS
WARNING: TO REDUCE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
DO NOT INSTALL THIS PRODUCT IN HAZARDOUS AREAS WHERE HIGHLY
COMBUSTIBLE OR EXPLOSIVE PRODUCTS ARE STORED OR USED.
The lightning flash/arrowhead symbol, within an equilateral triangle, alerts the user to the presence of a
shock hazard within the product’s enclosure.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the battery manufacturer. Dispose of used
batteries according to the battery manufacturer’s instructions.
VORSICHT: ZUR VERMEIDUNG EINES STROMSCHLAGES DARF DAS GEHÄUSE NICHT ENTFERNT
WERDEN. ES ENTHÄLT KEINE VOM BENUTZER ZU WARTENDEN TEILE. ÜBERLASSEN
SIE DIE WARTUNG NUR QUALIFIZIERTEM FACHPERSONAL.
ACHTUNG:Es besteht die Gefahr einer Explosion, wenn die Batterie nicht ordnungsgemäß
ausgetauscht wird.
WARNING: THIS EQUIPMENT IS A CLASS 1 LASER PRODUCT INCORPORATING A CLASS 1 LASER
DIODE AND IT COMPLIES WITH FDA RADIATION PERFORMANCE STANDARDS, 21 CFR
SUBCHAPTER J AND THE CANADIAN RADIATION EMITTING DEVICES ACT, REDR C1370.
Rack Mounting
Consult with the supplier of your equipment rack for adequate rack mounting means, with proper
consideration for the weight of this product.
Consult with the manufacturer of your rack regarding the proper hardware and procedure of mounting this
product in a safe and useable fashion
Avoid uneven loading or mechanical instability when rack-mounting units.
Make sure that units are installed to get enough air flow for safe operation.
The maximum temperature for rack-mounted units is 40° C.
Avoid uneven loading or mechanical instability when rack-mounting units.
Check product label for power supply requirements to assure that no overloading of supply circuits or
overcurrent protection occurs.
Mains grounding must be reliable and uncompromised by any connections.
WARNING: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR
A CLASS “A” DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE
LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL
INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL
ENVIRONMENT. THIS EQUIPMENT GENERATES, USES AND CAN RADIATE RADIO
FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE
INSTRUCTION MANUAL, MAY CAUSE INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
N205
2
geprüfte
Sicherheit
Installation and Operating Instructions
iv
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This product was FCC verified under test conditions that included the use of shielded I/O cables
and connectors between system components. To be in compliance with FCC regulations, the
user must use shielded cables and connectors for all except power and alarm cables.
This digital apparatus does not exceed the Class A limits for radio noise emissions as set out in the Radio
Interference Regulations (ICES-003) of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables de la
Classe A prescrites dans le Réglement (ICES-003) sur le brouillage radioélectrique édicté par le Ministère
des Communications du Canada.
Intellex DV16000 Digital Video Management System
v
LICENSE INFORMATION
READ THIS LICENSE AGREEMENT BEFORE OPENING THE DISK PACKAGE, INSTALLING THE
SOFTWARE, OR USING YOUR SYSTEM.
THIS LICENSE AGREEMENT DEFINES YOUR RIGHTS AND OBLIGATIONS. BY BREAKING THE SEAL
ON THIS PACKAGE, INSTALLING THE SOFTWARE, OR USING YOUR SYSTEM, YOU AGREE TO ALL
OF THE TERMS AND CONDITIONS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO ALL OF THE
TERMS AND CONDITIONS OF THIS AGREEMENT, YOU MAY, WITHIN 30 DAYS, RETURN THIS
PACKAGE, ALL THE DOCUMENTATION, AND ALL ACCOMPANYING MATERIAL(S) TO THE POINT OF
PURCHASE FOR A REFUND.
Software License
The Software includes the computer software, the associated media, any printed material, and any
electronic documentation and may be provided to you installed on a hard drive (the media) as part of a
system. The Software is licensed, not sold.
Grant of License
This agreement between Sensormatic and you permits you to use the Software you purchased. Once you
have purchased the number of copies you require, you may use the Software and accompanying material
provided you use no more than the licensed number of copies at one time. The Software is only licensed for
use with specified Sensormatic supplied equipment. If the Software is protected by a software or hardware
key or other device, the Software may be used on any computer where the key is installed. If the key locks
the Software to a particular System, the Software may only be used on that System.
Other Rights and Limitations
• A demonstration copy of the Software is considered purchased and is covered by this license
agreement.
• You may not de-compile, disassemble, reverse engineer, copy, transfer, or otherwise use the Software
except as stated in this agreement.
• The hardware/software key, where applicable, is your proof of license to exercise the rights granted
herein and must be retained by you.
• If the Software is provided as part of a System, the Software may only be used with the System.
• You may not sub-license, rent or lease the Software, but you may permanently transfer the Software to
another party by delivering the original disk and material comprising the Software package as well as
this license to the other party. Initial use of the Software and accompanying material by the new user
transfers the license to the new user and constitutes the new user’s acceptance of its terms and
conditions.
• Sensormatic reserves the right to revoke this agreement if you fail to comply with the terms and
conditions of this agreement. In such an event, you must destroy all copies of the Software, and all of its
component parts (e.g., documentation, hardware box, software key).
• The Software may contain software from third parties that is licensed under a separate End User
License Agreement (EULA). Read and retain any license documentation that may be included with the
Software. Compliance with the terms of any third party EULA is required as a condition of this
agreement.
Failure to comply with these restrictions will result in automatic termination of this license and will make
available to Sensormatic other legal remedies.
Upgrades
If the Software is an upgrade from another software version, you may use or transfer the Software only as
specified in this agreement. If the Software is an upgrade of a component of a package of Software
programs that you licensed as a single product, the Software may be used and transferred only as part of
that single product package and may not be separated for use on more than one computer.
Copyright
The Software is a proprietary product of Sensormatic and is protected by both the United States and
International copyright laws.
Installation and Operating Instructions
vi
Limited Warranty
Sensormatic warrants that the recording medium on which the Software is recorded, and the documentation
provided with it, will be free of defects in materials and workmanship under normal use for a period of ninety
(90) days from the date of delivery to the first user. Sensormatic further warrants that for the same period,
the software provided on the recording medium under this license will substantially perform as described in
the user documentation provided with the product when used with the specified hardware.
Customer Remedies
Sensormatic’s entire liability and your exclusive remedy under this warranty will be, at Sensormatic’s option,
to a). attempt to correct software errors with efforts we believe suitable to the problem, b). replace at no cost
the recording medium, software or documentation with functional equivalents as applicable, or c). refund
the license fee and terminate this agreement. Any replacement item will be warranted for the remainder of
the original warranty period. No remedy is provided for failure of the diskette or Software if such failure is the
result of accident, abuse, alteration or misapplication. Warranty service or assistance is provided at the
original point of purchase.
No Other Warranties
The above warranty is in lieu of all other warranties, express or implied, including, but not limited to the
implied warranties of merchantability and fitness for a particular purpose. No oral or written information or
advice given by Sensormatic, its representatives, distributors or dealers shall create any other warranty,
and you may not rely on such information or advice.
No Liability For Consequential Damages
In no event will Sensormatic be liable to you for damages, including any loss of profits, loss of data or other
incidental or consequential damages arising out of your use of, or inability to use, the Software or its
documentation. This limitation will apply even if Sensormatic or an authorized representative has been
advised of the possibility of such damages. Further, Sensormatic does not warrant that the operation of the
Software will be uninterrupted or error free.
This limited warranty gives you specific legal rights. You may have other rights that vary from state to state.
Some states do not allow the exclusion of incidental or consequential damages, or the limitation on how
long an implied warranty lasts, so some of the above limitations may not apply to you.
General
If any provision of the agreement is found to be unlawful, void, or for any reason unenforceable, then that
provision shall be severed from this agreement and shall not affect the validity and enforceability of the
remaining provisions. This agreement is governed by the laws of the State of Florida.
You should retain proof of the license fee paid, including model number, serial number and date of payment,
and present such proof of payment when service or assistance covered by this warranty is requested.
U.S. Government Restricted Rights
The software and documentation are provided with RESTRICTED RIGHTS. Use, duplication, or disclosure
by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical
Data and Computer Software clause at DFARS 252.227-7013 or subparagraph (c)(1) and (2) of the
Commercial Computer Software—Restricted Rights at 48 CFR 52.227-19, as applicable. Manufacturer is
Sensormatic Corporation, 6600 Congress Avenue, Boca Raton, FL, 33431.
Important Information
Before proceeding, please read and observe all instructions and warnings contained in this manual. Retain
this manual with the original bill of sale for future reference and, if necessary, warranty service.
When unpacking your Intellex unit, check for missing or damaged items. If any item is missing, or if damage
is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT. Contact Sensormatic or your dealer for
assistance.
For your Records
Complete the following product purchase information. The factory requests this information when contacted
for technical support. It is also valuable in case of loss or theft.
Intellex DV16000 Digital Video Management System
vii
Purchase Date: _______________________________________
Serial Number: ________________________________________
License Key
The Intellex 3.1 software is protected from unauthorized use by a software license key. This key matches
the electronic hardware of your system with the authorized software version and feature level of your
software to permit proper operation of your system. Any changes to the network adapter in your unit,
removal or modification of the license file, or replacement of the system disk will affect normal operation and
will require installation of a new license file. Please contact your authorized Sensormatic representative for
more information.
ix
TABLE OF CONTENTS
Introduction ............................................................................................................................ 1
Features ............................................................................................................................................1
Basic Intellex System ......................................................................................................................4
Sample Network Configuration ...................................................................................................5
Option Packs ...................................................................................................................................6
Accessories ......................................................................................................................................7
Intellex USB Floppy Drive .....................................................................................................7
Intellex USB CD-RW Drive ....................................................................................................7
Intellex USB/RS-232 4-Port Expander .................................................................................7
Intellex Speakers .....................................................................................................................7
Call Monitor .............................................................................................................................7
Dome Control ..........................................................................................................................7
Installation ..............................................................................................................................9
Finding a Location .......................................................................................................................10
Front Panel ....................................................................................................................................11
Rear Panel ......................................................................................................................................12
Required Connections .................................................................................................................15
Cameras In .............................................................................................................................15
Monitor ...................................................................................................................................15
Power Setting .........................................................................................................................15
Power In ..........................................................................................................................15
Mouse .....................................................................................................................................15
Optional Connections ..................................................................................................................16
Cameras Out ..........................................................................................................................16
Alarms ....................................................................................................................................16
Video Out ...............................................................................................................................16
Keyboard ................................................................................................................................16
Printer .....................................................................................................................................16
Com2 .......................................................................................................................................17
Video Out ...............................................................................................................................17
SCSI-3 ......................................................................................................................................17
Network ..................................................................................................................................17
Call Monitor ...........................................................................................................................18
System Setup .......................................................................................................................19
Starting the Intellex Unit .............................................................................................................20
Exiting to Windows .....................................................................................................................21
Regional Settings ..........................................................................................................................22
Installation and Operating Instructions
x
Mouse Settings ..............................................................................................................................23
Time Zone Settings .......................................................................................................................24
Network Settings ..........................................................................................................................25
Configuring Computer Name and Workgroup or Domain in Windows 2000 ............25
Configuring the Computer Name and Workgroup or Domain .....................................25
Changing the Computer Name ....................................................................................25
Changing the Workgroup .............................................................................................26
Changing to a Domain ..................................................................................................26
Setting up Autologin ....................................................................................................................27
Configuring Intellex 3.1 for Dial-up Networking ....................................................................28
Configuring the Dial-Up Server ..........................................................................................28
Procedure for Forcing an Intellex modem to Disconnect ................................................29
Graceful disconnect .......................................................................................................29
Non-graceful disconnect ...............................................................................................29
Timed disconnect ...........................................................................................................29
Installing the ESM and converting to NTFS .............................................................................30
Printer Settings ..............................................................................................................................31
Language Setup ............................................................................................................................32
Shutting Down and Restarting System .....................................................................................33
Main Screen ......................................................................................................................... 35
On-screen Controls and Indicators .....................................................................................36
Setup Options ...................................................................................................................... 39
Setup Options Screen ...................................................................................................................40
Cameras Option ............................................................................................................................42
Names Tab ..............................................................................................................................42
Termination Tab ....................................................................................................................42
Gain Mode Tab ......................................................................................................................43
Camera Control Tab ..............................................................................................................43
Covert Mode Tab ...................................................................................................................45
Configuring a Covert Camera ......................................................................................45
Live Mode .......................................................................................................................45
Playback Mode ...............................................................................................................46
Exporting with a Covert Camera .................................................................................47
Status Screen ...................................................................................................................47
Schedule Option ...........................................................................................................................48
Use Regular Schedule ...........................................................................................................48
Quality Tab .....................................................................................................................49
Time Tab ..........................................................................................................................50
Cameras (1-8 and 9-16) Tabs ........................................................................................50
Regular Schedule Popup Menu ...................................................................................51
Copying and Pasting a Filter ........................................................................................52
Intellex DV16000 Digital Video Management System
xi
Replacing a Filter ...........................................................................................................52
Deleting a Filter ..............................................................................................................52
Data Lifetime Tab ..........................................................................................................52
Use Custom Schedule ...........................................................................................................54
Time Tab ..........................................................................................................................55
Weekday/Weekend/Holiday Tabs ............................................................................57
Set Holidays Tab ............................................................................................................59
Data Lifetime Tab ..........................................................................................................60
Working with Schedule Segments ......................................................................................60
Defining a New Segment ..............................................................................................60
Changing a Segment ......................................................................................................61
Deleting a Segment ........................................................................................................61
Copying a Camera Schedule ........................................................................................62
Custom Schedule Popup Menu ..........................................................................................62
Configuring an Active Segment ..................................................................................66
Configuring an Alarmed Segment ..............................................................................68
Live Filter Configuration .....................................................................................................70
Motion Detection ...........................................................................................................70
Perimeter Protection ......................................................................................................72
Light Change ..................................................................................................................74
Motion Exception ...........................................................................................................76
What is Motion Exception? ..................................................................................................76
Active Zone Settings .............................................................................................................81
Size ...................................................................................................................................81
Speed ...............................................................................................................................81
Direction ..........................................................................................................................81
Testing .............................................................................................................................82
To use Motion Exception .....................................................................................................82
Environmental Factors .........................................................................................................84
Use Single Camera Schedule ...............................................................................................86
Single Camera Tab .........................................................................................................86
Data Lifetime Tab ..........................................................................................................87
Camera Selectable Rate Option ..................................................................................................88
Important Factors in Setting the Recording Rate .............................................................88
Recording Rate Descriptions ...............................................................................................89
Auto Rate Mode ....................................................................................................................90
Use Auto Rate Mode .....................................................................................................91
Camera Selectable Rate ........................................................................................... 91
Set Per Camera Rate Mode ...........................................................................................91
Image Rate Sliders .........................................................................................................92
Text Option ...................................................................................................................................94
Defining a Text Stream ........................................................................................................95
Installation and Operating Instructions
xii
Text Source Tab ..............................................................................................................95
Camera Associations Tab ..............................................................................................95
Adding a Text Stream ...........................................................................................................96
Editing a Text Stream ...........................................................................................................96
Deleting a Text Stream .........................................................................................................96
Advanced Text ..............................................................................................................................97
Advanced Text Criteria ........................................................................................................97
Transaction Definitions ......................................................................................................100
Alarms Tab ....................................................................................................................101
Perform an Advanced Text Search ...................................................................................101
Edit an Advanced Text Search ..........................................................................................102
Delete an Advanced Text Search ......................................................................................102
Save an Advanced Text Search .........................................................................................103
Load an Advanced Text Search .........................................................................................103
Audio Option ..............................................................................................................................104
Audio Mixer Tab .................................................................................................................104
Camera Associations Tab ...................................................................................................105
Security Option ...........................................................................................................................106
Enabling Security ................................................................................................................106
Classic Security .............................................................................................................107
Advanced Security .......................................................................................................107
Adding a New User ............................................................................................................108
Editing a User ......................................................................................................................110
Deleting a User ....................................................................................................................111
Enabling/Disabling Security .............................................................................................111
Record Mode Option .................................................................................................................113
Notify when _____% full ....................................................................................................114
Database Full .......................................................................................................................114
Unarchived Images ......................................................................................................115
Archived Images ..........................................................................................................115
Alarms Option ............................................................................................................................116
General Tab ..........................................................................................................................116
Alarm In Names Tab ..........................................................................................................118
Alarm In Polarity Tab .........................................................................................................118
Display Option ............................................................................................................................120
Mode Tab ..............................................................................................................................120
2x2, 3x3, and 4x4 Tabs ........................................................................................................121
Date/Time Option ......................................................................................................................123
Port Address Option ..................................................................................................................124
Storage Option ............................................................................................................................125
Add Volume .........................................................................................................................126
Archive Schedule Option ..........................................................................................................127
Intellex DV16000 Digital Video Management System
xiii
Archive All ...........................................................................................................................127
Archive Schedule ................................................................................................................127
Time Tab ........................................................................................................................128
Weekday/Weekend/Holiday Tab ...................................................................................131
Live Operation ....................................................................................................................133
Logging In ...................................................................................................................................134
Changing Users ..........................................................................................................................135
Controlling Image Display .......................................................................................................136
Screen Format ......................................................................................................................136
1x1 ..................................................................................................................................136
2x2 ..................................................................................................................................136
3x3 ..................................................................................................................................136
4x4 ..................................................................................................................................136
Image Area Popup Menu ...................................................................................................137
Switching to Menu/Full Screen .................................................................................138
Single Pane ....................................................................................................................138
Generating an Alarm ...................................................................................................138
Camera ..........................................................................................................................138
Mode ..............................................................................................................................138
Image Area Zoom ...............................................................................................................139
Full Screen Operation .........................................................................................................139
Camera Sequencing ............................................................................................................140
Live Monitor (Optional) .....................................................................................................140
Dome Controller (Optional) ..............................................................................................140
Dome Camera Control ................................................................................................141
Unit Schedule .......................................................................................................................142
Reviewing Unit Status ...............................................................................................................143
Utility Options ............................................................................................................................145
Begin Record ........................................................................................................................146
Activity Log .........................................................................................................................146
Creating an Activity Log ............................................................................................147
Generate Alarms .................................................................................................................148
Clear Latched .......................................................................................................................149
Erase CD-RW .......................................................................................................................149
Log Out .................................................................................................................................150
Shutdown .............................................................................................................................150
Restart ...................................................................................................................................150
Exit to System ......................................................................................................................151
About Intellex ......................................................................................................................151
Upgrade .........................................................................................................................152
Software Maintenance Identification ........................................................................152
Installation and Operating Instructions
xiv
Playback Operation ........................................................................................................... 153
Playback Screen ..........................................................................................................................154
Playback Controls and Indicators .....................................................................................156
Using Play/Pause .......................................................................................................................158
Multi-Camera Playback ......................................................................................................160
Right-click Pop-up Menu ...................................................................................................161
Switch ............................................................................................................................161
Switching Cameras .............................................................................................................162
Full Screen Operation .........................................................................................................163
Image Area Zoom ...............................................................................................................164
Playback with Text Display ...............................................................................................164
Audio ....................................................................................................................................165
Selective Export ..........................................................................................................................166
Export Directory ...........................................................................................................166
Playback Tools ............................................................................................................................168
Image Enhancement Tools .................................................................................................171
Bright/Contrast Tool ...................................................................................................171
Color/Light Tools ........................................................................................................172
Balance Light Tool .......................................................................................................173
Edge Detect Tool ..........................................................................................................173
Enhance Light Tool ......................................................................................................173
Noise Reduction Tool ..................................................................................................173
Sharpen Tool .................................................................................................................174
Sharpen More Tool ......................................................................................................174
Smooth Tool ..................................................................................................................174
Smooth More Tool .......................................................................................................174
Search Operation ...............................................................................................................175
Search Mode Screen ...................................................................................................................176
No Image Filters ..................................................................................................................176
Date/Time Tab .............................................................................................................177
Camera Tab ...................................................................................................................178
Alarm Tab .....................................................................................................................179
With Image Filters ...............................................................................................................180
Date/Time Tab .............................................................................................................180
Filters Tab ......................................................................................................................181
Search Filter Configuration ........................................................................................182
Text Streams .........................................................................................................................183
Date/Time Tab .............................................................................................................183
Text Streams Tab ..........................................................................................................184
Working with Search Results ...................................................................................................185
Sorting the Search Results ..................................................................................................185
Intellex DV16000 Digital Video Management System
xv
Selecting a Segment to Review ..........................................................................................185
Alarm Operation .................................................................................................................187
Mechanical Alarms ....................................................................................................................188
Live Filter Events ................................................................................................................189
Video Loss Alarms ..............................................................................................................190
Generated Alarms ...............................................................................................................191
Alarm Groups ......................................................................................................................192
Alarm Review Screen ................................................................................................................193
Selecting a Segment to Review ..........................................................................................194
Alarm Connectors ......................................................................................................................195
Installation and Use of Accessories ................................................................................197
USB Floppy Drive-RDVFLP01 .................................................................................................198
USB CD-RW Drive-RDVCDRX01 ............................................................................................199
USB/RS-232 Single COM Port Adapter ..................................................................................200
USB/RS-232 4-Port Expander-RDVEXP01 .............................................................................201
Serial Interfaces and Text Recording .......................................................................................202
Internal COM ports .............................................................................................................202
Port Expanders ....................................................................................................................202
Port Assignments ................................................................................................................202
COM Port Assignments .....................................................................................................202
Connecting Text Sources ....................................................................................................203
Connecting the Data Source ..............................................................................................203
Verifying Data Recording ..................................................................................................204
Port Expander Indicators ...................................................................................................204
Speakers-RDVSPK01 .................................................................................................................205
Archive Operation ..............................................................................................................207
Archive Options Screen .............................................................................................................208
Back Up Images to Tape .....................................................................................................208
Back up While Recording ...........................................................................................209
Stop Recording and Back Up Now ...........................................................................210
Restore Images From Tape ................................................................................................212
Play Restored Images .........................................................................................................213
Format Tape .........................................................................................................................214
Recover Data from Tape ....................................................................................................214
Recovering from an Interruption .............................................................................................215
Interrupting the Backup .....................................................................................................215
Record Capacity .................................................................................................................217
Activity Levels ............................................................................................................................221
Technical Specifications ...................................................................................................223
Programmable Settings .............................................................................................................224
Installation and Operating Instructions
xvi
Video Format ..............................................................................................................................225
Video Level ..................................................................................................................................226
Alarm ............................................................................................................................................227
Display .........................................................................................................................................228
Record Options ...........................................................................................................................229
On-Screen Controls ....................................................................................................................230
Rear Panel Connectors ...............................................................................................................231
Components ...............................................................................................................................232
Power Supply ..............................................................................................................................233
Accessories ..................................................................................................................................234
Physical Characteristics .............................................................................................................235
Environmental Requirements ...................................................................................................236
Index ................................................................................................................................... 237
Introduction 1
INTRODUCTION
The Intellex®DV16000 digital video management system combines multiplexing,
alarm/event detection, and records images from up to 16 video cameras. The images
are recorded directly to the internal hard drive which allows you quick and easy
access to your recorded images.
A variety of advanced, user-programmable features allow you to customize and
manage video data for your specific needs.
FEATURES
• The Activity Log provides a record of all activity that a user has performed on an
Intellex unit after the user has logged in, such as who changed a setting, which
menus were accessed, what video was downloaded, and so on.
• The Camera Selectable Rate feature lets you assign higher or lower recording rates
to specific cameras.
• The Covert Camera feature permits viewing and recording of video from specified
camera(s) by authorized users only.
• 15-Minute Index permits playback of video starting a full 15 minutes prior to the
actual alarm.
• Motion Exception permits filtering live video or searching recorded video for an
event or activity as defined by the size, direction, and speed of a moving object.
Figure 1 — Intellex
Installation and Operating Instructions
2Introduction
• Dome Camera Controls let you adjust dome camera and lens settings. You can
control the camera’s pan and tilt movements; adjust its lens zoom, focus and iris
settings; use preset position settings for instant recall (if supported by the camera);
and select a pattern scan (if supported by the camera).
• Advanced Security provides both local and remote secured access to Intellex units
and to designated Intellex features (downloading and viewing video, setting up a
schedule, etc.) or resources (cameras, alarms, alarm list database, recorded video
database, etc.). Advanced Security requires that Policy Manager be installed on the
network to which Intellex is attached. Policy Manager enables an administrator to
manage secured access to Intellex units and to Network Client.
• Advanced Text search lets you define complex search criteria to find specific
events in a text stream when filtering live video or searching recorded video.
• Video segments can be exported to an optional CD-RW. You can mark the
beginning and end of video segments in Playback Mode to export.
• 320x240 lower resolution recording available, selected in the schedule dialog for
each camera. This resolution can also be selected for alarm recording.
• Enhanced triplex operation provides simultaneous record/display, playback and
archiving.
• Use SmartSearch filters to quickly search the image database for video segments
containing specific types of activity (see Search Operation on page 175).
• Ethernet 10/100 Network Interface allows remote access to video and setup
functions. Dial-up modem is optional.
• Use date and time, camera and alarm criteria to quickly search the image database.
Play back these video segments.
• Records and stores pre-alarm images according to each camera’s pre-alarm setting
(0 to 300 seconds).
• Compatible with color and B&W video cameras or other NTSC/EIA (PAL/CCIR)
standard compatible video sources. Video synchronization is not required.
• Records images digitally, which eliminates the need for VCRs and videotape.
Backs up images to an optional CD-RW or an optional Digital Audio Tape (DAT),
saves them to a floppy diskette or transfers them to videotape.
• User can select, enhance and copy images onto a computer diskette or print them.
• Multi-camera live displays are available for any camera in any position in the
following formats: 1x1, 2x2, 3x3 and 4x4. A full-screen view hides the controls and
fills the entire screen.
• Provides outstanding picture quality using a 640x480 pixel display (800x600 in
full-screen mode) with 256 gray levels and over 16 million colors.
• Offers seven record rates: NTSC — 120, 60, 30, 15, 7.5, 2.5 and 1 images per second
(ips); PAL — 100, 50, 25, 12.5, 6.25, 2 and 0.8 ips.
Intellex DV16000 Digital Video Management System
Introduction 3
• On-screen menus simplify system setup and operation.
• Online help information is available from every screen.
• One alarm input and one alarm output are available for each camera. The polarity
for each alarm input can be set to either active high or active low.
• A security system provides password protection to restrict access to various
operation and configuration functions.
• On-screen display includes date, time, alarm status, video loss and 10-character
camera titles.
• Hard disk storage protects all system configuration information against power
loss.
• Unit storage capacity can be increased by purchasing an additional optional
internal storage or an optional external data storage unit.
• An optional dome controller (Sensormatic VM16 or American Dynamics ADTT16)
can be used to select cameras, change display format to 1x1, 2x2, 3x3 or 4x4 and to
sequence cameras (live mode only).
• One to five Intellex units can be connected over a TCP/IP local area network
(LAN) or wide area network (WAN). The Network Client software must be installed
on your computer.
• Internal floppy drive added.
• Supports simultaneous and synchronized playback of up to 16 cameras.
Table of contents
