Intelligent Facility Solutions g-force User manual
G-Force
user manual
2Intelligent Facility Solutions
ELECTRIC HAND DRYER G-Force
ATTENTION: Please read these instructions carefully before installation and retain for your
records
This manual supplies important information regarding maintenance, installation and in the
unlikely event of an emergency. An incorrect installation can cause potential harm. The
manufacturer or
Distributor, bear no responsibility if the product is not correctly installed. This hand dryer
should be installed by a qualified electrician only
FEATURES
Tension 220 - 240 VAC
Frequency 50 - 60Hz
Absorption (power) total Version 550 Watt
Version 1100 Watt
(Power is always indicated also on rating label on machine)
Protection Class Class II
Air flow 187 cbm/h, 3117 l/m (version 1100Watt)
Dimensions 285 x 221 x 157mm
CE-CEI Compliance RoHS – WEEE compliance
INSTRUCTIONS FOR INSTALLERS
THIS HAND DRYER HAS TO BE FIXED AT SAFE DISTANCE OF AT LEAST 60 CM FROM A BATHTUB,
SHOWER OR WASHBASIN.
Please verify that the electrical capacity of the system and the female plugs of
current are adapted to the maximum power of the apparatus.
Only fix the dryer to the wall with the fixing kit and mounting plate included in the
box.
Please note that any plug provided is for testing the appliance only, it should be
removed prior to installation and fitted into its own isolated fuse spur.
We recommend that the hand dryer’s air outlet is installed at least 120cm from the
ground.
This product is not intended to be used by people with reduced physical, sensory,
mental, or have a lack of experience and knowledge, unless they are controlled
by a person responsible for their safety.
Children should be supervised to prevent them from playing with the appliance.
If the power cord is damaged, it should be replaced by the manufacturer or a
appropriately qualified electrician.
OPERATING
The hand dryer is automatically activated and deactivated by a motion sensor that detects
the presence of the hands.
G-Force 3
Warning: In case of an overload of internal temperature, a thermostat with an automatic
reset protection will suspend the operation of the motor. This device gives the user greater
safety of operation.
The unit has no heating element. Air is then heated by the power of motor .This allows
considerable energy savings compared to traditional dryers. The first daily use could thus
give the impression of cold air, but it will be warming up coming from the second drying
cycle.
The device has a system that prevents vandalism, for example if the photocell sensor is
deliberately covered. If this occurs, the dryer will work without interruption for about 35
seconds, then automatically cut out and revert to stand by operation. Once the obstruction
has been removed, normal function will resume in 3-4 seconds.
MANTAINANCE
Warning: Before performing any maintenance, please disconnect the appliance from the
network.
Clean this dryer using a soft cloth dampened with water and detergent.
To ensure the durability and reliability of this product, periodically check that the grid
inlet and outlet of the cone are not clogged by dust or any equivalent material
FILTER HEPA H13 filter paper
The HEPA filter inside the machine, if present, guarantees air will be cleansed of
excessive dust and dirt. The filter must be periodically cleaned with a jet of compressed air
at a distance of about 20 cm. It must be replaced after a maximum of 1000 hours of use in
conjunction with the cartridges motor brushes. The quality H13 HEPA filter paper, if
maintained in good condition and replaced as instructed will provide protection against
bacteria by removing up to 99.997% of airborne particles.
BRUSH MOTOR (carbon brushes)
The motor brushes cartridge in the drive unit has a life of 1000 hours (360,000 uses), of
effective operation. The duration of the brushes varies depending on the conditions of use
and of cleaning the filter and general maintenance of the appliance. It is needed to contact
the service in order to restore the brushes at the end of the cycle.
General warnings
Do not use this product for a different function from that to which it is intended :HAND
DRYER
• Do not leave the appliance exposed to atmospheric conditions such as rain, sun, etc..
• Make no changes of any kind to the device
• Do not obstruct the air outlet or mouth
• Do not insert any object into the grid or the outlet air
In case of failure and / or malfunction, remove the mains and consult with the
manufacturer or dealer
IMPORTANT INFORMATION
This product falls within the competence of the EC Directive 2002/96 (WEEE) on disposal
4Intelligent Facility Solutions
of electrical and electronic equipment. Complies with RoHS legislation
NOTE:
This product should not be disposed with household waste.
Recycle it through the appropriate channels
Ask your local authority for recycling guidelines.
TROUBLE SHOOTING GUIDE
Cold air
wait to be warmed by motor operating
Continuous operating
on electric board decrease sensor sensibility by turning anti-clockwise
the white trimmer on board
N
ot operating
check all connections first , then change the electric board if
necessary. Contact your supplier
IMPORTANT INFORMATION
THIS PRODUCT IS INCLUDED IN THE SCOPE OF DIRECTIVE 2002/96 CE (WEEE-RAEE) CONCERNING THE
DISPOSAL OF ELECTRIC AND ELECTRONIC DEVICES. THIS PRODUCT MUST NOT BE DISPOSED OF WITH
HOUSEHOLD OR GENERAL COMMERIAL WASTE. IT MUST BE RECYCLED BY AN APPROPRIATE AUTHORITY.
ENQUIRE WITH YOUR LOCAL AUTORITHY AS REGARDS THE RECYCLING DIRECTIVES AND LOCATION OF
APPROVED RECYCLING BODIES FOR FURTHER DETAILS>
THE CONSUMER HAS RIGHT TO RETURN THE PRODUCT TO THE DISTRIBUTOR FOR RECYCLING AND
SAFE DISPOSAL. THIS PRODUCT DOES NOT CONTAIN ANY DANGEROUS SUBSTANCEs AS PER THE ROHS
DIRECTIVE 2002/95 CE (RoHS) THEREFORE IT CONTAINS NO SUBSTANCES THAT WILL HAVE A NEGATIVE
IMPACT ON HUMAN HEALTH OR ON ECOSYTEMS IN THE NATURAL ENVIRONMENT.
DO NOT TO USE THE PRODUCT FOR ANY OTHER USE THAN IT IS INTENDED, MISUSE WILL INCREASE THE
LIKLIHOOD OF AN ELECTRIC SHOCK.
THE SYMBOL OF THE CROSSED WASTE CONTAINER ON THE LABEL SHOWS
INDICATES THE MANUFACTURER AND DISTRIBUTORS COMMITMENT TO THE
CORRECT RECYCLING AND DISPOSAL PROCEEDURES OF THIS PRODUCT. IN THE
CASE OF INCORRECT DISPOSAL, FINES OF UP TO EUR 100.000, MAYBE
ENFORCED.
WARRANTY
This unit is under warranty for a period of THREE years from date of purchase, by proving
receipt or invoice and stamp dealer.
The guarantee does not cover damage caused by:
• improper use, misuse or neglect
• accidental breakage or brakes not caused by the supplier
• incorrect connection to voltage different from that expected, spikes on the network
• improper tampering with equipment
Also excluded from the warranty consumable items (cartridges and the carbon motor),
whose life depends on the terms and conditions of use. More information is available at
the offices of the distributor
Retailer stamp Date
G-Force 5
of electrical and electronic equipment. Complies with RoHS legislation
NOTE:
This product should not be disposed with household waste.
Recycle it through the appropriate channels
Ask your local authority for recycling guidelines.
TROUBLE SHOOTING GUIDE
Cold air
wait to be warmed by motor operating
Continuous operating
on electric board decrease sensor sensibility by turning anti-clockwise
the white trimmer on board
N
ot operating
check all connections first , then change the electric board if
necessary. Contact your supplier
IMPORTANT INFORMATION
THIS PRODUCT IS INCLUDED IN THE SCOPE OF DIRECTIVE 2002/96 CE (WEEE-RAEE) CONCERNING THE
DISPOSAL OF ELECTRIC AND ELECTRONIC DEVICES. THIS PRODUCT MUST NOT BE DISPOSED OF WITH
HOUSEHOLD OR GENERAL COMMERIAL WASTE. IT MUST BE RECYCLED BY AN APPROPRIATE AUTHORITY.
ENQUIRE WITH YOUR LOCAL AUTORITHY AS REGARDS THE RECYCLING DIRECTIVES AND LOCATION OF
APPROVED RECYCLING BODIES FOR FURTHER DETAILS>
THE CONSUMER HAS RIGHT TO RETURN THE PRODUCT TO THE DISTRIBUTOR FOR RECYCLING AND
SAFE DISPOSAL. THIS PRODUCT DOES NOT CONTAIN ANY DANGEROUS SUBSTANCEs AS PER THE ROHS
DIRECTIVE 2002/95 CE (RoHS) THEREFORE IT CONTAINS NO SUBSTANCES THAT WILL HAVE A NEGATIVE
IMPACT ON HUMAN HEALTH OR ON ECOSYTEMS IN THE NATURAL ENVIRONMENT.
DO NOT TO USE THE PRODUCT FOR ANY OTHER USE THAN IT IS INTENDED, MISUSE WILL INCREASE THE
LIKLIHOOD OF AN ELECTRIC SHOCK.
THE SYMBOL OF THE CROSSED WASTE CONTAINER ON THE LABEL SHOWS
INDICATES THE MANUFACTURER AND DISTRIBUTORS COMMITMENT TO THE
CORRECT RECYCLING AND DISPOSAL PROCEEDURES OF THIS PRODUCT. IN THE
CASE OF INCORRECT DISPOSAL, FINES OF UP TO EUR 100.000, MAYBE
ENFORCED.
WARRANTY
This unit is under warranty for a period of 5 years from date of purchase, by proving with
receipt or invoice and stamp dealer.
The guarantee does not cover damage caused by:
• improper use, misuse or neglect
• accidental breakage or brakes not caused by the supplier
• incorrect connection to voltage different from that expected, spikes on the network
• improper tampering with equipment
Also excluded from the warranty consumable items (cartridges and the carbon motor),
whose life depends on the terms and conditions of use. More information is available at
the offices of the distributor
Retailer stamp Date
Warning: In case of an overload of internal temperature, a thermostat with an automatic
reset protection will suspend the operation of the motor. This device gives the user greater
safety of operation.
The unit has no heating element. Air is then heated by the power of motor .This allows
considerable energy savings compared to traditional dryers. The first daily use could thus
give the impression of cold air, but it will be warming up coming from the second drying
cycle.
The device has a system that prevents vandalism, for example if the photocell sensor is
deliberately covered. If this occurs, the dryer will work without interruption for about 35
seconds, then automatically cut out and revert to stand by operation. Once the obstruction
has been removed, normal function will resume in 3-4 seconds.
MANTAINANCE
Warning: Before performing any maintenance, please disconnect the appliance from the
network.
Clean this dryer using a soft cloth dampened with water and detergent.
To ensure the durability and reliability of this product, periodically check that the grid
inlet and outlet of the cone are not clogged by dust or any equivalent material
FILTER HEPA H13 filter paper
The HEPA filter inside the machine, if present, guarantees air will be cleansed of
excessive dust and dirt. The filter must be periodically cleaned with a jet of compressed air
at a distance of about 20 cm. It must be replaced after a maximum of 1000 hours of use in
conjunction with the cartridges motor brushes. The quality H13 HEPA filter paper, if
maintained in good condition and replaced as instructed will provide protection against
bacteria by removing up to 99.997% of airborne particles.
BRUSH MOTOR (carbon brushes)
The motor brushes cartridge in the drive unit has a life of 1000 hours (360,000 uses), of
effective operation. The duration of the brushes varies depending on the conditions of use
and of cleaning the filter and general maintenance of the appliance. It is needed to contact
the service in order to restore the brushes at the end of the cycle.
General warnings
Do not use this product for a different function from that to which it is intended :HAND
DRYER
• Do not leave the appliance exposed to atmospheric conditions such as rain, sun, etc..
• Make no changes of any kind to the device
• Do not obstruct the air outlet or mouth
• Do not insert any object into the grid or the outlet air
In case of failure and / or malfunction, remove the mains and consult with the
manufacturer or dealer
IMPORTANT INFORMATION
This product falls within the competence of the EC Directive 2002/96 (WEEE) on disposal
Intelligent Facility Solutions Ltd
Electric Works
3 Concourse Way
Sheffield
S1 2BJ
T: +44 (0)114 2866394
email: service@ihdryers.co.uk
www.intelligenthanddryers.com
