OXFORD CRYOSYSTEMS AD51 User manual

OXFORD CRYOSYSTEMS
AD51 Dry Air Unit
Operation &
Instruction Gui e

Page 1
A D 5 1 D R Y A I R U N I T
Operation & Instruction Guide 1.3
Oxfor Cryosystems Lt
3 Blenheim Office Park
Lower Roa
Long Hanborough
Oxfor OX29 8LN
Unite King om
Phone [phone] • Fax [phone]
Email: [email protected]
© 2012 Oxfor Cryosystems Lt . All Rights Reserve .

AD51 Dry Air Unit Instruction Manual v1.3
Page 2
TABLE OF CONTENTS
TABLE OF CONTENTS..................................................................................................... 2
SPECIFICATION................................................................................................................ 3
INTRODUCTION ................................................................................................................ 4
EVEN QUIETER RUNNING............................................................................................... 4
REDUCED AND IMPROVED MAINTENANCE....................................................................... 4
BEFORE STARTING.......................................................................................................... 4
MODE OF OPERATION..................................................................................................... 4
USING THE AD51.............................................................................................................. 5
MAINTENANCE AND TROUBLE SHOOTING .................................................................. 6
PRECAUTIONS ............................................................................................................... 6
ROUTINE MAINTENANCE................................................................................................. 6
Compressor Delivery Filter ...................................................................................................6
Compressor............................................................................................................................6
CHECKING THE DRY AIR OUTPUT.................................................................................... 6
FAULTS ......................................................................................................................... 7
FACTORY OVERHAUL/SERVICE..................................................................................... 7
LIST OF APPENDICES...................................................................................................... 8
APPENDIX 1 - GENERAL CIRCUIT DIAGRAM ................................................................ 9
............................................................................................................................................ 9
APPENDIX 2 - CONTROL BOARD CIRCUIT DIAGRAM................................................ 10
.......................................................................................................................................... 10
APPENDIX 3 - COMPRESSOR DELIVERY FILTER REPLACEMENT........................... 11

AD51 Dry Air Unit Instruction Manual v1.3
Page 3
SPECIFICATION
DRY AIR Up to 25 litres / minute at less than -60°C dewpoint
DIMENSIONS Width: 660mm Depth: 300mm Height: 420mm (incl. feet)
WEIGHT 41.5 kg
POWER Specified at time of purchase:
220-240V ac, 50 Hz, 5A
or
100-115V ac, 50/60 Hz, 11A

AD51 Dry Air Unit Instruction Manual v1.3
Page 4
INTRODUCTION
The AD51 is a development of the AD41 Dry Air Unit that has seen a total service life of millions
of hours. The new benefits are:
EVEN QUIETER RUNNING
A brand-new quiet compressor has been fitted to almost eliminate any of the operating noise level
from the unit.
REDUCED AND IMPROVED MAINTENANCE
The new compressor has significantly improved maintenance intervals due to the new and better
quality lifetime of the compressor components. The new compressor design means that service
parts can be changed extremely easily and quickly without the need to remove the compressor.
A new internal pipe work design has been fitted to improve the lifetime of some of the components.
BEFORE STARTING
Make sure any transit material inside the AD51 has been removed before switching on. It may also
be necessary to plug the compressor back in inside the unit.
MODE OF OPERATION
This stand-alone unit draws in atmospheric air and converts it to dry air. The dry air has a
dewpoint of better than -60°C and a variable flowrate up to a maximum of 25 litres/minute.
The AD51 Flow Scheme (Fig 1) shows the air is compressed to 3.5 bar pressure and passed, via a
particle filter, to a factory-sealed, twin-column pressure-swing adsorption dryer. An oil-free
compressor is employed to avoid contamination of the molecular sieve drying agent by lubricating
oil.
At any one time, pressurised air is dried by passing it up one of the columns. Simultaneously, a
fraction of this dry air is bled back down the other column at low pressure to purge it of water
vapour. After a pre-set time, the action of the two columns is reversed by means of electrically
operated change over valves.
The pressurised dry air passes through a filter/regulator to remove pressure pulses during column
switching and limit the maximum output pressure. The output flowrate is controlled by the user
with a built-in needle valve and flowmeter.

AD51 Dry Air Unit Instruction Manual v1.3
Page 5
Fig 1 - AD51 Flow Scheme
USING THE AD51
If the AD51 has not been used for some time it is advisable to run the unit overnight to establish the
correct moisture gradient within the drying columns. This should be done before connecting any
moisture-sensitive equipment to the DRY AIR output.
To avoid overheating, the AD51 should be located away from sources of heat and in a position
where it can draw a supply of cool air through the high level inlet at the end of the quiet box. DO
NOT OBSTRUCT THE COOLING AIR GRILLS AT EACH END OF THE UNIT.
1. Connect the DRY AIR output to your equipment using 8mm OD nylon tube to minimise
pressure drop in the connecting tube. In Cryostream Cooler applications use the reducing
coupling supplied to connect 8mm tube to 6mm tube: the total length of 6mm OD tube should
be limited to 3 metres.
2. To obtain dry air, connect the AD51 to the appropriate electricity supply - the POWER lamp
should light.
3. Switch on the AD51. At this point, the RUN lamp should flash for 4 seconds after which you
will hear the compressor start and the RUN lamp will light continuously.
4. Set the required dry air flowrate with the needle valve on the flowmeter.
Note: As the AD51 warms up from cold the flow-rate may require adjusting. Once the unit is
warm the flow-rate will stay constant.
Inlet Filter
Oil Free
Compressor
After Cooler
Particle
Filter
Drying Columns
Purge
Valves
Air Valves
Filter/
Regulator Needle Valve
& Flowmeter
Dry Air
Outlet

AD51 Dry Air Unit Instruction Manual v1.3
Page 6
MAINTENANCE AND TROUBLE SHOOTING
The AD51 is designed to be a low-maintenance unit. A useful indication that the unit is functioning
correctly is that a brief hiss can be heard at regular (one minute) intervals as the air valves switch
the action of the columns.
When the AD51 is used with the Cryostream Cooler to provide the dry air shroud for the nitrogen
gas stream, a deterioration in the dryness of the dry air will show up as frost forming evenly all
around the cold nitrogen stream delivery nozzle.
PRECAUTIONS
If you have not used the AD51 for some time it may be necessary to run the unit overnight to dry
down the columns.
ROUTINE MAINTENANCE
The AD51 is designed to run for more than 15,000 hours before needing any maintenance.
However, local conditions may accelerate wear of components or clogging of filters. Routine or
preventative maintenance may be carried out by users, utilising a qualified technician. The
following items may require attention.
Compressor Delivery Filter
Eventually the Compressor Delivery Filter will become clogged with the finer particles of room dirt
and the wear products from the compressor. This large capacity filter element is designed to last
15,000 hours and should normally be replaced at the same time as the compressor is serviced. Do
not be surprised if the filter element is wet – the compressed air has not been dried at this point.
For details of the filter replacement see Appendix 3.
Compressor
At some stage (usually longer than 15,000 hours) the carbon impregnated plastic cup seal in the
compressor will wear out. The eventual failure of the cup seal is a very sudden process and the
dryness of the dry air will deteriorate rapidly, also the maximum flowrate of dry air will drop below
25 litres/minute (perhaps less than 10 litres/minute).
This situation requires the compressor to be serviced.
CHECKING THE DRY AIR OUTPUT
Note: Make sure to run the AD51 overnight before checking the dry air output, this will give the
drying columns a chance to dry down.
The residual water vapour content of the AD51 dry air output may be measured with a suitable
hygrometer calibrated down to -70°C dewpoint. Allow at least 10 minutes for the reading to reach
equilibrium.

AD51 Dry Air Unit Instruction Manual v1.3
Page 7
FAULTS
Note: If any trips are activated the cause should be determined, preferably by a qualified
technician, before restarting the unit.
A rear panel fuse (T1A, 220-240V or T2A, 100-115V) protects the transformer that drives the
power supply, control board, indicator lamps, cooling fan and solenoid valves.
A fuse (T2A) mounted internally on the control board protects the low voltage supply to the control
logic circuits.
A rear panel circuit breaker operates if the compressor draws excessive current – push the black
button in to reset.
A manual reset thermal switch operates if the temperature inside the quiet box rises excessively for
any reason. If an overheat occurs the HOT! lamp will flash until the thermal switch is reset. The
thermal switch is mounted in the compressor compartment (see Fig 4 (M)) - press the red button to
reset.
FACTORY OVERHAUL/SERVICE
After extended running you may consider it desirable for the AD51 to have a complete factory
service and full recommissioning procedure. Please contact your agent or Oxford Cryosystems to
discuss this type of service if required.

AD51 Dry Air Unit Instruction Manual v1.3
Page 8
LIST OF APPENDICES
APPENDIX 1 General Circuit Diagram
APPENDIX 2 Control Board Circuit Diagram
APPENDIX 3 Compressor Delivery Filter Replacement

AD51 Dry Air Unit Instruction Manual v1.3
Page 9
APPENDIX 1 - GENERAL CIRCUIT DIAGRAM
