IntelligentAg ENGAGE SPREADCONTROL User manual

Quick Reference Guide - Viewing Section Status
Bin Status
Indicates if the bin is on
or off. Also indicates if the
bin is full or empty.
Desired Rate
Desired product rate of
flow.
Actual Rate
Actual product rate of
flow.
Fan Speed
Task Controller Status
Select Off to manually
control each section.
Select On to let the
system control when
sections open and close.
Section Status
Section is enabled
(green) or disabled (red).
If controlling sections
manually, tap a section
number to change status.
Master Apply Status
Support: 877-912-5973 www.intelligentag.com

Quick Reference Guide - Calibrating the Funnel Boxes
+1(701) 356 - 9222 suppor[email protected] www.intelligentag.com
600820-000038 Rev. 1.1
At the beginning of each season, calibrate the funnel box to make sure
that the funnel box sections are correctly positioned.
NOTE: This process is easiest with two people.
1. Press Product on the right navigation.
2. Press Funnel Box Calib.
3. Calibrate the funnel box.
a. Tap Left, then tap Extended.
b. Use the +5, +1, -1, and -5 buttons to adjust the funnel box
position so that the bottom of the pivot lines up with the extended
position notch. The pivot material should ll in the notch cutout in
the cover.
Positive numbers lengthen the actuator, and negative numbers
shorten the actuator.
c. Repeat the steps above for the left centered and left retracted
positions. Then, calibrate all positions for the right funnel box.
Retracted
Centered
Extended
