INTRODUCTION
1 iNtroductioN
Thank you for purchasing the INTELLINET NETWORK SOLUTIONS™
Wireless 300N Presentation Gateway, Model 524759.
Operating as a standard access point, this convenient device lets you
connect up to 16 wireless computers to any VGA- or HDMI-equipped
projector or monitor — without connecting a single video cable but with
enough bandwidth for all your presentation needs.
The easy-to-follow instructions in this user manual help make setup and
operationrelativelysimple,soyou’llsoonbeenjoyingthebenetsof
these additional features:
• Upto300Mbpsnetworklinkspeed
• Complieswith2.4GHzDraftIEEE802.11nstandardandisbackward
compatible with IEEE 802.11g/b standards
• 2T2RMIMOtechnologyforenhancedthroughputandcoverage
• SupportsWi-FiProtectedSetup(WPS)
• SupportsWEPandWPA/WPA2(TKIPandAES)dataencryption
• DHCPserverassignsIPaddressesforallwirelessusers
• EasyinstallationthroughaWeb-baseduserinterface
• SupportsMPEG1/2/4,Motion-JPEG,WMV9andH.264videoformats
• Videomodeallowsvideoplaybackontheconnectedvideodeviceor
projector
• Firmwareupgradeable
•Three-YearWarranty
Package Contents
•Wireless300NPresentationGateway
•Usermanual
•Poweradapter
•EthernetCat5RJ45cable:1.0m(3ft.)
•Remotecontrolwithbattery
•23-dbiantennas
•4footpadstickers
NOTE:Somescreenimageshavebeenmodiedtottheformatofthis
user manual. Additionally, this device is also commonly referred to as
a Wireless Projector Server throughout this manual.

4
INTRODUCTION
1.1 reGulatory statemeNts
Federal Communications Commission (FCC) Part 68
This equipment complies with Part 68 of the FCC Rules. On the bottom
of this device is a label that contains the FCC registration number and
ringer equivalence number (REN) for this equipment. You must provide
this information to the telephone company upon request.
The REN is useful to determine the quantity of devices you may connect
to the telephone line and still have all of those devices ring when your
number is called. In most, but not all, areas, the sum of the REN of all
devicesconnectedtoonelineshouldnotexceedve(5).Tobecertain
of the number of devices you may connect to your line, as determined
by the REN, you should contact your local telephone company to determine
the maximum REN for your calling area. If the modem causes harm to
the telephone network, the telephone company may discontinue your
service temporarily. If possible, they will notify you in advance. But if
advancenoticeisn’tpractical,youwillbenotiedassoonaspossible.
YouwillbeadvisedofyourrighttoleacomplaintwiththeFCC.
The telephone company may make changes in its facilities, equipment,
operations or procedures that could affect the proper operation of your
equipment.Iftheydo,youwillbenotiedinadvancetogiveyouan
opportunity to maintain uninterrupted telephone service.
If you experience trouble with this device, the telephone company may
ask you to disconnect this equipment from the network until the problem
has been corrected or you are sure that the equipment is not malfunctioning.
This equipment may not be used on coin service provided by the
telephone company. Connection to party lines is subject to state tariffs.
FCC Part 15
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference

5
INTRODUCTION
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
This equipment must be installed and operated in accordance with the
provided instructions, and a minimum 20 cm (8 in.) spacing must be
provided between computer-mounted antennas and a person’s body
(excluding extremities of hands, wrists and feet) during wireless modes
of operation.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: 1) This device may not cause harmful
interference; and 2) This device must accept any interference received,
including interference that may cause undesired operation.
Anychangesormodicationsnotexpresslyapprovedbytheparty
responsible for compliance could void the authority to operate the
equipment.
FCC Radiation Exposure Statement
This equipment must be installed and operated in accordance with the
provided instructions and a minimum 20 cm (8 in.) spacing must be
provided between computer-mounted antennas and person’s body
(excluding extremities of hands, wrists and feet) during wireless modes
of operation.
The equipment version marketed in the U.S. is restricted to usage of
channels 1-11.
R&TTE Compliance Statement
This equipment complies with all the requirements of Directive 1999/5/EC
of the European Parliament and the Council of March 9, 1999, on radio
equipment and telecommunication terminal equipment and the mutual
recognition of their conformity (R&TTE).

6
INTRODUCTION
The R&TTE directive repeals and replaces in the directive 98/13/EEC
(Telecommunications Terminal Equipment and Satellite Earth Station
Equipment) as of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those
who install and use it. However, special attention must be paid to the
dangers of electric shock and static electricity when working with electrical
equipment. All guidelines must therefore be followed at all times to ensure
the safe use of the equipment. (See Safety Precautions below.)
EU Countries Intended for Use
TheETSIversionofthisdeviceisintendedforhomeandofceusein
Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland,
Italy,Luxembourg,Bulgaria,Cyprus,CzechRepublic,Estonia,Hungary,
Latvia, Lithuania, Malta, Poland, Romania, Slovakia, Slovenia, the
Netherlands, Portugal, Spain, Sweden and the United Kingdom.
TheETSIversionofthisdeviceisalsoauthorizedforuseinEFTAmember
statesIceland,Liechtenstein,NorwayandSwitzerland.
EU countries not intended for use: none.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures.

7
INTRODUCTION
1.2 safety PrecautioNs
•This device is not a toy. Keep it out of the reach of children!
•Do not place this device in a humid or hot environment, like a kitchen.
•This device is designed to be used indoors. Do not use it in any
outdoor environment, including gardens or open patios.
•If the device is dropped into water while it’s powered on, do not attempt
to retrieve it before you cut power to the device. Do not use the device
 againbeforeithasbeenproperlycheckedoutbyacertiedtechnician.
•If you’re suspending the device from the overhead or positioning it in
any elevated location, make sure that it’s properly secured, as it can
be damaged or cause injury when dropped from above.
•Do not yank any connected cord, as doing so could damage both the
cord and the connection.
•Use only a damp cloth to wipe the device clean. Do not use alcohol
or other chemical solutions.
•Do not attempt to open this device, as there are no user-serviceable
parts inside.
• Donotsetthisdeviceonorcoveritwithpaper,clothorotherammable
materials during operation, as it can become hot after extended use.
•Don’t connect or disconnect any cords or cables while the device is on.
•Don’t allow any image to remain on the screen of your display device
for long periods of time, as doing so could result in screen damage.
Always use a screen saver.
•If smoke or any strange odor emanates from the device, cut power
immediately, then call your dealer for assistance.

8
HARDWARE INSTALLATION
2 hardWare iNstallatioN
2.1 froNt PaNel
Remote: This is the IR signal receiver for the remote control. Don’t block
the receiver: If the remote transmitter doesn’t have a clear line of
sight, it won’t work.
USB: This can be used to connect a wired or wireless mouse.
Blackout: When lit, this LED indicates the device is in Blackout mode (no
display output): Nothing will be displayed on the external display.
Ready: When lit, this LED indicates the device is ready to serve incoming
requests.
WPS: When lit, this LED indicates the WPS mode is active.
WLAN:Whenashing,thisLEDindicateswirelessLANactivity.
LAN: When lit, this LED indicates the wired LAN is connected.
Power: When lit, this LED indicates the device is correctly powered.
WPS (Wi-Fi Protected Setup): Press this button to start WPS pairing.
Power: Press this button to switch this device on/off.
NOTE: The top of this device has heat sink holes, where heat generated
by the device is removed. Do not block these holes during operation.
2.2 back PaNel
5V: This is the power jack for connecting the 5 V power adapter.
Reset: When this device isn’t working properly, you can use a pen or pin
(or similar pointed object) to press and hold this button in for 5 seconds
to reset it.
Remote
Blackout Ready WPS WLAN LAN Power
USB WPS Power

9
HARDWARE INSTALLATION
Antennas (partially shown): For optimal results in transmitting the
wireless signal, it’s usually best to keep both antennas perpendicular
 totheoor.
HDMI: This audio/video output connects to any HDMI-compatible display.
VGA: This D-sub 15-pin video output connects to any VGA-compatible
display.
Audio Out: This stereo port connects to external speakers or an audio
 amplier.
USB: This can be used to connect a wired or wireless mouse.
LAN: This 10/100Mbps Fast Ethernet port connects to your local area
network.
2.3 bottom PaNel
Wallmount holes: Use these to hang the device on a wall. NOTE: If the
 deviceistobeplacedandoperatedonahorizontalsurface,consider
placing the included foot pads on the bottom panel.
MAC address label: This is information you may need during software
 installationandconguration.
Product label:Thisiswhereyou’llndthedevice’smodelnameand
serial number — useful when you request assistance.
2.4 remote coNtrol
Black out: Press this button to activate the Blackout
function, which removes contents on any external
display. Press again to resume.
Menu: Press this button to switch the display output
of the Wireless Projector Server between the
presenter’s computer display content and the
 device’scongurationmenu.
Page up: Equivalent to Left key on your computer
keyboard.
Page down: Equivalent to Right key on your
computer keyboard.
Prev.: Press to select the previous user (presenter)

10
HARDWARE INSTALLATION
 inthedevice’scongurationmenu.It’sequivalenttotheUpkeyon
your computer keyboard when a presentation is in progress.
Next: Press to select the previous user (presenter) in the device’s
 congurationmenu.It’sequivalenttotheDownkeyonyourcomputer
keyboard when a presentation is in progress.
(Start):Presstoselecttheuserinthedevice’scongurationmenu.
IR transmitter: As you view the controls on the remote, this is located on
the top “side.” Aim this infrared transmitter at the IR receiver (Remote)
front-panel of the Wireless Projector Server. Be careful not to block the
transmitter when using the remote.
Battery cover: This is on the back of the remote control. Press the bottom
edge and slide it out to open the battery compartment to install/remove
the required CR-2032 lithium battery.
2.5 coNNectioNs
Once you’ve positioned the Wireless Projector Server — either mounted
onawalloronahorizontalsurface(withthefootpadsinplace)—make
the connections below (see Section 2.2 Back Panel above).
1. Connect the Ethernet cable to the LAN port.
2.Ifusinganexternalaudioamplierorspeaker,connectitsaudiocable
to the Audio Out port.
3. Connect either the HDMI or VGA cable from the external video display
to the corresponding (HDMI or VGA) port. NOTE: You can only connect
to one or the other at any given time.
4.Adjusttheantennassothey’reperpendiculartotheoor.
5. Plug the power adapter into an electrical outlet, then connect it to the
5V jack.
6.PressthePowerbuttonandconrmthatthePowerLEDlights.(Ifit
doesn’t, check your connections or refer to Section 6 Troubleshooting.)
4
