Intellisystem IT-PMC-1100 P2 User manual

1
IT-PMC-1100 P2
10/100M Media Converter
(SM & MM)
Introduction:
IT-PMC-1100 P2, 10/100M Media Converter, provides a cost
effective plug-and-play solution for long-range 10Base-T or
100Base-TX Ethernet extensions and added benefit of 10/100
auto-negotiation, making it the perfect choice when planning future
upgrades of 10Base-T networks. IT-PMC-1100 P2 Ethernet Fiber
converters are ultra-miniature in size and feature a shielded RJ45
Ethernet jack, SC/ST/FC style fiber-optic connections. Built-in
auto-sensing capabilities enable full or half-duplex Ethernet
operation with no configuration required!
Packing List:
IT-PMC-1100 P2 is shipped with following items.
1. IT-PMC-1100 P2×1
2. 5VDC power adapter ×1(Media converter/5VDC)
3. User manual ×1

2
Features:
1. Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX,
IEEE802.3 100Base-FX.
2. MDI/MDI-X auto negotiation, 10M/100M auto negotiation.
3. Supports full /half duplex, Point-to-point transparent transfer.
4. Power External 5VDC input.
5. Plug-and-play, easy to installation.
6. Can insert to 2U 19", 14 slots Rackmount (power external).
Pinout Configuration:
Power
IT-PMC-1100 P2 adopt the power supply input is 5VDC external.
Ethernet(RJ45), Optical fiber interface
Optical fiber interface:
Optic fiber interface need use in pairs, OUT port is fiber send side,
connect another long-range light of interface fiber receive end IN;
IN port is fiber receive side, connect long-range same fiber send
side:
Optic fibers spent both ends mark the label (the following picture
show: A-A, B-B, can also mark another: A1-A2, B1-B2), in order to
use.

3
NOTE: SC, ST or FC, for optic fiber interface, SM is look the same
to MM for form. For example, IT-PMC-1100 P2SM/SC, the optic
fiber interface (SC) is look the same to IT-PMC-1100 P2MM/SC.
Ethernet interface:
Ethernet (RJ45) interface supports MDI/MDI-X auto negotiation,
can use straight-through cable connect PC or server, use across-over
connect cable Switch or HUB.
MDI: PIN 1, 2, 3, 6 connects opposite.
MID-X: 1→3, 2→6, 3→1, 6→2
MDI/MDI-X 10Base-T/100Base-TX PIN define as follow:

4
PIN
MDI
MDI-X
1
TX+
RX+
2
TX-
RX-
3
RX+
TX+
6
RX-
TX-
4、5、7、8
—
—
Note：“ TX±”Transfer data±，“RX±”Receive data±，“—”None。
MDI:
MDI-X:
1 8
1
8
RJ45
TX+
TX-
TX-
RX+
RX+
RX-
RX-
TX+
2
3
6
1
2
3
6
1
1
8
RJ45
TX+
TX-
TX-
RX+
RX+
RX-
RX-
TX+
2
3
6
1
6
1
2
3
(TX-)
(RX+)
(RX-)
(TX+)
(TX+)
(TX-)
(RX+)
(RX-)

5
LED indications:
LED
STATE
INDICATION
PWR
(Power)
OFF
Power Off
BRIGHT
Power On
100
(10/100M)
OFF
10M Ethernet
BRIGHT
100M Ethernet
FX
(Fiber Link Port)
OFF
Fiber Optic Unit is Faulty
BRIGHT
Fiber Optic Unit is Functional
Link/Act (TX)
(TX Port
Link/Activity)
OFF
Ethernet is not Connected
FLASHING
Transmitting or Receiving Data
BRIGHT
Ethernet is Connected
Link/Act (FX)
(FX Port
Link/Activity)
OFF
Fiber Links are not Connected
FLASHING
Transmitting or Receiving Data
BRIGHT
Fiber Links are Connected
FDX
(Full
Duplex/Collision)
OFF
Half-Duplex Mode or Network
Disconnected
FLASHING
Data Collision Detected
BRIGHT
Full-Duplex Mode
Specifications:
Standards: comply with IEEE802.1 10Base-T, IEEE802.3u
100Base-TX, IEEE802.3 100Base-FX
RJ45 port rate: 10/100Mbps auto negotiation
Optic port rate: 100Mbps
Transfer distance: RJ45port: 100m
Fiber optic: 20, 40, 60, 80, 120km(SM),

6
2, 5 km (MM) optional
RJ45 port cable: UTP 5E
Fiber connector: 2×SC, 2×ST, 2×FC optional
Fiber optic cables: Single Mode:8.3/125,8.7/125,9/125 or 10/125
um
Muti-Mode:50/125,62.5/125 um
Wavelength: 850nm, 1310nm, 1550nm
Power supply: External 5VDC input
Dimensions: 94.0mm×71.0mm×26.0mm
Installation: support DIN-Rail installation
Operating temp:-10°C to 65°C
Storage temperature: -20 to 70°C
Operating humidity: 5% to 95 %( no condensation)
Warranty: 5 years
Approvals: FCC, CE, RoHS approvals
Applications:
Extending 10/100M Ethernet data distance

7
Installation:
IT-PMC-1100 P2 provides DIN-rail and wall mounting two types of
installation.
Wall mounting installation

8
DIN-Rail Installation
Troubleshooting instructions:
1. Make sure the power is connected and turned on.
2. Make sure the converter Ethernet and fiber optic cables are
connected properly.
3. Check the connections according to the connection diagram.
4. Check the LED Indication status and identify possible problems
from the Indication LED table above.
Note:
1. Media Converter is a sensitive electronic item, please do handle
with extra care on delivery, shifting and humidity.
2. This unit will be warranty for 5 years.
3. Whenever there is a problem regarding the quality issue within
the warranty period, we will take the responsibility to repair with
free.
4. After the warranty period, we will charge accordingly
depending on the fault or damage.
5. Whenever there is a fault, you can contact our technical support
after you identify the problem and the alarm.

9
Common Problems:
1. PWR power supply indicator lamp not lighting
Cause:
1. Power supply not properly connected.
2. Protector tube damaged.
3. Power input tie-line in reverse connection.
4. Internal power supply circuit with failure.
Solution:
1. Check power switch and jack.
2. Replace protector tube.
3. Correct power supply line connection.
4. Returned to the manufacturer for repair.
2. FX Port Link/Act indicator lamp not lighting
Cause:
Optic fiber port link is fault.
Solution:
1. Check fiber optic is link or not.
2. Check fiber optic loss is high.
3. Clean the connector of optic interface.
4. Insert the well connector in place.
5. Returned to the manufacturer for repair.
3. TX Port Link/Act indicator lamp not lighting
Cause:
Ethernet port link is fault.
Solution:
1. Check Ethernet (RJ45) line is link or not.
2. Check Ethernet (RJ45) port is loose.
3. Check the rate of selected media converter.
4. Check the rate of Network.
5. Returned to the manufacturer for repair.

10
4. Network packet loss
Solution:
1. Check Ethernet rate or full/half duplex is matched or not.
2. Ethernet (RJ45) port is loose contact, or optic port is loose
contact and soiled.
3. Ethernet cable not comply with Ethernet standard.
