Intellisystem IT-PMC-3012 P2 User manual

1
IT-PMC-3012 P2
10/100/1000M Media Converter
(SS: single-mode single fiber)
Introduction:
IT-PMC-3012 P2, 10/100/1000Mbps adaptive Gigabit Ethernet
fiber converter uses the switching technology to conduct media
conversion, which meets the standards of IEEE802.3, IEEE802.3u,
IEEE802.3z and IEEE802.3ab.
This kind of media converter supports two types of media network
connections: 10Base-T/100Base-TX/1000Base-T and
1000Base-SX/LX.IT-PMC-3012 P2 can conduct mutual conversion
between 10Base-T/100Base-TX/1000Base-T twisted pair electrical
signals and 1000Base-SX/LX optical signals.
This media converter extends the transmission distance of a
network from 100m over copper wires to 120 Km. This media
converter supports transmission in single-fiber single-mode,
SC/ST/FC style fiber-optic connections.
Packing List:
IT-PMC-3012 P2 is shipped with following items.
1. IT-PMC-3012 P2×1
2. 5VDC power adapter ×1(Media converter/5VDC)
3. User manual ×1

2
Features:
1. Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE
802.3ab 1000Base-TX, IEEE802.3z 1000Base-SX/LX
2. MDI/MDI-X auto negotiation, 10M/100/1000M auto negotiation
3. Supports full /half-duplex, Point-to-point transparent transfer
4. Power External 5VDC input
5. Plug-and-play, easy to installation
6. Can insert to 2U 19", 14 slots Rack (power external)
Pinout Configuration:
Power
IT-PMC-3012 P2 adopt the power supply input is 5VDC external.
Ethernet (RJ45), Optical fiber interface
Optical fiber interface:
The optical fiber connection supports single-mode single fiber (1
SC, 1×FC, 1×ST, optional).
For Link: A-to-B (The mark A device link to the mark B device)

3
Ethernet interface:
Ethernet (RJ45) interface supports MDI/MDI-X auto
negotiation, can use straight-through cable connect PC or
server, use across-over connect cable Switch or HUB.
MDI: PIN 1, 2, 3, 6 connects opposite.
MID-X: 1→3, 2→6, 3→1, 6→2
MDI/MDI-X 10Base-T/100Base-TX PIN define as follow:
PIN
MDI
MDI-X
1
TX+
RX+
2
TX-
RX-
3
RX+
TX+
6
RX-
TX-
4、5、7、8
—
—
Note：“ TX±”Transfer data±，“RX±”Receive data±，“—”None。
1 8

4
MDI:
MDI-X:
1
8
RJ45
TX+
TX-
TX-
RX+
RX+
RX-
RX-
TX+
2
3
6
1
2
3
6
1
1
8
RJ45
TX+
TX-
TX-
RX+
RX+
RX-
RX-
TX+
2
3
6
1
6
1
2
3
(TX-)
(RX+)
(RX-)
(TX+)
(TX+)
(TX-)
(RX+)
(RX-)

5
LED indications:
LED
STATE
INDICATION
PWR
(Power)
OFF
Power Off
BRIGHT
Power On
FX
(Fiber Link Port)
OFF
Ethernet is not
Connected
BRIGHT
Ethernet is Connected
100M
(10/100M)
OFF
10M Ethernet
BRIGHT
100M Ethernet
1000M
OFF
Not 1000M Ethernet
BRIGHT
1000M Ethernet
DUP
(Duplex Mode)
OFF
Half Duplex
FLASHING
Full Duplex
TP-TX
(Ethernet Port)
OFF
Ethernet is not
Connected
FLASHING
Transmitting or
Receiving Data
BRIGHT
Ethernet is Connected
Specifications:
Standards: comply with IEEE802.1 10Base-T, IEEE802.3u
100Base-TX, IEEE 802.3ab 1000Base-TX, IEEE802.3z
1000Base-SX/LX standards
RJ45 port rate: 10/100/1000Mbps auto negotiation
Optic port rate: 1000Mbps
Transfer distance: RJ45port: 100m
Fiber optic: 20, 40, 60, 80,120km(SM),

6
RJ45 port cable: UTP 5E
Fiber connector: 1×SC, 1×ST, 1×FC optional
Fiber optic cables: Single Mode:8.3/125,8.7/125,9/125 or 10/125
um
Wavelength: 1310nm (Device A) 1550nm (Device B)
Power supply: External (5VDC), optional
Dimensions: 94.0mm×71.0mm×26.0mm
Installation: support DIN-Rail installation
Operating temp:-10°C to 65°C
Storage temperature: -20 to 70°C
Operating humidity: 5% to 95 % (no condensation)
Warranty: 5 years
Approvals: FCC, CE, RoHS approvals
Applications:
Extending 10/100/100M Ethernet data distance
Installation:
IT-PMC-3012 P2 provides DIN-rail and wall mounting two types of
installation.

7
Wall mounting installation

8
DIN-Rail Installation
Troubleshooting instructions:
1. Make sure the power is connected and turned on.
2. Make sure the converter Ethernet and fiber optic cables are
connected properly.
3. Check the connections according to the connection diagram.
4. Check the LED Indication status and identify possible problems
from the Indication LED table above.
Note:
1. Media Converter is a sensitive electronic item, please do
handle with extra care on delivery, shifting and humidity.
2. This unit will be warranty for 5 years.
3. Whenever there is a problem regarding the quality issue within
the warranty period, we will take the responsibility to repair with
free.
4. After the warranty period, we will charge accordingly
depending on the fault or damage.

9
5. Whenever there is a fault, you can contact our technical support
after you identify the problem and the alarm.
Common Problems:
1. PWR power supply indicator lamp not lighting
Cause:
1. Power supply not properly connected
2. Protector tube damaged
3. Power input tie-line in reverse connection
4. Internal power supply circuit with failure
Solution:
1. Check power switch and jack
2. Replace protector tube
3. Correct power supply line connection
4. Returned to the manufacturer for repair.
2. FX (Fiber Link Port) indicator lamp not lighting
Cause:
Optic fiber port link is fault.
Solution:
1. Check fiber optic is link or not.
2. Check fiber optic loss is high.
3. Clean the connector of optic interface.
4. Insert the well connector in place.
5. Returned to the manufacturer for repair.
3. TP-TX (Ethernet Port) indicator lamp not lighting
Cause:
Ethernet port link is fault.
Solution:
1. Check Ethernet (RJ45) line is link or not.
2. Check Ethernet (RJ45) port is loose.

10
3. Check the rate of selected media converter
4. Check the rate of Network.
5. Returned to the manufacturer for repair.
4. Network packet loss
Solution:
1. Check Ethernet rate or full/half duplex is matched or not.
2. Ethernet (RJ45) port is loose contact, or optic port is loose
contact and soiled.
3. Ethernet cable not comply with Ethernet standard.
Certifications:
