Intellisystem IT-PMC-3012 User manual

1
IT-PMC-3012
10/100/1000M Media Converter
(SM & MM)
Introduction:
IT-PMC-3012, 10/100/1000Mbps adaptive Gigabit Ethernet fiber
converter uses the switching technology to conduct media
conversion, which meets the standards of IEEE802.3, IEEE802.3u,
IEEE802.3z and IEEE802.3ab. This kind of media converter
supports two types of media network connections:
10Base-T/100Base-TX/1000Base-T and
1000Base-SX/LX.IT-PMC-3012 can conduct mutual conversion
between 10Base-T/100Base-TX/1000Base-T twisted pair electrical
signals and 1000Base-SX/LX optical signals.
This media converter extends the transmission distance of a
network from 100m over copper wires to 20 Km. This media
converter supports transmission in dual-fiber multi-mode, dual-fiber
single-mode, SC/ST/FC style fiber-optic connections.
Packing List:
IT-PMC-3012 is shipped with following items.
1. IT-PMC-3012×1
2. 5VDC power adapter ×1(Media converter/5VDC)
3. User manual ×1

2
Features:
1. Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE
802.3ab 1000Base-TX, IEEE802.3z 1000Base-SX/LX.
2. MDI/MDI-X auto negotiation, 10M/100M/1000M auto
negotiation.
3. Supports full /half duplex, Point-to-point transparent transfer.
4. Power External input.
5. Plug-and-play, easy to installation.
6. Can insert to 2U 19", 14 slots Rackmount (power external).
Pinout Configuration:
Power
IT-PMC-3012 adopt the power supply input is 5VDC external.
Ethernet (RJ45), Optical fiber interface
Optical fiber interface:
Optic fiber interface need use in pairs, OUT port is fiber send side,
connect another long-range light of interface fiber receive end IN;
IN port is fiber receive side, connect long-range same fiber send
side:
Optic fibers spent both ends mark the label (the following picture
show: A-A, B-B, can also mark another: A1-A2, B1-B2), in order to
use.

3
NOTE: SC, ST or FC, for optic fiber interface, SM is look the same
to MM for form. For example, IT-PMC-3012SM/SC, the optic fiber
interface (SC) is look the same to Mode3012MM/SC.
Ethernet interface:
Ethernet (RJ45) interface supports MDI/MDI-X auto negotiation,
can use straight-through cable connect PC or server, use across-over
connect cable Switch or HUB.
MDI: PIN 1, 2, 3, 6 connects opposite.
MID-X: 1→3, 2→6, 3→1, 6→2
MDI/MDI-X 10Base-T/100Base-TX PIN define as follow:

4
PIN
MDI
MDI-X
1
TX+
RX+
2
TX-
RX-
3
RX+
TX+
6
RX-
TX-
4、5、7、8
—
—
Note：“ TX±”Transfer data±，“RX±”Receive data±，“—”None。
MDI:
MDI-X:
1 8
1
8
RJ45
TX+
TX-
TX-
RX+
RX+
RX-
RX-
TX+
2
3
6
1
2
3
6
1
1
8
RJ45
TX+
TX-
TX-
RX+
RX+
RX-
RX-
TX+
2
3
6
1
6
1
2
3
(TX-)
(RX+)
(RX-)
(TX+)
(TX+)
(TX-)
(RX+)
(RX-)

5
LED indications:
LED
STATE
INDICATION
PWR
(Power)
OFF
Power Off
BRIGHT
Power On
FX
(Fiber Link Port)
OFF
Ethernet is not
Connected
BRIGHT
Ethernet is Connected
100M
(10/100M)
OFF
10M Ethernet
BRIGHT
100M Ethernet
1000M
OFF
Not 1000M Ethernet
BRIGHT
1000M Ethernet
DUP
(Duplex Mode)
OFF
Half Duplex
FLASHING
Full Duplex
TP-TX
(Ethernet Port)
OFF
Ethernet is not
Connected
FLASHING
Transmitting or
Receiving Data
BRIGHT
Ethernet is Connected
Specifications:
Standards: comply with IEEE802.1 10Base-T, IEEE802.3u
100Base-TX, IEEE 802.3ab 1000Base-TX, IEEE802.3z
1000Base-SX/LX standards
RJ45 port rate: 10/100/1000Mbps auto negotiation
Optic port rate: 1000Mbps
Transfer distance: RJ45port: 100m
Fiber optic: 20, 40, 60, 80,120km(SM),
220m, 550m (MM) optional

6
RJ45 port cable: UTP 5E
Fiber connector: 2×SC, 2×ST, 2×FC optional
Fiber optic cables: Single Mode:8.3/125,8.7/125,9/125 or 10/125
um
Multi-Mode: 62.5/125, 50/125 um
Wavelength: 850nm, 1310nm, 1550nm
Power supply: External 5VDC input
Dimensions: 94.0mm×71.0mm×26.0mm
Installation: support DIN-Rail installation
Operating temp:-10°C to 65°C
Storage temperature: -20 to 70°C
Operating humidity: 5% to 95 %(no condensation)
Warranty: 5 years
Approvals: FCC, CE, RoHS approvals
Applications:
Extending 10/100/100M Ethernet data distance
Installation:
IT-PMC-3012 provides DIN-rail and wall mounting two types of
installation.

7
Wall mounting installation

8
DIN-Rail Installation
Troubleshooting instructions:
1. Make sure the power is connected and turned on.
2. Make sure the converter Ethernet and fiber optic cables are
connected properly.
3. Check the connections according to the connection diagram.
4. Check the LED Indication status and identify possible problems
from the Indication LED table above.
Note:
1. Media Converter is a sensitive electronic item, please do
handle with extra care on delivery, shifting and humidity.
2. This unit will be warranty for 5 years.
3. Whenever there is a problem regarding the quality issue within
the warranty period, we will take the responsibility to repair with
free.
4. After the warranty period, we will charge accordingly
depending on the fault or damage.

9
5. Whenever there is a fault, you can contact our technical support
after you identify the problem and the alarm.
Common Problems:
1. PWR power supply indicator lamp not lighting
Cause:
1. Power supply not properly connected.
2. Protector tube damaged.
3. Power input tie-line in reverse connection.
4. Internal power supply circuit with failure.
Solution:
1. Check power switch and jack.
2. Replace protector tube.
3. Correct power supply line connection.
4. Returned to the manufacturer for repair.
2. FX (Fiber Link Port) indicator lamp not lighting
Cause:
Optic fiber port link is fault.
Solution:
1. Check fiber optic is link or not.
2. Check fiber optic loss is high.
3. Clean the connector of optic interface.
4. Insert the well connector in place.
5. Returned to the manufacturer for repair.
3. TP-TX (Ethernet Port) indicator lamp not lighting
Cause:
Ethernet port link is fault.
Solution:
1. Check Ethernet (RJ45) line is link or not.
2. Check Ethernet (RJ45) port is loose.
3. Check the rate of selected media converter

10
4. Check the rate of Network.
5. Returned to the manufacturer for repair.
4. Network packet loss
Solution:
1. Check Ethernet rate or full/half duplex is matched or not.
2. Ethernet (RJ45) port is loose contact, or optic port is loose
contact and soiled.
3. Ethernet cable not comply with Ethernet standard.
