intensity KJR-86C-E Operating instructions

WIRED REMOTE CONTROLLER
MAN-O-KJR86C-0615
intensity.mx
INSTALLATION &
OWNER´S MANUAL
KJR-86C-E
Please read this manual carefully before operation and keep it for future reference.

 This manual gives detailed description of the
precautions that should be brought to your
attention during operation.
 In order to ensure correct service of the wired
controller please read this manual carefully
before using the unit.
 For convenience of future reference, keep this
manual after reading it.

INSTALLATION
OPERATION
I. SAFETY PRECAUTIONS..............................................................2
II. OTHER PRECAUTIONS...............................................................4
III. INSTALLATION PROCEDURE....................................................6
IV. WIRING FIGURE OF THE WIRED REMOTE CONTROLLER CON-
NECT WITH THE INDOOR UNIT...............................................9
I. MAIN PARAMETERS.................................................................15
II. MAIN FUNCTIONS....................................................................15
III. NAMES AND FUNCTIONS OF KEYS..........................................16
IV.
OPERATION METHOD...............................................................17
CONTENTS PAGE

INSTALLATION

2
The following contents are stated on the product and the opera-
tion manual, including usage, precautions against personal harm
and property loss, and the methods of using the product correctly
and safely. After fully understanding the following contents
(identifiers and icons), read the text body and observe the follow-
ing rules.
 Identifier description
Identifier Meaning
Means improper handling may lead to personal
death or severe injury.
Means improper handling may lead to personal
injury or property loss.
[Note]: 1. “Harm” means injury, burn and electric shock which need
long-term treatment but need no hospitalization
2. “Property loss” means loss of properties and materials.
W
arning
arning
Caution
Caution
I. SAFETY PRECAUTIONS

3
 Icon description
Meaning lcon
It indicates forbidding. The forbidden subject-matter is
indicated in the icon or by images or characters aside.
It indicates compulsory implementation. The compulsory
subject-matter is indicated in the icon or by images or
characters aside.
Warning
W
arning
arning
Please entrust the distributor or profes-
sionals to install the unit. The installers
must have the relevant know-how.
Improper installation performed by the
user without perm ission may cause fire,
electric,shock, personal injury or water
leakage.
Delegate
installation
Forbid
Forbid
Usage
Usage
W
arning
arning
Do not spray flammable aerosol to the
wired remote controller directly. Otherwise,
fire may occur.
Do not operate with wet hands or let water
enter the wiredremote controller.
Otherwise, electric shock may occur.


4
Installation Location
Do not install the unit in a place with much oil, steam, sulfide gas.
Otherwise, the product may deform and fail.
Preparation before installation
1. Check whether the following assemblies are complete.
1
2
3
4
5 1
2
2
1
1
No. Name Qty. Remarks
Wired remote Controller
Installation & owner’s manual
II.OTHER PRECAUTIONS

Plastic screw bar
For installing the wire controller on
the electrical box
For installing the wire controller on
the electrical box
Connecting wires of signal
receiving panel
For connecting the signal receiving
panel with the 4-core shielding wire
M4×25 Cross head
screwdriver

5
2
1
3
4
5
1
1
1
1
1
2. Prepare the following assemblies on the site.
No. Name Qty. Remarks
Notice to installation of wired
remote controller
1). This manual contains
information about the procedure
of installing the controller.
2). The circuit of the wired remote
controller is low voltage circuit,
Never connect it with a
220V/380V circuit or put it into a
same Wiring Tube with the circuit.
and the interval must be more
than 300~500mm.
3). The shield cable must be
connected stable to the ground,
or transmission may fail.
4). Do not to attempt to extend
the shield cable by cutting, if it is
necessary, use Terminal
Connection Block to connect.
5). After finishing connection, do
not use Megger to have the
installation check to the signal
wire.
Electrical box
4-core shielding wire PVVR-0.5mm2x4,embedded in the
wall in advance.
Wiring tube(insulation casing) Embedded in the wall in advance,
the longest is 12M.
Cross head screwdriver For installing the cross head screw.
Small cross head screwdriver For taking down the bottom cover
of wire controller.
General electrical box size,
embedded in the wall in advance.

6
III.INSTALLATION PROCEDURE
A
B
C
D
A
B
C
D
+5V
GND
Fig.3.1
Fig.3.2
4-Core Shield Cable, the
length is decided by
installation
Indoor Unit
Indoor Unit display panel
Wired Remote
Controller
Principle diagram of wired remote controller:
Installation instruction figure
4-core shielding wire
embedded in the wall
Attached connecting wires for
the display panel
Display panel


7
Fig.3.5
Fig.3.4
Fig.3.3
4-core shielding wire
embedded in the wall

8
Warning
Warning
1.Insert the 4-core plug of the
connecting wires for the signal
receiving panel into the 4-core
socket of the signal receiving
panel. (Fig.3.2)
2.Connect the other terminal of
the connecting wires for the signal
receiving panel with the embed-
ded 4-core shielding wire, and
ensure the connection are reliable
and firm. (Fig.3.2)
3.Connect the led-out wire of the
wire controller with the embedded
4-core shielding wire, and ensure
the connection are reliable and
firm. (Fig.3.3)
4.Use a straight screwdriver to
insert into the catching groove in
the bottom of wire controller and
take down the bottom cover.
(Fig.3.4)
5.Adjust the length of two plastic
screw bars in the accessory to be
standard length from the electrical
box screw bar to the wall. Make
sure when install the screw bar to
the electrical box screw bar, make
it as flat as the wall.
6.Use cross head screws to fix the
wire controller bottom cover in the
electric control box through the
screw bar. Make sure the wire
controller bottom cover is on the
same level after installation, and
then install the wire controller back
to the bottom cover. (Fig.3.5 )
Over fasten the screw will lead to
deformation of back cover and
fracture of liquid screen.
When install the bolts, please make
the screw bar height to be the same
with the wire controller and will not
out of shape.
When under installation, reserve
certain length of the connecting wire
for convenient to take down the wire
controller while during maintenance.
(Fig.3.5)

9
IV. Wiring figure of the wired remote
controller connect with the indoor unit
1.Wiring figure of the wire controller connect with the four-way cassette
type indoor unit
fig.4.1
A B C D
Electric controlling
boxs’ plug CN10
Main board 10-core
connecting
wire group
4-core shield cable
Back of the wired remote Controller
Plane of indoor unit
Display panel
Indoor unit electric
controlling box

10
2.Wiring figure of the wire controller connect with the courtyard-style
duct type indoor unit
fig.4.2
A B C D
Plane of indoor unit
Indoor unit electric controlling box
Electric controlling
boxs’ plug CN10
Main board 10-core
connecting
wire group
Display panel
Back of the wired remote controller
4-core shield cable

11
3.Wiring figure of the wire controller connect with the high-static
pressure duct type indoor unit
A B C D
fig.4.3
Electric controlling
boxs’ plug CN10
Main board
Display panel
Back of the wired
remote controller
Indoor unit electric controlling box
4-core shield cable

12
4.Wiring figure of the wire controller connect with the wall hanging type
indoor unit
fig.4.4
A B C D
Indoor unit electric controlling box
Electric controlling
boxs’ plug CN10
Main board 10-core
connecting
wire group
Plane of indoor unit
Display panel
Back of the wired remote controller
4-core shield cable

13
5.Wiring figure of the wire controller connect with the stand-hanging
type indoor unit
fig.4.5
A B C D
Indoor unit electric controlling box
Electric controlling
boxs’ plug CN10
Main board
10-core connecting
wire group
Plane of indoor unit
Display panel
Back of the wired remote controller
4-core shield cable

OPERATION

15
I.MAIN PARAMETERS
II.MAIN FUNCTIONS
MODEL
Voltage input
Ambient tempera-
ture range
Ambient humidity
range




1. Set HEAT/ COOL operation
mode;
2. Set fan speed;
3. Temperature setting range:
17°C-30°C;
4. Power down memory function;
5. Room temperature display.

16
III. NAMES AND FUNCTIONS OF KEYS






17
IV.OPERATION
METHOD
SET TEMP DOWM
26°C SHORTCUT

FAN SPEED Select fan speed
Quickly set the operation tempareture
to 26°C




NO. KEY FUNCTION
SET TEMP UP
ON/OFF
Increase setting temperature
On/Off the unit
Decrease setting temperature
ON/OFF Selecting mode:
1.When the unit is turned off,
press the ON/OFF button, the
unit will be turned on and the
LCD screen of the wired remote
controller on.
2.When the unit is turned on,
press the ON/OFF button, the
unit will be turned off and the
LCD screen of the wired remote
controller off.
1.When the unit is turned on,
press the temperature adjusting
buttons “” and “” at the
same time for 3 seconds to
select the operation mode, each
press will switch the operation
mode as the following order:
COOL HEATCOOL
