intensity RM12F Specification sheet

REMOTE CONTROLLER
MAN-OIM-RM12F-1120
intensity.mx
OPERATION AND
INSTALLATION MANUAL
*imágenes con fines ilustrativos
MODEL: RM12F
Thank you for purchasing the remote controller.
This manual describes the safety precaution requirement of using this product.
2nd Generaon VRF Remote Controller

Thank you for purchasing this remote controller.
Carefully read this OPERATION AND INSTALLATION
MANUAL before using the controller. It will tell you how to use
the controller properly and help you if any trouble occurs. After
reading the manual, please keep it for future reference.

Contents
Installation ................................................................. 1
1. Installation Precautions ................................... 1
2. Installation Accessories ................................... 3
3. Dimensions of Remote Controller and Bracket 3
4. Installation and Fixing ........................................ 4
5. Replace the Batteries ........................................ 5
Operating the Remote Controller .............................. 7
1. Using Precautions ............................................. 7
2. Model and Key Parameters .............................. 8
3. Button Names and Functions ......................... 9
4. Name and Function on Display Screen .......... 11
5. Operating Methods ........................................ 12
5.1 On/Off Operations ................................... 12
5.2 Mode and Temperature Operations .......... 12
5.3 Fan Speed Operations .............................. 13
5.4 Soft Wind Operations ................................... 14
5.5 Vane Selection Operations ......................... 14
5.6 Swing Operation ........................................ 14
5.7 IDU Display Operations .............................. 15
5.8 Silent Mode Operation .............................. 16
5.9 ECO Operations ........................................ 16
5.10 Follow Me Operations .............................. 17
5.11 Timer On/Off Operations ......................... 17
5.12 Button Lock Operations ......................... 19
5.13 Auxiliary Heater Operations (reserved) ..... 19
Field Settings ............................................................ 20
Parameter Configuration for Remote Controller ..... 20

Installation
1. Installation Precautions
Safety Considerations
Please read this "Safety Considerations" carefully before installing
Controller and be sure to install it correctly. After completing the
installation, make sure the controller operates properly.
Please instruct the customer how to operate the controller and how to
perform maintenance.
Failure to observe these instructions properly may result in
property damage or personal injury.
Information as NOTE contains instructions to ensure proper
use of the controller.
controller.
transmitted.
lamps can easily be seen.
lamp near the receiver.
Meaning of Caution Symbols

Installation
WARNING
Precautions in handling remote controller
the air conditioner.
If something blocksthe transmitting and receiving path of the indoor unit
and the remote controller as curtains, it will not operate.
Transmitting distance is approximately 7 m.
1 short beeps from the receiver indicates that the transmission is properly
done.
Do not drop or get it wet.
It may get damaged.
Never press the button of the remote controller with a hard, pointed object.
The remote controller may get damaged.
Installation site
It is possible that signals will not be received in rooms that have electronic
fluorescent lighting. Please consult with the salesman before buying new
fluorescent lights.
If the remote controller operated some other electrical apparatus, move
that machine away or consult your dealer.

Installation
2. Installation Accessories
Please check that you have all the following parts.
3. Dimensions of Remote Controller and Bracket
Figure 2.1 Dimensions of remote controller
No. Name Schematic Qty
Remote controller bracket 1
Screw lid 1
Philips head screw (M2.0*4.5) 2
AAA battery 2
Remote controller manual 1
47 mm 25 mm
170 mm

Installation
Figure 2.2 Dimensions of remote controller bracket
4. Installation and Fixing
1) Use the screws (accessories) to fix and secure the remote controller
bracket in a stable position (see Figure 2.3);
Make sure you refer to "1. Installation Precautions" to determine the
location.
Figure 2.3
2) Slot the screw lid into the bracket cover on top of the screws (see
Figure 2.4);
25 mm
72 mm
89 mm
Installation

Installation
Figure 2.4
3) Slide the remote controller vertically down into the remote controller
bracket (see Figure 2.5).
Figure 2.5
5. Replace the Batteries
1) Slide to move the battery cover at the back of the remote controller in
the direction indicated by the arrow (Figure 2.6);

Installation
Figure 2.7
3) Take out the old batteries. Install two new AAA batteries according to
the positive and negative polarities indicated (see Figure 2.8). Close the
battery cover.
Figure 2.8
Figure 2.6
2) Lift up from the lower left end of the battery cover to open it (see
Figure 2.7);

Operating the Remote Controller
WARNING
Failure to follow these instructions properly may result in
personal injury or loss of life.
CAUTION
Failure to observe these instructions properly may result in
property damage or personal injury, which may be serious
depending on the circumstances.
Information as NOTE contains instructions to ensure proper
use of the controller.
After reading, keep this manual in a convenient place so that you can
refer to it whenever necessary. If the controller is transferred to a new
user, be sure also to hand over the manual.
Note that prolonged, direct exposure to cool or warm air from the air
conditioner or to air that is too cold or warm can be harmful to your
physical body and health.
directly on the remote controller as these may cause the device to
become deformed.
controller and contact your local agent.
remote controller. Do not wash the controller with water.
WARNING
1. Using Precautions
To gain full advantage of the controller's functions and to avoid
malfunction due to mishandling, we recommend that you read this
instruction manual carefully before use.
The precautions described here in are classified as WARNING and
CAUTION. They both contain important information regarding safety. Be
sure to observe all precautions without fail.

Operating the Remote Controller
Do not operate the device with wet hands to prevent water from
entering the remote controller and damage the circuit board.
it is intended. Do not use the air conditioner to cool precision
instruments, food, plants, animals or works of art as this may adversely
affect the performance, quality, and/or lifespan of the object concerned.
conditioner with other heating equipment. Insufficient ventilation may
result in oxygen deficiency.
CAUTION
Product Model RM12F
Rated Voltage 3.0 V (AAA battery x 2)
Ambient Temperature -5 to 43°C
Ambient Humidity RH 90%
2. Model and Key Parameters

Operating the Remote Controller
3. Button Names and Functions
Figure 3.1 External view of remote controller
16
17

Operating the Remote Controller
10
No. Button Function
ECO Turn on/off the economic
operation function
Mode Set operating mode: Cool
Dry Fan Heat
Adjust downwards
Adjust the temperature setting
or timer (programmed time)
downwards
Soft wind
Timer on Set the time to turn on the unit
Silent Turn on/off the silent function
Adjust upwards
Adjust the temperature setting
or timer (programmed time)
upwards
On/off switch Switch on/off the unit
Fan speed Fan speed setting
Timer off Set the time to turn off the unit
Turn on/off the vertical swing
function
Swing
Vane angle Adjust the angle of the
horizontal louver
Swing Turn on/off the horizontal swing
function
Vane select
Display Turn on or off the display of the
indoor unit
Auxiliary heater Turn on/off the auxiliary heater
function
Follow me Turn on/off the follow me
function
16
17
In Cool mode, press this button
to turn on or off the Soft wind
function.
In power-on status, press this
button to select a vane to be
controlled.

Operating the Remote Controller
Figure 3.2 Display screen of remote controller
No. Name Display Function
Temperature Displays current temperature setting
11
Follow me Shows that Follow Me is on
2
9
3
5
6
Operating mode Displays the current operating mode
Timer On/Off Displays times to turn on/off the unit
Silent mode Shows that Silent is on
Fan speed Displays the current fan speed
Soft wind In Cool mode, press this button to
turn on or off the Soft wind function
Note:
The buttons and are not available for first generation indoor units.
The button is only available for indoor unit with individual vane control
function.
The is only available for indoor unit with soft wind function.
4. Name and Function on Display Screen

12
Operating the Remote Controller
Lock
ECO
Auxiliary heater Shows that auxiliary heater is on
5. Operating Methods
5.1 On/Off Operations
1) Press (see Figure 3.3), Indoor unit starts to run;
Figure 3.3
2) Press again. the indoor unit stops running.In power-off status,
modes are displayed.
5.2 Mode and Temperature Operations
1) Press (see Figure 3.4). Display screen shows the operating
Figure 3.4
Shows that ECO function is on
Shows that the remote controller
button is locked
Signal transmission Displays signal sent to the indoor
unit from the remote controller
Horizontal swing Shows that Horizontal Swing is on
Vertical swing Shows that Vertical Swing is on

2) Press each time to change the operating mode according to the
order shown in Figure 3.5;
Figure 3.5
0.5°C (default). Long press to change the temperature continuously.
Note:
5.3 Fan Speed Operations
Figure 3.6
1) 7 fan speeds: The default in the remote controller is the mode with 7
fan speeds, where the Fan Speed will be adjusted in turn as shown in
Figure 3.7;
Cool Dry Fan Heat
Figure 3.7
2) 3 fan speeds: Fan Speed will be adjusted in turn as shown in Figure
3.8.
Figure 3.8
Operating the Remote Controller
13
Auto Speed 1 Speed 2 Speed 3 Speed 4 Speed 5 Speed 6 Speed 7
High
Auto Low Mid High
Every time when you press the button, fan speed is changed in
the following order.(see Figure 3.6).
Note: The fan speed set on the remote controller should match with
the air conditioner. For how to set the fan speed, see section
“Initial Settings” in this document.
Fan speeds cannot be adjusted in Dry mode.

Figure 3.11
5.4 Soft Wind Operations
Press to adjust the direction of the vertical louver (see Figure 3.9).
Operating the Remote Controller
14
Figure 3.9
5.5 Vane Selection Operations
Figure 3.10
In Cool mode, press this button toturn on or off the Soft wind function.
In Soft wind function, the fan operates at the minimum speed and swings
at the minimum angle.
In power-on status, press this button to select the vane to be controlled.
If you press this button continuously, you can select vanes in circulating
manner.
5.6 Swing Operation
1) Vertical Swing
When the unit is on. Press (see Figure 3.11). Start the vertical
swing function, and the will light up, and signal is sent to the indoor
unit;
The indicator in the indoor unit corresponding to the selected vane will be
on, and then off after 15 seconds. After selecting the vane to be controlled,
you can use and set the swing angle.
5.5 Vane Selection Operations
In Cool mode, press this button toturn on or off the Soft wind function.
In Soft wind function, the fan operates at the minimum speed and swings
at the minimum angle.

Figure 3.13
When the vertical swing is on, press to turn off this function.
Note:
for 15s and then disappears. The indoor unit remains vertical swing
operation.
2) Horizontal Swing
When the unit is on. Press (see Figure 3.12). Start the
horizontal swing function, and will light up, and signal is sent to the
indoor unit;
Figure 3.12
When the horizontal swing is on, press to turn off the horizontal
swing function.
Note:
up for 15s and then disappears. The indoor unit remains horizontal
swing operation.
5.7 IDU Display Operations
The Display function is used to control the on/off state of the display in
the indoor unit.
1) When the remote controller is in on or off state, press (see
Figure 3.13), and the display of the indoor unit lights up;
Operating the Remote Controller
15
In Soft wind function, the fan operates at the minimum speed and swings
