HT-100
Robotic Massage®Chair
USE & CARE MANUAL
Including
revolutionary

Thank you for choosing the HT-100 robotic massage®chair
from Interactive Health.
We are confident you will find this product to be among the best available.
Interactive Health®
Partners in Your Well-Being
For over two decades, Interactive Health has been a leader in the field of massage products. We create
state-of-the-art products that embrace the latest technology while applying the ancient healing art of massage.
With today’s fast-paced lifestyles, balancing your physical and mental needs requires the right mix of proper
nutrition, exercise, and massage. Interactive Health®Massage Systems are vital components for achieving
balance between physical and mental well-being.
To learn more about our company and our products, we invite you to visit us on the Internet at: www.
interhealth.com.
NEW Human Touch Technology®
Your new massage chair includes the revolutionary HTT.
HTT is a true step forward in Robotic Massage®technology. The result of years of research
and development, this revolutionary system emulates the latest techniques used by massage and
chiropractic professionals for back and spinal care.
HOW DOES IT WORK? It starts with a multi-patent pending mechanism that acts like “wrists and arms”. The “hands” consist of two,
three-dimensional massaging rollers, which are surrounded by a firm, yet comfortable material that feels like “fingers and
thumbs”. Working together, these robotic components deliver a variety of massage functions that feel great, and really work.
HTT, RECOMMENDED BY PROFESSIONALS, DESIGNED FOR YOU.
“HTT” is the preferred technology of the ACCO.
www.accoweb.org
®

PLEASE READ: To achieve the maximum results from your
HT-100, carefully read this manual. For additional questions,
please call our Customer Service Representatives at [phone].
CAUTION: Only for household use. Please read and observe these
safety instructions carefully to reduce the possibility of fire or injury.
• Those with the following conditions should consult their physician prior to using this massage chair.
a) Malignant tumor
b) Heart Disease
c) Pregnancy
d) Conditions requiring rest
e) Back Disease or back trouble from an injury or accident
• Do not use your massage chair in an excessively humid or dusty environment.
• Your massage chair should be operated at a room temperature of between 40° and 100° F.
• Make sure all operation switches are in the OFF position before connecting the power cord to an electrical outlet.
• Do not use attachments which are not recommended by the manufacture.
• Turn the power switch on the back of the chair to the OFF position when not in use.
• If you detect a malfunction or any other abnormal condition in the operation of your chair, turn off the power immediately
and disconnect the power cord from the outlet.
• If you feel severe discomfort during the operation of your massage chair, stop using the chair and consult your physician.
• Should you have a power failure, turn the power switch to the OFF position.
• You should not use the chair for more than 15 minutes at one time.
• If the chair has gotten wet or exposed to moisture, turn the chair off, unplug it from the wall socket
and call Interactive Health®customer service.
• Keep your massage chair clean and away from humidity.

Contents:
Important Safety Instructions 6
Important Assembly Instructions 8
Footrest Operations 9
Getting the most from your HT-100 10
While using your massage chair...
Basic Operating Instructions 11
Turning the HT-100 on and off
Understanding the controller
Using your HT-100 12
Features
Four Massage Modes
Product Care and Storage 14
General Maintenance
Warranty & Service 15
Specifications 16
HT-100
USE & CARE MANUAL

DANGER: To reduce the risk
of electrical shock
Always unplug massager from the electrical outlet immediately
after using and before cleaning.
Do not reach for an appliance that has fallen into water.
Unplug immediately.
WARNING: To reduce the risk of burns,
fire, electric shock or injury to persons
An appliance should never be left unattended when plugged in.
Unplug from outlet when not in use, and before putting on or
taking off parts.
Do not operate under blanket or pillow. Excessive heating can
occur and cause fire, electric shock, or injury to persons.
Close supervision is necessary when this appliance is used by,
on, or near children, invalids, or disabled persons.
Use this appliance only for its intended use as described in this
manual. Do not use attachments not recommended by the
manufacturer.
Never operate this appliance if it has a damaged cord or plug,
if it is not working properly, if it has been dropped or damaged,
or dropped into water. Return the appliance to a service center
for examination and repair.
Always keep the power cord away from heated surfaces.
Never operate the appliance with the air openings blocked.
Keep the air openings free of lint, hair, and the like.
Never drop or insert any object into any opening.
Do not use outdoors.
Do not operate where aerosol (spray) products are being used or
where oxygen is being administered.
To disconnect, turn all controls to the OFF position, then remove
plug from outlet.
Do not massage abdomen when pain is present or if you are pregnant.
Do not massage any area of the body that is swollen, inflamed or
covered with skin eruptions. Do not use on unexplained calf pain.
Do not use massager when standing on a damp floor, or when any
part of the body is in contact with plumbing or any similar ground.
Always connect massager to a properly grounded electrical outlet.
This unit is designed to operate on standard 120 Volt 60 Hz house current.
Do not use unit if noise above normal sound is heard.
The unit is designed for personal in-home use. Commercial use will
void warranty.
Important Safety Instructions
Read all instructions before using the HT-100.
WARNING: Do not put hands or fingers near
the massage mechanism or rollers while the HT-100 is
running. Touching the mechanism can result in injury
from the rollers squeezing together.
SAVE THESE INSTRUCTIONS
6

Grounding Instructions:
This product must be grounded. If it should malfunction or
breakdown, grounding provides a path of least resistance for
electrical current to reduce the risk of electric shock. This
product is equipped with a cord having an equipment-grounding
conductor and a grounding plug. The plug must be plugged into
an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING: Improper connection of
the equipment-grounding conductor can
result in a risk of electronic shock. Check
with a qualified electrician or serviceman if
you are in doubt as to whether this product
is properly grounded. Do not modify the
plug provided with the product – if it will
not fit the outlet, have a proper outlet
installed by a qualified electrician.
This product is for use on a normal 120-volt circuit and has a
grounding plug that looks like the plug illustrated in sketch (A).
A temporary adapter that looks like the adapter used in sketches
(B) and (C) may be used to connect this plug to a 2-pole
receptacle as shown in sketch (B), if a properly grounded plug is
not available. The temporary adapter should be used only until a
properly grounded outlet (sketch A) can be installed by a qualified
electrician. The green colored, rigid ear tab or the like extending
from the adapter must be connected to a permanent ground such
as a properly grounded outlet box cover. Whenever the adapter is
used, it must be held in place by a metal screw.
WARNING: Your chair is equipped with a thermal
resetting protection device. This is an added safety feature to
protect you and your massage chair from overheating. If the chair
should suddenly stop and will not start, turn the main power
switch, located on the back of the chair, off and do not operate
the chair for at least 30 minutes. Failure to turn the chair off may
result in the chair starting unexpectedly when the device cools.
For all grounded cord-connected products:
Grounding methods:
7
GROUNDED
OUTLET
GROUNDED
OUTLET
BOX
METAL
SCREW
TAB FOR
GROUNDING SCREW
ADAPTER
(B)
(A)
(C)
GROUNDING
PIN

8
Place Backrest Pad into position and
attach the Top flap with the hook and loop.
Important Assembly Instructions
Bring Backrest to an upright position
until it clicks into place.
Your HT-100 comes out of the box
as shown.
Attach the two side hook and loop
side flaps.
Pull down the backrest pad and attach
the two hook and loop flaps by folding
them under the backrest bottom.
Lift the ottoman up slightly and rotate
it as shown (reference figure 10 for
deployment of the ottoman). Fold the
hook and loop flaps around the ottoman
bar to attach.
Attach the base pad as shown.
Attach pillow using the hook and
loop flap.
1
5 6
78
23
4

9
Footrest Operations
ALWAYS LOWER THE FOOTREST BEFORE GETTING OUT OF
THE CHAIR.
DO NOT STAND OR SIT ON THE FOOTREST.
CAUTION: REMOVE YOUR LEGS FROM THE CALF
MASSAGER IF IT IS UNCOMFORTABLE.
Turn the switch on the back of the chair
back to the ON position.
For a calf massage insert your legs into
the massager and activate the calf
massager using the remote control.
To use the calf massager as a foot
massager, lower the ottoman until it is
comfortable for you, place your feet (no
shoes) into the ottoman and then activate
the calf massage function on the remote.
Pull the handle on the right side to
release the ottoman.
Pull the ottoman handle to release the
ottoman for rotation. The ottoman will
rotate and click into position for the
calf massage.
9
12 13
10 11

10
Getting the most from your HT-100
Safety Precautions while
using your Massage Chair
• Comfortable clothing is recommended while using
your massage chair.
• Your massage chair was meant to be used in a relaxed
position. While sitting in the chair, never force any body
part into the backrest area while the rollers are moving.
• Do not allow children to use the massage chair.
• If you feel any abnormal discomfort during the operation
of your massage chair, turn off the power immediately
and do not use the chair. Consult your physician.
• Do not sit on the controller.
• Do not pull on the AC cord.
• Always confirm that there are no obstacles behind the
chair and that there is sufficient space to recline.
• When using your massage chair after it has been in
storage, check to see that the chair is operating properly
prior to sitting in the chair.
• Do not attempt to repair your massage chair yourself.
If a malfunction occurs, please contact
Interactive Health at [phone].
Your HT-100 massage chair is a quality piece of
furniture, and can be utilized and cared for like
the rest of the furniture in your home.
The HTT robotic massage®system inside your chair
is a sophisticated electro-mechanical device that
requires some special care and safety precautions.
Please follow these basic guidelines carefully.
They are provided to ensure the maximum
enjoyment of your chair.
Massage Softening Pad
This pad is used to soften the intensity of the
massage. The Massage Softening Pad comes pre-
installed on your HT-100.
To Remove the pad:
1. On the backside of the back cover pad at the top
there is a zipper. Unzip this and you will find a
pocket in the back cover.
2. Remove the softening pad from this pocket and
close the zipper.
3. Use the chair as normal.
You will find the massage to be less intense when the
softening pad is installed. You can adjust the intensity
by adding or removing the softening pads. Addtional
softening pads are available for an additional charge
from Interactive Health.

Basic Operating Instructions
Understanding your Controller
Your HT-100 is simple to operate using the handheld controller
included with your chair. Before you use your chair, we
recommend that you familiarize yourself with the remote control
and the basic massage functions. To begin using your HT-100
massage chair:
• Plug in the power cord.
• Turn the ON/OFF switch located on the back of the
HT-100 massage chair to the ON position.
1. Stop/Park
Pressing this will stop the massage robot and park the
rollers at the top of the backrest.
2. Programmed Massages
Choose a Full back massage, an Upper Back massage or
a Lower back massage. This feature runs a pre-
programmed combination of the signature massage
modes for 15 minutes.
3. Shoulder Height
Adjusts the upper massage area for small, medium and
tall bodies.
4. Kneading
Starts "Kneading" function.
5. Percussion
Starts "Percussion" function.
6. Compression
Starts "Compression" function.
7. Full Rolling
Starts "Full Rolling" function.
8. Partial Rolling
Starts "Partial Rolling" function.
9. Power Recline
Activates the power mode to raise or lower the
backrest electrically.
10. Spot
Adjusts the massage mechanism up or down
in Kneading, Percussion and Compression
up / down modes.
11. Calf + Foot
Select High, Low or Auto.
11
1
2
3
4
5
6
7
8
9
10
11

12
Using your HT-100
UP  DOWN MASSAGE MODES
Rolling
Description:
Oval-elliptical nodes slowly and gently move up and down
your back, near the spine, gently alternating side to side.
Feels like:
The hands of a therapist pressing firmly yet gently on
your muscles. First on one side of the spine, then on
the other.
Massage technique:
Emulates effleurage, the first part of a massage
performed by a professional massage therapist.
It is designed to warm-up and loosen the muscles to
relieve tension, and prepare the back for a deeper,
therapeutic massage.
Benefits:
Relieves muscle tension; improves circulation and
relaxes the back.
Kneading
Description:
Massage nodes moving in small, circular motion on both
sides of spine simultaneously.
Feels like:
The thumbs or heels of the hand pressing firmly in a circular
motion on both sides of the spine.
Massage technique:
Emulates the thumb kneading performed by a massage
therapist or other professional. This second phase of
massage is slightly more intense than the rolling and is
considered to be a more deep muscle massage.
Benefits:
Relieves tension and soreness by lifting and stretching
muscles; improves circulation and helps bring vital nutrients
to spinal area.
As with all Interactive Health robotic massage®chairs,
you can customize the massage to your own needs.
You can select the massage functions, pinpoint the
massage anywhere on your back, or let the massage
move up and down your spine automatically. And, you
can choose the automatic program mode that will run
a varied massage session.
Rolling
Kneading

Percussion
Description:
Alternating strokes along the spine that stimulate both
spinal muscles and spinal joint areas.
Feels like:
Fists or length of hand rapidly tapping on back muscles.
Massage technique:
Emulates percussive massage, popular in sports medicine;
deep muscle therapy.
Benefits:
Flexes spinal joints and relieves pressure on spinal
column. Invigorates entire back area.
MANUAL UP  DOWN CONTROL
Manually moves the massage mechanism up or down the
back. This feature is meant to be used with the stationary
massage mode.
PROGRAMMED MASSAGE SESSION
This feature utilizes all of the features listed above
in a pre-determined program.
Just sit back, relax and enjoy your massage.
Compression
(An exclusive feature of Interactive Health HTT product line)
Description:
Alternating strokes along the back that press on both
spinal muscles and spinal joint areas.
Feels like:
Heels of hand firmly pushing on muscles along the side of
the spine, and then inward toward the spine. Alternating
“hands” also deliver a soothing rocking motion for the body.
Massage technique:
Emulates massage technique frequently used in sports
medicine, and in spinal therapy by chiropractors. Motion
spreads and places pressure on deep muscle tissue, forcing
it to relax. The rocking motion also loosens spinal joints
characteristic of spinal therapy.
Benefits:
Aids in muscle and joint repair due to strain from exercise,
long hours spent bent over a desk, or high stress levels;
can improve mobility and overall posture.
STATIONARY MASSAGE MODES
Kneading
The same feel and benefits as described in
“Up-Down Kneading” that can be applied in a
single area. Use the manual up & down keys to
apply the massage in the desired area.
Compression
The same feel and benefits as described in
“Up-Down Compression” that can be applied in a
single area. Use the manual up & down keys to
apply the massage in the desired area.
Compression Percussion
Using your HT-100 cont.
13
Stationary Kneading

14
Product Care & Storage
General Maintenance
1. Be sure to disconnect the power cord from the
electrical outlet before cleaning.
2. Do not use benzene, thinner or any other solvents
on your massage chair.
3. Remove dust on the backrest or armrest with a
vacuum.
4. If the backrest or armrest become soiled, wipe with
a damp cloth, then a dry cloth.
5. Common vinyl cleaners may be used for tough stains.
Please follow all manufacturer’s instructions on
cleaner packaging and pre-test any cleaner on a
small inconspicuous area prior to use.
6. When cleaning the controller or around the power
switch, use a dry cloth only. Never use a damp cloth
to clean the controller or power switch.
7. It is suggested that you cover the chair when not in
use for a long period of time.
8. The mechanics of this product are specially
designed and constructed to be maintenance free.
No periodic lubrication or servicing is required.
9. Foreign objects should not be inserted between the
massage nodes or the unit housing.
10. When not in use for a long period of time, we
recommend that the power cord be coiled and
that the unit be placed in an environment free
of dust and moisture.
11. Do not store near heat or open flame. Do not
leave this product exposed to direct sunlight for
long periods of time. This may cause fading or
damage.
To keep your product working and looking its best,
please follow these simple care guidelines.

15
Limited One (1) Year Warranty
Please read the following warranty information for important disclosures before using your new Human Touch Technology‚
massage chair.
It is Interactive Health’s mission to design, develop, manufacture and sell innovative, high quality massage products that create
a better and healthier way of life. We appreciate your commitment to our mission and our products and are pleased to let you
know that the Interactive Health‚ HTT massage chair that you purchased comes with a limited one-year warranty. The warranty
provides peace of mind that you are covered for mechanical or structural defects in workmanship within the coverage guidelines
and limitations outlined below.
Coverage Guidelines:
The warranty begins on the original purchase date and consists of:
• Factory Service (Labor): Interactive Health will supply packing materials, cover return shipping to Interactive Health,
repair parts covered by this warranty and labor for repair work and return shipping to purchaser when repairs are
completed.
• Parts Only (Parts): Interactive Health will supply repair parts that are covered by this warranty and return shipping to
purchaser for repairs performed at the factory.
• Structural (Metal Frame): Interactive Health will supply packing materials and repair parts covered by this warranty
and return shipping to purchaser for repairs performed at the factory.
In the unlikely event that your chair malfunctions or requires repair, please contact Interactive Health Customer Service at
[phone] or [email protected] between the hours of 9:00AM and 5:00PM PST for assistance.
All warranty service requires approval and authorization by Interactive Health. Products require a Return Merchandise
Authorization Number (RMA) for any returns to the factory. For returns, the consumer is responsible for packing the product
in the original box or in approved packaging that is available for sale from Interactive Health. Shipping and freight coverage
under this warranty requires scheduling by Interactive Health and only includes "curb-side" pickup/delivery. Products
received without a valid RMA number or one clearly marked on the box will be refused.
General Limitations:
• The warranty is only valid within the United States and Canada provided the product has been operated according to the
instructions accompanying it and has not been misused or damaged in any way that is beyond the control of Interactive
Health.
• All service covered by this warranty must be approved by Interactive Health and repairs performed by authorized
technicians.
• The warranty applies only to the massage chair; accessories or enhancements are not covered.
• Important exclusions apply to cosmetic items such as fabrics, woods, foams, padding, plastics covers, etc.
• Interactive Health is not responsible in any way for losses, damages, or inconvenience caused by equipment failure.
• For a complete listing of warranty coverage, exclusions, and limitations, visit www.interhealth.com.
• Warranties do not apply to rental, business, commercial, institutional, or other non-residential users.
• Separate warranty terms apply to used/refurbished products including those received out-of-box. Proof of purchase (original
receipt) is required for all warranty repairs.
EXTENDED WARRANTIES:
Interactive Health offers extended warranty programs of up to FIVE YEARS to enhance ownership of the Interactive Health
HTT
®
Chair (HTT Models) Factory Service Parts Structural
New Products (Original Packaging Only) 90 days 1 year 1 year
Refurbished Products 60 days 6 months 6 months
Floor Demos (including "out of box") NONE 6 months 6 months

Operating Voltage: 120 V
Power Consumption: 150 Watts
Size: Chair (reclined) 28”W x 54”L x 32”H
Weight: Chair 135 Lbs
Recline Angle: 115 - 155 Degrees
Number of Massage Functions: Four (4)
Programmed Function: 4 Steps (Repeating)
Massage Head Storage: Auto at Top
Automatic Timer Shut-Off: 15 minutes
Total Massage Stroke Length: 21.0 Inches
Full Length Travel: 43 seconds (25 - 35 - 45 In/Min)
Rolling: 26/60 In/Minute
Kneading: 120/220 Impacts/Minute
Compression: 60/128 Impacts/Minute
Percussion: 240/480 Impacts/Minute
Up/Down: 25 - 35 - 45 In/Minute
Cover Fabric Material: Vinyl
Accessories: Massage Softening Pad
*Specifications are subject to change without prior notice.
Specifications*
16

© Interactive Health®, 2004
Patents Pending and intellectual property rights enforced.
No medical claims are warranted or implied by the use of this product.
