interactive scape Capore Basic User manual

Capore®
Basic
cb-010
Operating manual

1. General
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 2 of 10 poc: SFi
Capore® Basic
Operating manual
Contents
1. General _____________________________________________________________________________________________________________4
1.1. Safety instructions ___________________________________________________________________________________________________ 4
1.2. Cleaning information__________________________________________________________________________________________________5
1.3. Transport information ________________________________________________________________________________________________5
2. Troubleshooting____________________________________________________________________________________________________6
2.1. Manufacturer – Support _____________________________________________________________________________________________ 6
3. Annex ______________________________________________________________________________________________________________ 7
3.1. Technical drawings ___________________________________________________________________________________________________7
3.1.1. Perspective ________________________________________________________________________________________________________7
3.1.2. Top view__________________________________________________________________________________________________________ 8
3.1.3. Right view ________________________________________________________________________________________________________ 9

1. General
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 3 of 10 poc: SFi
Notes
This manual is applicable for the following objects only:
·Capore® Basic (cb-010)
Information in this document is subject to change without notice.
©2019 Interactive Scape GmbH. All rights reserved.
The document or excerpts from the document may not be duplicated without the prior permission of Interactive Scape
GmbH.
Interactive Scape GmbH shall not be liable for any errors contained in this document or any other incidental or
consequential damages resulting from the delivery, use or application of this material.
All product names mentioned in this document are trademarks or registered trademarks of their respective owners.

1. General
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 4 of 10 poc: SFi
1. General
This manual describes the proper use of Capore® Basic objects. Please be aware of any additional documents
that may be required.
In order for the objects to function on a Scape® Tangible touchscreen, a pattern configuration file matching the
respective object type must be activated in the Capore® API Box of the screen, if not already configured. For more
information, refer to the Capore® Touch and Object Assistant manual.
Stable functionality of the objects is only guaranteed when used on Scape® Tangible touchscreens from Interactive
Scape GmbH.
1.1. Safety instructions
Follow these safety precautions before and during the use of your Capore® Basic objects to protect yourself, your
environment, and the Capore® Basic objects from damage.
Moisture, liquids and vapours
Moisture, liquids and vapours can impair the functionality of your Capore® Basic objects and your Scape® Tangibles. In
particular, the undersides of the objects should always be kept completely dry during use.
·Use the Capore® Basic objects only inside buildings.
·Do not allow the Capore® Basic objects to come into contact with liquids.
·Protect your Capore® Basic objects from vapors and moisture.
Improper cleaning
Improper cleaning with strong detergents and solvents or dripping wet cloths can damage the Capore® Basic objects.
·Please observe the information on cleaning your Capore® Basic objects (Chapter 1.2 Cleaning information).
Improper opening and repair
Improper opening and repair can cause Capore® Basic objects to lose their functionality and damage the surface of the
Scape® Tangible.
·Do not open the object housings.
·If repairs are required, contact the manufacturer or a specialist dealer.
Load and damage to the surface
Rough or sharp-edged materials can particularly damage the underside of Capore® Basic objects and impair object
recognition.
·Do not place heavy items on top of the objects.
·Store objects only on smooth or soft surfaces.
·Do not use objects with a dirty underside or on dirty screens.

1. General
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 5 of 10 poc: SFi
1.2. Cleaning information
Capore® Basic objects usually do not need to be maintained. Nevertheless, it is recommended to clean the surfaces
regularly to avoid scratching the undersides of the Capore® Basic objects.
Clean the undersides of the Capore® Basic objects regularly before and during use to avoid scratching the screen
surface.
·Commercially available plastic cleaner is suitable for cleaning the surfaces.
·Apply the solution to a soft, lint-free cloth. Avoid coarse materials.
·Do not use microfibre cloths to clean the glass surfaces.
·Moisten the cloth and clean the Capore® Basic objects from all sides. Apply the liquid only to the cloth and never
directly to the object. This will prevent liquid from penetrating inside the object.
1.3. Transport information
Always transport your Capore® Basic objects adequately padded and protected against moisture. It is generally
recommended to use the original packaging.

2. Troubleshooting
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 6 of 10 poc: SFi
2. Troubleshooting
Do not open the housing of the Capore® Basic objects yourself.
If your Capore® Basic objects do not work as intended, contact Interactive Scape Hardware Support. You can reach
them on weekdays at [phone].
2.1. Manufacturer – Support
Interactive Scape GmbH
Wilhelmine-Gemberg-Weg 6
10179 Berlin
[phone]

3. Annex
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 7 of 10 poc: SFi
3. Annex
3.1. Technical drawings
3.1.1. Perspective

3. Annex
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 8 of 10 poc: SFi
3.1.2. Top view

3. Annex
—
Capore® Basic Technical specifications are subject
cb-010 to change without notice.
Operating manual Version 1.1 – Status: 12/2019
Page 9 of 10 poc: SFi
3.1.3. Right view

Interactive Scape GmbH
Wilhelmine-Gemberg-Weg 6, D-10179 Berlin
T [phone], F [phone]
www.interactive-scape.com, [e-mail]
