Intercel Smart SAM2W User manual

Smart SAM2W User Guide V1.2
I
Ver1.2
Smart SAM2W
User Guide

Smart SAM2W User Guide V1.2
II
Ver1.2
Revision History
Version
Modified By
Date
Description
1.0
18/04/2012
Initial version
1.1
28/11/2012
Updated to Smart SAM2W
1.2
09/10/2013
New Packaging Information

Smart SAM2W User Guide V1.2
1
Ver1.2
Contents
1Introduction..........................................................................................................................................................2
2Safety Precautions.............................................................................................................................................3
3Radio Frequency Exposure - SAR...................................................................................................................4
4WEEE Directive 2002/96/EC, Disposal Of Old Electronic Equipment .......................................................5
5Packaging............................................................................................................................................................6
5.1 Contents............................................................................................................................................................6
5.2 Packaging Box..................................................................................................................................................6
5.3 Production Label ..............................................................................................................................................7
6Functionality........................................................................................................................................................8
6.1 General..............................................................................................................................................................8
6.2 RJ45 Socket......................................................................................................................................................9
6.3 FME-Male 50Ω Antenna Connector ..............................................................................................................9
6.4 SIM Holder........................................................................................................................................................9
6.5 LED Status........................................................................................................................................................9
6.6 Data Cable.....................................................................................................................................................10
7Electrical Characteristics.................................................................................................................................11
7.1 Power Consumption ......................................................................................................................................11
7.2 RF Bands ........................................................................................................................................................11
7.3 Receive Sensitivity.........................................................................................................................................11
7.4 Conducted Transmit Power..........................................................................................................................11
7.5 Main Antenna Specifications........................................................................................................................12
7.6 Environmental Characteristics .....................................................................................................................12
8The AMR TCP/IP STACK ...............................................................................................................................13
8.1 Descriptions....................................................................................................................................................13
8.2 TCP/UDP/IP AT Commands.......................................................................................................................14
9Remote Escape Sequence.............................................................................................................................23
10 Specific Requirements.....................................................................................................................................24

Smart SAM2W User Guide V1.2
2
Ver1.2
1Introduction
The Smart SAM2W is a compact, light-weight, GSM/GPRS based modem. It is a quad-band
850/900/1800/1900MHz modem, providing GSM and GPRS connectivity.
The Smart SAM2W also provides Open-AT platform for different applications.
The Smart SAM2W is designed for both mobile and fixed M2M applications. It has an RJ45 socket for input
voltage and the serial RS232 signals, an FME-male for antenna connection, a SIM holder and an LED
indicator.
The Smart SAM2W is capable of sending/receiving SMS; Circuit switched data and Packet-switched data.
FME-Male antenna connector
SIM holder
LED indicator
RJ45 socket for input power and serial RS232
Mobile station engine SL6087
EU approval CE-0682
GCF-CC Version 3.27.1
A-tick

Smart SAM2W User Guide V1.2
3
Ver1.2
2Safety Precautions
The following safety precautions must be observed whenever the Smart SAM2W modem is in operation or in
service. Failure to comply with these precautions violates the safety standards of the design, manufacture
and intended use of the product
- Switch off the Smart SAM2W modem :
In hospitals or places where medical equipment may be in use.
In an aircraft
Refuelling points
Explosive areas
- Restricted use of the Smart SAM2W modem
Near any chemical plant
Near any fuel depot
Areas with mobile phone warning signs
Respect national regulations on the use of cellular devices.
The Smart SAM2W modem receives and transmits radio frequency energy while switched on, therefore
interference can occur if the Smart SAM2W is near TVs, radios, PCs or any inadequately shielded
equipment.

Smart SAM2W User Guide V1.2
4
Ver1.2
3Radio Frequency Exposure - SAR
The Smart SAM2W modem is a low-power transceiver, similar to a typical handheld GSM/GPRS/UMTS
mobile phone. When it is turned on, it will emit low-level radio frequency energy.
There are different guidelines and standards around the world that govern the permitted levels of radio
frequency exposure for general population. The levels include a safety margin to a human body.
The Specific Absorption Rate (SAR) is a measure of the rate at which radio frequency energy is absorbed by
the body when exposed to radio frequency electromagnetic field. The SAR value is determined at the highest
certified power level in the laboratory conditions, but the actual SAR level of the transceiver while operating
can be well below this value. This is because the transceiver is designed to use minimum power to connect
to the network.
The Smart SAM2W modem is approved to use in applications where the antenna is placed more than
21cm from the body.
For other applications, the integrator is responsible for the local SAR requirements.

Smart SAM2W User Guide V1.2
5
Ver1.2
4WEEE Directive 2002/96/EC, Disposal Of Old Electronic
Equipment
This symbol on the product indicates that this product shall not be treated as household waste.
It must be placed at an appropriate collection point for the recycling of electrical and electronic equipments.
By ensuring the correct disposal of this equipment, it will help the environment and human health. Recycling
will help to conserve natural resources.
The Smart SAM2W product is RoHS compliant

Smart SAM2W User Guide V1.2
6
Ver1.2
5Packaging
5.1 Contents
The Smart SAM2W package consists of:
- A Smart SAM2W Modem
- A Data Cable
- A Smart SAM2W Short Specification
- A Smart SAM2W User Guide
5.2 Packaging Box
The carton box dimensions are 230mm x 155mm x 70mm
The data cable is 2m long
The label size is 50mm x 33mm
A power supply is available on request. It is recommended that the Smart SAM2W is powered using a
12Vdc/1A power supply.
The antenna is also available on request. Please make sure the correct antenna is used to get optimised
performance from the Smart SAM2W.

Smart SAM2W User Guide V1.2
7
Ver1.2
5.3 Production Label
The production part number is located at the back of the Smart SAM2W, which includes:
- The product model
- The software version
- The hardware version
- The IMEI number
- The manufacturer
- The part number
Product Model: Smart SAM2W
Software : Version 1.2
Hardware : Version 1.2
IMEI
352679010 049570
Made by: Intercel Pty Ltd
Part number : ASSSMRTS2W
SAM2WAMR

Smart SAM2W User Guide V1.2
8
Ver1.2
6Functionality
6.1 General
The Smart SAM2W modem consists of an RJ45 socket for serial port and input power, an FME male
antenna connector and a SIM holder. The LED indicator, located next to the SIM holder, indicates the Smart
SAM2W operating status.
FME connector
The Smart SAM2W also contains the power assist circuitry. This PA circuitry is optionally loaded and
activated when the power supply does not have enough power to assist the Smart SAM2W when it is in a
CSD call or in a GPRS session. It also helps to send the last-gasp message back to the server when power
is cut off to the modem.
SL6087
ENGINE
(Supporting
Open-AT
platform)
Switching
Power
Supply
RS232
Serial Data
Interface
SIM Interface
RJ45
Socket
LED Indicator
The Smart SAM2W Functional Block Diagram
Power assist
(optional)

Smart SAM2W User Guide V1.2
9
Ver1.2
6.2 RJ45 Socket
Pin Signals Description
1 VIN Input Voltage 5Vdc - 32Vdc
2 DCD Data Carrier Detect
3 DTR Data Terminal Ready
4 GND Common Ground
5 RXD Serial Data out of the Smart SAM2W
6 TXD Serial Data into the Smart SAM2W
7 CTS Clear to Send
8 RTS Ready to Send
6.3 FME-Male 50Ω Antenna Connector
The FME male antenna connector is a 50Ω impedance antenna connector. The antenna used for the Smart
SAM2W must have 50Ω impedance.
6.4 SIM Holder
The SIM holder is designed to accommodate a mini-SIM card. The SIM card can either be 3V or 1V8 SIM. To
insert the SIM card, remove the door by sliding it back toward the end. Make sure the SIM card faces the
right way as indicated on the box. Voltage levels over this SIM interface complies with 3GPP standards
6.5 LED Status
The LED indication has the following status:
- LED on steady: No SIM card or no SIM PIN or Network search in progress.
- 200ms on/ 2sec off: Idle mode, registered to the GSM network.
- 200ms on/600ms off: CSD or PSD data transfer in progress.
- 100ms on/200ms off: The downloaded firmware is either not compatible or corrupted.
- LED is off permanently : No power

Smart SAM2W User Guide V1.2
10
Ver1.2
6.6 Data Cable
The data cable is 2m long. It consists of an RJ45 plug, a DB9-female connector and a 2-wire input power.
5 4 3 2 1
9 8 7 6
DB9 Signals RJ45 Description
1 DCD 2 Data Carrier Detect
2 RXD 5 Serial Data out of the Smart SAM2W
3 TXD 6 Serial Data into the Smart SAM2W
4 DTR 3 Not Used
5 GND 4 Common Ground
6 DSR
7 RTS 8 Ready to Send
8 CTS 7 Clear to Send
9 RI Not used
1 RED wire: Input voltage from 5Vdc to 32Vdc
4 BLACK wire: Power Ground

Smart SAM2W User Guide V1.2
11
Ver1.2
7Electrical Characteristics
7.1 Power Consumption
Network search 65mA @ 12V
Idle mode 40mA @ 12Vdc
Connected mode 90mA @ 12Vdc
GPRS PSD transfer 245mA @ 12Vdc
Peak current during the 577µs transmission pulse 500mA @ 12V
7.2 RF Bands
GSM850 Tx = 824MHz –849MHz Rx = 869MHz –894MHz
EGSM900 Tx = 880MHz - 915MHz, Rx = 925MHz - 960MHz
DCS1800 Tx = 1710MHz - 1785MHz, Rx = 1805MHz - 1880MHz
PCS1900 Tx = 1850MHz - 1910MHz, Rx = 1930MHz - 1990MHz
7.3 Receive Sensitivity
Band Typical Rx Sensitivity
(dBm)
GSM850 -109dBm
EGSM900 -109dBm
DCS1800 -108dBm
PCS1900 -108dBm
7.4 Conducted Transmit Power
Parameter Min Max
GSM850 & EGSM900 +5dBm +33dBm
DCS1800 & PSC1900 +0dBm +30dBm

Smart SAM2W User Guide V1.2
12
Ver1.2
7.5 Main Antenna Specifications
Max cable loss 0.5dBm
Impedance 50Ω
VSWR 1.5 : 1
The maximum antenna gain recommended for consideration against RF exposure and ERP/EIRP limits, is:
- In Cellular band : 5dBi
- In PCS band : 4dBi
7.6 Environmental Characteristics
Operating temperature -30°C to +70°C
Storage temperature -40°C to +85°C
Humidity 93% relative humidity (non-condensing)

Smart SAM2W User Guide V1.2
13
Ver1.2
8The AMR TCP/IP STACK
8.1 Descriptions
The AMR TCP/IP stack allows the Smart SAM2W modem to make/receive GSM data call and at the same
time enables the modem to act as a GPRS TCP server/client and UDP server/client. When powered up this
stack will automatically activate a GPSR connection then create 3 sockets; one TCP port in server mode for
data transfer, TCP port 11111 for remote AT Command and one UDP port for data transfer. The modem can
also create a TCP client to a remote TCP server if it is programmed to do so:
Server TCP Data: Socket connection allows transparent data to pass through from host computer to the
modem serial port and vice versa. This operation is similar to the GSM data communication.
Idle connection is disconnected after 5 minutes.
TCP Command: Socket (port 11111) connection allows a user from the host computer to send AT command
to the modem and receive its response. Idle connection is disconnected after 5 minutes.
UDP Data: Socket connection allows transparent data to pass through from host computer to the
modem serial port and vice versa. This operation is similar to the GSM data communication.
In server mode modem switches serial port from data mode to AT Command mode if there
is no data from remote for 2 minutes.
Client TCP Data: Socket connection allows transparent data to pass through from host computer to the
modem serial port and vice versa. This operation is similar to the GSM data communication.
Connection is permanent.
The software stack also allows remote sending of AT Commands over SMS and GSM data call. Firmware
download over the air can be done over GSM data call using 1K XModem protocol or over GPRS using File
Transfer Protocol.
GPRS connectivity is maintained by meaning of sending Ping. The modem is also set to reset daily at 11 pm
(time feature needs support from GSM/GPRS network provider).
The modem keeps a 250 event log in a cyclical buffer which is stored in flash memory. The events log can
be retrieved by means of an AT Command either locally or remotely

Smart SAM2W User Guide V1.2
14
Ver1.2
8.2 TCP/UDP/IP AT Commands
The TCP/UDP/IP stack provides some AT commands for setting up communication parameters, software
upgrade, checking status and more.
AT$SETGPRS
Use to set up the GPRS parameters required for GPRS connection. This command can be sent from serial
port, over SMS, GSM data call and TCP GPRS.
AT$SETGPRS=?
$SETGPRS: APN(100),Username(50),Password(50)
OK
AT$SETGPRS?
$SETGPRS: <ApnServ>,<ApnUn>,<ApnPw>
OK
AT$SETGPRS=<ApnServ>,<ApnUn>,<ApnPw>
OK
<ApnServ> : Access Point Name, maximum length allow = 100
<ApnUn> : Username, maximum length allow = 50
<ApnPw> : Password, maximum length allow = 50
AT$SETGPRS=”mach2”,”intercel”,”mach”
OK
AT$SETGPRS?
$SETGPRS: =”mach2”,”intercel”,”mach”
OK

Smart SAM2W User Guide V1.2
15
Ver1.2
AT$SETTCP
Use to setup parameters for TCP data socket. This command is for serial port entry only.
AT$SETTCP=?
$SETTCP: Port(1-65535), TimeOutTrigger(0-65535),Server(120)
OK
AT$SETTCP?
$SETFTP: <TCPPort>,<TimeOutTrigger>,<TCPServ>
OK
AT$SETTCP=<TCPPort>,<TimeOutTrigger>,<TCPServ>
<TCPPort> : From 1 to 65535, is port number for both local TCP server and remote TCP
server, default is10000.
<TimeOutTrigger>: This defines a time interval of no data activity in the serial data stream that is
used as the trigger to packetize and transmit the collected data. The time is entered in milliseconds
and between 0 and 65535 but only affective in multiples of 20, default is 100ms.
<TCPServ> : IP address of the remote server, default is 255.255.255.255.
AT$SETTCP=10000,100,”255.255.255.255”
OK

Smart SAM2W User Guide V1.2
16
Ver1.2
AT$SETUDP
Use to setup parameters for UDP data socket. This command is for serial port entry only.
AT$SETUDP=?
$SETUDP: Port(1-65535),TimeOutTrigger(0-65535),Server(120)
OK
AT$SETUDP?
$SETUDP: <UDPPort>,<TimeOutTrigger>,<UDPServ>
OK
AT$SETUDP=<UDPPort>,<TimeOutTrigger>,<UDPServ>
<UDPPort> : From 1 to 65535, is port number for both local UDP server and remote UDP server,
default is 20000.
<TimeOutTrigger>: This defines a time interval of no data activity in the serial data stream that is
used as the trigger to packetize and transmit the collected data. The time is entered in milliseconds
and between 0 and 65535 but only affective in multiples of 20, default is 100ms.
<UDPServ> : IP address of the remote server, default is 255.255.255.255.
AT$SETUDP=20000,100,”255.255.255.255”
OK
AT$SETPING
Use to set up Ping parameters. The software usea Ping to maintain GPRS connection. This command is for
serial port entry only.
AT$SETPING=?
$SETPING: PingIP(120),Interval(5-1440)
OK
AT$SETPING?
$SETPING: <PINGRemote>,<PINGPeriod>
OK
AT$SETPING=<PINGRemote>,<PINGPeriod>
<PINGRemote> : PING IP address, in xxx.xxx.xxx.xxx format.
<PINGPeriod> : PING period in minute, from 5 –1440, default is 1441 (more than 24 hour so no
PING, the modem will be reset every 24 hour instead).
AT$SETPING= “192.168.80.40”,60
OK
AT$TCPMODE
Set modem TCP mode. This command is for serial port entry only.

Smart SAM2W User Guide V1.2
17
Ver1.2
AT$TCPMODE=0
Modem does not make TCP connection to remote TCP server after connected to GPRS.
AT$TCPMODE=1
Modem makes TCP connection to remote TCP server after connected to GPRS.
Default is 0.
AT$TCPMODE?
$TCPMODE: 0
OK
AT$GSMMODE
Set modem operating mode. This command is for serial port entry only.
AT$GSMMODE=0
Modem available for both GSM and GPRS. It makes and maintains GPRS connectivity after power on.
AT$GSMMODE=1
Modem works in GSM mode only. This mode prevents modem from resetting if SIM is not setting up for
GPRS connectivity.
Default is 0.
AT$GSMMODE?
$GSMMODE: 0
OK

Smart SAM2W User Guide V1.2
18
Ver1.2
AT$SMSNUMBER
Set phone number to receive alarm SMS when modem looses power (for Super CAP hardware only), this
command is for serial port entry only.
AT$SMSNUMBER=”0418505361”
AT$SMSNUMBER?
$SMSNUMBER: 0418505361
OK
AT$SERIALMODE
Set modem serial mode. This command is for serial port entry only.
AT$SERIALMODE=0
Modem stays in AT Command mode when there is no TCP active connection, modem can response to UDP
data from remote but is not able to initiate an UDP data session to remote server.
AT$SERIALMODE=1
Modem go into online data mode after connected to GPRS, modem can initiate an UDP data session to
remote server.
Use sequence +++ to escape to AT Command mode and ATO to go back to data mode.
Default is 0.
AT$SERIALMODE?
$SERIALMODE: 0
OK
