Concord 4 Installation Guide
Content
Contact information 1
Description 1
Panel location 2
Power and wire length 2
Mounting the panel 3
Programming 4
Sensor group characteristics 7
Specifications 9
Regulatory information 9
Contactinformation
For contact information, see www.utcfireandsecurity.com
or www.interlogix.com.
For technical support, toll-free: 888.437.3287 in the US
including Alaska, Hawaii, Puerto Rico, and Canada.
Outside the tool-free area, contact your dealer.
© 2016 UTC Fire & Security Americas Corporation, Inc.
Interlogix is part of UTC Climate Controls & Security, a
unit of United Technologies Corporation.
All rights reserved.
Description
This is the Installation Guide for the following Concord 4
control panel models:
•600-1021-95RConcord4RF
•600-1022-95RConcordExpress V4
•600-1040ConcordCommercialV4
•600-1042ConcordHybrid
This manual provides information for installing a basic
UL Listed Fire and Security System. To modify or use for
other purposes, visit the UTC Fire & Security website for
additional instructions and training.
Table 1 below shows the standard panel capabilities.
Table 1:Panelcapabilities
Capabilities
Concord Expressv4
Concord 4/Concord
Commercialv4
Zones
32
96
Partitions
2
6
Bus devices
16
16
User codes
16
230
Table 2 below describes the basic panel (out-of-box)
hardware capabilities for all panels:
Table 2:Panelhardwarecapabilities
Power
Input for anAC step-down,plug-in style
transformer.
Auxiliary power
output
Output that supplies 9 to 14VDC withupto 1
amp for bus devices andhardwireddetectors,
suchas smoke and motion detectors.
Bus A and B
Input andoutput that provides communication
betweenbus devices andthepanel.
Siren driver
Output that candrivean 8-ohmload and provides
intrusion and fire alarm sounds for partition1 (6
watts maximum).
Twoonboard
outputs
Can beusedto activateothersignaling devices
basedon systemevents.Out1 is a 9 to14 VDC
sourceoutput,limited to 1.0 amp maximum. Out
2 is anopen-collector output,ratedup to 14 VDC,
300 mA maximum.
Microphone input
Input usedfor tw o-wayaudio whenusedin
conjunctionw iththeInterrogator 200 audio
verificationmodule.
Eight supervised
hardwiredzones
Inputs for various hardwireddetectors. Zone8
canbe setup in programming to accepttwo-wire
smoke detectors.It sources 9to14 VDC, 90mA
maximum.
Built-in RF
receiver
Allows useof upto96or 32 319.5MHz crystal
and/or SAWlearn mode w irelesssensors and
touchpads.

2 Concord4 Installation Guide
Phone line
connection
Allows paneltocommunicate w ithcentral
monitoring station and/or pagers.
Note: The total current sourced from all terminals cannot
exceed 1 amp.
Panellocation
Before permanently mounting the panel, use the
following guidelines to choose a mounting location.
•To helpreducewire runlengths andlabor,centrallylocate
the panelwithrelationto detection devices whenever
possible.
•Locate the panelwherethe temperaturewillnotexceed
120ºF (49ºC) or fall below32ºF (0ºC).
•To prevent wire runs from pickingup electricalnoise,
avoid runningwires parallel withelectricalwiringorfixtures
suchas fluorescentlighting.
•Mount the panelat a comfortableworkingheight.
•Leave atleast24 inches infront of the panelto openthe
cabinetdoorand access thepanel.
•Leave spaceto the leftand rightof the panelfor wiring,
phone jack, andmounting optionalmodules.
•Leave at least9 inches abovethe panelcabinetfor
antennas.
Powerandwirelength
The panel can supply up to 1 amp (1,000 mA) in full load
alarm condition for system devices connected to panel
terminals 4 (+12V), 7 and 8 (speaker terminals), 9
(OUT1), 11 (+12V), 24 (2W SMK ZONE 8), and
SnapCard terminals.
For 24-hour backup, the total standby current draw for all
devices connected to panel terminals 4 (+12V), 9
(OUT1), 11 (+12V), 24 (if configured for two-wire smoke
loop), and SnapCard terminals is limited to 90 mA
(during normal standby condition) using a 4.5 or 5.0 Ah
battery, or 190 mA (during normal standby condition)
using a 7.0 Ah battery.
The total system wire length allowed can vary depending
on devices powered by the panel, the wire length
between devices and the pane, and the combined wire
length of all devices.
Table 3 below describes the maximum wire length
allowed between compatible devices and the panel, and
the minimum and maximum current draw of each device.
Table 3:Wire lengthrequirements
Device
Max.wire
length to
panel
Standby
mA draw
Alarm mA
draw
SuperBus 2000 2x16LCD
alphanumeric touchpad
22 ga.: 300ft.
18 ga.: 750ft.
15 mA
90 mA
SuperBus 2000 ATP1000
alphanumeric touchpad
22 ga.: 300ft.
18 ga.: 750ft.
12 mA
110 mA
SuperBus 2000 ATP2100
alphanumeric touchpad
22 ga.: 300ft.
18 ga.: 750ft.
30 mA
165 mA
SuperBus 2000 ATP2600
alphanumeric touchpad
22 ga.: 300ft.
18 ga.: 750ft.
30 mA
165 mA
SuperBus 2000 GTS 50
22 ga.: 100ft.
18 ga.: 250ft.
270 mA
300 mA
SuperBus 2000 fixeddisplay
touchpad
22 ga.: 300ft.
18 ga.: 700ft.
11 mA
65 mA
SuperBus 2000 FTP 1000
fixeddisplay touchpad
22 ga.: 300ft.
18 ga.: 700ft.
12 mA
75 mA
SuperBus 2000 RF
transceiver
22 ga.: 1,000ft.
18 ga.: 2,500ft.
45 mA
55 mA
SuperBus 2000 RF receiver
1
22 ga.: 1,100ft.
18 ga.: 2,800ft.
35 mA
35 mA
SuperBus 2000 phone
interface/voicemodule
22 ga.: 40ft.
18 ga.: 120ft.
25 mA
600 mA
SuperBus 2000 voice-only
module
22 ga.: 40ft.
18 ga.: 120ft.
20 mA
300 mA
(jumper)
600 mA (no
jumper)
SuperBus 2000 2amp
power supply
N/A
No load
No load
4 input/2 output SnapCard
N/A
20 mA
185 mA 1
8Zhardwiredzone
expander SnapCard
N/A
38 mA
230 mA 1
4 output SnapCard
N/A
1 mA
130 mA 1
SuperBus 2000 8Z input
module
22 ga.: 1,800ft.
18 ga.: 4,000ft.
18 mA
35 mA
SuperBus 2000 4-relay
output module
22 ga.: 350ft.
18 ga.: 900ft.
12 mA
180 mA
SuperBus 2000 energy
saver module
22 ga.: 1,600ft.
18 ga.: 4,000ft.
20 mA
20 mA
SuperBus 2000 cellular
backupmodule
Standard
power 22ga.:
15 ft. 18ga.:
40 ft.High
power 22
ga.: 10 ft. 18
ga.: 30 ft.
90 mA
90 mA
1600 mA
1900 mA
SuperBus 2000 automation
module
22 ga.: 1,500ft.
18 ga.: 4,000ft.
30 mA
35 mA
SuperBus 2000 wireless
gateway-readykit
22 ga.: 40ft.
18 ga.: 90ft.
65 mA
1600 mA
Interrogator 200
22 ga.: 3,200ft.
18 ga.: 4,500ft.
10 mA
10 mA

Concord 4 Installation Guide 3
Device
Max.wire
length to
panel
Standby
mA draw
Alarm mA
draw
Interrogator AVM
22 ga.: 110ft.
18 ga.: 260ft.
45 mA
300 mA
Two-wiresmokedetectors
(429AT,429C, 429CT,
521B, 521BXT, 521NCSXT
22 ga.: 330ft.
18 ga.: 330ft.
70 uA
60 mA
Two-wiresmokedetectors
(systemsensor 2400,
2400TH)
22 ga.: 330ft.
18ga.: 330ft.
120 uA
80 mA
Hardw iredinterior siren(13-
949)
22 ga.: 750ft.
18 ga.: 1,500ft.
0 mA
85 mA
Piezo dynamic exterior siren
(13-060)
22 ga.: 750ft.
18 ga.: 1,500ft.
0 mA
150 mA
Speaker siren(60-528or
13-060)
18 ga.: 100ft.
0 mA
500 mA
1Maximum currentdraw for theSnapCards does notincludethe load
whichmay beapplied to their auxiliary DC supply.
Note: When installing SuperBus 2000 RF receiver
modules, the antenna tamper feature must be set to off.
Table 4 below describes the total system wire lengths
allowed for all SuperBus 2000 devices when installing
systems using unshielded or shielded cable. The
maximum wire length for individual devices is shown
instable below.
Table 4:Total system wirelengths
Wire type
Totalsystemwire
18-gauge,unshielded
4,000 ft.
18-gauge,shielded
3,000 ft.
22-gauge,unshielded
4,000 ft.
22-gauge,shielded
3,000 ft.
After determining panel location, run all necessary wires
to that location using the guidelines in Table.
Table 5:Device wirerequirements
Device
Wire requirements
AC pow er transformer
2-conductor,18-gauge,25ft.max.
Earth ground
Single conductor,16-gaugesolid,25ft.max.
Telephone (RJ-31X)
4-conductor
Detection devices
2- or 4-conductor,22-gauge,1,000ft.max.
2- or 4-conductor,18-gauge,2,500ft.max.
(basedon30 ohms max. loop resistance
including device)
Speakers
2-conductor,18-gauge,100ft.max.
Device
Wire requirements
SuperBus 2000
devices
4-conductor, 22- or 18-gauge
Interrogator 200 AVM
power andmicrophone
4-conductor,22-gauge,shielded
Two-wiresmoke
detectors
2-conductor,22-gauge,330ft.max.
2-conductor,18-gauge,830ft.max.
Mountingthepanel
Mount the panel to the wall or wall studs.
Caution: Make sure you are free of static electricity
whenever you work on the panel with the cover open. To
discharge any static, first touch the metal panel chassis,
and then stay in contact with the chassis when touching
the circuit board. We recommend using a grounding
strap.
To mount the panel:
1. Remove the panel door and remove the necessary
wiring knockouts. Be careful not to damage the
circuit board.
2. Feed all wires through wiring knockouts and place
the panel in position against the wall.
3. Level the panel and mark the top and bottom
mounting holes.
4. Install anchors where studs are not present.
5. Partially insert screws into the two top mounting hole
locations, then hang the panel on the two screws.
6. Recheck for level, insert the two lower screws, and
tighten all four mounting screws.
Figure 1 below shows the main component locations.
Figure 1:Panelcomponents
EPROM
Antennas
Mounting hole Mounting hole
Mounting holes
Snapcard
connector
Terminal strip
Programming
touchpad
header
Battery
terminals

4 Concord4 Installation Guide
Grounding the panel
For maximum protection from lightning strikes and
transients, connect the enclosure to earth ground. Use
16-gauge, solid copper wire from an earth grounded cold
water pipe clamp to the enclosure. For best results, we
recommend that you crimp a spade lug on the wire end
at the panel and secure the lug to the enclosure.
Antenna shrouds
Install a plastic antenna shroud (included with the panel)
over each antenna and snap them into the holes on top
of the enclosure (skipthis step for hybrid and
commercial systems).
Programming
For onsite system programming, you must have an
alphanumeric touchpad.
You must use an installer/dealer code (default 4321) to
enter program mode. You may place the system into
programming mode only when you disarm all partitions.
Note: If the system is powered up after the programming
touchpad is connected or if a bus command scan is
executed, the programming touchpad will be learned
(programmed) into the system and must later be
manually deleted.
To enter program mode:
1. Make sure you disarm the system in all partitions.
2. Press 8, 4321, 0, 0.
The display shows SYSTEM PROGRAMMING.
To enter program mode using a programming
touchpad:
1. Connect the red, black, green, and white wires from
the programming touchpad cable (60-791) to the
power and bus wires/terminals on an alphanumeric
touchpad, matching the +12V (red), Bus A (green),
Bus B (white), and GDN (black) on each.
2. Make sure the system is powered up and disarmed.
3. Connect the plug on the cable onto the panel
programming touchpad header.
4. Press 8, 4321, 0, 2.
The touchpad sounds one short beep.
5. Press * and verify that the display shows SERVICE
TOUCHPAD ACTIVE.
6. Press 8, 4321, 0, 0.
The display shows SYSTEM PROGRAMMING.
7. After programming is complete, disconnect the
touchpad from the panel header.
Touchpad programming options
In program mode, touchpad buttons let you navigate to
all installer programming menus for configuring the
system.
Table 6 below describes the touchpad button functions
in program mode.
Table 6:Touchpad programming functions
Button
Programmingfunction
#
Select menu item or data entry.
*
Deselectmenu item or dataentry (if pressed
before#).
A ()
B ()
Scroll throughavailable option at the current
menu tier.Scroll throughsensor textoptions
during sensor textprogramming.
C
Enter pauses whenprogrammingphone
numbers.
D
Delete certainprogramming settings.
0 to 9
Enter numeric values whereverneeded.
1 and 2
Select off (1) or on(2) wherever needed.
1 to 6
Press and hold to enter alphabetical characters A
throughF for accountnumbers.
7 and 9
Press and hold to enter * (7) or # (9) for phone
numbers.
Menu navigation
There are two basic tiers of programming menus, tier 1
and tier 2.
From the tier 1 System Programming menu, you can
access the following tier 2 programming menus:
•Security
•Phones
•Phoneoptions
•Timers
•Lightcontrols
•Touchpadoptions
•Reporting
•Sirenoptions
•Sensors
•Audio verification
•Accessorymodules
•Onboardoptions
•Macro keys

Concord 4 Installation Guide 5
Only when the display shows SYSTEM PROGRAMMING
can you advance to tier 2 programming menus.
Press B or # to advance forward through menus. Press
A or * to move backward through the menus.
Only when a specific menu is displayed can you
advance to those menu settings. For example, from the
SENSORS display, pressing # gives you access to
learning sensors, programming sensor text, deleting
sensors, and viewing/editing sensor programming.
To exit program mode:
1. Press * until the display shows SYSTEM
PROGRAMMING.
2. Press A or B until the display shows EXIT
PROGRAMMING READY.
3. Press # and the touchpad displays the time and
date.
Sensors menu
The Sensors menu gives you access to the following
settings:
•Learn sensors. Add (learn)hardwired zones,wireless
sensors,and wireless touchpads intopanelmemory.
•Sensor text. Namethe sensors andzones youhave
addedto the system.
•Delete sensors. Deletezones andsensorsfrom panel
memory.
•Edit sensors. View or changea sensorgrouporpartition
assignment.You canalsoidentifywhethera zone is
wireless orhardwired,whetheritis configuredas normally
closed(NC)or normallyopen(NO), and whetherthe zone
is a touchpad.
Table 7 below describes how to trip different types of
sensors to program (learn) them in the panel.
Table 7:Tripping sensors
Sensor
How to trip the sensor
Hardwiredzones
Start w iththezonein its normal state,and
then trip thezoneinto its alarm state.A
normally closeddoor, for example, should
be closedwhenyoubeginthelearn
sensors process.To tripthe zone,open
the door.
Wireless sensors
Follow the instructions includedwitheach
sensor.
Wireless door/w indow
sensors withexternal
contacts
Place theexternalcontactin the alarm
condition, andthen activatethe sensor
tamper switch.
Self-actuatedbells
Activatethetamper switch.
Sensor
How to trip the sensor
Handheld wireless
touchpads
Press the BYPASS button.
Key fobs *
Press and hold the lock and unlock
buttons together until thekey fob LED
flashes.
ELM key fobs *
Press and releasethe unlockbuttontwice
quickly, thenpress andhold until the LED
flashes threetimes.
Press and releasethe unlockbuttononce
quickly, thenpress andhold until the LED
flashes twotimes.
Press and hold the unlock buttonuntil the
LED flashes once.
* Key fobs havenot beeninvestigatedby UL for usein a UL Listed
installation.
Learn sensors
The default setting is “None”.
The panel comes with factory programmed onboard
hardwired zones. Install 2 kohm, end of line (EOL)
resistors on all unused factory sensors shown above and
hardwired zones. If you don’t want to install EOL
resistors, delete any unused zones from memory. See
Table on page 6 for onboard hardwired zone factory
programming. Sensors must be placed in a partition or
sensor group. To change the sensor group or partition
assignment after adding a sensor or zone, use the Edit
Sensors menu.
To add (learn) sensors into panel memory:
1. With the display showing SENSORS, press #.
The display shows LEARN SENSORS.
2. Press #.
The display shows SENSOR PTN 1.
3. Press # to select partition 1 or press 2, 3, 4, 5, or 6
and then press # to select the desired partition.
The display shows SENSOR GROUP 0.
4. Enter the sensor group and press #. (See Table for
a description of all sensor group characteristics.)
The display shows TRIP SENSOR nn, where nn is
the displayed (next available) sensor number.
5. To change the displayed sensor number, enter the
desired sensor number and press #.
The desired sensor number is displayed.
6. Withthe desired sensor number displayed, use the
guidelines in Table 6 to force the sensor or zone you

6 Concord4 Installation Guide
are adding (learning) into the panel memory to send
a signal to the panel.
7. To add another sensor to the same sensor group
and partition, repeat the process.
8. To add sensors to another sensor group or partition,
press * twice and repeat the process.
Table 8 below describes the factory default zone inputs.
Table 8:Zone factoryprogramming
Zone input
Group numberand description
1
10 - entry/exit
2
17 –instantinterior follower
3
13 –instantperimeter
4
13 –instantperimeter
5
13 –instantperimeter
6
13 –instantperimeter
7
13 –instantperimeter
8
13 –instantperimeter
If the panelmemory is cleared,all onboardhardwiredzonefactory
programming willbecleared.
Quick programming mode
Use the quick programming mode to program basic
system programming with a SuperBus 2000 fixed display
touchpad, SuperBus 2000 FTP 1000 touchpad, or any
SuperBus 2000 alphanumeric touchpad. The following
menus are accessible:
•Account number(allpartitions)
•SC phone1
•CS phone2
•CS phone3
•Learnsensors(limitedtoselectingsensornumber,sensor
group,and partitionassignment).An alphanumeric
touchpadis required forprogrammingsensortext in
standardprogrammingmode.
Use the A and B buttons to toggle across main menus
and use the # and * buttons to toggle up and down
through the submenus.
To enter quick programming mode:
1. Make sure the system is disarmed in all partitions.
2. Press 8, enter the installer/dealer code, and then
press 03.
The display shows ACCOUNT NUMBER.
3. Cycle through the menus as shown in Table 9
below.
Table 9:Quick programming menustructure
Accountnumber
Partition number 1 to 6
Accountnumber 00000
CS phone
CS phone1
CS phonenone
CS phone2
CS phonenone
CS phone3
CS phonenone
Learnsensors
Sensor partition number 1 to 6
Sensor group0
Trip sensornumber 1 to 96
End programming

Concord 4 Installation Guide 7
Sensor group characteristics
Table 10 below shows what the sensors on your Concord 4 system do. Every sensor is assigned to a group, and this
table specifies those groups and functions. Every device must be assigned to one of these groups.
Note: The “X” marks in the table represent characteristics present in a group.
Table 10:Sensorgroup characteristics
Number
Name
Application
Alarm
Delay
Restoral
Supervisor
y
CS
report
Chime
(level)
Active
(level)
00
Fixed panic
24-hour audible fixedemergency
buttons
Police
Instant
X
X
1, 2, 3
01
Portable
panic
24-houraudible portable emergency
buttons
Police
Instant
X
1, 2, 3
02
Fixed panic
24-hour silent fixed emergency
buttons
Silent
Instant
X
X
1, 2, 3
03
Portable
panic
24-hour silent portable emergency
buttons
Silent
Instant
X
1, 2, 3
04
Fixed
auxiliary
24- hour auxiliary sensor, suchas
pendant panic or holdup button
Auxiliary
Instant
X
X
1, 2, 3
05
Fixed
auxiliary
24-hour auxiliary emergency button,
sirenshutoff confirms CSreport
Auxiliary
Instant
X
X
1, 2, 3
06
Portable
auxiliary
24-hour portable auxiliary alert
button
Auxiliary
Instant
X
1, 2, 3
07
Portable
auxiliary
24-hour portable auxiliary button,
sirenshutoff confirms CSreport
Auxiliary
Instant
X
1, 2, 3
08
Special
intrusion
Special belongings, suchas gun
cabinets andw allsafes
Police
Instant
X
X
X
1, 2, 3
09
Special
intrusion
Special belongings, suchas gun
cabinets andw allsafes
Police
Standard
X
X
X
1, 2, 3
10
Entry/exit
delay
Entry and exitdoors that requirea
standarddelay time
Police
Standard
X
X
X
X
2, 3
11
Supplementary
Extended Delay
Garage doors andentrances that
requireextendeddelay time
1,5
Police
Extended
X
X
X
X
2, 3
12
Drivew ay gates andentrances that
require a twiceextendeddelay time
1,5
Police
Twice
extended
X
X
X
X
2, 3
13
Instant
perimeter
Exterior doors andw indows
Police
Instant
X
X
X
X
2, 3
14
Instant
interior
Interior doors (hardwired)
Police
Follower
X
X
X
2, 3
15
Instant
interior
Interior PIR motion sensors 1(RF
wireless)
Police
Follower
X
X
2, 3
16
Instant
interior
Interior doors (hardwired)
Police
Follower
X
X
X
3
17
Instant
interior
PIR motion sensors 1(RF wireless)
Police
Follower
X
X
3
18
Instant
interior
Instant interior cross-zone#PIR
motion sensors
1, 2
Police
Follower
X
X
3
Supplementary
Extended Delay

8 Concord4 Installation Guide
Number
Name
Application
Alarm
Delay
Restoral
Supervisor
y
CS
report
Chime
(level)
Active
(level)
19
Delayed
interior
Interior doors that initiate a delay
beforegoinginto alarm 1
Police
Interior
X
X
X
3
20
Delayed
interior
PIR motion sensors thatinitiate a
delay beforegoing into alarm 1
Police
Standard
X
X
3
21
Localinstant
interior
24-hour local alarm zoneprotecting
anythingthat opens and closes
Police
Instant
X
X
1, 2, 3
22
Local
delayed
interior
Same as group21, plus activation
initiates a delay beforegoinginto
alarm
Police
Standard
X
X
1, 2, 3
23
Localinstant
auxiliary
24-hour local alarm zoneprotecting
anythingthat opens and closes 3
Auxiliary
Instant
X
X
1, 2, 3
24
Localinstant
auxiliary
24-hour local alarm zoneprotecting
anythingthat opens and closes,
sirens shutoff atrestoral1
Auxiliary
Instant
X
X
1, 2, 3
25
Local
special
chime
Notify the user w hena door is
opened, soundsemit froma local
annunciator 1
Special
chime
Instant
X
1, 2, 3
26
Fire
24-hour fire,rate-of-riseheat,and
smoke sensors
Fire
Instant
X
X
X
1, 2, 3
27
Output
module
Hardwiredoutputmodule (HOM)
lamp controlor other customer
features 3
Silent
Instant
X
X
1, 2, 3
28
Output
module
HOM, PIR motion sensor,sound
sensor, or pressuremat 3
Silent
Instant
X
1, 2, 3
29
Auxiliary
Freezesensor
Auxiliary
Instant
X
X
X
1, 2, 3
32
Output
module
HOM, PIR motion sensor,sound
sensor, or pressuremat 3
Silent
Instant
1, 2, 3
33
Siren
Wireless sirensupervision
Silent
Instant
X
X
1, 2, 3
34
Gas
Carbon monoxide (CO) gas
detectors 3
Auxiliary
Instant
X
X
X
1, 2, 3
35
Localinstant
police (day
zone)
Localalarm levels 1 and 2, reportto
CS in level 3
Police
Instant
X
X
X (level 3
only)
1, 2, 3
38
Auxiliary
Water sensor 3
Auxiliary
Instant
X
X
X
1, 2, 3
1. This groupis not certifiedas aprimary protectioncircuit for UL-listedsystems andis forsupplementary useonly.
2. Sound instantpolice sirenif twoor more sensors aretrippedwithin4minutes. Otherwisesensorsarefollowerstodelayedsensors.If
AlarmVerificationis on,group18 functions like group17.
3. This grouphas notbeen investigatedby UL.
4. This groupis requiredfor UL-listed residentialfirealarm applications.
5. Does not satisfy Auto Stay Arming exit requirement.

Concord 4 Installation Guide 9
Specifications
Power requirements
Class 2, 16.5VAC,40 VA,60Hz (600-1023or
600-1024)
Rechargeablebattery:12 VDC, 4.5 or 5.0Ah
lead-acid (60-681) or 12 VDC, 7 Ah(60-680).
The battery w illlast 24 hours w ithnoACand
specifiedstand-by load.
Auxiliary power
output
1.0 A at 9 to 14VDC (12VDC typical)
Radio frequency
319.5 MHz
Nominal RF range
1,000 feet(305m) typicalopen air
Storagetemperature
-30to 140ºF(-34to 60ºC)
Operating
temperature
32 to 120ºF(0to 49ºC)
Maximum humidity
85%relative humidity, noncondensing
Dimensions (Hx W x
D)
14 x 12 x 3 in. (35.6 x 30.5 x 7.6 cm)
Regulatoryinformation
UL listed installations
This section describes the requirements for UL listed
installations.
Basic system:
•Controlpanel(600-1021-95R Concord4 RF,600-1022-
95RConcordExpress V4, 600-1040ConcordCommercial
V4, or 600-1042Concord4Hybrid).
•Standardclass 216.5VAC, 40 VA powertransformer22-
145or 22-156 (600-1023),22-156-CN,or22-145-CN
(600-1023-CN),orpowerlinecarrierclass 216.5 VAC, 40
VA powertransformer22-149(600-1024)or22-149-CN
(600-1024-CN).Youmustorderthese transformers
separatelyfrom UTC Fire & Security.
•Backupbattery 12 V 4.5 or 5.0 Ah (60-681)or12 V 7 AH
(60-680).
•SuperBus 2000fixed displaytouchpad(60-820),FTP
1000(600-1020),2x16 LCDtouchpad (60-746-01),ATP
1000(60-983),ATP 2100 (60-985),ATP 2600(60-984),
2x20 LCD touchpad(60-803),or 2x20 VFD touchpad (60-
804).
•Interior speakersiren (60-528),hardwired interiorsiren
(13-949),or speakersiren(13-060).
•Basicsystem butalso includeaSuperBus 2000 RF
receiver (60-764-95R-01)oraSuperBus transceiver(600-
1025-01-95R).
Household burglary alarm system unit (UL 1023)
Basic system plus the following:
•Hardwiredmagneticcontact(13-068or13-071)or
wireless learnmode door/windowsensor(60-362)
•Immediatebeepssettoon.
•UL 98options setto on.
•Receiver failuresetto on (if wireless devices areused).
•Siren verify set to on.
•Exit delaysetto 60 seconds.
•Quick exit setto off.
•Sirentimeoutsetto 4 minutes ormore.
•Entry delaysetto 45 seconds orless.
•RF TX timeoutsetto 24 hours (if system includes builtin
receiver or SuperBus 2000RFreceiver or SuperBus 2000
RF transceiverand wirelessburglarysensors).
•Extended delaysetto off.
•Sleeptimesetto off.
•Two trip error setto off.
•Alarm verify setto off.
•Disabletroublebeepssettooff.
Household fire warning system (UL 985)
Basic system plus the following:
•Wireless smokesensor60-506-319.5,60-848-02-95,or
TX-6010-01-1 learnedintosensorgroup26.
•Immediatebeepssettoon.
•UL 98options setto on.
•Receiver failure setto on (if wireless devices areused).
•Siren verify set to on.
•Sleeptimesetto off.
•Sirentimeoutsetto 4 minutes ormore.
•Two-trip errorset to off.
•Disabletroublebeepssettooff.
•RF TX timeoutsetto 4 hours (if system includes builtin
receiver or SuperBus 2000RFtransceiver and wireless
smokesensors).
UL 1023 and 985 24-hour backup
For 24-hour backup, the total current draw for all
connected devices is limited to 90 mA (during normal
standby conditions) using a 4.5 or 5.0 Ah battery, or 190
mA (during normal standby conditions) using a 7.0 Ah
battery.
SIA system requirements
SIA system requirements are the same as those
described for a UL-listed basic system. If multiple
annunciation is required, use additional touchpads. This
applies to model numbers 60-746-01, 60-803, 60-804,
60-820, 60-983, 60-984, 60-985, and 600-1020. UL
requirements take priority over SIA requirements.
Table 11 on page 10 describes programming
requirements to meet ANSI-SIA CP-01.

10 Concord4 Installation Guide
Table 11:SIA setting requirements
Function
Default setting
Requiredsetting
Exit extension
On
On
Duress code
Disabled
Disabled
Dialer abortdelay
30 seconds
15 to 45 seconds
Cancel message
On
On
Call w aitcancel
Disabled
On if reportingto
centralstationand
customer has call
waitingservice.
Entry delay
30 seconds
30 to 240seconds
Exit delay
60 seconds
45 to 184seconds
Swinger limit
1
1
Smoke verify
Off
On if smoke alarms
areprogrammed into
system.
Cross zone
Disabled
Enabled for zones
withhighprobability of
falsealarms
Table 12 below describes nonprogrammable (hard-
coded) system operation, as required to meet ANSI-SIA
CP-01 and is provided only for your reference.
Table 12:ANSI-SIA CP-01requirements
Function
Operation
SIA falsealarm
Enabled
Autostay arming
Enabled
Disarm duringentry delay
Enter code only (or 1 + CODE)
Cancel alarm
Enter code only (or 1 + CODE).
Abortannunciation
Enabled
Exit error
Enabled
Entry/exitprogress annunciation
Enabled
Notes:
1. Auto Stay Arming is attached to "Standard" entry/exit
delays. (Please refer to table 10,"delay" column).
Commercial burglary alarm system unit (UL 1610)
Basic system using control panel 600-1040, SuperBus
2000 RF transceiver module (600-1025-01-95R), plus
the following:
•Hardwiredmagneticcontact(13-068or13-071)or
wireless learnmode door/windowsensor(60-499).
•SAW PIR sensor(60-639-95R),crystalPIR sensor(60-
703-95R),or DS924iPIR sensor(60-511-01-95).
•UL approvedbell/housing,suchas Ademco#AB12Mor
equivalent.
•Immediatebeepssettoon.
•UL 98options setto on.
•Receiver failuresetto on (if wireless devices areused).
•RF TX timeoutsetto 4 hours.
•24-hourtampersetto on.
•System tampersetto on.
•Automatic phonetestsetto on.
•Phonetext frequencysetto 1.
•Next phone testset to 1.
•Siren verify set to on.
•AC failuresetto on.
•Exit delayset to 120 seconds orless.
•Quick exit setto off.
•Two-trip errorset to off.
•Alarm verify setto off.
•Disabletroublebeepssettooff.
•Phonenumbermustbeprogrammed.
•Highlevel reports setto on.
•Lowlevel reports setto on.
•Communicationfailuresettoon.
•Extended delaysetto off.
•Sleeptimesetto off.
•Sirentimeoutsetto 4 minutes ormore.
UL 1610 24-hour backup
Same as UL 1023 and 985.
UL 1635 digital alarm communicator system
For UL 1635 installations, entry delay plus dialer abort
delay must not exceed 60 seconds. Same as UL 1023,
985, and 1610 plus:
•AC failuresetto on.
•Phonenumbermustbeprogrammed.
•LowCPU battery setto on.
•Next phone testset to 1.
•Phonetest frequencysetto 1.
•Highlevel reports setto on.
•Lowlevel reports setto on.
•Communicationfailuresettoon.
•RF TX timeoutsetto 4 hours.
Central station reporting
The panel has been tested with the following central
station receivers using SIA and Contact ID reporting
formats:
•CS-5000centralstationreceiver
•Sur-Gard centralstationreceiver with models SG-DRL2A
andSG-CPM2
•OsborneHoffmancentralstationreceiver
2. You may use the silent arming feature to suppress
arming level and exit beeps for the current arming
period. Refer to the Concord 4 user manual for more
information on silent arming.
1
2

Concord 4 Installation Guide 11
Note: The installer must verify the compatibility between
this panel and the central station receivers being used.
UL Canada listed installations
This section describes the requirements for CUL (UL
Canada) listed installations.
Residential burglary alarm system unit (ULC subject
C1023-1974)
Basic system as described for UL 1023 listed
installations plus:
•Hardwiredmagneticcontact(13-068or13-071)or
wireless learnmode door/windowsensor(60-362)
•Sirentimeoutsetto 5 minutes ormore
Residential fire warning system control unit (ULC-
S545-M89)
Basic system as described for UL 985 listed installations
plus:
•Hardwiredsmoke detector:System sensormodels 2400
or 2400TH learnedintosensorgroup26,or ESL models
429AT, 429CT, 521B,521BXT, 521NCSXT, 711U,711UT,
721U,721UT, TS7-2, or TS7-2T learnedintosensorgroup
26.
•Wireless smokesensor60-319.560-848-02-95,TX-6010-
01-1learnedintosensorgroup26.
•Sirentimeoutsetto 5 minutes ormore.
•RF TX timeoutsetto 4 hours (if system includes SuperBus
2000RF transceiverand wireless smoke sensors).
•Immediatetroublebeepssettoon.
Note: For 24-hour backup, external power drain is
limited to 90 mA (during normal standby condition) using
a 4.5 or 5.0 Ah battery, or 190 mA continuous using a
7.0 Ah battery.
California State Fire Marshall listed installations
Same as Household Fire Warning System (UL 985) plus:
•Smokeverify mustbe setto off.
FCC compliance
Changes or modifications not expressly approved by
UTC Fire & Security can void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
residential environment. This equipment generates,
uses, and can radiate radio frequency energy and, of not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following:
•Reorientor relocatethe receivingantenna.
•Increase theseparationbetweenthe equipmentand
receiver.
•Connectthe affected equipmentandthe panelreceiver to
separateoutlets,on different branchcircuits.
•Consultthedealeror anexperiencedradio/TV technician
for help.
Part 68. This equipment complies with Part 68 of the
FCC rules. Located on this equipment is a label that
contains, among other information, the FCC registration
number and the ringer equivalence number (REN) for
this equipment. If requested, this information must be
provided to the telephone company.
FCC Part 68 registration number: US: B4ZAL02B55910.
