SLEIPNER MOTOR AS SIDE-POWER PJC-322 User manual

Keep this
manual onboard !
Installation and user's manual
GB
NInstallasjons og brukermanual
Made in Norway
©Sleipner Motor AS 2010
SLEIPNER MOTOR AS
P.O. Box 519
N-1612 Fredrikstad
Norway
Tel: [phone]
Fax: [phone]
www.side-power.com
[e-mail]
PJC-322/321
S-link
Control Panel
SIDE-POWER
Thruster Systems

2PJC-212 1.0.0- 2010
PJC-322 / 321
Control panel with S-link™CAN-bus connection
Product features
• ForproportionalthrustercontrolwiththenewS-LinkcontrolledHydraulicThrusters
• Back-litLCDdisplaywithinstantfeedback
 - Systemstatus
 - Amountofthrust&directionofthrust
 - Oiltemperature&pressure
• Interactivemulti-languagemenus
• CAN-Buscommunicationwiththrustersandaccessories
• Plug&playcables,waterproofandcompactconnectors
• Diagnosticsviapanel
• Connectorforexternal“buzzer”/loudaudiblealarms
DISPLAY IN NORMAL USE:
1 hydraulic tank
OilTemperature
Thrustpower
anddirection
2 hydraulic tanks
Buttons/Indicationsonscreen-lefttoright:
ON/OFF-DAYTIME/NIGHTBacklightmode-EMERGENCYSTOP-SETTINGSMENU
OilTemperature,
PortTank
OilTemperature,
StarboardTank

3
PJC-212 1.0.0- 2010
DISPLAY WARNINGS & ALARMS:
FILTER MONITORING WARNINGS (IF SENSORS ARE INSTALLED)
PRESSUREFILTER:
Pressureltersymbol(upperright)willblinkwhenlterchangeisdue.Inaddition
redLEDsonbothsidesofthepanelwillblinkandtheexternalbuzzerisactivated.
RETURNFILTER:
Returnltersymbol(lowerright)willblinkwhenthelterneedstobereplaced.
InadditionredLEDsonbothsidesofthepanelwillblinkandtheexternalbuzzeris
activated.
Theexternalbuzzercanbemutedbypressingthebuttonundertheloud-
speakersymbol.Warningswillberesetwhenthelterarereplaced.
Thethrusterscanberunwhilethewarningsisdisplayed.
(Filterwarningswillnotbeshownonsystemswithtwooiltanks)
ALARMS (Systems with one oil tank)
OILLEVEL:
Oillevelsymbol(upperleft)willblinkwhenoillevelislow.InadditionredLEDson
bothsidesofthepanelwillblinkandtheexternalbuzzerisactivated.
ThealarmwillberesetautomaticallywhentheoillevelisOK

OILTEMPERATURE:
Oiltemperaturesymbol(lowerleft)willblinkwhentemperatureisabove75oC.In
additionredLEDsonbothsidesofthepanelwillblinkandtheexternalbuzzerisacti-
vated.Thealarmwillberesetautomaticallywhentemperaturegoesbelow65oC
Thethrusterscanberunwhentheoilalarmsareactive.
COMMUNICATIONERROR:
Ifthereisacommunicationerrorbetweenthepanelandthesystemcontrolunit
locatedontheoiltank,thecommerrorsymbolwillbeshownonthelowerleftsideof
thepanel
Theexternalbuzzercanbemutedbypressingthebuttonundertheloud-
speakersymbol.
ALARMS (Systems with two oil tanks)
OILLEVEL:
Oillevelsymbol(upperleft/right)willblinkwhenoillevelislow.InadditionredLEDs
onbothsidesofthepanelwillblinkandtheexternalbuzzerisactivated.
ThealarmwillberesetautomaticallywhentheoillevelisOK

OILTEMPERATURE:
Oiltemperaturesymbol(lowerleft/right)willblinkwhentemperatureisabove75oC.
InadditionredLEDsonbothsidesofthepanelwillblinkandtheexternalbuzzeris
activated.Thealarmwillberesetautomaticallywhentemperaturegoesbelow65oC.
Thethrusterscanberunwhentheoilalarmsareactive.
COMMUNICATIONERROR:
Ifthereisacommunicationerrorbetweenthepanelandthesystemcontrolunit
locatedontheoiltank,thecommerrorsymbolwillbeshownonthelowerleft/right
sideofthepanel
Symbolsonleftsideindicatesporttank,symbolsonrightindicatesstarboardtank.
Theexternalbuzzercanbemutedbypressingthebuttonundertheloud-
speakersymbol.

4PJC-212 1.0.0- 2010
MENU SYSTEM:
Access menu system by pressing menu button
EMERGENCY STOP:
WhentheSTOPbuttonispressed,thehydraulicdumpvalvewillactivateandthe
thrusterswillstop.Onsystemswithtwooiltanks,dumpvalvesonbothtankswill
activateandallthrusterswillstop.
TheEMERGENCYSTOPACTIVATEDsybolwillbeshownonthedisplay.Inadditionred
LEDsonbothsidesofthepanelwillblinkandtheexternalbuzzerisactivated.
NB: FOR EMERGENCY STOP ONLY!
PressSTOPagaintoreactivatethehydraulicsystem.
Theexternalbuzzercanbemutedbypressingthebuttonundertheloud-
speakersymbol.
SETTINGS
The menu system contains of 5 settings:
1 - Cooling Pump
2 - Pump Settings
3 - Language
4 - Display Settings
5 - Automatic OFF time
Select settings
Ends settings
Chooses function
1/5 Cooling Pump
Thecoolingpumpcanbesetto“alwaysON”or“Automatic”.
Whentheoption“Automatic”isselected,thecoolingpumpwillstartwhenoiltem-
peratureexceeds50oCandstopwhentheoiltemperaturegoesbelow40oC.
Onsystemswithtwooiltanks,thissettingwillapplytobothtanks.
2/5 Pump Settings
Use tochoosebetweenPump1orPump2andselectbypressing .
Whenapumpischoosen,switchbetweenavailablesettingswith.
Usetosavesettings.
PUMP1(PTO-mounted):PumpcanonlybesettoOFForON
PUMP2(PTO-mounted):PumpcanbesettoONorAUTO
Whenpump2issettoAUTOandanSPSstabilizerisactive,thepumpwillstart
whenoilpressuregoesbelow80Barandrunfor15minutesorwhenathrusteris
running.
WhenanSPSStabilizerisnotactive,Pump2willalwaysrun.AUTOisusedwhen
theSPSstabilizerisinstalledtosavefuel/energywhilethestabilizersystemisrun-
ning.Onsystemswithtwooiltanks,thesettingswillapplyforbothtanks.
NB: “Pump 2: AUTO” must only be used on PHC 024 with rmware v.1.008
or newer!

5
PJC-212 1.0.0- 2010
3/5 Language
ChoosebetweenEnglish,Norwegian,German,French,SpanishorItalian.
Thesettingwillnotaffectotherpanelsinthesystem.
4/5 Display settings
SetcontrastandbacklightlevelforDaytime/Nightmodes
Settingswillnotaffectotherpanelsinthesystem.
Presstostartadjustment-Press+or-toadjustcontrastorbacklight.
Usetoswitchbetweendaytimeornightsettings.
Endsettingbypressing
Adjustmentswillautomaticallyendafter3secondsofinactivity.
5/5 Automatic OFF time
SettimefromlastactivitytoPanelautomaticallyturnsoff.
Thetimecanbesetat5minutesinterval,rangingfrom5to60minutes-orbe
disabled.When“Disabled”isselected,thepanelwillneverbeturnedoffauto-
matically.
Settingswillnotaffectotherpanelsinthesystem.
Presstoadjusttimein5minutesintervals.
Endsettingbypressing
Storesettingsbypressing


6PJC-212 1.0.0- 2010
SERVICE MENU (Systems with one oil tank)
Access SERVICE MENU by pressing MENU button and hold it for 5 Seconds
Showsoilpressureandtemperatureinthehydraulictankaswellastheserial
numberofthepanel.
Thrusterscanbeoperatedwhilethisdisplayisshown.
ExitServiceMenubypressing
SERVICE MENU (Systems with two oil tanks)
Showsoilpressureandtemperatureinbothhydraulictanksaswellastheserial
numberofthepanel.
Thrusterscanbeoperatedwhilethisdisplayisshown.
ExitServiceMenubypressing
TECHNICAL SPECIFICATIONS,
LCD DISPLAY:
IP67
Lowtempfunctionality(-40oC)
Mountingbracket
Alarmoutputmaxload200mA
Inputvoltage9-31V
Maxcurrentconsumption110mA

7
PJC-212 1.0.0- 2010
