This quick reference guide explains how to use Fast Setup to configure the Model
200 Controller.
About Fast Setup
Use Fast Setup to configure the Model 200 Controller quickly so you can
•demonstrate the controller.
•verify your network environment is functioning.
•learn about the controller and its graphical user interface (GUI) before
using Advanced Setup.
•do preliminary configuration for your data collection network.
Fast Setup uses default values for many of the configuration parameters and
it only prompts you to enter a few required parameters.
When you configure the controller in Fast Setup, you set up a host
connection, define your Intermec equipment, and set up the routing for data
to the correct destination.
Network Adapter Cards
Depending on the upline network cards in your controller, you can connect
the controller to
•any TCP/IP host on an Ethernet or token ring network that supports
Telnet.
•any SNA host on a token ring, twinaxial, coaxial, or SDLC network that
supports APPC and 5250 or 3270 terminal connections.
Note: You can also set up VT, ANSI, 3270, and 5250 terminal sessions, but you
can only start these terminal sessions on your controller. Fast Setup does not let
you configure screen mapping.
Depending on the downline cards in your controller, you can connect the
controller to
•Intermec’s 900 MHz RF network.
•Intermec’s 2.4 GHz RF network (UDP Plus) through access points
connected to the Ethernet network.

Fast Setup Quick Reference Guide
6
The controller also has two serial ports (COM1 and COM2) that let you
connect external Intermec controllers for CrossBar™ network support, a
9180 Network Controller, an uninterruptable power supply, or an external
modem.
Using Online Help
The Model 200 Controller includes online help that provides descriptions of
the toolbars, dialog boxes, and options. Help also includes step-by-step
procedures and some background information.
To get help
•Choose the Help button.
The Help window opens and displays the topic for the toolbar or dialog box
you were using. If you requested Help from the main menu, the Getting
Started topic appears. You can resize and move your Help window to see
more of a topic at one time or to see more of the configuration window.
Colored or underlined text indicates that you can jump to topics.
To jump to another help topic
•Double-click the topic name. Or, press Tab until the topic is highlighted,
and then press Enter.
To use the help buttons
•Choose Previous or press Esc to jump to the previous topic.
•Choose Search to search for Help on a specific word or phrase.
•Choose Index to look up a topic in the Index.
•Choose Contents to look up a topic in the Contents.

Fast Setup Quick Reference Guide
7
Connecting the Controller to Your Data Collection Network
Ethernet
RS- 485
RS-232
RS-232
Model 200
Controller
J2010
9445
JG2020 JG2050
J2050
9189
JR2020 3400
900 MHz
2.4 GHz
0200-024
CrossBar
3400
Host
9181
T2425
9154
Access Point
