Intermec CK60 Ethernet Multidock User manual

CK60 Mobile
Computer with
Windows Mobile
User's Manual

ii CK60 Mobile Computer with Windows Mobile User’s Manual
Intermec Technologies Corporation
Worldwide Headquarters
6001 36th Ave.W.
Everett, WA 98203
U.S.A.
www.intermec.com
The information contained herein is provided solely for the purpose of allowing customers to operate
and service Intermec-manufactured equipment and is not to be released, reproduced, or used for any
other purpose without written permission of Intermec Technologies Corporation.
Information and specifications contained in this document are subject to change without prior notice
and do not represent a commitment on the part of Intermec Technologies Corporation.
© 2005-2006 by Intermec Technologies Corporation. All rights reserved.
The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar,
dcBrowser, Duratherm, EasyADC, EasyCoder, EasySet, Fingerprint, i-gistics, INCA (under license),
Intellitag, Intellitag Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower,
Sabre, ScanPlus, ShopScan, Smart Mobile Computing, TE 2000, Trakker Antares, and Vista Powered
are either trademarks or registered trademarks of Intermec Technologies Corporation.
There are U.S. and foreign patents as well as U.S. and foreign patent applications pending.
Wi-Fi is a registered certification mark of the Wi-Fi Alliance.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in
the United States and/or other countries.
Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.
This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.
(www.openssl.org).
This product includes cryptographic software written by Eric Young (EA[email protected]).
This product uses Regex++, Index software during its operational phases. The owner of Regex++ has
granted use of the software to anyone provided such use is accompanied by the following copyright
and permission notice:
Regex++, Index. (Version 3.31, 16th Dec 2001)
Copyright © 1998-2001 Dr John Maddock
Permission to use, copy, modify, distribute and sell this software and its documentation for any pur-
pose is hereby granted without fee, provided that the above copyright notice appear in all copies and
that both that copyright notice and this permission notice appear in supporting documentation. Dr
John Maddock makes no representations about the suitability of this software for any purpose. It is
provided "as is" without express or implied warranty.

CK60 Mobile Computer with Windows Mobile User’s Manual iii
Document Change Record
This page records changes to this document. The document was originally
released as version 001.
Version
Number Date Description of Change
002 12/2006 Added more troubleshooting information, RoHS model
numbers, refined the installation procedure, and updated
802.11 information to include the “A” functionality.

iv CK60 Mobile Computer with Windows Mobile User’s Manual

Contents
CK60 Handheld Computer with Windows Mobile User’s Manual v
Contents
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Global Services and Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Who Should Read This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Patent Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
1 Using the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introducing the CK60 Mobile Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Learning Software Build Versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Resetting Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preferred Reset Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Secondary Reset Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Performing a Clean Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Scanning Bar Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Reading Distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Scanning with the 2D Area Imager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Supported Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the Ambient Light Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Changing and Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maximizing Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Checking the Battery Status Via LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Checking the Battery Status Using the Power Applet . . . . . . . . . . . . . . . . . . . . . . 14
Adjusting the Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Using the Intermec Settings Applet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Using the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
32-Key Large Numeric Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
58-Key Full Alphanumeric Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the Color-Coded Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Capitalizing All Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using the Power Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Turning on the Keypad Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Using the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Using the Secure Digital Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Contents
vi CK60 Handheld Computer with Windows Mobile User’s Manual
Using Software Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
SmartSystems Foundation Console (www.intermec.com/SmartSystems) . . . . . . . 19
SmartSystems Platform Bundles (SSPB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Intermec Resource Kits (www.intermec.com/IDL) . . . . . . . . . . . . . . . . . . . . . . . . 20
Using the Speakers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using the Status Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using the Stylus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting the Vibrate Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting the CK60 to Vibrate Using the Volume Control . . . . . . . . . . . . . . . . . . . 22
Setting the Vibrate Mode Using Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting the Vibrate Mode Using Sounds & Notifications . . . . . . . . . . . . . . . . . . . 24
Physical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Accessories for the CK60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2 Windows Mobile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Software Builds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Where to Find Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Basic Skills. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Today Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Navigation Bar and Command Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Pop-up Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Notifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Entering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Typing With the Onscreen Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using Block Recognizer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using Letter Recognizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using Transcriber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Selecting Typed Text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Writing on the Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Selecting the Writing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Converting Writing to Text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Drawing on the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Recording a Message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Using My Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Finding and Organizing Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Customizing Your CK60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Microsoft ActiveSync. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Contents
CK60 Handheld Computer with Windows Mobile User’s Manual vii
Microsoft Pocket Outlook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Calendar: Scheduling Appointments and Meetings. . . . . . . . . . . . . . . . . . . . . . . . 47
Synchronizing Calendar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Why Use Categories in the Calendar? . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
What’s an All Day Event? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
What’s a Recurrence Pattern? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Viewing Appointments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Creating or Changing an Appointment . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Adding a Note to an Appointment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Sending a Meeting Request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Changing Calendar Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Contacts: Tracking Friends and Colleagues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Synchronizing Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Viewing Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Adding a Note to a Contact. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Finding a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Tasks: Keeping a To Do List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Notes: Capturing Thoughts and Ideas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Messaging: Sending and Receiving E-mail Messages . . . . . . . . . . . . . . . . . . . . . . . 64
Synchronizing E-mail Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Managing E-mail Messages and Folders. . . . . . . . . . . . . . . . . . . . . . . . . . 65
Connecting to a Mail Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Composing and Sending Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Companion Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Word Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Creating a Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Typing Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Writing Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Synchronizing Word Mobile Documents . . . . . . . . . . . . . . . . . . . . . . . . 70
Excel Mobile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Creating a Workbook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Tips for Working in Excel Mobile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
PowerPoint Mobile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Windows Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Internet Explorer Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Mobile Favorites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Favorite Links. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Mobile Favorites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Using Internet Explorer Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
3 Configuring the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Developing Applications for the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Packaging Applications for the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Installing Applications on the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Using Microsoft ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Using a Storage Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Using Wavelink Avalanche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Using the SmartSystems Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Contents
viii CK60 Handheld Computer with Windows Mobile User’s Manual
Launching Your Application Automatically . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
PreShell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
PostShell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
RunAutoRun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
AutoExec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
AutoRun. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
AutoCopy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
AutoReg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
AutoCab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Customizing How Applications Load on the CK60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Configuring CK60 Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Configuring with the Setup Assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Configuring the Computer With Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . 92
Synchronizing the Computer System Time with a Time Server . . . . . . . . . . . . . . 93
Configuring the Computer through the Network. . . . . . . . . . . . . . . . . . . . . . . . . 93
Configuring the Computer in a TCP/IP Direct Connect Network . . . . . 93
Configuring the Computer in a UDP Plus Network . . . . . . . . . . . . . . . . 94
Reprogramming the CK60 Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Registry Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Programming the Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Alphanumeric Scan Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Numeric Scan Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Configuring the SF51 Cordless Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Imager Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Enabling Bluetooth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Creating an SF51 Connection Label. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Viewing SF51 Information from Your Computer. . . . . . . . . . . . . . . . . . . . . . . . 100
Using Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
4 Maintaining the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Upgrading the Operating System on Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Using a Secure Digital Card to Upgrade the Computer . . . . . . . . . . . . . . . . . . . 105
Upgrading Both Operating System and PSM Files . . . . . . . . . . . . . . . . 105
Upgrading the Operating System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Upgrading the PSM Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Using the SmartSystems Console to Upgrade the Computer . . . . . . . . . . . . . . . 107
Troubleshooting Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Cleaning the Scanner Window and Computer Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Contents
CK60 Handheld Computer with Windows Mobile User’s Manual ix
5 Network Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Personal Area Networks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
About the Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Wireless Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Bluetooth Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Configuring Bluetooth Using Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . . . 124
Connecting with Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Local Area Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Configuring Serial Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Configuring 802.11a/b/g Radio Communications . . . . . . . . . . . . . . . . . . . . . . . 128
Configuring the Network Parameters for a TCP/IP Network . . . . . . . . 129
Configuring the Network Parameters for a UDP Plus Network. . . . . . . 129
Controlling the 802.11 Radio Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Configuring Ethernet Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
AutoIP/DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Wide Area Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Remote Access (Modems) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Connecting to an Internet Service Provider . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Connecting to Work. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Creating a VPN Server Connection to Work . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Ending a Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
iConnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Ethernet Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
No Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Wireless 802.11b Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Testing Your Network Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Configuring Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Choosing Between Microsoft and Funk Security . . . . . . . . . . . . . . . . . . . . . . . . 142
Configuring Funk Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Configuring Microsoft Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Loading Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
SmartSystems™ Foundation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
I Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Contents
x CK60 Handheld Computer with Windows Mobile User’s Manual

Before You Begin
CK60 Mobile Computer with Windows Mobile User’s Manual xi
Before You Begin
This section provides you with safety information, technical support
information, and sources for additional product information.
Safety Information
Your safety is extremely important. Read and follow all warnings and
cautions in this document before handling and operating Intermec
equipment. You can be seriously injured, and equipment and data can be
damaged if you do not follow the safety warnings and cautions.
This section explains how to identify and understand dangers, warnings,
cautions, and notes that are in this document.
Global Services and Support
Warranty Information
To understand the warranty for your Intermec product, visit the Intermec
web site at www.intermec.com and click Service & Support. The
Intermec Global Sales & Service page appears. From the Service & Support
menu, move your pointer over Support, and then click Warranty.
Disclaimer of warranties: The sample code included in this document is
presented for reference only. The code does not necessarily represent
complete, tested programs. The code is provided “as is with all faults.” All
warranties are expressly disclaimed, including the implied warranties of
merchantability and fitness for a particular purpose.
Web Support
Visit the Intermec web site at www.intermec.com to download our current
manuals (in PDF). To order printed versions of the Intermec manuals,
contact your local Intermec representative or distributor.
Visit the Intermec technical knowledge base (Knowledge Central) at
intermec.custhelp.com to review technical information or to request
technical support for your Intermec product.
A warning alerts you of an operating procedure, practice, condition, or
statement that must be strictly observed to avoid death or serious injury
to the persons working on the equipment.
A caution alerts you to an operating procedure, practice, condition, or
statement that must be strictly observed to prevent equipment damage
or destruction, or corruption or loss of data.
Note: Notes either provide extra information about a topic or contain
special instructions for handling a particular condition or set of
circumstances.

Before You Begin
xii CK60 Mobile Computer with Windows Mobile User’s Manual
Telephone Support
These services are available from Intermec Technologies Corporation.
Outside the U.S.A. and Canada, contact your local Intermec representative.
To search for your local representative, from the Intermec web site, click
Contact.
Who Should Read This Manual
This document is written for the person who is responsible for installing,
configuring, and maintaining the CK60 Mobile Computer.
This document provides you with information about the features of the
CK60, and how to install, configure, operate, maintain, and troubleshoot.
Before you work with the CK60, you should be familiar with your network
and general networking terms, such as IP address.
Related Documents
This table contains a list of related Intermec documents and part numbers.
Service Description
In the U.S.A. and Canada,
call 1-800-755-5505 and
choose this option
Order Intermec
products
• Place an order.
• Ask about an existing order.
1 and then choose 2
Order Intermec media Order printer labels and ribbons. 1 and then choose 1
Order spare parts Order spare parts 1 or 2 and then choose 4
Technical Support Talk to technical support about
your Intermec product.
2 and then choose 2
Service • Get a return authorization
number for authorized service
center repair.
• Request an on-site repair
technician.
2 and then choose 1
Service contracts •Askaboutanexisting
contract.
•Renewacontract.
• Inquire about repair billing or
other service invoicing
questions.
1 or 2 and then choose 3
Document Title Part Number
CK60 Mobile Computer Quick Start Guide 962-054-115
Intermec Computer Command Reference Manual 073529
TE 2000 Terminal Emulation Programmer’s Guide 977-055-008

Before You Begin
CK60 Mobile Computer with Windows Mobile User’s Manual xiii
The Intermec web site at www.intermec.com contains our documents (as
PDF files) that you can download for free.
To download documents
1Visit the Intermec web site at www.intermec.com.
2Click Service & Support > Manuals.
3In the Select a Product field, choose the product whose documentation
you want to download.
To order printed versions of the Intermec manuals, contact your local
Intermec representative or distributor.
Patent Information
4,882,476; 4,894,523; 4,953,113; 4,961,043; 4,970,379; 4,988,852;
5,019,699; 5,021,642; 5,038,024; 5,081,343; 5,095,197; 5,144,119;
5,144,121; 5,182,441; 5,187,355; 5,187,356; 5,195,183; 5,195,183;
5,195,183; 5,216,233; 5,216,550; 5,218,191; 5,227,614; 5,233,172;
5,241,488; 5,243,602; 5,258,606; 5,278,487; 5,288,985; 5,308,966;
5,322,991; 5,331,136; 5,331,580; 5,342,210; 5,349,678; 5,359,185;
5,371,858; 5,373,478; 5,389,770; 5,397,885; 5,410,141; 5,414,251;
5,416,463; 5,442,167; 5,464,972; 5,468,947; 5,468,950; 5,477,044;
5,486,689; 5,488,575; 5,500,516; 5,502,297; 5,504,367; 5,508,599;
5,514,858; 5,530,619; 5,534,684; 5,536,924; 5,539,191; 5,541,419;
5,548,108; 5,550,362; 5,550,364; 5,565,669; 5,567,925; 5,568,645;
5,572,007; 5,576,529; 5,592,512; 5,594,230; 5,598,007; 5,608,578;
5,616,909; 5,619,027; 5,627,360; 5,640,001; 5,657,317; 5,659,431;
5,671,436; 5,672,860; 5,684,290; 5,719,678; 5,729,003; 5,742,041;
5,761,219; 5,764,798; 5,777,308; 5,777,309; 5,777,310; 5,786,583;
5,793,604; 5,798,509; 5,798,513; 5,804,805; 5,805,807; 5,811,776;
5,811,777; 5,818,027; 5,821,523; 5,828,052; 5,831,819; 5,834,749;
5,834,753; 5,837,987; 5,841,121; 5,842,070; 5,844,222; 5,854,478;
5,862,267; 5,869,840; 5,873,070; 5,877,486; 5,878,395; 5,883,492;
5,883,493; 5,886,338; 5,889,386; 5,895,906; 5,898,162; 5,902,987;
5,902,988; 5,912,452; 5,923,022; 5,936,224; 5,949,056; 5,969,321;
5,969,326; 5,969,328; 5,979,768; 5,986,435; 5,987,192; 5,992,750;
6,003,775; 6,012,640; 6,016,960; 6,018,597; 6,024,289; 6,034,379;
6,036,093; 6,039,252; 6,064,763; 6,075,340; 6,095,422; 6,097,839;
6,102,289; 6,102,295; 6,109,528; 6,119,941; 6,128,414; 6,138,915;
6,149,061; 6,149,063; 6,152,370; 6,155,490; 6,158,661; 6,164,542;
6,164,545; 6,173,893; 6,195,053; 6,234,393; 6,234,395; 6,244,512;
6,249,008; 6,328,214; 6,330,975; 6,345,765; 6,356,949; 6,367,699;
6,375,075; 6,375,076; 6,431,451; 6,435,411; 6,484,944; 6,488,209;
6,497,368; 6,532,152; 6,538,413; 6,539,422; 6,621,942; 6,641,046;
6,681,994; 6,687,403; 6,688,523; 6,732,930;
Des. 417445
There may other U.S. and foreign patents pending.

Before You Begin
xiv CK60 Mobile Computer with Windows Mobile User’s Manual

CK60 Mobile Computer with Windows Mobile User’s Manual 1
1Using the Computer
This chapter introduces the CK60 Mobile Computer, developed by
Intermec to enhance wireless connectivity needs and contains hardware and
software configuration information to assist you in making the most out of
your CK60.
Note: Desktop icons and settings applet icons are shown to the left. Any
place that Start is mentioned, tap the following Windows icon in the top,
left corner of your CK60 desktop.

Chapter 1 — Using the Computer
2 CK60 Mobile Computer with Windows Mobile User’s Manual
Introducing the CK60 Mobile Computer
The Intermec CK60 Mobile Computer is an ergonomically designed
mobile computer built on the MicrosoftrWindowsrMobile 5.0 operating
system. It is a lightweight, easy-to-use, reliable computer that runs client/
server applications, terminal emulation applications, as well as browser-
based applications.
The CK60 is available with the following:
• Ethernet
• 802.11a/b/g radio
• Bluetooth - *Bluetooth is a trademark owned by Bluetooth SIG, Inc., USA
• 64MB or 128MB RAM/64MB Flash Memory
• Disk on Chip (128MB)
• 2D Area Imagers
• EA10, EA11, EL10, EL11, and EV10 Imagers
Use this manual to understand how to use the features and options
available on the CK60.
CK60s with an IEEE 802.11a/b/g radio installed are Wi-Fircertified for
interoperability with other 802.11a/b/g wireless LAN devices.
Enter
Battery status
Microphone
Microphone
Scan button
Intermec Ready-To-Work™
Good read light
Indicator
Front Speaker
Scan button
Keyboard function

Chapter 1 — Using the Computer
CK60 Mobile Computer with Windows Mobile User’s Manual 3
Learning Software Build Versions
The Persistent Storage Manager (PSM) is an area of storage which is
embedded in a section of the system’s FLASH memory. This storage area is
not erased when a cold-boot is performed. It may, however, erase during the
reflashing process. In addition to storing applications and data files, you
can store a persistent registry to the PSM region.
To learn the PSM build version or operating system version
1Select Start > Internet Explorer > the following Intermec logo.
2Note the information beneath the CK60 Version Information title.
3Tap the Close icon in the top right corner to exit the Internet Explorer.
Resetting Your Computer
You may need to reset your computer if:
• the CK60 completely stops responding.
• an application is locked up and stops responding.
• when you upgrade the firmware, or
• when you reflash the CK60.
Preferred Reset Method
This procedure is the recommended method in recovering the CK60. It
performs a graceful system shutdown and no data is lost in the process.
To recover the CK60
• Press and hold the power switch on the front of the CK60 for about 10
seconds.

Chapter 1 — Using the Computer
4 CK60 Mobile Computer with Windows Mobile User’s Manual
Secondary Reset Method
If performing the recommended reset method does not restore system
operation, try using this method. It does not guarantee that cached disk
data is saved, and as such, transactional data may be lost during the reset.
All other data is preserved.
To press the reset button
1Press the power switch to suspend the CK60, then remove the battery
pack from the back of the CK60.
2With a stylus, press the reset button in the battery cavity in the back.
3Press and hold the power switch as you put the battery back in.
Performing a Clean Boot
If performing either reset method fails to restore system operation, you may
have to perform a clean boot. This is a boot method which formats the
object store to clean data and registry information from the CK60 system
and restores them to their factory-default state.
To perform a clean-boot
1Press the power switch to suspend the CK60.
2Remove the battery pack from the back of the CK60.
3With a stylus, press the reset button in the battery cavity in the back.
4Press and hold the power switch as you put the battery back in the unit.
5Continue to hold the power switch until a Warning message appears on
the display.
6Release the power switch, then read the message.
7To continue with the clean-boot, press the right side button. To cancel
the clean-boot, press the left side button.
Do not use force or a sharp object when pressing the reset button.
You may damage the reset button.
Note: This will erase the memory in the CK60, including all applications
and data files found in the object store (user store). See “Packaging
Applications for the Computer” on page 80 for more information.
Press this reset button with your stylus.

Chapter 1 — Using the Computer
CK60 Mobile Computer with Windows Mobile User’s Manual 5
Scanning Bar Codes
Use the scanner to scan and enter bar code data. The type of scanner you
are using and the type of bar code you are decoding determines the way you
scan the bar code. The CK60 supports the scanning of 2D images. Plus, if
you are using an integrated handle or a tethered scanner, the way you scan
bar codes is different.
When you unpack the CK60, the Code 39, UPC/EAN, and PDF417 (if
supported) bar code symbologies are enabled.
If you are using bar code labels that are encoded in a different symbology,
you need to enable the symbology on the computer. Use the Intermec
Settings applet to enable and disable symbologies for your scanner. For help
on using the Intermec Settings applet, see “Using the Intermec Settings
Applet” on page 15.
Reading Distances
Typical reading distances are done in an office environment using office
lights (4 lux). Minimum distances are measured in the dark (0 lux). Both
reading distances are provided in respective scan engine integration guides.
Contact your Intermec representative for more information.
The minimum standard reading distances for CK60s built with integrated
scan engines are shown on the next several pages. When correctly mounted,
an exit window reduces reading distances by about 4% for all scan engines,
with the exception of the EL10 with its reading distances reduced by 25%.
Do not look directly into the window area or at a reflection of the laser
beam while the laser is scanning. Long-term exposure to the laser beam
can damage your vision.

Chapter 1 — Using the Computer
6 CK60 Mobile Computer with Windows Mobile User’s Manual
EA10 Minimum Reading Distances with 0.04" Setbacks
Symbology Density Minimum Distance Maximum Distance
Code 39 0.125 mm/ 5 mil
0.15 mm/ 6 mil
0.20 mm/ 8 mil
0.25 mm/ 10 mil
0.30 mm/ 12 mil
0.50 mm/ 20 mil
1.00 mm/ 40 mil
8.03 cm/ 3.16"
7.39 cm/ 2.91"
5.49 cm/ 2.16"
3.96 cm/ 1.56"
3.71 cm/ 1.46"
4.98 cm/ 1.96"
3.71 cm/ 1.46"
11.84 cm/ 4.66"
14.38 cm/ 5.66"
19.46 cm/ 7.66"
24.03 cm/ 9.46"
25.81 cm/ 10.16"
35.97 cm/ 14.26"
50.95 cm/ 20.06"
UPC/EAN 4.98 cm/ 1.96" 29.97 cm/ 11.76"
PDF417 0.168 mm/ 6.6 mil
0.254 mm/ 10 mil
0.381 mm/ 15 mil
7.26 cm/ 2.86"
4.47 cm/ 1.76"
10.06 cm/ 3.96"
12.85 cm/ 5.06"
20.98 cm/ 8.26"
28.35 cm/ 11.16"
Data Matrix 0.254 mm/ 10 mil
0.381 mm/ 15 mil
0.508 mm/ 20 mil
6.50 cm/ 2.56"
5.99 cm/ 2.36"
4.98 cm/ 1.96"
17.93 cm/ 7.06"
27.84 cm/ 10.96"
32.92 cm/ 12.96"
